Service Manual
Experience™ Series 800 line
StairClimbers™

Contents
Introduction 1
Service manual contents 1
Additional Service Documentation and Videos 2
Service Safety Guidelines 3
Safety guideline you need to know and follow: 3
General Information 5
Features 5
Model and Serial Numbers 7
Model Numbers 7
Serial Numbers 9
About 9
Serial Number Label Location 10
Orientation 10
Tools and Supplies 11
Specification Summary 12
Fastener Torque Specification 12
Calibration Specification 13
Bolt Grade Identification 13
Bolt Grade Markings Chart 13
Parts 14
Lubricants 14
Cleaning Procedure 15
Approved Cleaning Products 15
Cleaning Procedure 15
Power Requirements 16
Equipment Spacing Requirement 16
Operation Verification 18
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page ii

Operation Verification Tests 18
Standard Service Menus 22
About 22
Service Menu Access Codes 22
LED Consoles: P10, P30, P30i and P31 23
Touchscreen Consoles: P62, P80, and P82 23
How to Access the Standard Service Menus 24
P10, P30, P30i and P31 LED consoles 24
P80 touchscreen console 25
P62 and P82 touchscreen consoles 26
Diagnostics menu access 26
Touchscreen Display Calibration shortcut 26
Debug Information Report shortcut 27
Navigating the Service Menus 29
P10, P30, P30i and P31 LED consoles 29
P10, P30 and P31 consoles 29
P30i consoles 30
P80 and P82 touchscreen consoles 30
P62 touchscreen consoles 31
LED Console Standard Service Menus 32
Hardware Validation Diagnostics Tests Menu (51765761) 32
Club Settings Menu (5651565) 34
Information Display (65) 36
Touchscreen Console Standard Service Menus 39
Service Settings Menu ( (51765761) 39
About menu 41
43
Equipment Usage menu 43
Maintenance menu(1) 43
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page iii

System Settings menu 45
System Tests menu 49
Club Settings (5651565) 51
Information Display (65) 51
Adjustment Procedures 52
Available Adjustment Procedures 52
Drive Belt Tension Adjustment 53
About 53
About Sonic belt tension adjustment 53
Specialized Tools 54
Specifications 54
Service Videos 54
Procedure 54
Drive Chain Tension Adjustment 60
About 60
Specifications 60
Service Videos 60
Procedure 60
Step Chain Tension Adjustment 66
About 66
Specifications 66
Service Videos 67
Procedure 67
Gates® Carbon Drive™ Mobile App User Guide 71
Gates Carbon Drive™ Mobile App Download 71
Gates Instructional Video 72
Measurement Guidelines: 72
Specialized Tools 73
Procedure 73
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page iv

How to delete measurements: 76
Replacement Procedures 78
Available Replacement Procedures 78
Covers and Panels Replacement 79
About 79
Service Videos 81
Top Cover Replacement 81
Upper and Lower Forward Access Cover Replacement 88
Side Access Covers Replacement 92
Base Cover Replacement 95
Inner Panel Covers Replacement 98
Chain Rail Cover Replacement 103
Step Cover Replacement 108
Handlebar Replacement 111
Drip Shield Replacement 122
About 122
Procedure 122
Power Cord Replacement 125
About 125
Power Entry Switch Assy Replacement 126
About 126
Fuse Replacement 126
Wire Diagram 127
Procedure 128
Handlebar Replacement 131
About 131
Procedure 132
Handlebar HHHR Grips and Remote Stop & Speed Control Buttons Replace-
ment 142
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page v

About 142
Procedure 143
Right Handlebar HR Grip and Remote Stop Button Replacement 143
Left Handlebar HR Grip and Remote Speed Control Button Replace-
ment 146
LPCA (Lower PCA) Board Replacement 151
About 151
LPCA Interface Cable Connections 152
Procedure 154
Active Status Light "ASL" PCA board Replacement 161
About 161
Procedure 161
OBS Obstruction Sensor Replacement 169
About 169
Procedure 169
Drive Belt Replacement 175
About 175
Specifications 176
Service Videos 176
Procedure 176
Brake Assembly Replacement 182
About 182
Procedure 182
Drive Chain Replacement 190
About 190
Procedure 190
Input Drive Assy Replacement 195
About 195
Procedure 195
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page vi

Intermediate Sprocket & Speed Sensor Wheel Replacement 204
About 204
Special Replacement Parts 204
Procedure 204
Intermediate Sprocket & Speed Sensor Wheel Replacement 211
About 211
Special Replacement Parts 211
Procedure 211
Speed Sensor PCA board Replacement 218
About 218
Procedure 218
Stair Step Replacement 222
About 222
Special Replacement Parts 222
Procedure 222
Lower Bearing Rail Replacement 232
About 232
Procedure 232
Troubleshooting 240
About 240
Introduction to Troubleshooting 240
Basic Troubleshooting Steps 240
Validate the customer reported issue 241
Verify Input Power 241
Verify (reproduce) the customer issue 242
Verify the Club Settings 242
Verify service bulletin and software update incorporation 242
Verify console operation 243
Verify that there are no current active error codes 244
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page vii

Verify hardware validation diagnostic tests 244
Verify that there are no new error codes 245
Error Log & CPA Event Log 246
About 246
Error Log 247
Error Log 247
CPA Event Log 249
CPA Event Log 249
Active Status Light "ASL" 252
About 252
ASL Light Equipment Location 252
ASL Overview 253
ASL States 253
ASL Settings and Functions 254
Preventive Maintenance (PM) 258
About 258
PM Guides and Videos 258
Product PM Guides 258
PM Service Videos 259
System Wiring Diagram 260
System Wire Diagram 260
Left and Right Handlebar Cable Wire Diagram 261
Power Entry Assemble Wire Diagram 262
COMM Cable Wire Diagram 263
Product Literature & Videos 264
Service & Maintenance Documentation 264
Precor Websites 264
Service Videos 265
Parts 267
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page viii

About 267
Precor Connect Partner's website 267
Exploded View Diagrams and Parts List 270
Exploded View Diagram 271
Parts List - SCL800 280
Appendix A : Edition Information i
Edition i
Additional Documentation i
Copyright i
Appendix B : Notices and Safety ii
Trademarks ii
Intellectual Property ii
Warranty ii
Safety Notices iii
Service Safety Guidelines iii
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page ix

Introduction
Only Precor certified technicians are authorized to service Precor equipment. If you are not
a Precor certified servicer, you must not attempt to service any Precor product. Call your
dealer for service information
WARNING: This service documentation is for use by Precor certified servicer pro-
viders only. Personal injury can result from electrical shock and/or mechanical mov-
ing parts.
This service manual applies to the Experience™ Series 800 Line StairClimber™ including
the 120 VAC and 240 VAC models.
Model Configuration
SCL835 SCL800-21 base with P31 stairclimber model specific console, standard fea-
tures.
Service manual contents
The service manual contains information to service, repair, troubleshoot, and maintain the
machine base.
This manual does not include console service and repair information. Refer to the console
service manual for service and repair information. This service manual does include inform-
ation to use the standard service menus: Hardware Validation Diagnostic Tests, Information
Display, and Club Settings service menus.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 1
1 Introduction
Service manual contents

Additional Service Documentation and Videos
There are additional literature and video resources available that can help you to use, ser-
vice, troubleshoot, and repair the machine. Refer to Product Literature & Videos topic:
l"Product Literature & Videos" on page 264
See Also
"General Information" on page 5
"Operation Verification" on page 18
"Standard Service Menus" on page 22
"Adjustment Procedures" on page 52
"Replacement Procedures" on page 78
"Troubleshooting" on page 240
"Preventive Maintenance (PM)" on page 258
"System Wiring Diagram" on page 260
"Product Literature & Videos" on page 264
"Parts " on page 267
"Edition Information" on page i
"Service Safety Guidelines" on the facing page
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 2
1 Introduction
Additional Service Documentation and Videos

Service Safety Guidelines
WARNING: Only Precor certified servicers and technicians are permitted to ser-
vice Precor products. Personal injury can result from electrical shock and/or mech-
anical moving parts.
Review the following safety information prior to servicing the equipment. This safety inform-
ation will help to prevent personal injury or damage to the equipment while servicing the
equipment.
Safety guideline you need to know and follow:
lRead and follow all Warning notices to protect yourself from personal injury.
lRead and follow all Caution notices to prevent damage to the equipment.
lRead the owner’s manual and follow all operating instructions.
lOperate the equipment on a solid, level surface.
lVisually check the equipment before beginning service or maintenance operations. If
it is not completely assembled or is damaged in anyway, do not attempt to operate the
equipment.
lNever place liquids on any part of the equipment while performing service.
lTo prevent electrical shock, keep all electrical components away from water and
other liquids.
lDo not use accessory attachments that are not recommended by the manufacturer.
Non-OEM accessories can cause injuries.
lDo not stand or climb on the handlebars, display enclosure or cover.
lOn a self-powered unit, it will either be necessary to either equip the unit with the
optional external power supply or have an assistant pedal on the unit while voltage
measurements are being taken. Because of the danger of working on the unit while it
is in motion using the optional external power supply is strongly recommended.
lOn AMT1units when the stairarms are in motion; the generator will operate and pro-
duce potentially hazardous voltages even when the battery is disconnected.
lOn AMT units with Cardio Theater PVS2units will have external power supply and
coaxial cable routed through the bottom of the unit to the top of the display console.
Cord management must be maintained
lOn AMT units, a pinching hazard exists when the unit is operated. It is possible to ser-
iously pinch a finger. The AMT can be mechanically locked by inserting a screwdriver
through the primary sheave and frame.
1Adaptive Motion Trainer
2Personal Viewing System display.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 3
1 Introduction
Service Safety Guidelines

lOn treadmills, removing the hood exposes high voltage components and potentially
dangerous machinery. Exercise extreme caution when you perform maintenance pro-
cedures with the hood removed.
When servicing the equipment:
lDuring service operations you will be very close to moving machinery and voltage
bearing components:
oRemove jewelry (especially from ears and neck).
oTie up long hair.
oRemove neck ties.
oDo not wear loose clothing.
See Also
"Notices and Safety" on page ii
"Safety Notices" on page iii
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 4
1 Introduction
Service Safety Guidelines

General Information
The following information provides general equipment and service information that will help
you to use this manual to properly repair and maintain the treadmill.
Features
The equipment operating specifications.
Feature Specification
Console
P31 with optional PVS1(personal viewing system)
SCL800 model specific console:
The PAUSE key is replaced with a STOP key. Functions as a typ-
ical P31 PAUSE key plus as a manual emergency stair stop key.
Speed
(step rate)
Range: 20 - 165 SPM2(steps per minute)
Levels: 30 levels, 5 spm increments
Note: Numeric keypad: Can be used to set the speed to any value
between 20 - 165 spm.
StairClimber Metrics Steps/Min, Average Steps/Min, Total Steps, Floors (16 steps/-
floor), Elevation Gain, Step Rate Levels (1 - 30)
Manual Stop keys
There is a console STOP key and a handlebar Remote STOP key.
Pressing either STOP key initiates a pause and immediately slows
and stops the stairs.
Exception: Pressing the Stop key once during a workout starts the
Pause session, except for the fitness tests (WFI and CPAT),
where pressing Pause terminates the workout.
Auto Stop The stairs will stop when weight is removed from the stairs.
Drive System &
Speed Control
The drive system is comprised of a low friction, two-stage drive sys-
tem with a proven electro-mechanical EMS braking system. The
first "resistance brake" stage uses a belt drive system. The second
"stair step" drive stage uses a heavy duty 428 O-Ring motorcycle
chain drive system.
The step drive uses the weight of the user and a resistance brake
(EMS brake) to control the step speed. The minimum weight of the
1Personal Viewing System display.
2steps per minute
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 5
2 General Information
Features

Feature Specification
user is rated at 90 lbs (41 kgs) and the maximum weight is 400 lbs
(181.5 kgs).
The speed of the steps is controlled by the resistance brake (EMS
brake). The resistance brake keeps the stairs from going faster
than the console target SPM.
Dismounting and Offloading
• Dismounting – the user completely takes off their weight from
the Stairclimber, and the stairs slowly come to a stop.
• Offloading – the user takes some weight off the stairs, so there
is not enough weight to maintain the speed and the stairs slow
down. Some speed can still be maintained during an offload situ-
ation. When the exerciser returns more than 90 lbs on the stairs
(reloads), the speed will return to the target SPM.
During an offload situation the SPM display will show the target
speed if the SPM is within 10 SPM of target or will show the actual
speed if it is more than 10 SPM from the target speed. If the SPM
slows to much, the machine will go into pause mode.
If the user attempts to make SPM changes during an offload con-
dition, the target SPM will be set to the actual SPM of the unit. The
user will be unable to make target SPM changes until enough
weight has been applied to the stairs for the actual and target SPM
to be within 5 SPM. If a workout has preprogrammed SPM
changes, the target SPM will continue to change.
The rate of speed change that occurs with offloading and reload-
ing will be controlled at a linear rate and not immediately returned
to the previously set target SPM.
Drive Belt Replace-
ment
The drive belt must be replaced every 39 million steps of use.
A belt replacement notification message will show prior to reach-
ing the 39 million step interval. The machine will be disabled
"out-of-service" if the drive belt has not been replaced.
Obstruction Sensor
There is an Obstruction "OBS1" sensor located at the bottom of
the stairs. There is an IR2emitter sensor on the left side and an IR
receiver sensor on the right side. When an obstruction is detected
(blocked IR beam), the workout is paused, and an
OBSTRUCTION DETECTED" message is shown. The workout
will resume when the obstruction is removed.
1Obstruction sensor.
2Infrared Radiation: Electromagnetic radiation with wavelengths longer than those of visible
light. It is therefore invisible to the human eye. IR is generally understood to encompass
wavelengths from the nominal red edge of the visible spectrum around 700 nanometers (fre-
quency 430 THz), to 1 millimeter (300 GHz).
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 6
2 General Information
Features

Feature Specification
Heart Rate
Two Heart Rate sensor types:
• Touch Handheld Handlebar Heart Rate sensors (HHHR1).
• Telemetry equipped for wireless chest strap heart rate mon-
itoring.
Active Status Light Active Status Light "ASL2" enabled.
Alerts facility staff the operating condition of the machine.
Power Require-
ments
The StairClimber requires input power to operate the console, sys-
tem electronics and resistance brake system.
Input: 100 V-240 V, 50-60 Hz3, 2.0-0.8 Amps
Power cord: A locking power cord is used to prevent accidental
disconnect.
Stair Dimensions Step Height: 8" (20 cm)
Tread: 20.8" W x 11" D
Min and Max User
Weight
Minimum user weight: 90 lbs (41 kgs)
Maximum exerciser weight: 400 lbs (181 kgs)
Frame Multi-model common frame (TRM600, TRM700, TRM800).
Dimension/Weight
Weight: 375 lbs (170 kgs
Dimensions:
59" L x 31.7" W x 84" H (150 cm L x 81 cm W x 213 cm H )
Recommended Minimum Facility Ceiling Height:
9' 9" (3.0 m)
Model and Serial Numbers
Model and Serial Numbers
Model Numbers
The product model number is a six digit alphanumeric code "AAAXXX" containing the
product type, product line, console type, and feature level designator:
1Handheld Handlebar Heart Rate
2Active Status Light: Service and maintenance status light.
3The hertz (symbol: Hz) is the derived unit of frequency in the International System of Units
(SI) and is defined as one cycle per second.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 7
2 General Information
Model and Serial Numbers

l"AAA" - three alpha character PRODUCT TYPE designator
l"X" – 1 digit numeric PRODUCT LINE designator
l"X" – one digit numeric CONSOLE type designator
l"X" – one digit numeric FEATURE LEVEL designator
Example
Product model number: TRM1833
lTRM – Treadmill
l8 – Experience Line
l3 – P30 console
l3 – Fixed ramp
Product Model Number Designator Definitions
PRODUCT TYPE PRODUCT LINE CONSOLE FEATURE LEVEL
TRM: treadmill
EFX2: elliptical
AMT3: AMT
UBK4: Upright
RBK5: Recumbent
SCL6StairClimber
8-Experience
Premium
7-Experience Stand-
ard
6-Experience Good
6-Assurance Stand-
ard
4-Precision, Con-
sumer
2-Energy, Consumer
8-P80, P82
6-P62
4-R40
3-P30, P31
2-P20/R20
1-P10
7EFX: Mov Ramp/Cnvrt
Arms
5TRM: High Speed/De-
cline
AMT: Moving Step Height
EFX: Mov Ramp/Mov
Arms
RBK: Standard features
UBK: Standard features
SBK7Standard features
3TRM: Fixed Ramp
AMT: Fixed Step Height
EFX: Moving Ramp/Fixed
Arms
2EFX: Man Ramp/Mov
Arms
1EFX: Fixed Ramp/Moving
Arms
1Treadmill
2Elliptical Fitness Crosstrainer
3Adaptive Motion Trainer
4Upright Bike
5Recumbent Bike
6StairClimber
7Spinner Indoor Cycle
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 8
2 General Information
Model Numbers

Serial Numbers
About
The serial number uniquely identifies each machine. The serial number is an alphanumeric
code comprised of a four character model designator, a 1 letter build month code, a 2 digit
day built, a 2 digit year built and a four digit consecutive daily build number.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 9
2 General Information
Serial Numbers

Serial Number Label Location
Orientation
The equipment orientation (front, right, left, & back) is referenced to an exerciser standing
on the machine facing the console.
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 10
2 General Information
Orientation

Tools and Supplies
Tools and supplies required to complete the machine service and repair.
Tools
• US and Metric Hex Key set • Standard straight slot tip screw drive set
• US and Metric socket set • Philips tip screwdriver set
• Us and Metric wrench set • US & metric Allen wrench set
• Wire Cutters • Hex key socket set
• Rubber mallet • Pliers
• Tape measure /Straight edge ruler • Inner and outer snap ring pliers
• • Torque1Wrenches: 9 in lbs to 100 in - lbs
(83 ft-lbs)
• Master Link Clip Pliers • DVM2Multimeter
1Torque is a measure of the force that can cause an object to rotate about an axis. Bolt/nut
example: 5 NM torque is equivalent to 5 newton's of force applied one meter from the center
of the bolt, 6 ft-lb is equivalent to 6 lbs of force applied 1 foot away from the center of the
bolt.
2digital volt meter
Contact Precor Customer Support at [email protected] or 800.786.8404 with
any questions.
Page 11
2 General Information
Tools and Supplies
