Planet MII Series User manual

Fast / Gigabit Ethernet Switch Module
MII series
User's Manual

Trademarks
Copyright © PLANET Technology Corp. 2008.
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other
trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work
properly in all environments and applications, and makes no warranty
and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or tness for a particular
purpose.
PLANET has made every effort to ensure that this User’s Manual is
accurate; PLANET disclaims liability for any inaccuracies or omissions
that may have occurred.
Information in this User’s Manual is subject to change without notice
and does not represent a commitment on the part of PLANET. PLANET
assumes no responsibility for any inaccuracies that may be contained in
this User’s Manual. PLANET makes no commitment to update or keep
current the information in this User’s Manual, and reserves the right
to make improvements to this User’s Manual and/or to the products
described in this User’s Manual, at any time without notice.
If you nd information in this manual that is incorrect, misleading, or
incomplete, we would appreciate your comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the Instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to
take adequate measures.
WEEE Warning
To avoid the potential effects on the environment and human
health as a result of the presence of hazardous substances in
electrical and electronic equipment, end users of electrical
and electronic equipment should understand the meaning of
the crossed-out wheeled bin symbol. Do not dispose of WEEE as
unsorted municipal waste and have to collect such WEEE separately.
Revision
User’s manual for Fast / Gigabit Ethernet Switch Module
For model: MII-VSC / MII-VST / MII-VS15 / MII-VSA20 / MII-VSB20 /
MII-GT/ MII-SX / MII-LX / MII-L40 / MII-L70 / MII-SFP /
MII-LA15 / MII-LB15
Rev: 7.0 (JULY, 2008)
Part No: 2010-000021-007

Table of Contents
Chapter 1 OVERVIEW...................................................................... 5
Chapter 2 MODEL LIST ................................................................... 6
Chapter 3 CHECKLIST ..................................................................... 7
Chapter 4 INTRODUCTION ............................................................. 8
4-1 1-Port 100Base-FX Fast Ethernet Modules-MII-VSC /
MII-VST / MII-VS15 / MII-VSA20 / MII-VSB20 .................... 8
4-2 1-Port 1000Base-T Gigabit Ethernet Module-MII-GT ............11
4-3 1-Port 1000Base-SX/LX Gigabit Ethernet
Modules-MII-SX / MII-LX / MII-L40 / MII-L70 /
MII-LA15 / MII-LB15........................................................12
4-4 1-Port 1000Base-T/Mini GBIC interface Module-MII-SFP ......14
Chapter 5 Installing Optional Modules..............................................16

5
Chapter 1 OVERVIEW
Thank you for purchasing PLANET MII family Fast / Gigabit Ethernet
module. The MII family Fast / Gigabit Ethernet module can install into
PLANET FNSW / FGSW family Switch. The distance can be extended
from 100 meters (TP), 2 kilometers (Multi-mode, SC or ST), up to 120
kilometers (Single-mode, SC/LC).

6
Chapter 2 MODEL LIST
Your MII family Fast / Gigabit Ethernet module comes with one of the
following models.
Model Interface Fiber connector
and distance
Fast Ethernet
MII-VSC 100Base-FX Module (SC, MM, 2km)
MII-VST 100Base-FX Module (ST, MM, 2km)
MII-VS15 100Base-FX Module (SC, SM, 15km)
MII-VSA20 100Base-FX Module (SC, SM, 20km)
MII-VSB20 100Base-FX Module (SC, SM, 20km)
Gigabit Ethernet
MII-GT 10/100/1000Base-T Module (RJ-45, 100m)
MII-SX 1000Base-SX Module (SC, MM, 550m)
MII-LX 1000Base-LX Module (SC, SM, 10km)
MII-L40 1000Base-LX Module (SC, SM, 40km)
MII-L70 1000Base-LX Module (SC, SM, 70km)
MII-SFP 1000Base-T/Mini-GBIC Module (RJ-45, 100m)
MII-LA15 1000Base-LX Module (SC, SM, 15km)
MII-LB15 1000Base-LX Module (SC, SM, 15km)
Models with LX or last two numbered characters indicate the ber-port
is with “Single-Mode” optic ber connector and the number indicates
the maximum distance in km. The rest will be “Multi-Mode” optic
ber models.

7
Chapter 3 CHECKLIST
Your MII carton should contain the following items:
The MII family Fast / Gigabit Ethernet module
This user’s manual
If any item is missing or damaged, please consult the dealer from
whom you purchased your MII family Fast / Gigabit Ethernet module.

8
Chapter 4 INTRODUCTION
4-1 1-Port 100Base-FX Fast Ethernet Modules - MII-VSC /
MII-VST / MII-VS15 / MII-VSA20 / MII-VSB20
Figure 1. 1-Port 100Base-FX (SC, Multi-mode) Module Front View
Features:
● Comply with IEEE 802.3u, 100Base-FX Fast Ethernet standard
● 1 x 100Base-FX ber ports (SC/ST/single SC ber connectors)
● Store-and-Forward technology for abnormal packet ltering
● For establishing ber link with cable length up to 2km (Multi-mode
module) and 15/20km (Single-mode module) or 412m (half-duplex
mode)
● Slide switch for Half /Full-Duplex selection (default in full-duplex)
● Plug and Play Installation
Note
1. The fiber connector and distance support will be
different by various models.
2. The MII-VSA20/VSB20 should runs in pair. It means
you must connect MII-VSA20 in one end and another
MII-VSB20, for example, in the other end.

9
LED DEFINITION
LED Color Function
LNK/
ACT Green
Lit: indicate the link through that port is
successfully established.
Blink: indicate that the switch is actively sending
or receiving data over that port.
FDX Orange
Lit: indicate that port is operating in full-duplex
mode.
Off: indicate that port is operating in half-duplex
mode.
Blink: if a collision is detected when the port is
in half-Duplex mode.
Table 1. LED denition of 100Base- FX module
Slide switch settings:
Figure 2 shows the 100Base-FX module slide switch overview and the
screen in Figure 3 appears shows the web settings for working under
100Mbps full-duplex mode and half-duplex mode.
Please make sure you have correctly congured the 100Base-FX
module in the same duplex mode between the module’s slide switch
and web interface speed duplex mode settings of module slots before
physically installing the modules.
F U L L
H A L F
Figure 2. Slide switch overview of 100Base- FX module

10
Figure 3. 100Base- FX module duplex mode setting of web interface
Table 2 below shows the settings for working under 100Mbps full-
duplex mode and half-duplex mode. Both module (slide-switch) and the
switch (web interface) should be xed on the same mode.
Speed/duplex 100Full-duplex mode 100Half-duplex mode
Hardware (module) Full-duplex mode Half-duplex mode
Software (rmware) 100 Full 100 Half
Table 2. Settings of 100Base-FX module
Table 3 below shows the slide switch operation for full duplex and half
duplex mode.
Slide Switch Description
FDX
The module works on full duplex mode. The other side must
be also congured on full duplex mode. This provides up
to 2km distance by multi-mode module and 15/20km by
single-mode module.
HDX
The module works on half duplex mode. The other side must
be also congured on half duplex mode. This provides up to
412m distances.
Table 3. Slide switch settings of 100Base-FX module

11
4-2 1-Port 1000Base-T Gigabit Ethernet Module-MII-GT
Figure 4. 1-Port 1000Base-T Module Front View
Features:
● Comply with IEEE 802.3 Ethernet, IEEE 802.3u Fast Ethernet, IEEE
802.3ab Gigabit Ethernet standard
● 1 x 10/ 100/1000Mbps N-Way auto-negotiation switch port
● Automatic MDI/MDI-X crossover function
● Store-and-Forward technology for abnormal packet ltering
● Non-blocking and full wire speed forwarding rate
● LED indicators for Speed status
● Up to 100m over 4-pair UTP Cat.5e cable
● Plug & Play Installation

12
LED DEFINITION
LED Color Function
LNK/ACT
1000 Green
Lit: indicate that the port is operating at
1000Mbps.
Off: indicate that the port is operating at 10
Mbps or 100Mbps.
Blink: indicate the trafc sending or receiving
over that port.
LNK/ACT
100 Green
Lit: indicate that the port is operating at
100Mbps.
Off: indicate that the port is operating at 10
Mbps or 1000Mbps.
Blink: indicate the trafc sending or receiving
over that port.
LNK/ACT
10 Green
Lit: indicate that the port is operating at
10Mbps.
Off: indicate that the port is operating at 100
Mbps or 1000Mbps.
Blink: indicate the trafc sending or receiving
over that port.
Table 4. LED denition of 1000Base-T Module
4-3 1-Port 1000Base-SX/LX Gigabit Ethernet Modules-
MII-SX / MII-LX / MII-L40 / MII-L70 / MII-LA15 /
MII-LB15
MII-VSC
Figure 5. 1-Port 1000Base-SX Module Front View

13
Features:
● Comply with the IEEE 802.3z Gigabit Ethernet standard
● 1 X 1000Mbps ber port (SX/LX/single SC ber connectors)
● Store-and-Forward technology for abnormal packet ltering
● Full-duplex mode supported
● Plug and Play Installation
● LED indicators for LNK/ACT, FDX status
● MII-SX provide distance up to 220m over 62.5/125μm ber cable
and 500m over 50/125μm ber cable
● MII-LX provide distance up to 550m over multimode ber cable and
10km over 9/125μm single mode ber cable
● MII-L40 provide distance up to 550m over multimode ber cable and
40km over 9/125μm single mode ber cable
● MII-L70 provide distance up to 550m over multimode ber cable and
70km over 9/125μm single mode ber cable
● MII-LA15 / LB15 provide distance up to 550m over multimode ber
cable and 15km over 9/125μm single mode ber cable
Note
1. The fiber connector and distance support will be
different by various models.
2. The MII-LA15/LB15 should runs in pair. It means you
must connect MII-LA15 in one end and another MII-
LB15, for example, in the other end.
LED DEFINITION
LED Color Function
LNK/ACT Green
Lit: indicate the link through that port is
successfully established.
Blink: indicate that the switch is actively
sending or receiving data over that port.
FDX Orange Lit: indicate that port is operating in full-
duplex mode.
Table 5. LED denition of 1000Base-SX/LX Module

14
4-4 1-Port 1000Base-T/Mini GBIC interface Module-
MII-SFP
Figure 6. 1-Port 1000Base-T/Mini GBIC Module Front View
Features:
● Comply with the IEEE 802.3ab, IEEE 802.3z Gigabit Ethernet stan-
dard
● 1-Port 1000Base-T/Mini GBIC interface module
● High performance Store-and-Forward architecture
● Auto-MDI/MDI-X on 1000Base-T port
● Mini-GBIC interface for optional Mini GBIC module
● Plug and Play Installation
● LED indicators for LNK/ACT status on 1000Base-T port
● LED indicators for LNK/ACT, FDX status on Mini GBIC interface
Note
The MII-SFP module does not supports the 1000Base-T
port and Mini-GBIC interface operate at the same time.

15
LED DEFINITION
Mini GBIC interface
LED Color Function
LNK/ACT Green
Lit: indicate the link through that port is
successfully established.
Blink: indicate that the switch is actively
sending or receiving data over that port.
FDX Orange Lit: indicate that port is operating in full-
duplex mode.
Table 6. LED denition of Mini GBIC interface from MII-SFP Module
1000Base-T port
LED Color Function
1000
LNK/ACT Green
Lit: indicate the link through that port is
successfully established.
Blink: indicate that the switch is actively
sending or receiving data over that port.
100
LNK/ACT Orange
Lit: indicate the link through that port is
successfully established.
Blink: indicate that the switch is actively
sending or receiving data over that port.
Table 7. LED denition of 1000Base-T port from MII-SFP module

16
Chapter 5 Installing Optional Modules
You can purchase optional modules separately to meet the needs of
your network. The process of installing optional modules is the same.
Follow these steps to install the optional module:
1. Power the Switch off before installing the optional module.
2. Place the Switch on a at surface. Grasp the thumbscrew on the
sides of the optional module or blank bracket and turn counter-
clockwise to unscrew them. You can also use a screwdriver. Remove
the old module or the blank bracket and set aside. Do not discard
the module or blank bracket. Put the module or blank bracket back
in if you remove the new module.
3. Install the new module by inserting it into the guides and sliding it in
until it stops (See Figure 7). Press it rmly until you feel the module
snap into place. Never force, twist or bend the optional module. The
optional module slides in smoothly.
4. Gently push the thumbscrews in and turn clockwise to tighten. Do
not over tighten the thumbscrews.
5. Power the Switch on after you have installed the new module. The
Switch will automatically detect the new module.
Intelligent 10/100/1000Mbps Ethernet Switch
1 2 3 4
13 14 15 165 6 7 8
9 10 11 12
Slot 2
WGSW-2402A
LNK/ACT
100/10
PWR
13 14 15 16
1 2 3 4 5 6 78
9 10 11 12
LNK/ACT
100/10
TX RX
WGSW-C1ST
100Mbps
100Base - FX
ACT
24 Slot 1
WGSW-C1GT
1000
100
10
Mbps
10/100/1000Base-T
100Base - FX
Figure 7. Insert the modules
6. Take off the dust cover from the transceiver and plug the cable in, if
you are installing a ber optic module.
7. Check the LEDs to verify that if there is a link and a proper connec-
tion at the port.
Please refer to the Switch’s user’s manual for more about Switch or
module’s management.
