Pixsys HMI series User manual

HMI series
HMI TOUCH SCREEN
410-710-810-820
Quick start guide - Guida breve all’installazione
12”
10”
7”
4,3”

Table of contents
1 Safety guidelines.......................................................................................................................................................... 5
1.1 Policies and procedures....................................................................................................................... 5
1.2 Installation guidelines ......................................................................................................................... 5
1.3 Viruses and dangerous programs..................................................................................................... 5
1.4 Organization of safety notices .......................................................................................................... 5
2 Device installation ....................................................................................................................................................... 6
2.1 Spacing for air circulation and ventilation..................................................................................... 6
3 Power supply and grounding.................................................................................................................................... 6
4 Wiring connections ..................................................................................................................................................... 7
5 Technical data............................................................................................................................................................... 7
5.1 Main features......................................................................................................................................... 7
5.2 Hardware features................................................................................................................................ 7
5.3 Touch LCD: 4 wires resistive................................................................................................................ 7
6 Communication interfaces........................................................................................................................................ 7
6.1 CANopen ................................................................................................................................................. 8
6.1.a Using CAN / EXP1 on terminal M1....................................................................................... 8
6.2 RS232........................................................................................................................................................ 8
6.2.a Using RS232 / COM1 on DB9 (No available for TD410).................................................. 8
6.3 RS485 ....................................................................................................................................................... 8
6.3.a Using RS485 / COM2 on terminal M1................................................................................. 8
6.3.b Using RS485 / COM2* MASTER on DB9 (No available for TD410) ............................... 8
6.3.c Using RS485 / COM2 SLAVE on DB9 (No available for TD410)..................................... 9
6.4 USB interfaces ........................................................................................................................................ 9
7 Ethernet interface ........................................................................................................................................................ 9
7.1 Technical data ....................................................................................................................................... 9
8 Internal ethernet Switch (only TD810-TD820)..................................................................................................... 10
9 Battery .......................................................................................................................................................................... 10
9.1 Internal battery replacement........................................................................................................... 10
9.2 Battery detail ....................................................................................................................................... 10
10 TdControlPanel........................................................................................................................................................... 11
10.a WIN EXPLORER ................................................................................................................................................. 11
10.b HMI_MOVICON................................................................................................................................................ 11
10.c PLC LOGICLAB................................................................................................................................................... 12
10.d LAN ETH1 ........................................................................................................................................................... 12
10.e BACKLIGHT - BUZZER...................................................................................................................................... 12
10.f WINVNC ............................................................................................................................................................. 12
11 LogicLab Suite............................................................................................................................................................. 13
11.a Language modification ................................................................................................................................. 13
11.b Create - load a project.................................................................................................................................... 13
11.c Connection to target ...................................................................................................................................... 14
11.d Compiling and downloading the code ...................................................................................................... 15
11.e Watch window ................................................................................................................................................. 15
12 Interfacing Movicon 11 with LogicLab.................................................................................................................. 16
12.a Creating a new Movicon project.................................................................................................................. 16
12.b Driver configuration ....................................................................................................................................... 16
12.c Downloading the Movicon code to the target......................................................................................... 18
13 Simulation of the whole project SoftPLC + SCADA............................................................................................ 18

User manual - HMI Series - 5
1 Safety guidelines
Programmable logic controllers (PLCs), operating/monitoring devices (industrial PCs, HMI) have
been designed, developed and manufactured for conventional use in industrial environments. They
were not designed, developed and manufactured for any use involving serious risks or hazards that
could lead to death, injury, serious physical damage or loss of any kind without the implementation
of exceptionally stringent safety precautions. In particular, such risks and hazards include the use of
these devices to monitor nuclear reactions in nuclear power plants, their use in flight control or flight
safety systems as well as in the control of mass transportation systems, medical life support systems
or weapons systems.
1.1 Policies and procedures
Electronic devices are never completely failsafe. If the programmable control system, operating/
monitoring device or uninterruptible power supply fails, the user is responsible for ensuring that other
connected devices, e.g. motors, are brought to a secure state.
When using programmable logic controllers or operating/monitoring devices as control systems
together with a soft PLC, safety precautions relevant to industrial control systems must be observed
in accordance with applicable national and international regulations. The same applies for all other
devices connected to the system, such as drives.
All tasks such as the installation, commissioning and servicing of devices are only permitted to be
carried out by qualified personnel. Qualified personnel are those familiar with the transport, mounting,
installation, commissioning and operation of devices who also have the appropriate qualifications
(e.g. IEC 60364). National accident prevention regulations must be observed.
The safety notices, information on connection conditions (type plate and documentation) and limit
values specified in the technical data are to be read carefully before installation and commissioning
and must always be observed.
1.2 Installation guidelines
• These devices are not ready for use upon delivery and must be installed and wired according to the
specifications in this documentation in order for the EMC limit values to apply.
•
Installation must be performed according to this documentation using suitable equipment and tools.
• Devices are only permitted to be installed by qualified personnel without voltage applied. Before
installation, voltage to the control cabinet must be switched off and prevented from being switched
on again.
• General safety guidelines and national accident prevention regulations must be observed.
• Electrical installation must be carried out in accordance with applicable guidelines (e.g. line cross
sections, fuses, protective ground connections).
1.3 Viruses and dangerous programs
This system is subject to potential risk each time data is exchanged or software is installed from a data
medium (e.g. diskette, CD-ROM, USB flash drive, etc.), a network connection or the Internet. The user is
responsible for assessing these dangers, implementing preventive measures such as virus protection
programs, firewalls, etc. and making sure that software is only obtained from trusted sources.
1.4 Organization of safety notices
Safety notices in this manual are organized as follows:
Safety notice Description
Danger! Disregarding these safety guidelines and notices can be life-threatening.
Warning! Disregarding these safety guidelines and notices can result in severe injury or
substantial damage to property.
Caution! Disregarding these safety guidelines and notices can result in injury or damage to
property.
Information! This information is important for preventing errors.

6 - HMI Series - User manual
2 Device installation
The device panel is installed in the cutout using provided plastic hooks. The number of provided
plastic hooks depends on the panel. The thickness of the wall or cabinet plate must be between 1 mm
and 5 mm. An ISO 7045 (ex UNI 7687 DIN 7985A) Phillips screwdriver is needed to tighten and loosen
the screws on the retaining clips. The maximum tightening torque for the retaining clips is 0,5 Nm.
Devices must be installed on a flat, clean and burr-free surface; uneven areas can cause damage to
the display when the screws are tightened or the intrusion of dust and water. (as per figures 1 and 2)
Cut-out Fig. 1 Fig. 2
L (± 0,5 mm)
H (± 0,5 mm)
TD410 TD710 TD810 TD820
External dimensions (mm) 140 x 100 x 29 204 x 160 x 35 274 x 216 x 35 317 x 256 x 35
Cut-out (mm) 132 x 90 181 x 144 259 x 202 302 x 242
2.1 Spacing for air circulation and ventilation
In order to guarantee sufficient air circulation, allow 5cm of empty space above, below, to the side
and behind the device. No other ventilation system is required. The HMI device is self-ventilated and
approved for inclined mounting at angles up to ±35°in stationary cabinets.
Information! If additional space is needed to operate or maintain the device, this must be taken into
consideration during installation.
Caution! The spacing specifications for air circulation are based on the worst-case scenario for
operation at the maximum specified ambient temperature. The maximum specified ambient
temperature must not be exceeded!
Caution! An inclined installation reduces the convection by the HMI device and therefore the
maximum permissible ambient temperature for operation.
3 Power supply and grounding
Danger! This device is only permitted to by supplied by a SELV /
PELV (class 2) power supply or with safety extra-low voltage (SELV)
in accordance with EN 60950.
Connect a 24VDC 1,0A (min.) power supply, as showed into the figure.
Connect the device grounding with a conductor of 18AWG (2,5mmq)
minimum section. For the whole series it is suggested to use a 24
VDC 1,0A 24VA power supply (Pixsys code 2700.10.008).
Use Copper, Copper-Clad Aluminium or Aluminium conductors wire
for all electric connection.
Caution!
24VDC power supply line must be protected by a 1,0A fuse.
Caution! Functional ground must be kept as short as possible and
connected to the largest possible wire cross section at the central
grounding point (e.g. the control cabinet or system).

User manual - HMI Series - 7
4 Wiring connections
This device has been designed and manufactured in conformity to Low Voltage Directive 2006/95/EC,
2014/35/EU (LVD) and EMC Directive 2004/108/EC, 2014/30/EU (EMC). For installation into industrial
environments please observe following safety guidelines:
• Separate control lines form power wires;
• Avoid proximity of remote control switches, electromagnetic contactors, powerful engines and use
specific filters;
• Avoid proximity of power groups, especially those with phase control;
• It is strongly recommended to install adequate mains filter on power supply of the machine where
the controller is installed, particularly if supplied 230 VAC. The controller is designed and conceived
to be incorporated into other machines, therefore CE marking on the controller does not exempt
the manufacturer of machines from safety and conformity requirements applying to the machine
itself.
5 Technical data
5.1 Main features
TD410 TD710 TD810 TD820
Power supply voltage 12 ÷ 24 VDC ± 10%
Consumption (typical
use with 2 USB devices) 7,5 VA 13 VA 16 W 15 W
Temperature range 0..50°C
Humidity range 10..90% (without condensation)
5.2 Hardware features
CPU ARM® CORTEX™ - A8 @1.0GHz
RAM 512 MB DDR3
eMMC 4GB
5.3 Touch LCD: 4 wires resistive
TD410 TD710 TD810 TD820
Resolution 4.3” TFT
480 x 272
7” TFT
800 x 480
10” TFT
800 x 600
12” TFT
1280 x 800
Colors 65K (16 bit) 65K (16 bit) 65K (16 bit) 65K (16 bit)
Back-lighting LED 400 cd/m2 LED 280 cd/m2 LED 320 cd/m2 LED 220 cd/m2
Back-lighting duration* 50000 h Typ @ 25°C** 30000 h Typ @ 25°C**
Lifetime** 17 10
* Brightness reduction to the 80% of default setting
** Functioning years per 8 hours / day
6 Communication interfaces
TD410 TD710*** - TD810 - TD820
*** ETH2 not available on this model.

8 - HMI Series - User manual
6.1 CANopen
6.1.a Using CAN / EXP1 on terminal M1
DIP2
OFFON
EXP1/CAN with termination resistor 120Ω
EXP1/CAN con terminazione 120Ω
PIN5: GND (brown)
PIN6: CANH (blue)
PIN7: CANL (white)
6.2 RS232
6.2.a Using RS232 / COM1 on DB9 (No available for TD410)
Standard RS232 connection:
PIN2: RX (green)
PIN3: TX (blue)
PIN5: GND (brown)
RS232 connection with RTS / CTS:
PIN2: RX (green)
PIN3: TX (blue)
PIN5: GND (brown)
PIN7: RTS (white)
PIN8: CTS (yellow)
6.3 RS485
6.3.a Using RS485 / COM2 on terminal M1
DIP2
OFFON
RS485 MASTER:
Polarization only 470Ω
Solo polarizzatore 470Ω
OFFON
RS485 MASTER:
Termination 330ΩPolarization 470Ω
Terminatore 330ΩPolarizzatore 470Ω
OFFON
RS485 SLAVE
PIN3: B+ (green)
PIN4: A- (yellow)
PIN5: GND (brown)
6.3.b Using RS485 / COM2* MASTER on DB9 (No available for TD410)
1
5
9
6
COM2 RS485
EARTH
Pin 5 : C
Pin 8
Pin 7 : 5Vi
Pin 3
470 Ω
470 Ω
330 Ω
B+
A-
MASTER
1 - Input
2 - C
3
4
5 - C
7 - 5V
8
9
Note: 5V Is isolated an can supply 70mA max
OFFON
DIP2 2,3,4 to off
DIP2
* Using the DB9 connector it is possible to introduce termination resistances using DIP2 as for terminal M1 or short-circuiting terminals 3-4 e 8-9, as showed
in the figure.

User manual - HMI Series - 9
6.3.c Using RS485 / COM2 SLAVE on DB9 (No available for TD410)
1 - Input
2 - C
3 -
4 - A-
5 - C
7 - 5V
8 -
9 - B+
1
5
9
6
Pin 5 : C
Pin 8
Pin 7 : 5Vi
Pin 3
470 Ω
470 Ω
330 Ω
SLAVE
COM2 RS485
EARTH
Note: 5V Is isolated an can supply 70mA max
OFFON
DIP2 2,3,4 to off
DIP2
6.4 USB interfaces
The HMI comes equipped with a USB 2.0 (Universal Serial Bus) host controller with multiple USB
interfaces accessible externally for the user.
Warning! Peripheral USB devices can be connected to the USB interfaces on this device. Due to the
large number of USB devices available on the market, Pixsys cannot guarantee their performance.
Caution! Because this interface is designed according to general PC specifications, extreme care
should be exercised with regard to EMC, cable routing, etc.
Type USB 2.0
Design Type A
Transfer rate Low speed (1.5 Mbit/s), Full speed (12 Mbit/s), High speed (480 Mbit/s)
Current-carrying capacity Max. 0,8 A (total of all USB ports)
Cable length Max. 3 m (without hub)
7 Ethernet interface
7.1 Technical data
This Ethernet controller is connected to external devices via the system unit.
Ethernet 1 interface (ETH1) TD410 - TD710 TD810 - TD820
Number of ports 1 2
Controller LAN8710A
Cabling S/STP (Cat 5e)
Transfer rate 10/100 Mbit/s 10/100 Mbit/s ETH1-ETH2 to CPU Link
10/100/1000 Mbit/s ETH1-ETH2 link
Cable length Max. 100 m (min. Cat 5e)
LED
Green Link On = Gigabit connection
Off = 10/100 Mbit connection
Yellow 10/100 Mbit Activity On =Link
Blink = Activity (data transfer)

10 - HMI Series - User manual
8 Internal ethernet Switch (only TD810-TD820)
Two Ethernet 10/100/1000 Mbit ports on the rear side of the
operator panel are available. ETH1 and ETH2 are internally
connected to CPU through a Gigabit switch.
Thanks to dual port it is possible to make daisy-chain of more
devices without using external ethernet switches.
Using VLAN system option, each port can be used as separated
network interface. See TDControl user manual for more details.
For TD410 and TD710 only one Ethernet port is available.
LAPTOP
9 Battery
9.1 Internal battery replacement
BIOS and clock store data also in case of power failure thanks to a CR2032 battery placed on the side.
To replace the battery it is necessary to remove the protection and pull out the extraction box using
a blade screwdriver.
9.2 Battery detail
Classification Lithium Coin
Chemical System Lithium / Manganese Dioxide (Li/MnO2)
Nominal Voltage 3.0 Volts
Typical Capacity 235 mAh (to 2.0 volts)
Typical (Li) Content 0.109 grams (0.0038 oz.)
Energy Density 198 milliwatt hr/g, 653 milliwatt hr/cc
Operating Temp -30C to 60C
Warning! CR2032 is a
“Lithium Coin” battery
Danger! KEEP OUT OF REACH OF CHILDREN. Swallowing may lead to serious injury or death in as little
as 2 hours due to chemical burns and potential perforation of the esophagus. To prevent children
from removing batteries, battery compartments is designed to be opened with a screwdriver and is
protected by a security label.
Warning! It is suggested to replace the battery every 3 years. When the battery is removed, an
internal dedicated device allows replacement without data loss if operation is completed within 1
hour since battery removal.

User manual - HMI Series - 11
10 TdControlPanel
At switch-on a project starts allowing to verify the machine
general status, date/system hour, related IP address, SoftPLC
execution in background.
Using a VNC client you can view from your PC what is displayed on the PLC / HMI. Starting a browser
with active Java service it is possibile to test if the device Webserver function is active. For this function
it is necessary to use Internet Explorer.
Press “Td Control Panel,” to access the device control
panel and verify/configure all the services and projects to
be launched at starting. It is possible also to configure the
standby time for the backlighting switch off and the buzzer
at display pressure.
The following paragraphs describe each function of the TdControlPanel windows.
NB: Pictures show device standard configuration.
10.a WIN EXPLORER
From this window it is possible to choose a set of options to
start Windows CE and execute TDControlPanel.
• The first option starts Windows CE with desktop.
• The second option allows TDControlPanel starting if ,
during the switch on , the key
“Stop” is keep pressed .
• Enabling the third option it is possible to set a protection
password to avoid that unauthorized users, keeping
pressed
“STOP” , access TDControlPanel settings..
“START WINDOWS DESKTOP” allows to start “Explorer.exe” to access Windows CE desktop.
10.b HMI_MOVICON
From this window it is possible to select which Movicon 11
services/programs execute automatically at starting.
The functions of the Movicon scada are available in all
HMI and in “WEB” version PL500 (PL500-335-1AD-WEB)
“START” activates manually the Movicon project (and the file upload service)
