Portfolio WL121MBKP User manual

ATTACH YOUR RECEIPT HERE
Serial Number Purchase Date
EB1597 1
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. -
5 p.m., EST, Friday.
ITEM #0206819
0208502
MODEL #WL121MBKP
WL120MWWP
WALL LANTERN
Français p. 10
Español p. 19
Lowes.com/
p
ortfolio
Portfolio® is a registered trademark
of LF, LLC. All Rights Reserved.

2
A
A Fixture 1
PART DESCRIPTION QUANTITY
PACKAGE CONTENTS
READ AND SAVE THESE INSTRUCTIONS.
DANGER
• For your protection and safety, carefully read and understand the information provided in this manual
completely before attempting to assemble, install or operate this product. Failure to do so could lead
to electrical shock, fire or other injuries that could be hazardous or even fatal.
F Fixture Cover 1
B Mounting Strap 1
C Decorative Nut 2
(preassembled to screw (D))
(preassembled to fixture (A))
F
E Nut 2
D Screw 2
(preassembled to mounting strap (B))
(preassembled to screw (D))
B
C
D
E
SAFETY INFORMATION
HARDWARE CONTENTS (shown actual size)
E3 Wire
Connector
Qty. 3
AA
Lowes.com/
p
ortfolio
G
G Shade 1

3
DANGER
• If using this light fixture in a WET of DAMP location, this light fixture must be connected to a supply
circuit that is protected by a Ground Fault Circuit Interrupter (GFCI) to reduce the risk of personal
injury, electrical shock or death.
• DO NOT connect this fixture to an electrical system that does not provide a means for
equipment grounding. Never use a fixture in a two-wire system that is not grounded. Installing
a fixture into an electrical system not having a proper grounding means could cause metal
parts of the fixture to carry electrical currents if any of the fixture wires, wire connections or
splices were to become broken, cut or loose during the mounting or normal operation of the
fixture. Under this condition, anyone coming in contact with the fixture would be subject to
electrical shock, which could cause serious injury or death.
• DO NOT connect the bare or green insulation fixture ground wire to the black (HOT)
current-carrying wire or the white neutral house wire. Connection of the bare or green fixture
ground wire to the black or white house wires may cause metal parts of the fixture to carry
electrical currents. Under this condition, anyone coming in contact with the fixture will receive
electrical shock, which could cause serious injury or death.
• DO NOT damage or cut the wire insulation (covering) during installation of fixture. DO NOT permit
wires to contact any surface having a sharp edge. To do so may damage or cut the wire insulation,
which could cause serious injury or death from electrical shock.
WARNING
• All electrical connections must be in agreement with local codes and ordinances, the National
Electric Code (NEC) and ANSI/NFPA 70-1999. Contact your municipal building department to learn
about your local codes, permits and/or inspections. Risk of fire – most dwellings built before 1985
have supply wire rated for 140°F. Consult a qualified electrician before installation.
• To avoid personal injury, the use of gloves may be necessary while handling fixture parts with
sharp edges.
• DO NOT suspend any fixture by the house wires.A fixture must always be mounted directly
to a mounting strap that is first attached to the outlet box. Wire connectors will not support the
weight of a fixture. Suspending a fixture by the house wires and wire connectors will result in the
fixture falling, with the possibility of personal injury and the danger of electrical shock or fire.
• To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this
light fixture are designed to accept only one 12-gauge house wire and two lead wires from the light
fixture. If your house wire is larger than 12-gauge or there is more than one house wire to connect
to the corresponding fixture lead wires, consult an electrician for the proper size wire connectors to
use.
• Failure to caulk fixture mounting surface with silicone weather sealant may result in water damage
in outlet box, which may cause electrical malfunction or electrical shock.
SAFETY INFORMATION
Lowes.com/
p
ortfolio

4
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 30 minutes
Tools Required for Assembly (not included): Flathead Screwdriver, Phillips Screwdriver, Wire
Strippers, Pliers, Wire Cutters, Safety Glasses, Stepladder, Electrical Tape, Silicone Weather Sealant
Helpful Tools (not included): A/C Tester Light, Do-It-Yourself Wiring Handbook, Soft Cloth
ASSEMBLY INSTRUCTIONS
ON
OFF
ON
OFF
Turn off circuit breakers and wall switch to
the fixture supply line leads.
DANGER: Failure to disconnect
power supply prior to installation may result
in serious injury or death.
1
1.
PREPARATION
CAUTION
• TURN OFF ELECTRICITY at main fuse box (or circuit breaker box) before beginning installation
by removing the fuse (or switching the circuit breaker off).
• If you are not sure the lighting system has a grounding means, DO NOT attempt to install this
fixture. Contact a qualified, licensed electrician for information regarding the proper grounding
methods as required by the local electrical code in your area.
• All fixtures must be mounted to an outlet box that is supported by the building structure.
• DO NOT use bulbs having a wattage greater than the maximum value stated on the fixture. The
use of bulbs with higher wattage than specified will increase temperatures and risk of fire.
•If a dimmer control switch is used with this fixture, obtain professional advice to determine the
correct type to use as well as the electrical rating required.
• To avoid water damage to fixture or possible electrical malfunction, install fixture at least 4 ft.
above the ground/floor.
SAFETY INFORMATION
Lowes.com/
p
ortfolio

5
ASSEMBLY INSTRUCTIONS
Attach mounting strap (B) to outlet box (not
included) using the existing outlet box
screws and washers. Make sure screw (D)
posts are level horizontally. This will help
ensure the fixture (A) is level when
attached. Tighten outlet box screws to
secure mounting strap (B).
CAUTION: Make sure the outlet box
can support 35 lbs. hanging weight. Use
metal outlet box; plastic outlet boxes are
not recommended.
Remove existing fixture and disconnect all
electrical wiring.
2.
Remove decorative nuts (C) from front of
fixture (A) in order to remove mounting
strap (B) from back of fixture (A).
3a.
2
Outlet Box
Outlet Box
Outlet Box
Screws and
Washers
3b
3a AB
D
C
C
B
Lowes.com/
p
ortfolio
3b.

6
ASSEMBLY INSTRUCTIONS
5a.
Hardware Used
E3 Wire Connector x 3
Adjust screws (D) to proper length by
screwing them completely into mounting strap
(B). Temporarily place fixture (A) over
mounting strap (B) to determine amount of
adjustment necessary for screws (D); screws
(D) should come through holes in fixture (A)
just enough so decorative nuts (C) will fit flush
against fixture (A) when mounted.
Once screws (D) are adjusted, use pliers (not
included) to tighten nuts (E) on screws (D)
until nuts (E) touch mounting strap (B).
4.
Unwrap BARE wire from BLACK and WHITE wires
on back of fixture (A). Prepare wire by stripping 3/4
inch of insulation from wire ends using wire
strippers (not included).
Connect WHITE wire from fixture (A) to WHITE
wire from outlet box using existing wire connector
or wire connector (AA). Connect BLACK wire from
fixture (A) to BLACK wire from outlet box using
existing wire connector or wire connector (AA).
Connect BARE/GREEN ground wire from outlet
box to BARE ground wire from fixture (A) using
wire connector (AA).
NOTE: Screw wire connectors (AA) on in a
clockwise direction.
WARNING: Never connect ground wire to
white or black power supply wires.
WARNING: To reduce the risk of fire,
electrical shock or personal injury, wire connectors
(AA) provided with this light fixture are designed to
accept only one 12-gauge house wire and two
lead wires from the light fixture. If your house wire
is larger than 12-gauge or there is more than one
house wire to connect to the corresponding fixture
lead wires, consult an electrician for the proper
size wire connectors to use.
4
4
5a
5b
4
Outlet Box
Outlet Box
WHITE WHITE
BLACK
BARE/GREEN
BLACK
B
A
C
DE
AA
AA
AA
AA
Lowes.com/
p
ortfolio
5b.

7
6
6.
ASSEMBLY INSTRUCTIONS
Wrap electrical tape (not included) around
each individual wire connector (AA) down
to the wire.
WARNING: Make sure no bare wire or
wire strands are visible after making
connections.
Push wire connectors (AA) gently into
outlet box. Carefully push excess wiring
into outlet box.
6
7. Align holes in fixture (A) with screws (D) on
mounting strap (B) and push fixture (A)
toward wall. Attach fixture (A) to mounting
strap (B) using the decorative nuts (C) that
were previously removed.
NOTE: Check fixture (A) with level (not
included), and adjust if necessary, before
tightening decorative nuts (C) completely.
6
4
4
7
C
A
D
AA
AA
AA
C
Lowes.com/
p
ortfolio
8. Slide shade (G) into fixture (A).
A
G
6
8

6
9. 9
Install one standard-base bulb (not included).
Use either a 60-watt max. incandescent or a
13-watt CFL.
CAUTION: When replacing bulb, please
allow bulb and fixture (A) to cool down before
touching them.
8
ASSEMBLY INSTRUCTIONS
10.
Restore power and test fixture (A).
If light does not function, please refer to
TROUBLESHOOTING on the following
page.
Bulb
6
11
11. After completing installation, caulk fixture
(A) mounting surface with silicone weather
sealant (not included).
A
6
10
Align the three tabs on fixture cover (F) with the
three slots on fixture (A) and twist fixture cover
(F) clockwise until it stops.
Tabs
Slots
F
A
A
Lowes.com/
p
ortfolio
WARNING: Failure to caulk fixture
mounting surface with silicone weather
sealant may result in water damage in outlet
box, which may cause electrical malfunction or
electrical shock.

9
CARE AND MAINTENANCE
The distributor warrants all of its lighting fixtures against defects in materials and workmanship for
five (5) years from the date of purchase. If within this period the product is found to be defective, take
a copy of the bill of sale as a proof of purchase and the product in its original carton to the place of
purchase. The distributor will, at its option, repair, replace or refund the purchase price to the
consumer. All costs of installation and removal of the fixture is the responsibility of the consumer. This
warranty does not cover fixtures becoming defective due to misuse, accidental damage or improper
handling and/or installation and specifically excludes liability for direct, incidental or consequential
damages, improper packaging of returned products and acts of God. As some states do not allow
exclusions of limitations on an implied warranty, the above exclusion and limitation may not apply.
This warranty gives you specific rights and you may also have other rights which may vary from state
to state.
WARRANTY
TROUBLESHOOTING
WARNING: Before beginning work, shut off the power supply to avoid electrical shock.
Bulb will not light.
Fuse blows out or
circuit breaker trips.
1. Bulb is burned out.
2. Power is OFF.
3. Faulty connection.
1. Crossed wires.
2. Power wire is grounding out. 1. Check wiring. 2. Check all connections.
1. Replace bulb.
2. Make sure power supply is ON.
3. Check wiring and all connections.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
•Shut off main power supply. Wipe fixture with a soft, damp cloth. Use window cleaner to clean
shade. Do not use an abrasive cleaner on shade or fixture.
Portfolio® is a registered trademark
of LF, LLC. All Rights Reserved.
Printed in China
