Parasol Patio Heater
Mo el: HQH2000H
Please rea this instruction manual before operating
an keep safe for future reference.
ONE (1) YEAR LIMITED WARRANTY
Save This Warranty Information
HS (International) Ltd. G
uarantees this product free from defects in
materials and workmanship for a period of one (1) year.
Should this unit be operated under conditions other than those
recommended, at voltages other than the
voltage indicated on the unit, or
any attempts made to service or modify the unit, will render this
WARRANTY VOID. Th
e product you buy may sometimes differ slightly
from illustration.
This warranty is in addition to, and does not affect, your
statutory rights.
Should you have a problem with this product, please call our Help Desk
on: [phone]
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling
advice.

A. IMPORTANT SAFETY INSTRUCTIONS
Thank you for purchasing this patio heater. With the unpredictable
British weather this easy to use energy efficient patio heater can
be powered up to provide instant direct heat to your patio or deck
area all year round. This heater can also be used to provide
supplementary heat to a garage or workshop.
CAUTION: Rea an follow all instructions before operating this heater.
Failure to comply with these instructions may cause a fire, electrical
shocks or other injury to persons or property
WARNING
When using electrical appliances, basic safety precautions should
always be followed:
1. xtreme care should be taken when any product is used by, or near
children, and whenever the product is left operating and unattended.
2. Before operating the product remove the unit from its packaging and
check it is in good condition.
3. DO NOT let children play with the packaging, for example plastic
Bags, as there is a danger of suffocation.
4. DO NOT operate any product with a damaged cord or plug. If the
supply cord is damaged it must be replaced by the Manufacturer or
an authorised service centre in order to avoid a hazard.
5. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
6. DO NOT attempt to repair or adjust any electrical or mechanical
functions on this unit, as this may void warranty. Take the unit to a
qualified service engineer for inspection and repair.
7. Check the household voltage to ensure it matches the units rating
plate specification before operating.
8. DO NOT cover, or block any of the heater grilles.
9. Always unplug the appliance from the power source before
servicing or removing the unit.
10. Always use an RCD (Residual Current Device) socket or plug adaptor to
prevent an electrical shock due to accidental damage of the power cord or
appliance.
11. Always unplug the product when not in use. To disconnect from the
power supply, grip the plug and pull from the power socket. Never
pull by the cord.
12. DO NOT run power cord under carpeting, or cover with rugs or
runners.
13. Arrange the cord away from areas where it may be tripped over.
14. DO NOT insert or allow objects to enter any ventilation or exhaust
opening as this may damage the product and could cause an
electrical shock or fire.
15. DO NOT use the product in areas where petrol, paint, or other
flammable goods and objects are present.
16. Use the heater on a firmly mounted vertical pole (flat surface) or
ceiling mounted. Should the heater be tilted or fall over, the auto cut
off switch will activate.
17. The unit must be correctly installed according to the instructions.
18. When assembling, keep clear from any board or flammable
material.
19. Do not use the heater near bathtubs, wash areas or swimming
pools.
20. Do not use the heater near bathtubs, wash areas or swimming
pools.
21. Do not place on or near flammable things such as gas, petrol, paint,
curtains etc.
22. Do not put a cover on the grille of the heater head, during operation.
23. Do not leave unattended if the heater is switched on.
24. The unit must be placed at least 180cm from the floor level and at
least 60cm away from the parasol cloth or ceiling.
25. The unit is at high temperature during operation. It remains hot for a
period of time after power off. Potential danger would occur when
touching it during this period.
26. One or two dark points may exist on the surface of the heating
elements during the first few minutes after it is turned on. This is
quite normal, and will not affect the performance of the unit.
27. The unit must be securely grounded during operation.
28. A tilt switch is fitted inside the unit for safety purposes.
SAVE AND READ THESE IMPORTANT SAFETY
INSTRUCTIONS

B. BS PLUG WIRING
WARNING: This heater is equipped with moulded UK plug from
manufacturing. It is not recommended to use re-wire plug in this heater.
Please consult with your local services. We’re recommend to use splash
proof socket if re-wire plug is replaced.
Wiring Instructions: Shoul it be necessary to change the plug please
note the wires in the mains lea are coloure in accor ance with the
following co e :
BLUE - NEUTRAL
BROWN - LIVE
GREEN AND YELLOW - EARTH
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying he terminals in your plug,
proceed as follows:
1. The BLUE wire is the NEUTRAL and must be connected to the terminal,
which is marked with the letter N or coloured BLACK.
2. The BROWN wire is the LIVE and must be connected to the terminal,
which is marked with the letter L or coloured RED.
3. The GREEN/YELLOW is the EARTH and must be connected to the
terminal which is marked with the letter E or or coloured GREEN OR
GREEN/YELLOW.
4. Always ensure that the cord grip is positioned and fastened correctly.
If a 13A (BS 1363) fused plug is used it must be fitted with a 13A fuse. If in
doubt consult a qualified electrician.
Wiring for a 13Amp Plug (BS1363)
Please note. The arth Terminal is marked with the letter E or arth Symbol
C. TECHNICAL SPECIFICATION
Model No. HQH2000H
Voltage 220-240V~
Frequency 50Hz
Wattage 2000-2200W
Net Weight 3.9kg
Gross Weight 4.95kg
For replacement heater tubes please contact the Prem-I-Air Spares
Department on 0870 744 0161 or email: [email protected]
D. PARTS DESCRIPTION
1 Heating Tube 2 Pole clamp screw 3 Power switches
4 Fold lock button 5 Cool touch fence 6 Pole clamp
7 nd handle 8 Mounting core 9 Aluminium guard
Note :
- Tip over switch is built inside of product.
- Auto power cut-out is built in each heater’s arm. It is automatically shut-off
if arm is not fully opened.
IP24

E. ASSEMBLY INSTRUCTIONS
Unpack the electric parasol heater and make sure that all items are
complete.
Step 1: Slide the pole clamp part (B) from mounting core. Place the
Heater mounting core (A) on a Pole with diameter between 35-60 mm.
Step 2: Slip the pole clamp part (B) and fit it to the mounting core (A)
from the bottom up.
Step 3: Fasten the pole clamp screw until the pole & firmly tightened
with the parasol heater..
Step 4: Before operate the heater, please ensure that all three arms are
fully lifted and secured. To do this, lift each arm by holding the small
end handle and lift until a ‘click’ is heard and the arm is horizontal and
fully locked.
Step 1 Step 2 Step 3
Step 4a Step 4b Step 5
Step 5: When you have finished
using the heater, allow each of the
arms to cool down sufficiently
before touching. Beware, as these
will still be hot for a while after
operation. Then, whilst holding the
arm with one hand, press the fold
lock button as shown in the
diagram with the other hand and
gently lower each arm to a vertical
position.
IMPORTANT: DO NOT ATT MPT TO FORC TH ARMS DOWN
WITHOUT PR SSING TH FOLD LO K BUTTON AS THIS COULD
R SULT IN S RIOUS DAMAG .
F. OPERATING INSTRUCTIONS
Check the household voltage to ensure it matches the units rating plate
specification before operating. Plug into a power supply (220-240V~
50Hz) that is located in a safe, dry area.
1. The switch on the heater centre piece is used to control the
heating tubes ON/OFF. Press ‘I’ on to turn single tube ON; press
‘II’ on to turn two tubes ON. Press ‘I” &”II” on to turn three tubes
ON.
Note: ach heating tube is 650W.
2. Although this electric parasol heater is splash proof, do not use
when raining or in wet conditions.
3. Always unplug from the electrical outlet, when the heater is not in
use.
G. MAINTENANCE
WARNING: Unplug, disconnect the heater from the power supply and
remove from the parasol pole (reverse step from ASS MBLY
INSTRUCTION), before attempting any maintenance work.
• Dampen a clean cloth with water and use on the exterior of the unit
to remove any dust or dirt.
• Never use detergents, corrosive elements, solvents or any
chemicals to clean this product.
