POLTI VAPORETTO EVOLUTION User manual

Polti S.p.A. - 22070 Bulgarograsso (CO) - Italy - Via Ferloni, 83
www.polti.com
EDITION
EVOLUTION
COP - VT EDITION - VT EVOLUTION M0S09652 1R04:Layout 1 22/04/2011 11.53 Pagina 2

Fig. 5
Fig. 1
Fig. A
Fig. 3Fig. 2
Fig. 6
OFF
ON
Fig. 4a Fig. 4b
H
G
D
C
I
A
B
F
E
11
9
11
15
13
12 11
11
9
10
8
9
117
20
11 19
U R
S
5
64
T
11
23
V
Q
21
22
24 18
14
2
5
4
6
1
3
2A
17
11
16
VT EDITION VT EVOLUTION
Vaporetto Edition - Vaporetto Evolution M0S09652 1R04
COP - VT EDITION - VT EVOLUTION M0S09652 1R04:Layout 1 22/04/2011 11.52 Pagina 1

VAPORETTO EDITION - VAPORETTO EVOLUTION
34
E
EN
NG
GL
LI
IS
SH
H
GENERATOR
A) Patented Safety Cap
B) Generator on/off switch
C) Accessories on/off switch
D) Central connector block with splashproof
cover
E) Lock-in aperture for central connector
F) Power supply cable
G) Carrying handle
H) Pivoting wheels
I) Steam regulation control
ACCESSORIES
1) Flexible hose
2) Steam gun
2A) Safety switch
3) Steam request lever
4) Connector assembly
5) Press down connector button
6) Locking tab
7) Extension tubes
8) Large brush
9) Cloth retaining clips
10) Replaceable bristles plate
11) Accessories locking button
12) Small brush
13) Cotton cloths
14) Filler bottle (VT EVOLUTION)
14) Filler funnel (VT EDITION)
15) Spare washers for accessory connections
16) 120° nozzle(*)
17) Small round brush for 120° nozzle(*)
18) Window squeegee tool (*)
19) Small blade for window tool (*)
20) Large blade for window tool (*)
(*) OPTIONAL for Vaporetto EDITION
ACCESSORIES SOLD SEPARATELY
21) High pressure lance
22) Triangular brush
23) Large round brush for 120° nozzle
24) Wallpaper stripper tool
Q) Iron
R) Steam request button
S) Temperature regulation dial
T) Iron res mat
U) Continuous steam jet button
V) “Iron heating” indicator light
Dear Customer,
Congratulations and thank you for purchasing this POLTI product, contributing to the
conservation of our most precious natural resource: the Environment. VAPORETTO solves all cleaning
and hygiene problems without the use of detergents - all that’s needed is just normal tap water which our
system transforms into steam at a constant powerful pressure, allowing you to clean more thoroughly and
in an ecological way.
Our Technical Development team have added a range of sophisticated improvements to make cleaning
tasks both safer and more effective:
• The new handle is smaller, lighter, easier to handle and more comfortable to use because you can start
producing steam with just one finger, by lightly pressing a button.
Safety is guaranteed by the strict tests all Polti products and accessories are subjected to. The STEAM
COMFORT handle has passed the strict Splash Proof Test certifying its resistance to splashes of water.
• The Safety Cap - a unique Polti patent, prevents opening whilst any residual pressure remains in the sy-
stem.
• Steam pressure is controlled by a pressure switch and the steam flow can be regulated while opera-
ting.
Polti’s products are submitted to very strict testing.Vaporetto passed also the Splash Proof Test, since it
has been designed to be splash proof.
VAPORETTO is built according to the IEC regulations, and is equipped with a safety valve, a safety ther-
mostat and an additional protective thermostat which prevents operation of the machine when it is empty
and which maintains VAPORETTO in an absolutely safe condition at all times. The accessories and all the
components are manufactured with highest quality materials which are resistant to the high temperatures
attained during the operation of this machine.
Read these instructions carefully before using the appliance.
VT EDITION - VT EVOLUTION M0S09652 1R04:VT 2300 M0S05357 1L05 22/04/2011 11.58 Pagina 34

VAPORETTO EDITION - VAPORETTO EVOLUTION
35
E
EN
NG
GL
LI
IS
SH
H
plugs in water or another liquid.
• Use of the appliance in places where there is a
danger of explosions is prohibited.
• Do not use the product with toxic substances.
• Do not lay the hot appliance on surfaces sensi-
tive to heat.
• Do not leave the appliance exposed to wind or
rain.
• Do not place the appliance near a live element,
an electric stove or any other source of heat.
• Do not expose the appliance to extreme tempe-
ratures
• Never let children or people who are not familiar
with how the appliance works use it.
• Do not press the buttons hard or with a pointed
object such as a pen.
• Always rest the appliance on a stable surface.
• In case of accidental fall of the appliance it is ne-
cessary to have it checked by an authorized Polti
Service Centre as the internal safety features
may have been affected.
• In case of breakdown or malfunction switch off
the appliance and never attempt to disassemble
it, but refer to an authorized Service Centre.
• To avoid prejudicing the safety of the appliance,
use only original spare parts and accessories ap-
proved by the manufacturer.
• Do not wind the power cable around the ap-
pliance, especially when the appliance is still hot.
• During refilling with water, switch off and discon-
nect the appliance from the mains.
• It is necessary to keep the unit in horizontal posi-
tion during operation.
• Do not direct the steam jet onto electrical and/or
electronic appliances.
• Let the appliance cool down before cleaning it.
• Before storing the appliance make sure that it
has completely cooled down.
• This appliance is equipped with safety devices
which are to be replaced only by a suitably quali-
fied technician.
• Do not direct the steam jet at people, animals or
debris.
• Never place your hands inside the jet of steam.
• When Refilling the boiler, use HOT rather than
cold water, pour in gently at first and keep expo-
sed skin and your face away. Otherwise the still
hot tank walls can spit drops of very hot water or
steam spray.
• Do not put any detergent or chemical substance
in the boiler. Water by its nature contains magne-
ATTENTION:
Danger of burns!
This unit conforms with EC-directives
2004/108/CE (EMC) and 2006/95/CE (low
voltage).
Polti S.p.A. reserves the right to change equipment
or accessory specification without prior notice.
P
PR RE EC CA AU UT TI IO ON NS S
KEEP THESE INSTRUCTIONS
• Read these instructions for use carefully before
using the appliance, and make sure that anyone
using the machine is familiar with these instruc-
tions and the warnings.
• DO NOT USE THE STEAM FUNCTION ON
DRAYLON, VELVET, LEATHER OR OTHER
SENSITIVE FABRICS.
• Any use which does not comply with these in-
structions will invalidate the warranty.
• The wiring system to which the appliance is con-
nected must always comply with the laws in
force.
• Before connecting the appliance, make sure that
the mains voltage is the same as the voltage in-
dicated on the data label of the appliance and
that the power outlet is connected to earth
• Always turn off the appliance at the on/off switch
before unplugging it.
• If the appliance is left unused, always disconnect
it from the mains. Never leave the appliance
unattended with the cable plugged into the
mains.
• Always make sure the appliance is unplugged
before performing maintenance work of any kind
• Do not pull the power cable out of the socket, but
grasp the plug itself to avoid damage to the
socket.
• Do not allow the power cable to be twisted, cru-
shed, stretched, or come into contact with sharp
or hot surfaces.
• Do not use the appliance if the power cable or
other important parts are damaged.
• Do not use electric extension leads that are not
authorized by the manufacturer, as they may
cause damage or fire.
• If it is necessary to replace the power supply ca-
ble, please refer to the nearest Polti authorised
service centre, since the use of a special tool is
necessary.
• Never touch the appliance with wet hands or feet
with the cable plugged into the mains.
• Do not use the appliance when barefoot.
• Do not use the appliance near a bathtub, shower
or container full of water
• Never immerse the appliance, the cable or the
VT EDITION - VT EVOLUTION M0S09652 1R04:VT 2300 M0S05357 1L05 22/04/2011 11.58 Pagina 35

VAPORETTO EDITION - VAPORETTO EVOLUTION
36
E
EN
NG
GL
LI
IS
SH
H
sium, mineral salts and other deposits which in
hard water areas can contribute to limescale
build up in the boiler. To avoid these problems, it
is necessary to swill out with tapwater and empty
the boiler after every 3 or 4 uses.In very hard wa-
ter areas we recommend the use of our KAL-
STOP, a special natural-base decalcifier which
inhibits and breaks down limescale, making it
easy to remove just by swilling out the tank with a
little tapwater. This is a preventive against scale
build-up and protects the metal walls of the
steam generator tank. KALSTOP is available
from Polti dealers or by mail-order from your Polti
Service Centre.
• We recommend you use original Polti pro-
ducts only, as products of other brands may
not be suitable for use in Polti products and
could cause damage.
• Never use distilled water or scented water.
• Make sure the patented safety cap is fully and
correctly screwed on, otherwise you may expe-
rience steam escaping from around the cap.
• Check periodically the safety cap and MAKE
SURE the rubber gasket is in place around the
base of the screw thread.
Replace with original spare parts if necessary.
DO NOT USE the appliance if the rubber gasket
is not in position.
• Do not refill the tank while it is still hot, allow it to
cool down for a few minutes before refilling.
• Do not empy the appliance when the water in the
boiler is still hot.
• Do not try to unscrew the safety cap when the
appliance is in use.
• If you iron sitting down, do not put your legs un-
der the ironing board, the steam can cause
burns.
• Iron only on heat resistant surfaces and on surfa-
ces that allow the steam to escape, e.g. mesh
ironing boards.
• The iron must be used and rested on a stable
surface.
• When placing the iron on its stand, make sure
that the surface on which the stand is placed is
stable.
• This appliance is not intended for use by persons
(including children) with reduced physical, sen-
sory or mental capabilities, or lack of experience
and knowledge, unless they have been given su-
pervision or instruction concerning use of the ap-
pliance by a person responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• The appliance must not be used if it has fallen,
been dropped or when it has visible signs of da-
mage or leaks.
• If the supply cord is damaged, it must be repla-
ced by the manufacturer, its service agent or si-
milarly qualified persons in order to avoid a ha-
zard.
C
CO OR RR RE EC CT T U US SE E O OF F T TH HE E P PR RO OD DU UC CT T
This appliance is intended for home use as a
steam cleaner as described and in accordance
with the instructions provided in this manual.
Please read these instructions carefully and keep
them, as you may find them useful in future.
Polti declines liability for any damage or acci-
dent derived from any use of this appliance
which is not in conformity with the instructions
contained in this booklet.
A
AT TT TE EN NT TI IO ON N
Directive 2002/96/EC (Waste Electrical and Elec-
tronic Equipment - WEEE): information for users
This product complies with EU Directive
2002/96/EC.
The crossed-out wastebasket symbol on
the appliance means that at the end of its
useful lifespan, the product must be di-
sposed of separately from ordinary hou-
sehold wastes.
The user is responsible for delivering the appliance
to an appropriate collection facility at the end of its
useful lifespan.
Appropriate separate collection to permit recycling,
treatment and environmentally compatible disposal
helps prevent negative impact on the environment
and human health and promotes recycling of the
materials making up the product. For more informa-
tion on available collection facilities, contact your
local waste collection service or the shop where
you bought this appliance.
I
IM MP PO OR RT TA AN NT T
Before leaving our factory all our products are rigo-
rously tested. For this reason, your VAPORETTO
may contain some residual water in the boiler from
the testing.
S
SE ET T U UP P
Before using VAPORETTO for the first time assem-
ble the pivoting wheels as indicated in the Fig. A.
VT EDITION - VT EVOLUTION M0S09652 1R04:VT 2300 M0S05357 1L05 22/04/2011 11.58 Pagina 36

VAPORETTO EDITION - VAPORETTO EVOLUTION
37
E
EN
NG
GL
LI
IS
SH
H
P
PR RE EP PA AR RA AT TI IO ON N F FO OR R U US SE E
1. Unscrew the patented safety cap (A) and fill the
boiler with about 1,3 litres of water using the fil-
ler bottle / funnel (14) making sure that it does
not overflow (fig. 1). Normal tapwater can be
used. However, as hard water by its nature
contains limestone, which may cause a build-
up of limescale in the tank, in hard water areas
we recommend the use of our natural-base de-
calcifier KALSTOP, available from your Polti
dealer or by mail order from your Polti service
Centre.
2. Carefully screw on the safety cap to hand tight
(Fig. 2). Make sure the patented safety cap (A)
is fully and correctly screwed on, otherwise you
may experience steam escaping from around
the cap.
3. Connect the power supply cable (F) into an
earthed power supply of the correct voltage.
WARNING: Do NOT under any circumstances put
or leave the filler bottle in the water filling aperture
of the appliance when the appliance is connected
to the mains electricity supply. Danger of burns!
Always make sure generator on/off switch (B) is
switched OFF before connecting the appliance to
the mains.
I
IN NS ST TR RU UC CT TI IO ON NS S F FO OR R U US SE E
1a. Press down the generator on/off switch (B) and
the accessories on/off switch (C) which will light
up.
2a. Open the cover of the central connector block
(D) and insert the central connector (4) pres-
sing the connector button (5) and taking care
that the locking tab (6) is correctly positioned in
the lock-in aperture (E) on the block (Fig. 3).
3a. When the generator on/off switch (B) goes out,
the steam cleaner is ready for use
4a. The steam gun (2) is equipped with a safety
switch (2A) which prevents the accidental start
of the steam jet by children or people who do
not know how to operate the appliance.
With the switch (2A) in the “OFF” position, the
lever controlling the steam jet is locked
(Fig.4b). Should the hose be left unattended for
a moment whilst the appliance is connected to
the mains, it is recommended to put the safety
switch in the “OFF” position. To start working,
set the (2A) switch to the “ON” position and
press the steam button (Fig.4a).
The first burst of steam may contain some water
droplets, due to imperfect thermic stabilisation in-
side the flexible hose. We would therefore advise
that the first jet of steam is played onto an old cloth
until a constant pressure of steam is obtained.
Note: The generator on/off switch (B) may go on
and off from time to time during use of VAPO-
RETTO. This means the machine is maintaining the
correct and constant pressure and is quite normal.
S
ST TE EA AM M R RE EG GU UL LA AT TI IO ON N F FE EA AT TU UR RE E
VAPORETTOs are equipped with a steam regula-
tion control (I) (Fig. 5). You can increase the steam
flow by turning the control in clockwise direction.
Turning it in an anti- clockwise direction reduces
the steam flow. Here are some suggestions for the
choice of steam flow level:
• Strong steam: for encrusted dirt, stains, grease
and for sanitising.
• Normal steam: for carpets, rugs, glass, tiles etc.
• Delicate steam: for vaporising plants and clea-
ning delicate surfaces.
Please read separate warning about use on dray-
lon, velvet and other delicate fabrics, or on sensi-
tive wood surfaces.
C
CO ON NN NE EC CT TI IO ON N O OF F A AC CC CE ES SS SO OR RI IE ES S
All the accessories of VAPORETTO can be con-
nected to the handle or to the extension tubes as
per the following instructions (fig. 6):
1b. Move the locking button (11) on the accessory
to the “open” position.
2b. Attach the required accessory to the hand gun
or to the extension tube.
3b. Move the locking button (11) back to the posi-
tion ‘closed’.
4b. Check that the locking button has engaged and
the accessory is fully connected.
P
PA AT TE EN NT TE ED D S SA AF FE ET TY Y C CA AP P / /
’
’’ ’W WA AT TE ER R O OU UT T’ ’’ ’
The appliance is equipped with a safety cap, which
prevents opening of the generator tank as long as
there is any pressure remaining inside. This is an
important and indispensable safety device, and it is
necessary to follow the procedure here below when
re-filling the generator tank.
When you have used up all the water in the tank,
proceed as follows:
1c. Switch off the machine at the generator on/off
switch (B)
2c. Press the steam request lever (3) on the steam
gun (2) or, if using the iron, the steam request
button (R) on the iron (Q) so as to fully exhaust
the steam supply from the tank.
3c. Switch OFF the accessory on/off switch (C).
4c. Disconnect the power supply cable (F) from the
VT EDITION - VT EVOLUTION M0S09652 1R04:VT 2300 M0S05357 1L05 22/04/2011 11.58 Pagina 37

VAPORETTO EDITION - VAPORETTO EVOLUTION
38
E
EN
NG
GL
LI
IS
SH
H
mains.
5c. Unscrew anti-clockwise the patented safety
cap (A)
6c. Wait for a few minutes to allow the generator
tank to cool down.
7c. When cool proceed to carefully refill the tank as
described in paragraph 1 of the section “Prepa-
ration for Use”. If refilling the generator when
not completely cooled, pour only very small
quantities of water at each pouring into the
tank, so as to avoid spitting from the tank, and
cover exposed skin and face whilst filling
U
US SE E O OF F T TH HE E P PR RO OF FE ES SS SI IO ON NA AL L I IR RO ON N
(
(O OP PT TI IO ON NA AL L) )
Vaporetto can be quickly transformed into a hi-
ghly effective ironing system to make ironing
quick and easy. Simply connect the product to
the iron accessory for Vaporetto.
• mod. PFEU0013 - Professional Iron
• mod. PFEU0031 - Inox Iron
You may purchase the iron accessory at any
Polti service centre or from top home appliance
retailers.
1d. Connect the connector assembly at the end of
the iron hose (4) to the generator as shown in
point 2a of the section “Instructions for Use”.
Check the manufacturer’s label on the garment,
and interpret the symbol on the label as follows:
STEAM IRONING
2d. For STEAM ironing, turn the dial (S) and set the
iron temperature to its maximum travel on the
“COTTON-LINEN” steam position.
NB YOU MUST SET AT ITS MAXIMUM PO-
SITION, DO NOT SET AGAINST THE PIC-
TURE OF THE IRON ON THE DIAL (S).
Most types of fabric, other than delicates can
be STEAM ironed at this temperature, please
consult the garment manufacturer’s instruc-
tions on the label.
NB FABRIC INDICATIONS ON DIAL ARE
FOR DRY IRONING, NOT STEAM IRONING.
3d. Wait for a few minutes until the “Iron heating”
indicator light (V) goes out, to show that the so-
leplate of the iron has reached the required
temperature.
4d. Press the steam request button (R) to enable
the steam to come out. The steam flow will stop
when the button is released. After each filling,
when you first start to use the iron, a few drops
of water mixed with the steam may be emitted
(due to imperfect heat stabilisation). It is there-
fore advisable to direct the first jet of steam
onto a rag.
5d. The iron can also be used in a vertical position
e.g. for removing creases from curtain, clothing
etc.
6d. To obtain a continuous jet of steam move the
sliding button (U). The steam will continue to
come out even when the steam request button
(R) is released. To stop the steam flow move
the sliding button backwards (U).
NOTE: using the iron, it is advisable to adjust
the steam jet at medium output, or to do some
testing in order to find the position on (U) which
is most suitable to the fabric to be ironed.
RECOMMENDED TECHNIQUE for steam iron-
ing with the Polti iron is APPLY steam (button
R) on the upstroke, then release button R (so
no steam) for the backstroke, thus reclosing the
fibres, preventing oversteaming and wetness.
DRY IRONING
7d. If you need to DRY iron (ONLY) (NOT steam
ironing), press the accessory on/off switch (C)
and adjust the temperature of the iron by turn-
ing dial (S) to the temperature required for the
fabric (as shown on the dial).
ATTENTION: when dry ironing, be careful not
to press the steam request button (R), as hot
water could come out of the iron onto your gar-
ment and board.
I
IM MP PO OR RT TA AN NT T
• Do not leave the iron unattended whilst con-
nected to the mains.
• Iron only on heat resistant surfaces and on sur-
faces that allow the steam to escape e.g. MESH
ironing boards.
•ATTENTION: if you iron sitting down, do not
place your legs under the ironing board, the
steam can cause burns.
Steam ironing allowed
For dry ironing, set thermostat on •••
Steam ironing allowed
For dry ironing, set thermostat on ••
Check the fabric's resistance to steam
ironing or dry iron with thermostat set
on •
- do not iron
- steam ironing or treatment not al-
lowed
VT EDITION - VT EVOLUTION M0S09652 1R04:VT 2300 M0S05357 1L05 22/04/2011 11.58 Pagina 38

VAPORETTO EDITION - VAPORETTO EVOLUTION
39
E
EN
NG
GL
LI
IS
SH
H
T
TI IP PS S F FO OR R B BE ET TT TE ER R U UN NI IT T P PE ER RF FO OR RM MA AN NC CE E
WARNINGS
• For cleaning leather, wood or delicate fabrics
especially dralon, velvet and other pile surfaces,
consult the manufacturers instructions. Clean
only by using the hand gun at a safe distance to-
gether with a soft cloth and always do a test on a
non visible part of the item first or on a sample.
Allow the test area to dry completely before ob-
serving results and effects on surface or colour
before proceeding to clean further areas.
• For cleaning wood surfaces (furniture, doors
etc.) take great care as a too long application of
the steam could alter the waxed appearance, the
shine or the colour of the surfaces cleaned. We
therefore recommend you to apply the steam on
such surfaces only for brief periods or to clean
these surfaces using a cloth first held in the
steam.
• Please pay particular attention while cleaning
brick floors: a too long application of steam could
damage wax, brightness or colour of these surfa-
ces.
• For delicate surfaces (e.g. synthetic materials,
lacquered surfaces etc.) we recommend to
always cover the small brush with at least two
cloths to reduce the intensity of the steam, and
(on machines with steam variation control) with
the steam set at low level. Always test first on a
non-visible area, allow to dry thoroughly, and if
successful, be sure to use exactly the same tool,
technique, steam level and steam jet distance.
• If cleaning glass surfaces in particularly low tem-
peratures preheat the glass using the hand gun
from about 50 centimetres distance from the sur-
face to be cleaned.
• For care of your plants vaporise at a minimum di-
stance of 50 centimetres.
STEAM GUN (2)
The steam gun can be used directly on all spots re-
quiring a stronger, closer treatment without con-
necting the brushes. The more resistant the stain,
the closer you should hold the gun, the steam pres-
sure and temperature being higher at the source.
Always wipe with a dry cloth (or a slightly abrasive
sponge if the spot is a difficult one to remove) after
using the gun. Steam gun is particularly efficient at:
• breaking down rug and carpet stains before they
are treated with the large brush;
• cleaning stainless steel surfaces, panes, mirrors,
enamelled surfaces;
• cleaning hard-to-reach corners, such as stairs,
window sills, door posts;
• cleaning cooking top knobs, taps bases
• cleaning window shutters, heaters, car interiors;
• spraying plants (from a distance);
• removing odours and creases from clothes.
To reach higher points, the steam gun can be con-
nected to one or both extension tubes.
LARGE BRUSH (8)
To clean floors, put a clean, dry kitchen cloth under
the brush and swing back and forth without ap-
plying any pressure. Use the other side of the cloth
when the first one is impregnated with dirt. Use the
brush directly without the cloth on particularly dirty
or incrusted areas and in spaces between the tiles:
swing the brush sideways to detach the dirt. Highly
obstinate stains may require a steam gun treatment
before the brush and cloth are used (an old bath
towel is an ideal cloth) . The same procedures ap-
ply to ceilings and vertical surfaces, like wallpaper.
The cloth can easily be fastened around the brush
and held in place by the 4 clips (9) on the brush it-
self. Smooth cotton cloths are suitable for the treat-
ment of glass surfaces: fasten the cloth around the
brush then pass it over the window pane (or mirror)
to remove the greasy film. Finally, spray the surface
with the steam gun and wipe dry with a clean cloth.
In cold weather, window panes will require pre-hea-
ting with the steam gun (from a distance of 50 cm),
prior to the actual cleaning with the the brush. VA-
PORETTO is ideal for both syntetic and wool rugs
as well as for all types of carpets. Its use ensures
total hygiene, revives colours and restores the ori-
ginal brilliance of the pile. Drying occurs practically
at once. Fold a cotton cloth over 2 or 3 times (ac-
cording to the length and resistance of the pile) and
fasten it onto the brush. Move the brush rapidly in
all directions without applying any pressure. You
should avoid lingering in the same place, as this
may soak the area. Particularly dirty rugs may need
several treatments. Obstinate stains may require
the use of the steam gun (at a distance of 5-10 cm)
prior to treatment.
SMALL BRUSH (12)
The small brush is used whenever the big brush is
too big or not practical to be used.
The small brush can be connected directly to the
steam gun or to the extension tubes. The small
brush can be used on:
• furnishing fabrics (after testing on a small hidden
area)
• car linings (not pile surfaces), car windows (not
in freezing temperatures)
• small window surfaces
• tile and other small surfaces
To clean wood ( doorposts , floors etc) do not apply
VT EDITION - VT EVOLUTION M0S09652 1R04:VT 2300 M0S05357 1L05 22/04/2011 11.58 Pagina 39

VAPORETTO EDITION - VAPORETTO EVOLUTION
40
E
EN
NG
GL
LI
IS
SH
H
the steam directly but cover the brush (big or small)
with a doubled cotton cloth. For furniture cleaning,
direct the steam jet onto a dry cotton cloth, and
then start the cleaning. The warm moisture on the
cloth traps the dust, spots and the static electricity
so that the furniture stays clean longer.
120° STEAM NOZZLE (16) (*)
The 120° nozzle (which can be connected directly
to the gun or together with the extension tubes) al-
lows you to concentrate a powerful jet of steam to
otherwise inaccessible locations, such as radiators,
door posts, sills and shutters, as well as for sterili-
sing toilet bowls. It’s a very useful and indispensa-
ble tool.
WINDOW SQUEEGEE TOOL (18,19,20) (*)
DO NOT USE STEAM ON GLASS IN FREEZING
TEMPERATURES
The window squeegee tool allows you to clean ef-
fectively and rapidly all glass surfaces without using
detergents. Your glass will remain cleaner longer
thanks to the absence of the film normally left
behind by chemical cleaning products on which
new dust and grease can attach themselves.
Cleaning glass is done in two stages:
• Spray the steam onto the surface to be cleaned
to loosen the dirt (not touching with the blade).
• Pull the blade straight down the window surface
from top to bottom without applying the steam, to
take away the dirt.
• FOR EXTRA ABRASIVE ACTION AND MORE
EFFECTIVE REMOVAL OF DIRT, WE RECOM-
MEND USING THE BRISTLES SUPPLIED
WITH THE LARGE WINDOW CLEANING KIT
To clean especially large glass surfaces, attach the
window squeegee tool to the extension tubes.
(*) OPTIONAL for Vaporetto EDITION
C
CA AR RE E O OF F Y YO OU UR R V VA AP PO OR RE ET TT TO O
• Before attempting any maintenance operation,
make sure to always disconnect the appliance
from the mains
•Check periodically the condition of the
coloured washer connections on the central
connector (4). If necessary, replace the
washers with the spare washers supplied
(15).
Make the same check also on the connection
washers of the extension tubes (7) and of the
steam gun (2).
• To clean the body of the appliance, simply use a
moist cloth.
O
OP PT TI IO ON NA AL L A AC CC CE ES SS SO OR RI IE ES S
Vaporetto can be quickly transformed into a hi-
ghly effective ironing system to make ironing
quick and easy. Simply connect the product to
the iron accessory for Vaporetto.
• mod. PFEU0013 - Professional Iron
• mod. PFEU0031 - Inox Iron
You may purchase the iron accessory at any
Polti service centre or from top home appliance
retailers.
HIGH PRESSURE LANCE (21)
This accessory allows you to reach the most inac-
cessible places. Ideal for cleaning large radiators or
shutters etc.
TRIANGULAR BRUSH (22)
A new accessory whose shape allows access into
the most difficult corners.
LARGE ROUND BRUSH FOR 120° ACCESSORY
(23)
A very useful new accessory which allows the 120°
steam nozzle to be used for cleaning larger surfa-
ces.
WALLPAPER STRIPPER TOOL (24)
Specially designed for easy removal of wallpaper
without significant wetting.
VT EDITION - VT EVOLUTION M0S09652 1R04:VT 2300 M0S05357 1L05 22/04/2011 11.58 Pagina 40

VAPORETTO EDITION - VAPORETTO EVOLUTION
41
E
EN
NG
GL
LI
IS
SH
H
S
ST TE EA AM M D DI IS SI IN NF FE EC CT TO OR R
(
(m mo od d. . P PA AE EU U0 01 19 97 7) )
The Steam Disinfector is the sanitiser for household
surfaces that can connect up to your Vaporetto to
deliver steam at high temperatures (up to 180°C)
together with the sanitising solution HPMed. The
system allows for the elimination of the bacterial,
fungous and viral load on the surfaces and fabrics
to which it is applied in just a few seconds. This
helps prevent the risk of possible infections. When
surfaces and fabrics are sanitised using the Steam
Disinfector, the risk of contagion deriving from sur-
face contamination is drastically reduced.
The Steam Disinfector is a Polti exclusive and is
only available from the best electrical appliance
stores.
VT EDITION - VT EVOLUTION M0S09652 1R04:VT 2300 M0S05357 1L05 22/04/2011 11.58 Pagina 41
