phyBOARD®-Wega AM335x
Get your phyBOARD®-Wega powered up and connected in just a few simple steps.
1) Preparing the Hardware
1. Check the kit content (see overview on the right hand side).
2. Have your connection cables at hand: You need an RS-232 cable (one-to-one) and a standard
Ethernet cable. Phytec offers an accessory kit which includes these cables.
3. Power up the phyBOARD-Wega. For the 24 V-kit version (A): Connect the 2-pin PHOENIX
connector (included) to a 12 V-24 V (±10%) DC power supply.
For the 5 V-kit version (B): Connect the 2-pin PHOENIX connector (included) to a 5 V
(
±
5%)
DC power supply. In both cases please note the polarity of the connectors (see picture A/B)!
If you have bought the optional power supply with your kit, it comes already with the 2-pin connector wired.
4. Turn your power supply on and plug the 2-pin PHOENIX connector into the green jack of your kit.
The Power LED D58 will light up.
Please note: only the 24V-kit version
comes with the power adapter board.
Kit Contents Optional Accessories
phyBOARD®-Wega AM335x 2-pin Evaluation Module Power Module 12 V-24 V
PHOENIX (PEB-EVAL-01) (PEB-POW-01)
RS-232 and HDMI Adapter
CAN Adapter (PEB-AV-01)
Additional Equipment required
Power Adapter 5 V or 24 V RS-232 Cable Ethernet Cable Virtual Machine Hard Disk Image available from
www.phytec.de or on
an optionally purchasable USB Flash Drive
12V-24V-kit version
A
5V-kit version
+ GND
B
+
GND

2) Preparing and Starting
the Virtual Machine
To follow this QuickStart and the descriptions in the Application Guide you need our
phyBOARD-Wega virtual machine hard disk image. The hard disk image includes all
software installations and configurations (e.g. pre-built Yocto BSP, Eclipse, Qt Creator)
necessary for a successful start-up of the phyBOARD-Wega.
You can freely download the compressed virtual machine hard disk image from our
website, if you did not purchase an USB flash drive with our image. The compressed
image (SO-530v4.xz) has a size of approx. 15 GB and includes a virtual machine disk
file (.vmdk) which is suitable for most virtualization software, and which can be moun-
ted to an appropriate Linux machine (tested with VMware Player and VirtualBox).
1. Plug-in the purchased USB flash drive or download the compressed VM hard disk
image from http://www.phytec.de/de/support/faq/faq-phyboard-wega.
2. Unpack the compressed file with an appropriate tool to get the included .vmdk file.
3. Follow the instructions of your virtualization software to create a new virtual machine.
However, pay regard to the following settings required to obtain a correctly working
virtual machine: - choose Linux-Ubuntu 64-bit version as operating system
- use the unpacked file SO-530v4.vmdk as hard disk
- an Ethernet adapter, as well as a serial interface, or the USB
controller must be available to connect to the phyBOARD-Wega
In order to avoid any conflicts we recommend to have only the Ethernet adapter in the
virtual machine which will be used for the peer to-peer connection between your PC and
the phyBOARD Wega.
4. Start the virtual machine with our hard disk image. You will see the modified Ubuntu
desktop (A) . For further use of the virtual machine the pre-created login data is:
username: „phyvm“ — password: „phytec“.
Now you are ready to connect your PC with the phyBOARD-Wega.
Serial connection
1. Connect one end of the serial cable to the DB-9 connector on the Evaluation
Module (PEB-EVAL-01).
2. Connect the other end to the first serial interface of your PC (or to an USB to DB-9
dongle, connected to your host).
3. Click the Microcom_ttyS0 icon (B) on the Ubuntu desktop (for direct serial interface
connection) or click the Microcom_ttyUSB0 icon if you are using an USB to DB-9 dongle.
4. Click the reset button S2 on the phyBOARD-Wega (or power the board off and on).
A serial console has been started within your virtual machine. You should see a boot
message and the login-prompt on this console (C) .Congratulations!
5. Use “root” as the login name on the serial console and press Enter.
6. As a good example (and helpful for understanding the next step) enter ifcong.
You will get information about the configuration of the Ethernet interface on the
phyBOARD-Wega
(D).
Ethernet connection
In the virtual machine hard disk image the Ethernet adapter eth0 is preconfigured to
the IP address 192.168.3.10 and netmask 255.255.255.0 to establish the peer-to-peer
connection to the phyBOARD-Wega.
1. Connect your preferred Ethernet interface on your PC, which is passed on the
virtual machine, with RJ45 connector X16 (eth0) on the phyBOARD-Wega using
a standard Ethernet cable.
You are now ready to test the Ethernet network connection.
2. Click on the SSH for Target icon (E) on your desktop. A console window will
open and you will see an authentication question. Type yes and press Enter.
You are now connected to the target (F) .Congratulations!
Your possible next steps
• Read our Application Guide available on the desktop of the virtual machine.
• Check out the FAQ pages on the PHYTEC website for latest information and downloads
(www.phytec.de/de/support/faq/faq-phyboard-wega)
• Contact our support team if you have any questions getting the phyBOARD-Wega up
and running.
Enjoy!
3) Getting Connected
A
CB
E F
D
