VIP-450SIPcommandReference Guide
The VIP-450 is aSIPversion 2.0compliant voicegateway,whichintegrates a
web-basedgraphicaluser interface, andcommandlineadministrationthatcan cover
most configurations andapplication demands.

PLANETVIP-450SIPReferenceGuide
2
TABLE OF CONTENTS
1.ABOUT THISGUIDE 3
2. SIPCOMMAND REFERENCE. ...3
3. DIALPLAN SETUP.. .. 5
4. CALLTRANSFER ..5
5. CONFIGURATION EXAMPLE ... .6

PLANETVIP-450SIPReferenceGuide
3
ABOUTTHIS GUIDE
This VIP-450 SIP(SessionInitiation Protocol) Reference Guide provides SIPconfiguration commands.
Before starting configurations, it is suggestedtocheck the SIPconnectionrequirement carefully,then
configure therequired valueinmachine. If you re not surewhich parametersshould be inserted, please
check thisguide for correspondingparameters to establish the voice connection onyour side. Inthe
meantime, more VOIPconcept and machinedesignalgorithm can be referredin the user smanualCD for
more understandings.
This Guide contains thefollowing information:
SIPCommand Reference: Thischapterillustrates howtousethesip command for the Internet
TelephonyGateway(ITG), toregister with the SIPproxyserver.
Dial PlanSet Up: Shows the differencebetween the H.323and SIPprotocol.
Call Transfer: This chapter illustrates the operations of call transfer.
ConfigurationExample: This chapter showsyou how to set up the ITGtostart up your call.
Before readingthis guide,itisbest thatyouarefamiliar withthe “QUICK INSTALLATION GUIDE”and
youknowthe network configurations, aswell as the dialplan set up.

PLANETVIP-450SIPReferenceGuide
4
1. SIPCOMMANDREFERENCE
showsip reg
- displays the informationofregistration
showsip cfg
- displays theconfigurationof registration
showsip proxy
- displays theconfigurationof proxy server
showsip dns_ip
- displays theconfigurationof DNS server
showsip info_sw
- displays theinformationswitch
showsip auto_reg
- displaysauto-registrationon/off whenreboot
showsip nat_call
- displaysnat_call switch
showsip outboundproxy
- displays theoutbound proxy
set sip reg add
- used toadd registration information
set sip regadd [reg_num][expires][#registrar] [ip][port] {name | 0} {passwd|
0} {ipport …}

PLANETVIP-450SIPReferenceGuide
5
Syntax description
reg_num the phone number to beregistered
expires how long thereg_numistore-register
#registrar the number ofregistrar
ip IPofthe registrar
port port oftheregistrar
name [thename for authentication| 0 forno authentication]
passwd [thepasswordforauthentication | 0forno authentication]
set sip reg del
- used todeleteregistrationinformation
set sip reg del [reg_num]
Syntax description
reg_num the phone number to bedeleted
set sip cfg
- used tosettheconfigurationof sip
set sip cfg [udp_ctl_port] [rtp_data_port]
Syntax description
udp_ctl_port <udp controlport>|( 0 : defaultport willbe used)
rtp_data_port <rtpdataport>|( 0 : defaultport willbeused)
set sip proxy
- used tosettheconfigurationof sip
set sip proxy [#proxy_svr] [ proxysvr-1 nwa ] { proxy svr-2nwa}…
Syntax description
#proxy_svr numberof proxyserver | 0toremove existingserver
proxysvr nwa <ip> <port>
set sip actreg

PLANETVIP-450SIPReferenceGuide
6
- used tosend out theregistration
set sip actreg
set sip dns_ip
- used to setthe domain nameserver.TheIPdomainshould bein
numericalformat
set sip dns_ip [ip]
Syntax description
ip <x.x.x.x> | 0 to remove dns ip
set sip info_sw
- used tosetthesipprocess informationswitch
set sip info_sw[on/off]
set sip auto_reg
-used to setregistration auto start when rebootin thecondition ofregistration
serveris set
set sip auto_reg [on/off]
set sip nat_call
-used to setnat_callswitchon/offwhether thegateway in public IP is toreceive
calls from the privateIPor not.Thedefaultis on
set sip nat_call [on/off]
set sip outboundproxyadd
- used toadd outbound proxy
set sip outboundproxyadd [ip/hostname] [port]
set sip outboundproxydel
- used todeleteoutboundproxy
set sip outboundproxydel

PLANETVIP-450SIPReferenceGuide
7
2. DIAL PLAN SETUP
Here, we list the differencesbetweenthe H.323 and SIPdialplanconfigurations. If you arenot familiar
with machine dialplansetup,please referto theVIPQuick Installation Guide and the User s manual
formoreunderstandings of thedialplanoperationsin machine.
Calling destination inPLANET H.323voice gateways canbeadded via following commands:
atpm dadd [dest_id] h323 [destipaddr] [port]
atpm dadd [dest_id] dns [desthost name] [port]
In VIP-450 the “h323”part in the command is replaced by “sip”:
atpm dadd [dest_id] sip [dest ip addr] [port]
atpm dadd [dest_id] dns [desthost name] [port]
3. CALL TRANSFER
VIP-450 supports unattended call transfer.
3-1The Operations
When aremote sessionis established, bothends ofthe partiescan transferacall toanother location
bypressing theFlash/Transfer keypad on the phoneset.
3-2Operation Recovery
When theuseris transferringacalltoadestination thatdoes not exist on the dialplan, an
out-of-service tone willbegenerated. PressingtheFlash/Transferkeypad can bring usersback to
theoriginal session.
4. CONFIGURATION EXAMPLE
Now,it is assumedthat youare registering toaproxyserver(referred toregistrar). Theinformation for
registration is as follows:
ITGIP: 211.20.1.5
Registered ID: 2001

PLANETVIP-450SIPReferenceGuide
8
ExpiredTime: 500
ProxyServer IP: 211.20.1.1
ProxyServer Port: 5060
Set the information of registration.
ITG>set sip reg2001 500 1 211.20.1.5506000
Then youneed set up theserver.
ITG>set sip cfg 00
Then youneed set up theserver.
ITG>set sipproxy1211.20.1.15060
In ordertosupport the complete function, you needto set a port cid number.Weassume port 0isused.
ITG>set port 0cid number 2001
Next, youneed tosave the information andsend out the registration.
ITG>config activate
ITG>config store
ITG>set sipactreg
*Note: Before startingthefirst call,you need toset up the dialplan.Don tforget touse “sip”whenyou
type “atpm dadd”.
