Plantronics ML10 User manual

LEARN
MORE
ML10 and ML12
Bluetooth®Headset

2
CALL BUTTON
• Takeacallorendit(1 tap)
• Redial(2 taps)
• Initiatephone’svoice-dialing
(2 second press until tone is heard)
• ReconnectlostBluetoothconnection
(1 tap if the headset doesn’t
automatically reconnect)
• Activatepairingmodeafterinitialset
up(press until LED flashes red/blue)
• CancelmissedcallLED(1 tap)
POWER SWITCH
• On(slide to reveal black)
• Off(slide to reveal red)
MICRO USB CHARGING PORT
• UsewiththeACcharger
1 hour before first use
2 hours (for full charge)
• Donotuseheadsetwhilecharging
VOLUME BUTTONS
• Volumeup/down (tap + or –
buttons per level change)
LED
• Charging(solid red)
• Lowbattery(3 red flashes at
powering on)
• Onacall(blue flash every 2 seconds)
• Missedcall(purple flashes. Repeats
for 5 minutes or until cancelled.)
• Pairingmode(repeating red/blue
flashes)
Besafe!Pleasereadthesafety
guideforimportantsafety,charging,
batteryandregulatoryinformation
beforeusingyournewheadset.
TAKE A GOOD LOOK

3
CONNECT TO YOUR PHONE
“Pairing” is the set-up process
of introducing your headset
to your phone.
Before using your headset
for the first time, you must
pair it with your Bluetooth-
enabled phone.
Pairing is a one-time process
unless your phone loses the
connection or you want to
pair a new phone.
1. READY
Activate the Bluetooth feature
on your phone, then get phone
to add/search/discover new
Bluetooth devices.
Phoneshavedifferentmenusto
selectfrom
iPhone Settings > General >
Bluetooth > On
(starts the search for devices)
BlackBerry®smartphone
Settings/options > Bluetooth: On >
Search for devices
2. SET
Firsttime,rightoutofthebox
With headset turned off, activate
Bluetooth pairing mode by
sliding Power switch on. The
LED flashes red/blue to indicate
pairing mode.
Pairingnewphone/
reconnectingoriginal
With headset turned off, slide
Power switch on. Press and
hold the Call button until the
LED flashes red/blue.
3. CONNECT
Select “PLT_MLXX” from the list of
Bluetooth devices shown on your
phone.
If phone asks for a passcode,
enter four zeros (0000). You
may see **** on screen. Some
phones also ask to confirm
headset connection after pairing.
Headset LED will stop flashing
red/blue once your phone and
headset are successfully paired/
connected.
You can now make a call using
your phone’s keypad or voice-
dialing feature.

4
2
1
FIT EITHER EAR
Left ear Right ear

5
TIPS
Understand the tones you hear:
This headset beeps different tones to advise you on what
it is doing.
Usually, a high tone requires you to act (e.g. you lost the
Bluetooth connection or need to recharge battery) but a low
tone is just a reaction to you pressing a button (e.g. volume
changes, call start/end).
Stay near your phone:
Bluetooth has a working “range” of up to 10 metres (33 feet)
between the phone and headset before audio degrades and
the connection is lost.
Know how to reconnect:
Your headset tries to reconnect a lost connection. If it can’t,
then tap the Call button once or manually reconnect via the
phone’s Bluetooth device menu.

6
SPECIFICATIONS
Talktime Up to 7 hours
Standbytime Up to 8 days
Operatingdistance(range) Up to 10 metres (33 feet), Class II
Headsetweight 11.5 grams
Chargeconnector Micro USB charging
Batterytype Rechargeable non-replaceable lithium ion polymer
Chargetime(maximum) 2 hours for full charge
Powerrequirements 5V DC – 180mA
Bluetoothversion Bluetooth v2.0
Bluetoothproles Hands-Free (HFP) Profile 1.5 and Headset (HSP) Profile 1.1
Operatingtemperature 0 - 40°C (32°F - 104°F)
Storagetemperature 0 - 40°C (32°F - 104°F)
Chargingtemperature 0 - 40°C (32°F - 104°F)

7
NEED MORE HELP?
Plantronics Ltd
Wootton Bassett, UK
Tel: [phone]
[phone]*
Czech Republic
[phone]*
Danmark
Tel: [phone]
Plantronics GmbH
Hürth, Deutschland
Kundenservice:
Deutschland 0800 9323 400
Österreich 0800 242 500
Schweiz 0800 932 340
Για περισσότερες
πληροφορίες:
[phone]*
Plantronics Iberia, S.L.
Madrid, España
Tel: [phone]
Finland
Tel: [phone]
Plantronics Sarl
Noisy-le-Grand
France
Tel: [phone]
Plantronics BV
Regus House
Harcourt Centre
Harcourt Road
Dublin 2, Ireland
Service ROI: 1800 551 896
:רתאב רקב ,ףסונ עדימל
[phone]*
További információk:
[phone]*
Plantronics Acoustics
Italia Srl, Milano, Italia
Numero Verde: 800 950934
Plantronics B.V.
Hoofddorp, Nederland
NL 0800 7526876
BE 0800 39202
LUX 800 24870
Norge
Tel: [phone]
Aby uzyskać więcej informacji:
[phone]*
Portugal
Tel: [phone]
Pentru informaţii
[phone]*
Дополнительная
информация:
[phone]*
Sverige
Tel: [phone]
Daha fazla bilgi için:
[phone]*
en
cs
da
de
el
es
fl
fr
ga
he
hu
it
nl
ar
no
pl
pt
ro
sv
tr
ru
*Support in English www.plantronics.com

Safety information:
see the separate “For Your Safety” booklet
2-year limited warranty details:
www.plantronics.com/warranty
NEED MORE HELP?
Plantronics B.V.
Scorpius 140
2132 LR Hoofddorp
Netherlands
www.plantronics.com
© 2011 Plantronics, Inc. All Rights Reserved. Bluetooth is a registered trademark
of Bluetooth SIG, Inc. and any use by Plantronics is under license. All other
trademarks are the property of their respective owners. U.S. Patents Pending.
AM85663-03 (03.11) EN-UK
AE11
EEE Yönetmeliğine Uygundur
