1 INTRODUCTION
User’s Manual Planmeca ProMax Cephalostat 1
1 INTRODUCTION
This manual describes how to operate the Planmeca
ProMax Cephalostat.
The Planmeca ProMax Cephalostat is used to position the
patient’s head accurately for taking X-ray images of the
skull. The device can also be used for taking hand images
for bone age studies.
The cephalostat is attached to a 2D or 3D Planmeca
ProMax X-ray unit. The X-ray unit has a separate manual.
Refer to the User’s Manual of the X-ray unit for any
general information about the X-ray unit.
NOTE
This manual is valid for software version 3.8.0.0.r or later.
This software version is compatible with Planmeca
Romexis software version 4.5.0.r or later. To check the
software version of your X-ray unit, select Settings > About
> 4100 Component Information > ProMax SW version.
Make sure that you are fully acquainted with the
appropriate radiation protection measures and these
instructions before you use the X-ray unit.
NOTE
The X-ray unit may be used by health care professionals
only.
2 SWITCHING X-RAY UNIT ON
The on / off switch is located on the underside of the
stationary column top.
NOTE
To prolong the lifetime of your X-ray unit, always switch the
X-ray unit off when it is not in active use.

3 MAIN PARTS
2 Planmeca ProMax Cephalostat User’s Manual
3 MAIN PARTS
3.1 General view of cephalostat
1 Height adjusting button
2 Head support plate
3 Rotation scale
4 Nasal positioner
5 Dimax sensor
6 Ear posts
(see section 3.2 “Patient supports” on page 3)
7 Release lever on ear post holder (patient’s left ear)
8 Collimator
Ceph&Dimax2.eps
5
1
234
7
8
6

3 MAIN PARTS
User’s Manual Planmeca ProMax Cephalostat 3
3.2 Patient supports
1 Ear post for patient’s left ear (marked with letter L)
2 Ear post for patient’s right ear (marked with letter R)
3 Positioning cones
4 Nasal positioner
5 Hand imaging support
1
23
L
Hand_imaging_support.eps
4
5

3 MAIN PARTS
4 Planmeca ProMax Cephalostat User’s Manual
3.3 Patient positioning controls
The patient positioning controls are located above the
touch screen.
The up and down buttons are used to adjust the
cephalostat to suit the height of the patient.
The cephalostat moves slowly at first, then faster.
NOTE
If for some reason either of the buttons gets stuck during
operation, you can stop the up / down movement by
pressing any of the other control buttons or the positioning
joystick. This is a safety measure that guarantees that the
up / down movement can be stopped in an emergency.
There is an additional height adjusting button on the
underside of the cephalostat. The cephalostat moves up
or down depending on which side the button is pressed.
NOTE
Be careful that the X-ray unit does not hit the ceiling when
you press the up button. The maximum height can be
adjusted to suit offices with a low ceiling, contact your
service technician for help.
NOTE
Make sure that there is no object under the X-ray unit
when you press the down button. If something is in danger
of becoming trapped, release the button immediately to
stop the movement. Clear any obstruction before pressing
the button again.
Ceph&Dimax2.eps

3 MAIN PARTS
User’s Manual Planmeca ProMax Cephalostat 5
NOTE
The column movement stops automatically if the
emergency stop plate at the bottom is pressed upwards.
Clear any obstruction before moving the column again.
NOTE
When positioning seated patients (e.g. in a wheelchair)
always first move the cephalostat down before you
position the patient.
3.4 Emergency stop button
The emergency stop button is located on the top of the
stationary column. Press the button to stop the X-ray unit
operating in an emergency. When the emergency stop
button is pressed down, all movements of the X-ray unit
are blocked and the unit will not generate radiation. The
up / down movement will stop within a distance of 10 mm
(0.4 in.).
A help message will appear on the touch screen. Guide
the patient away from the X-ray unit. Then release the
emergency stop button. The X-ray unit will automatically
restart.
emergency_stop.eps

4 PREPARATIONS FOR EXPOSURE
6 Planmeca ProMax Cephalostat User’s Manual
4 PREPARATIONS FOR EXPOSURE
4.1 Preparations on all X-ray units
4.1.1 Attaching cephalometric patient supports
The ear posts are marked with the letter L for the patient’s
left ear and letter R for the patient’s right ear.
The positioning cones contain small metal objects that are
visible in the image. They help you to identify the patient’s
left and right side.
• The left ear post contains a ball.
• The right ear post contains a ring.
NOTE
Ensure that you position the ear posts the right way round.
NOTE
The nasal positioner has to point inward as shown.
1. Lift the locking clip up and slide the ear post / nasal
positioner as far up as it will go.
2. Press the locking clip down to lock the ear post /
nasal positioner in place.
L
R.
O
L
L

4 PREPARATIONS FOR EXPOSURE
User’s Manual Planmeca ProMax Cephalostat 7
4.1.2 Removing 2D or 3D patient supports
If the temple supports are in place, turn them down and
remove all patient supports from the patient support table.
If the support bars are in place, remove all patient
supports from the patient support table, including support
bars, chin cup and adapter.
• To remove the support bars, first loosen the locking
knobs and then pull the support bars out.
enter_to_ceph_scr2.eps
Head_support_attach.eps
ProMax_5_2.eps

4 PREPARATIONS FOR EXPOSURE
8 Planmeca ProMax Cephalostat User’s Manual
4.2 Additional preparations on X-ray units with Dimax sensor
If a Dimax sensor is attached to the C-arm, the sensor
must be moved to the cephalostat before you can take
cephalometric exposures.
4.2.1 Removing sensor from C-arm
NOTE
Do not remove the sensor during imaging process.
1. Push in the C-arm electrical connector. This will
disconnect the electrical connection between the
sensor and C-arm.
Attach Dimax sensor
to cephalostat
(refer to section 4.2.2)
Remove Dimax sensor
from C-arm
(refer to section 4.2.1)
X-ray unit with
Dimax sensor
Sensor1.eps

4 PREPARATIONS FOR EXPOSURE
User’s Manual Planmeca ProMax Cephalostat 9
2. Turn the locking knob 180 degrees. This will release
the locking mechanism.
3. Carefully pull the sensor out.
CAUTION
Do not drop the sensor. Planmeca limited warranty
does not cover damage which is due to misuse, e.g.
dropping the sensor, neglect, or any cause other than
ordinary use.
Do not use the sensor if the shock indicator (1) is red
- contact your service technician for help.
If you have any reason to believe that the sensor
might be faulty, take a test exposure before taking a
patient exposure.
Sensor2.eps
Sensor3 .eps
shockwarningD3.eps
1

4 PREPARATIONS FOR EXPOSURE
10 Planmeca ProMax Cephalostat User’s Manual
4.2.2 Attaching Dimax sensor to cephalostat
1. Push the sensor onto the adapter on the cephalostat.
2. Turn the locking knob 180 degrees in order to
complete the mechanical connection.
3. Push in the cephalostat electrical connector button on
the other side. This will make the electrical
connection between the sensor and cephalostat.
Sensor4.eps
Sensor5.eps
Sensor6.eps

4 PREPARATIONS FOR EXPOSURE
User’s Manual Planmeca ProMax Cephalostat 11
4.3 Additional preparations on 3D X-ray units
If your X-ray unit has a non-rotating tube head, you must
remove the 3D sensor from the C-arm before you can
take cephalometric exposures.
4.4 Preparing Planmeca Romexis
First select the patient.
Then select the cephalometric exposure.
Refer to the Planmeca Romexis User’s Manual for details
on Romexis functions.
Tube_head_non_rotating.eps
Tube_head_rotating.eps
No joint Joint
(tube head rotates
(tube head does
not rotate)
Non-rotating tube head
-> remove 3D sensor from C-arm Rotating tube head
-> no need to remove 3D sensor
to ceph position)
(refer to section 4.2.1)
3D unit
C-arm

4 PREPARATIONS FOR EXPOSURE
12 Planmeca ProMax Cephalostat User’s Manual
4.5 Preparing patient
Ask the patient to remove any spectacles, hearing aids,
dentures, hairpins, and personal jewellery such as
earrings, necklaces and piercings as these can produce
shadows or reflections in the image. The patient should
also remove any loose items of clothing (e.g. scarf, tie)
that might get caught in the arm structures of the X-ray
unit.
Place a protective lead apron over the patient’s back if
required.
NOTE
We recommend that you image patients with poor health
in a sitting position.

5 CEPHALOMETRIC EXPOSURE
User’s Manual Planmeca ProMax Cephalostat 13
5 CEPHALOMETRIC EXPOSURE
5.1 Selecting general exposure settings
Refer to section “Touch screen” in the User’s Manual of
the X-ray unit for general information on how to make or
cancel selections on the touch screen.
5.1.1 Selecting program
Select the cephalometric program (2D Dental >
Cephalostat).
5.1.2 Selecting program type
Select the program type from the drop-down menu at the
top of the screen.

5 CEPHALOMETRIC EXPOSURE
14 Planmeca ProMax Cephalostat User’s Manual
5.1.3 Selecting patient size
Use this button to select the patient size:
• XS = Child
• S = Small adult
• M = Medium-sized adult
• L = Large adult
• XL = Extra large adult
NOTE
The exposure values will automatically change according
to the selected patient size and program type.
NOTE
The patient size can also be selected on the next screen.

5 CEPHALOMETRIC EXPOSURE
User’s Manual Planmeca ProMax Cephalostat 15
5.2 Patient positioning in lateral projection
1. Select the lateral program from the drop-down menu
at the top of the screen.
2. Rotate the head support plate
a. to the 0° position if you want the patient to face
away from the wall
OR
b. to the 180° position if you want the patient to
face towards the wall.
3. Select the patient size as described in section 5.1.3
“Selecting patient size” on page 14.
X2_Di_Ceph2.eps
2 a) 0°
X2_Di_Ceph2.eps
2 b) 180°

5 CEPHALOMETRIC EXPOSURE
16 Planmeca ProMax Cephalostat User’s Manual
4. Select the area that you wish to expose:
• Gray prohibition sign = area to be exposed
• Red prohibition sign = area NOT to be exposed
NOTE
The size of the exposure area is indicated on the screen.
The exposure area is automatically reduced for child
patients (XS).
NOTE
The illustration on the screen is only an example.
5. To go to the next screen, select
• this symbol
OR
• the forward button.
