Phoenix Contact GW PN/DP 1E/1DB9 User manual

User manual
Protocol converter for ASCII to
PROFINET®

2018-04-11
PHOENIX CONTACT 3886_en_A
Protocol converter for ASCII to PROFINET®
A
Designation Order No.
GW PN/ASCII 1E/1DB9
GW PN/ASCII 1E/2DB9
GW PN/ASCII 2E/2DB9
GW PN/ASCII 2E/4DB9
1021080
1021058
1021056
1020882
User manual
Revision:
This user manual is valid for:

3886_en_A PHOENIX CONTACT 1
Table of contents
1 Description..................................................................................................................................3
1.1 Structure................................................................................................................ 4
2 Installation ..................................................................................................................................9
2.1 Safety regulations and installation notes ............................................................... 9
2.2 Mounting ............................................................................................................... 9
2.3 Data interfaces .................................................................................................... 11
2.3.1 Connecting the V.24 (RS-232) cable ................................................... 11
2.3.2 Connecting the RS-422 cable .............................................................. 12
2.3.3 Connecting the RS-485 cable .............................................................. 12
2.3.4 Connecting the Ethernet cable ............................................................. 13
2.4 Connecting the power supply .............................................................................. 14
3 Configuration and startup..........................................................................................................15
3.1 Default settings.................................................................................................... 15
3.2 Web-based management .................................................................................... 15
3.3 Login ................................................................................................................... 15
3.4 Home screen ....................................................................................................... 16
3.5 General settings .................................................................................................. 17
3.6 LAN settings ........................................................................................................ 18
3.6.1 IP address ............................................................................................ 18
3.6.2 Security ................................................................................................ 19
3.6.3 PROFINET IO ...................................................................................... 20
3.7 Serial settings ...................................................................................................... 21
3.7.1 Port configuration ................................................................................. 21
3.8 Socket settings .................................................................................................... 25
3.8.1 Socket configuration ............................................................................ 26
3.9 Diagnostics.......................................................................................................... 29
3.9.1 Communication statistics ..................................................................... 29
3.9.2 PLC interface ....................................................................................... 31
3.9.3 Serial logs ............................................................................................ 33
3.9.4 Ethernet logs ........................................................................................ 34
3.10 Maintenance........................................................................................................ 35
3.10.1 Passwords ........................................................................................... 35
3.10.2 Restore defaults ................................................................................... 36
3.10.3 Log files ............................................................................................... 37
3.10.4 Configuration files ................................................................................ 38
3.10.5 Update firmware .................................................................................. 38

GW PN/ASCII...
2PHOENIX CONTACT 3886_en_A
4 Data message format................................................................................................................41
4.1 Input and output submodule data format ............................................................. 41
4.1.1 Data format of an input submodule. ..................................................... 41
4.1.2 Data format of an output submodule. ................................................... 41
5 Troubleshooting........................................................................................................................43
5.1 Resetting the device ............................................................................................ 43
5.1.1 Hardware reset .................................................................................... 43
5.1.2 Software reset ...................................................................................... 43
5.2 LEDs.................................................................................................................... 43
A Appendixes...............................................................................................................................45
A 1 List of figures ...................................................................................................... 45
B 2 List of tables ....................................................................................................... 47

Description
3886_en_A PHOENIX CONTACT 3
1Description
The GW PN/ASCII... devices provide a simple way to integrate Raw/ASCII serial and
Ethernet devices, such as bar code scanners, weigh scales, or radio frequency
identification (RFID) tags, into PROFINET®controllers.
The family consists of universal RS-232/422/485 one-, two-, and four-port serial versions,
with one or two Ethernet ports to fit any application.
This user manual is valid for:
Table 1-1 GW PN/ASCII... types
Type Description Order No.
GW PN/ASCII 1E/1DB9 1021080
GW PN/ASCII 1E/2DB9 1021058
GW PN/ASCII 2E/2DB9 1021056
GW PN/ASCII 2E/4DB9 1020882

GW PN/ASCII...
4PHOENIX CONTACT 3886_en_A
1.1 Structure
GW PN/ASCII 1E/1DB9
The GW PN/ASCII 1E/1DB9 features one Ethernet port and one RS-232/422/485 serial port
with a D-SUB 9 connector.
Figure 1-1 GW PN/ASCII 1E/1DB9
Table 1-2 GW PN/ASCII 1E/1DB9 structure
Item Description
1 Power connector
2 P1 D-SUB 9 connector
3 Ethernet port (RJ45)
4StatusLED
5 Reset button
6 Ethernet activity status LED
7 Ethernet link status LED
1
2
3
5
6
7
4

Description
3886_en_A PHOENIX CONTACT 5
GW PN/ASCII 1E/2DB9
The GW PN/ASCII 1E/2DB9 features one Ethernet port and two RS-232/422/485 serial
ports with D-SUB 9 connectors.
Figure 1-2 GW PN/ASCII 1E/2DB9
Table 1-3 GW PN/ASCII 1E/2DB9 structure
Item Description
1 Power connector
2P1D-SUB9connector
3 Ethernet port (RJ45)
4P2D-SUB9connector
5 Status LED
6 Ethernet activity status LED
7 Ethernet link status LED
8 Reset button
1
2
3
8
5
4
6
7

GW PN/ASCII...
6PHOENIX CONTACT 3886_en_A
GW PN/ASCII 2E/2DB9
The GW PN/ASCII 2E/2DB9 features two Ethernet ports with integrated switch functionality
and two RS-232/422/485 serial ports with D-SUB 9 connectors.
Figure 1-3 GW PN/ASCII 2E/2DB9
Table 1-4 GW PN/ASCII 2E/2DB9 structure
Item Description
1 Power connector
2 P1 D-SUB 9 connector
3 Ethernet link status LED
4 E2 Ethernet port (RJ45)
5 Ethernet activity status LED
6 P2 D-SUB 9 connector
7 Status LED
8 Ethernet activity status LED
9 E1 Ethernet port (RJ45)
10 Ethernet link status LED
11 Reset button
1
2
4
11
7
6
8
3
5
9
10

Description
3886_en_A PHOENIX CONTACT 7
GW PN/ASCII 2E/4DB9
The GW PN/ASCII 2E/4DB9 features two Ethernet ports with integrated switch functionality
and four RS-232/422/485 serial ports with D-SUB 9 connectors.
Figure 1-4 GW PN/ASCII 2E/4DB9
Table 1-5 GW PN/ASCII 2E/4DB9 structure
Item Description
1 Power connector
2 P3 D-SUB 9 connector
3 Ethernet link status LED
4 E2 Ethernet port (RJ45)
5 Ethernet activity status LED
6 P4 D-SUB 9 connector
7 P2 D-SUB 9 connector
8StatusLED
9 Ethernet activity status LED
10 E1 Ethernet port (RJ45)
11 Ethernet link status LED
12 Reset button
13 P1 D-SUB 9 connector
1
2
8
12
6
13
7
4
3
5
9
10
11

GW PN/ASCII...
8PHOENIX CONTACT 3886_en_A

Installation
3886_en_A PHOENIX CONTACT 9
2 Installation
2.1 Safety regulations and installation notes
Installation, operation, and maintenance may be carried out only by qualified electricians.
Follow the specified installation instructions. The applicable specifications and safety
directives (including the national safety directives), as well as the general technical
regulations, must be observed during installation and operation. The technical data should
be taken from the packaging instructions and the certificates (conformity assessment, other
possible approvals).
Opening the device or making changes to it is not permitted. Do not repair the device
yourself, but replace it with an equivalent device. Repairs may be carried out only by the
manufacturer. The manufacturer is not liable for any damage caused by violation of the
prescribed regulations.
The IP20 degree of protection (EN 60529) of the device is intended for a clean and dry
environment.
Do not subject the device to any load that exceeds the prescribed limits.
The device is not designed for use in environments with danger of dust explosions.
2.2 Mounting
To mount on the DIN rail:
1. Place the device onto the DIN rail from above (A), so that the upper housing keyway
hooks onto the top edge of the DIN rail.
2. Hold the device by the housing cover and carefully push the device toward the
mounting surface (B).
3. After the foot is snapped onto the DIN rail, verify that it is attached securely.
Figure 2-1 DIN rail mounting
A
B

GW PN/ASCII...
10 PHOENIX CONTACT 3886_en_A
To remove:
1. Use a suitable screwdriver to release the locking mechanism (A) on the snap-on foot of
the device.
2. Hold on to the device by the housing cover and carefully tilt it upward (B).
3. Remove the device from the DIN rail (C).
Figure 2-2 DIN rail removal
A
C
B

Installation
3886_en_A PHOENIX CONTACT 11
2.3 Data interfaces
2.3.1 Connecting the V.24 (RS-232) cable
The D-SUB 9 connector may function as an RS-232, RS-422, or RS-485 interface. The
RS-232 interface is a data terminal equipment (DTE) device that behaves like a personal
computer (PC). A null modem cable or adapter is required to connect to a PC.
Connect the GW PN/ASCII... to the V.24 (RS-232) device to be connected (for example, a
PC) by way of the PSM-KA-9SUB 9/BB/2 METER V.24 (RS-232) cable (Order No.
2799474). The cable is an interface cable with 1:1 connected contacts.
The V.24 (RS-232) interface of the GW PN/ASCII... is a DTE assignment.
Table 2-1 D-SUB 9 to RS-232 pin out
GW PN/ASCII... End device
RS-232 D-SUB 9
(DCE)
D-SUB 9
(DTE)
D-SUB 25
(DCE)
D-SUB 25
(DTE)
1DCD14820
2RxD2332
3TxD3223
4DTR4 1,620 6,8
5GND5577
6DSR64620
7RTS7845
8CTS8754
9RI 9 - 22 -

GW PN/ASCII...
12 PHOENIX CONTACT 3886_en_A
2.3.2 Connecting the RS-422 cable
Figure 2-3 Pin 1 location
In RS-422 mode, a point-to-point connection can be established. Use a twisted-pair,
common shielded bus cable to connect the I/O device.
To connect the RS-422 cable:
1. Connect the individual conductors of the data cable to the GW PN/ASCII... using a
SUBCON 9/F SH (Order No. 2761499).
2. Make sure the signal assignment is correct.
This operating mode supports full duplex transmission mode.
2.3.3 Connecting the RS-485 cable
In RS-485 mode, an RS-485 network with several I/O devices can be created. Use a
twisted-pair, common shielded bus cable to connect the I/O devices.
Connect the individual conductors of the data cable to the GW PN/ASCII... using a
SUBCON 9/F SH (Order No. 2761499) (see Table 2-2).
Table 2-2 D-SUB 9 to RS-422 and RS-485 pin out
GW PN/ASCII... End device
RS-422 RS-485 RS-422 RS-485
2T(A) – D(A)–
3 D(A) D(A) T(A) D(A)
5 GND GND GND GND
7 D(B) D(B) T(B) D(B)
8T(B) – D(B)–
1
NOTE:
Observe the polarity of the RS-485 cable.
Fit this bus cable with a termination network at the two furthest points of the RS-485
network.
The termination resistors are integrated in the GW PN/ASCII... and can be switched on
through the web-based management interface.

Installation
3886_en_A PHOENIX CONTACT 13
2.3.4 Connecting the Ethernet cable
The GW PN/ASCII... has an Ethernet interface on the front in RJ45 format, to which only
twisted-pair cables with an impedance of 100 Ωcan be connected. The data transmission
rate is either 10 or 100 Mbps. The GW PN/ASCII... supports the auto negotiation function
for automatic selection of the transmission speed, as well as an automatic crossover feature
for the selection of line or crossover cabling.
Push the Ethernet cable with the crimped RJ45 connector into the GW PN/ASCII... until it
engages with a click.
2.3.4.1 Models with two Ethernet ports
When using two Ethernet ports, the GW PN/ASCII... is classified as a switch. When using
only one port, it is a simple end node device. The maximum number of daisy-chained
GW PN/ASCII... units, and the maximum distance between units, is based on the Ethernet
standards, and is determined by the environment and conformity of the network to these
standards. There may be some performance degradation on the devices at the end of the
chain, so it is recommended to overload and test for performance in the environment. The
application may also limit the total number of ports that may be installed. Some basic
guidelines are listed below.
–Ethernet10BASE-Trules
– The maximum number of repeater segments is four.
– Use Category 3 or 5 twisted-pair 10BASE-T cables. The maximum length of each
cable is 100 m (328 ft.).
– Fast Ethernet 100BASE-TX rules
– The maximum number of repeater segments is two (for a Class II hub). A Class II
hub can be connected directly to one other Class II Fast Ethernet hub. A Class I hub
cannot be connected directly to another Fast Ethernet hub.
– Category 5 twisted-pair cable must be used. The maximum length of each twisted-
pair cable is 100 m (328 ft.).
– The total length of twisted-pair cabling (across directly connected hubs) must not
exceed 205 m (672 ft.).
– IEEE 802.3 specification: A network using repeaters between communicating stations
(PCs) is subject to the 5-4-3 rule of repeater placement on the network:
– The maximum number of segments connected on a network is five.
– Four repeaters is the maximum that can be applied to a network.
– Only three segments can have user connections. The other two segments must act
as repeaters with no user connections.

GW PN/ASCII...
14 PHOENIX CONTACT 3886_en_A
2.4 Connecting the power supply
The device can be connected to a single power source or two power sources for
redundancy. The GW PN/ASCII... is powered using a +24 V DC SELV power supply. The
power supply is connected by way of COMBICON plug-in screw terminal blocks (24 V and
0V).
Figure 2-4 Single power supply connection
Figure 2-5 Redundant power supply connection
CAUTION:
Incorrect connection may result in damage to equipment and/or serious personal injury.
Only qualified personnel may connect the power, start up, and operate this device.
According to the safety instructions in this text, qualified personnel are persons who are
authorized to start up, to ground, and to mark devices, systems, and equipment according
to the standards of safety technology. In addition, these persons must be familiar with all
warning instructions and maintenance measures in this text.
Disregarding this warning may result in damage to equipment and/or serious personal
injury.

Configuration and startup
3886_en_A PHOENIX CONTACT 15
3 Configuration and startup
3.1 Default settings
The default network settings of the GW PN/ASCII... are:
IP address: 192.168.254.254
Subnet mask: 255.255.255.0
Gateway: 0.0.0.0
3.2 Web-based management
The user-friendly, web-based management interface, a graphical user interface (GUI), can
be used to manage the GW PN/ASCII... from anywhere in the network using a standard
browser. Comprehensive configuration and diagnostic functions, including a wide range of
information about the device itself, the current parameters, and the operating state, are
clearly displayed.
3.3 Login
To log in:
1. Set the IP address of the connected PC to the subnetwork of the GW PN/ASCII...: for
example, IP = 192.168.254.10, subnetwork = 255.255.255.0.
2. Open a web browser and enter the IP address of the GW PN/ASCII... in the “Address”
field (default = 192.168.254.254).
Figure 3-1 “Login” screen
The web server responds immediately.
The default settings are invoked whenever the system is reset.
If the web server does not load, first check the IP parameters of the PC. If everything is set
correctly, check to see if there are any proxy settings loaded in the web browser. The proxy
setting must be set to “Load automatically” or “Deactivated” to properly establish
communication.

GW PN/ASCII...
16 PHOENIX CONTACT 3886_en_A
3. Enter the credentials to access the web server configuration pages. The default
credentials are:
User name: Admin
Default password: admin
3.4 Home screen
Immediately after login, the “Home” screen is displayed. From the “Home” screen, the basic
settings of the GW PN/ASCII... can be immediately configured by clicking on the
appropriate Ethernet port or serial port in the diagram of the module.
Figure 3-2 “Home” screen
Advanced settings can be accessed through the menu at the top of the screen. The “Home”
screen can be accessed at any time by clicking the “Home” button in the upper-left corner
of the web-based management interface.
Powering multiple devices with factory default IP addresses causes a network conflict, and
incorrect parameters may be set in the GW PN/ASCII... modules. When programming
modules for the first time, it is important to apply power to only one at a time, and change
the IP address of each module to a unique IP address. Once all devices have a unique IP
address, they can be powered on together while on the same network.

Configuration and startup
3886_en_A PHOENIX CONTACT 17
3.5 General settings
To view and edit general settings:
1. Click the “General Settings” tab to view and edit general information about the
GW PN/ASCII....
Figure 3-3 “General Settings” page
2. View the listed information.
3. If desired, change the listed information.
The “Device Identification” group provides fields for entering descriptive information
about individual devices.
Device Name: Enter a name for the device. The field accepts up to 16 characters.
Contact: Enter the name of a contact person, group, or department responsible for this
device. The field accepts up to 16 characters.
4. Click the “Apply Changes” button to save the configuration.

GW PN/ASCII...
18 PHOENIX CONTACT 3886_en_A
3.6 LAN settings
3.6.1 IP address
To enter the IP address:
1. From the “LAN Settings” page, click the “IP Address” tab to access the “IP Address”
page.
Figure 3-4 “LAN Settings/IP Address” page
2. Select the method for assigning the LAN IP address.
If a DHCP server assigns IP addresses, click the “Automatic address assignment
(DHCP)” button.
If using static IP addresses, click the “Manual address assignment” button and enter the
appropriate information in the various fields.
MAC Address: The MAC address of the GW PN/ASCII... is displayed.
3. Click the “Apply Changes” button to save the configuration.
Discover and basic configuration protocol (DCP) settings will overwrite the Device Name
configured in the web manager.
