Introduction to the PM-6000
The PM-6000 is a handheld broadband power meter capable of de-
tecting forward and reflected power in a microwave radio system.
The meter is capable of detecting various types of wireless broad-
band modulation schemes in multiple frequency bands.
The meter was designed with the system integrator and installer in
mind. It is the perfect tool for the verification of transmitter power,
transmission line loss characteristics, and antenna performance.
Key features of the PM-6000:
• affordability
• portability
• use in the microwave bands (2.4, 3.5, 4.9, 5.3, 5.5, 5.7, 5.8, 6.0,
6.2, 6.3, 6.6, 6.7, and 6.8 GHz)
• verification of system installation

Using the PM-6000
The PM-6000 ships with a durable nylon case that is secured with
hook and loop flaps. The package is designed so that the meter can
be used while still in the nylon case. The flaps that cover and protect
the meter can be secured behind the unit while it is in use. This is
shown on the front cover of this manual.
Packaged with the meter is a male-to-male type “N” adapter (in the left
pocket), a 50 Ωtermination (right pocket), and a 5 W 10 dB attenu-
ator (in the pocket above the meter).
Most transmitters have a female type “N” output connector. The dou-
ble male adapter can be used to connect the meter directly to the
transmitter. The meter should always have a 50 Ωload on its output
when connected to a transmitter. Depending on the type of test, this
can be an antenna or the 50 Ωtermination included in the kit. The
10 dB attenuator is included for use when the device under test trans-
mits a signal higher than 20 dBm in amplitude. When using the 10 dB
attenuator it is a good idea to change the offset to “10 attn” in the
MODE settings. Note that the input to the 10 dB attenuator should
not exceed 33 dBm (2 W). If an attenuator with a higher power rating
is used, the input into the attenuator can be increased such that the
output of the attenuator does not exceed 23 dBm. The attenuator
offset should be set for “00 attn” when no attenuator is used.
The meter should always be inserted into the system in the forward
50 Ωtermination
5 W 10 dB attenuator
Male-to-male adapter
Page 2
PRAXSYM

power direction. Use the arrow labeled “FORWARD SIGNAL” as a
guide when connecting the meter.
Pressing and quickly releasing the ON-OFF button turns the meter
on. The meter will display a less than sign, “<”, along with the lowest
signal level the meter can measure in the selected band if it is not
connected to a source that is within the meter’s dynamic range. The
meter’s set up information will also be displayed.
Once the meter is connected to a source, and a 50 Ωtermination is
placed on the meter’s output connector, the forward and reflected
power can be measured. If the meter is not properly terminated the
forward power measurement may be inaccurate.
If the signal applied to the meter exceeds the measurement range,
the meter will display a great than sign, “>”, along with the highest
signal level the meter can measure in the selected band.
VSWR is automatically calculated and displayed according to the for-
ward and reflected measurements. The accuracy of the VSWR meas-
urement depends on several variables (forward and reflected power
levels, attenuation in the transmission line, etc).
Button Description
ON-OFF: Turns the unit ON or OFF. Unit also powers down five
minutes after last key depression. Powers up to the last
state that it was in.
SELECT: Depressing the SELECT button cycles through the op-
tions available in each mode. The arrow points to the
selected option. Once the desired option has been se
lected depress the mode button until the main screen
returns.
MODE: First push - Displays remaining battery life.
Second push - Allows selection of the unit of power
(dBm or mW) on the display.
Third push - Allows selection of the frequency band of
interest.
Fourth push - Allows selection of the inline attenuator
offset (0 dB, 10 dB, 20 dB, or 30 dB).
Fifth push - Exits MODE and returns to selected moni-
toring state (FWD or REFL.)
PM-6000
Page 3

Page 4
PRAXSYM
Depressing FWD or REFL also exits MODE at any
time.
FWD: Displays forward power and VSWR. A right-
pointing arrow in the upper right of the display
indicates the meter is measuring forward power.
The power measurement is displayed continu
ously. The VSWR is displayed for two seconds on
the bottom display line and then is replaced for
one second by the band indicator (“2.4G,” “3.5G,”
“4.9G,” “5.3G,” “5.5G,” “5.7G,” “5.8G,” “6.0G,”
“6.2G,” “6.3G,” “6.6G,” “6.7G,” or “6.8G”) and the
in-line attenuator setting (“00 attn,” “10 attn,” “20
attn”, or “30 attn”).
REFL: Similar in function to the FWD button, except it
displays the reflected power and shows a left-
pointing arrow in the upper right of the display.

Measuring Transmitter Power
The meter should be connected to the transmitter according to the
“FORWARD SIGNAL” label on the meter (see the illustration on the
opposite page). Depending on the gender of the type “N” connector
on the transmitter it may be necessary to use the double male type
“N” adapter. The meter should be terminated with the 50 Ωload in-
cluded in the kit.
Turn the PM-6000 on by pressing the ON-OFF button. Select the fre-
quency band of interest by pressing the MODE button until the fre-
quency list is shown. Use the SELECT button to scroll through, and
select the appropriate band. A small arrow will be displayed beside
the selected band.
Press the FWD button to read the forward power. A small right-
pointing arrow will appear in the upper right side of the display. This
is the amplitude of the signal (in dBm or mW, depending on the unit
selected in the MODE menu) in the forward direction.
The meter is designed to detect signals between 0 and 20 dBm in the
forward direction, and -20 to 17 dBm in the reflected. Damage can
occur to the meter if the forward power into the meter (without the
attenuator) exceeds 33 dBm.
Most broadband radio transmitters deliver less than 100 mW
(20 dBm). The 5 W 10 dB attenuator can be used for sources that are
between 20 and 30 dBm in amplitude. Remember to apply the ap-
propriate offset in the MODE setting (“10 attn” if the attenuator in-
cluded in the kit is used). If the output of the transmitter exceeds
33 dBm (2 W), an attenuator of the appropriate power rating and
insertion loss should be used to lower the signal to a level below 20
dBm. Using the MODE button an offset can be configured for attenu-
ators up to 30 dB. If an attenuator is not used, the offset should be
set to “00 attn”.
While the forward power is displayed constantly on the top line of
the display, the bottom line alternates between the VSWR and the
frequency band and offset settings.
NOTE: A good way to verify proper operation of the 50 Ωtermination
(included in the kit) is to make sure that a VSWR of 1.2:1 (or1.5:1 for
6 GHz ranges) is displayed when the meter is connected according to
the diagram on the opposite page. If the VSWR is not 1.2:1 the termi-
nation should be replaced.
PM-6000
Page 5

Page 6
PRAXSYM

Measuring Transmission Line Loss
Measure the forward power of the transmitter as shown on the previ-
ous pages. Use the 50 Ωtermination included in the kit as the load.
Make note of the forward power reading.
Disconnect the meter from the transmitter. NOTE: The transmitter
should always be powered down when there is no load present, or
when connecting the meter or transmission line. Connect the trans-
mission line directly to the transmitter with the proper amount of
attenuation (if necessary).
Move the PM-6000 to the opposite end of the transmission line. Con-
nect the meter as shown on the opposite page. Take another for-
ward power reading. Subtract this forward power reading from that
taken directly off the back of the transmitter. This is the amount of
signal lost due to attenuation in the transmission line and termina-
tions.
This value can be compared to the loss specifications of the transmis-
sion line and connectors to verify that the coax is properly termi-
nated.
PM-6000
Page 7

Page 8
PRAXSYM

Measuring VSWR of Antenna and Termina-
tions
To measure the VSWR of an antenna, place the meter into the system
between the transmission line and the antenna. Use the “FORWARD
SIGNAL” arrow on the meter to orient the meter properly. The arrow
will point towards the antenna when it is properly inserted. The dou-
ble male type “N” adapter can be used if the antenna has a female
type “N” connector.
Apply power to the transmitting device. The meter will display the
VSWR if the transmitter power is within the dynamic range of the
meter for the selected band. If the transmit power of the radio minus
the transmission line loss is below range, the meter will display a less
than sign, “<”, along with the lowest level the meter can measure.
Likewise, if the power at the meter is above its measurement range,
the meter will display a great than sign, “>”, along with the highest
level the meter can measure.
The best return loss* that the meter can read accurately in 2.4, 3.5,
4.9, 5.3, 5.5, 5.7, or 5.8 GHz is roughly 20.8 dB. This correlates to a
VSWR of roughly 1.2:1. Most antenna manufacturers in the license-
exempt broadband wireless market advertise a VSWR of 1.5:1.
Therefore, a defective or damaged antenna feed should be evident
using the PM-6000 as they will indicate a VSWR higher than 1.5:1.
It is possible to measure the VSWR (or return loss) of a transmission
line termination by placing the meter between it and the radio. It is
necessary to properly terminate the far-end termination with the 50
Ωtermination, and typically a type “N” double female adapter (not
included). These measurements are often only accurate for the ‘local’
terminations, or the terminations that are physically close to the me-
ter. The two-way transmission line loss may mask any reflections
further down the transmission line or at the far-end terminations (i.e.
make the VSWR look better than it really is). The problem becomes
more pronounced as the two-way loss of the transmission line ap-
proaches the dynamic range of the meter, which is 20 dB. Therefore,
it is best to have as little transmission line loss as possible when at-
tempting to measure return loss or VSWR of a termination with the
meter. A VSWR vs. return loss table is included in the Appendix.
NOTE: Reflections are usually due to bad terminations, kinks in the
transmission line, bend radii which are too tight, or moisture in the
line or connectors.
*Return loss is simply the forward power minus the reflected power.
PM-6000
Page 9

Page 10
PRAXSYM

Electrical Specifications
Frequency Range: 2.4G 2400-2484 MHz
3.5G 3400-3600 MHz
4.9G 4940-4990 MHz
5.3G 5250-5350 MHz
5.5G 5470-5598 MHz
5.7G 5598-5725 MHz
5.8G 5725-5850 MHz
6.0G 5925-6095 MHz
6.2G 6095-6260 MHz
6.3G 6260-6425 MHz
6.6G 6526-6650 MHz
6.7G 6650-6775 MHz
6.8G 6775-6875 MHz
Forward Power Measurement Range:
2.4, 3.5, 4,9, 5.3, 5.5, 5.7, and 5.8 GHz bands
0 dBm to 20 dBm (no inline attenuation)
10 dBm to 30 dBm (10 dB inline attenuator)
20 dBm to 40 dBm (20 dB inline attenuator)
30 dBm to 50 dBm (30 dB inline attenuator)
6.0, 6.2, 6.3, 6.6, 6.7, and 6.8 GHz bands
0 dBm to 23 dBm (no inline attenuation)
10 dBm to 33 dBm (10 dB inline attenuator)
20 dBm to 43 dBm (20 dB inline attenuator)
30 dBm to 53 dBm (30 dB inline attenuator)
Reflected Power Measurement Range:
2.4, 3.5, 4,9, 5.3, 5.5, 5.7, and 5.8 GHz bands
-20 dBm to 17 dBm (no inline attenuation)
-10 dBm to 27 dBm (10 dB inline attenuator)
0 dBm to 37 dBm (20 dB inline attenuator)
10 dBm to 47 dBm (30 dB inline attenuator)
6.0, 6.2, 6.3, 6.6, 6.7, and 6.8 GHz bands
-17 dBm to 20 dBm (no inline attenuation)
-7 dBm to 30 dBm (10 dB inline attenuator)
3 dBm to 40 dBm (20 dB inline attenuator)
13 dBm to 50dBm (30 dB inline attenuator)
Power Measurement Accuracy: +/- 0.5 dBm (with a 1.2:1 LOAD)
PM-6000
Page 11

Insertion Loss: 0.4 dB @ 2.4 GHz, 0.75 dB @ 5.8 GHz
VSWR Measurement Range:
2.4, 3.5, 4,9, 5.3, 5.5, 5.7, and 5.8 GHz bands
1.2:1 to 6.0:1
6.0, 6.2, 6.3, 6.6, 6.7, and 6.8 GHz bands
1.5:1 to 6.0:1
Environmental Specifications
Temperature Range: -10 to 50° C
Humidity: 0 to 95% RH non-condensing
Altitude: 0 to 15,000 feet
Mechanical Specifications
RF Connectors: Type “N” female (input, output)
Display: 2 lines by 8 characters, LCD – not illuminated
Keypad: Five keys – see definition on page 3
Enclosure: Black ABS
Power Source: 2 AA alkaline batteries – industrial grade
Size: 4.9 x 2.7 inches (excluding N connectors)
Weight: 10 ounces
Page 12
PRAXSYM

VSWR Return Loss (dB) Reflected Power (%) Transmiss. Loss (dB)
1 oo 0 0
1.01 46.1 0.005 0.0002
1.02 40.1 0.01 0.0005
1.03 36.6 0.022 0.0011
1.04 34.1 0.04 0.0018
1.05 32.3 0.06 0.0028
1.06 30.7 0.082 0.0039
1.07 29.4 0.116 0.0051
1.08 28.3 0.144 0.0066
1.09 27.3 0.184 0.0083
1.1 26.4 0.228 0.01
1.11 25.6 0.276 0.0118
1.12 24.9 0.324 0.0139
1.13 24.3 0.375 0.016
1.14 23.7 0.426 0.0185
1.15 23.1 0.488 0.0205
1.16 22.6 0.55 0.0235
1.17 22.1 0.615 0.026
1.18 21.6 0.682 0.0285
1.19 21.2 0.75 0.0318
1.2 20.8 0.816 0.0353
1.21 20.4 0.9 0.0391
1.22 20.1 0.98 0.0426
1.23 19.7 1.08 0.0455
1.24 19.4 1.15 0.049
1.25 19.1 1.23 0.053
1.26 18.8 1.34 0.056
1.27 18.5 1.43 0.06
1.28 18.2 1.52 0.064
1.29 17.9 1.62 0.068
1.3 17.68 1.71 0.073
1.31 17.4 1.81 0.078
1.32 17.2 1.91 0.083
1.33 17 2.02 0.087
1.34 16.8 2.13 0.092
1.35 16.53 2.23 0.096
1.36 16.3 2.33 0.101
1.37 16.1 2.44 0.106
Appendix - VSWR Table
PM-6000
Page 13

VSWR Return Loss (dB) Reflected Power (%) Transmiss. Loss (dB)
1.38 15.9 2.55 0.112
1.39 15.7 2.67 0.118
1.4 15.55 2.78 0.122
1.41 15.38 2.9 0.126
1.42 15.2 3.03 0.132
1.43 15.03 3.14 0.137
1.44 14.88 3.28 0.142
1.45 14.7 3.38 0.147
1.46 14.6 3.5 0.152
1.47 14.45 3.62 0.157
1.48 14.3 3.74 0.164
1.49 14.16 3.87 0.172
1.5 14 4 0.18
1.55 13.3 4.8 0.21
1.6 12.6 5.5 0.24
1.65 12.2 6.2 0.27
1.7 11.7 6.8 0.31
1.75 11.3 7.4 0.34
1.8 10.9 8.2 0.37
1.85 10.5 8.9 0.4
1.9 10.2 9.6 0.44
1.95 9.8 10.2 0.47
2 9.5 11 0.5
2.1 9 12.4 0.57
2.2 8.6 13.8 0.65
2.3 8.2 15.3 0.73
2.4 7.7 16.6 0.8
2.5 7.3 18 0.88
2.6 7 19.5 0.95
2.7 6.7 20.8 1.03
2.8 6.5 22.3 1.1
2.9 6.2 23.7 1.17
3 6 24.9 1.25
3.5 5.1 31 1.61
4 4.4 36 1.93
4.5 3.9 40.6 2.27
5 3.5 44.4 2.56
6 2.9 50.8 3.08
Page 14
PRAXSYM

PM-6000
Page 15
Notes

Page 16
PRAXSYM
Notes

121509 Rev -
P/N 900-000002-006
PRAXSYM
