Owner’s Manual
YOU MUST READ THE ENTIRE
CONTENTS OF THIS OWNERS
MANUAL BEFORE USING
YOUR POWER CHAIR.

2 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
SAFETY GUIDELINES
Copyright © 2003
Pride Mobility Products Corp.
INFMANU2090
Please read and follow all instructions in this owners manual before attempting to operate your power chair for the first
time. If there is anything in this manual you do not understand or if you require additional assistance for set-up contact
your authorized Pride provider.
Using your Pride product safely depends upon your diligence in following the warnings cautions and instructions in this
owners manual. Using your Pride product safely also depends upon your own good judgement and/or common sense as
well as that of your provider caregiver and/or healthcare professional. Pride is not responsible for injuries and/or damage
resulting from any persons failure to follow the warnings cautions and instructions in this owners manual. Pride is not
responsible for injuries and/or damage resulting from any persons failure to exercise good judgement and/or common
sense.
The symbols below are used throughout this owners manual to identify warnings and cautions. It is very important for you
to read and understand them completely.
WARNING! Failure to heed the warnings in this owners manual may result in personal injury.
CAU ION! Failure to heed the cautions in this owners manual may result in damage to your power chair.

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 3
I. INTRODUCTION ................................................................................................................................4
II. SAFETY ................................................................................................................................................. 6
III. EMI/RFI ................................................................................................................................................ 12
IV. THE JAZZY 1133 ............................................................................................................................ 14
V. DISASSEMBLY ................................................................................................................................. 19
VI. COMFORT ADJUSTMENTS ........................................................................................................ 22
VII. BATTERIES AND CHARGING.................................................................................................... 27
VIII.OPERATION ....................................................................................................................................... 31
IX. CARE AND MAINTENANCE ....................................................................................................... 35
X. OPTIONAL ACCESSORIES ......................................................................................................... 41
XI. WARRANTY ....................................................................................................................................... 42
CONTENTS

4 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
INTRODUCTION
Welcome to Pride Mobility Products Corporation (Pride). Congratulations on the purchase of your new Jazzy
Power Chair. The Jazzy design combines the most advanced state-of-the-art components with modern attractive
styling. We are certain that the design features and trouble-free operation of your new power chair will add conve-
nience to your daily living.
At Pride your safety is important to us. Please read and follow all of the instructions in this manual before you
attempt to operate your power chair for the first time. These instructions were produced for your benefit. Your
understanding of these instructions is essential for the safe operation of your new power chair.
Pride is not liable for damage to property or personal injury arising out of unsafe use of a power chair. Pride is also
not liable for any property damage or personal injury arising out of the failure of any person and/or user to following the
instructions and recommendations set forth in this manual or any other instructions or recommendations contained in other
Jazzy related literature issued by Pride or contained on the power chair itself.
This owners manual is compiled from the latest specifications and product information available at the time of
publication. We reserve the right to make changes as they become necessary. Any changes to our products may
cause slight variations between the illustrations and explanations in this manual and the product you have pur-
chased.
If you experience any problems with your power chair that you are unable to solve or if you do not feel capable of
safely following any of the instructions and/or recommendations as contained in this manual please contact your
authorized Pride provider for assistance.
Once you understand how to operate and take care of your power chair we are certain that it will give you years of
trouble-free service and enjoyment.
Information Exchange
We want to hear your questions comments and suggestions about this manual. We would also like to hear about
the safety and reliability of your new power chair and about the service you received from your authorized Pride
provider.
Please notify us of any change of address so we can keep you apprised of important information about safety new
products and new options that can increase your ability to use and enjoy your power chair. Please feel free to
contact us at the address below:
Pride Mobility Products Corporation
Attn: Customer Care Department
182 Susquehanna Avenue
Exeter PA 18643-2694
[e-mail]
800-424-8205
I. INTRODUCTION

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 5
Pride Owners Club
As an owner of a Pride product you are invited to register your products warranty and enroll in the Pride Owners
Club. You may do so by filling out and returning your enclosed registration card or by visiting Prides web site at
www.pridemobility.com. As a registered member each time you visit our site you will have access to the most
interactive and honest educational venue available today for people with mobility needs their families and friends.
From our home page select Owners Club to enter a page dedicated to current and potential Pride product own-
ers. You will gain access to interviews stories recreation ideas daily living tips product and funding information
and interactive message boards. These message boards invited you to communicate with other Pride customers as
well as Pride representatives who are available to assist you with any questions or concerns you may have. You will
receive a free gift simply for registering with the Pride Owners Club.
My Authorized Pride Provider Is:
Name:_______________________________________________________________________________
Address:_____________________________________________________________________________
Phone Number:________________________________________________________________________
Quick Reference Information:
Purchase Date:________________________________________________________________________
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.
I. INTRODUCTION

6 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
II. SAFETY
SAFETY
WARNING! Do not operate your new power chair for the first time without completely reading and
understanding this owners manual.
Your power chair is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an extensive
variety of products to best fit the individual needs of the power chair user. Please be aware that the final selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user who is
capable of making such a decision and his/her healthcare professional (i.e. medical doctor physical therapist etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted the power chair
to the user and has assisted the prescribing healthcare professional and/or the authorized Pride provider in the instruction
process for the use of the product.
There are certain situations including some medical conditions where the power chair user will need to practice operating
the power chair in the presence of a trained attendant. A trained attendant can be defined as a family member or care
professional specially trained in assisting a power chair user in various daily living activities.
As you begin using your power chair during daily activities you will probably encounter situations in which you will need
some practice. Simply take your time and you will soon be in full and confident control as you maneuver through doorways
on and off of elevators up and down ramps and over moderate terrain.
Below are some precautions tips and other safety considerations that will help the user become accustomed to operating
the power chair safely.
Modifications
Pride has designed and engineered your power chair to provide maximum mobility and utility. A wide range of accessories
is available from your authorized Pride provider to further customize your power chair to better suit your needs and/or
preferences. However under no circumstances should you modify add remove or disable any feature part or function
of your power chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Get to know the feel of your power chair and its capabilities. Pride recommends that you perform a safety check before
each use to make sure your power chair operates smoothly and safely. See IX. Care and Maintenance.
Perform the following inspections prior to using your power chair:
nCheck for proper tire inflation. Maintain 30-35 psi in each tire (if equipped with pneumatic tires).
nCheck all electrical connections. Make sure they are tight and not corroded.
nCheck all controller connections to the electronics tray. Make sure they are secured properly.
nCheck the brakes. See IX. Care and Maintenance.
nCheck battery charge. See VII. Batteries and Charging.
NOTE: If you discover a problem, contact your authorized ride provider for assistance.

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 7
II. SAFETY
eight Limitations
Your power chair is rated for a maximum weight capacity. Please refer to the specifications table for this limit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
If your power chair is equipped with pneumatic tires you should check or have the air pressure checked at least once a
week. Proper inflation pressures will prolong the life of your tires and help ensure the smooth operation of your power
chair.
WARNING! It is important that 30-35 psi tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 30-35 psi tire pressure in pneumatic tires at all
times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your Jazzy.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire and/or personal injury.
Incline Information
More and more buildings have ramps with specified degrees of inclination designed for easy and safe access. Some ramps
may have turning switchbacks (180-degree turns) that require you to have good cornering skills on your power chair.
nProceed with extreme caution as you approach the downgrade of a ramp or other incline.
nTake wide swings with your power chairs front wheels around any tight corners. If you do that the power
chairs rear wheels will follow a wide arc not cut the corner short and not bump into or get hung up on any
railing corners.
nWhen driving down a ramp keep the power chairs speed adjustment set to the slowest speed setting to ensure
a safely controlled descent. See VIII. Operation.
nAvoid sudden stops and starts.
When climbing an incline try to keep your power chair moving. If you must stop start up again slowly and then accelerate
cautiously. When driving down an incline set your power chair to the slowest setting and drive in the forward direction
only. If your power chair starts to move down the incline faster than you anticipated or desired allow it to come to a
complete stop by releasing the joystick then push the joystick forward slightly to ensure a safely controlled descent.

8 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
II. SAFETY
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. his greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backwards. his may result in personal injury.
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated in
figure 1, do not, under any circumstances, exceed the incline guidelines or any other specifications
presented in this manual. Doing so could cause instability in your power chair, resulting in personal injury
and/or damage to your power chair.
In compliance with the Americans with Disabilities Act of 1990 all handicap public access ramps are required to have a
maximum slope of 5°. Therefore Pride recommends that the maximum slope of an incline you attempt to safely ascend or
descend on your power chair does not exceed 5°. See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° may put your power chair in
an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Your power chair is equipped with two powerful brake systems:
1. Regenerative  uses electricity to rapidly slow the vehicle when the joystick returns to the center/stop position.
2. Disc Park Brake  activates mechanically after regenerative braking slows the vehicle to near stop or when
power is removed from the system for any reason.
Cornering Information
While your power chair is equipped with rear caster wheels in back and anti-tip wheels in front excessively high cornering
speeds can still create the possibility of tipping. Factors which affect the possibility of tipping include but are not limited to:
cornering speed steering angle (how sharply you are turning) uneven road surfaces inclined road surfaces riding from an
area of low traction to an area of high traction (such as passing from a grassy area to a paved area  especially at high
speed while turning) and abrupt directional changes. High cornering speeds are not recommended. If you feel that you
may tip over in a corner reduce your speed and steering angle (i.e. lessen the sharpness of the turn) to prevent your power
chair from tipping.
Figure 1. Maximum Safe Angle (Ascending and Descending)

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 9
II. SAFETY
WARNING! When cornering sharply, reduce your speed. his greatly reduces the possibility of a
tip or fall. o avoid personal injury and/or property damage, always exercise common sense when
cornering.
Outdoor Driving Surfaces
Your power chair is designed to provide optimum stability under normal driving conditionsdry level surfaces composed
of concrete blacktop or asphalt. However Pride recognizes that there will be times when you will encounter other surface
types. For this reason your power chair is designed to perform admirably on packed soil grass and gravel. Feel free to
use your power chair safely on lawns and in park areas.
nReduce your power chairs speed when driving on uneven terrain and/or soft surfaces.
nAvoid tall grass that can entangle the running gear.
nAvoid loosely packed gravel and sand.
nIf you feel unsure about a driving surface avoid that surface.
Freewheel Mode
Your power chair is equipped with a manual freewheel lever to allow for manual maneuverability by a trained attendant.
For more information about how to place your power chair into and out of freewheel mode see IV. The Jazzy 1133.
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. he chair could
roll uncontrollably on its own, causing personal injury.
Stationary Obstacles (Steps, Curbs, etc.)
Proceed with extreme caution when driving near raised surfaces unprotected ledges and/or drop-offs (curbs porches
stairs etc.). The correct method for approaching a curb is illustrated in figure 2.
Figure 2. Curb Approach (Correct and Incorrect)

10 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
II. SAFETY
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than two inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backward down any step, curb, or
other obstacle. his may cause the power chair to tip and cause personal injury.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
Stairs and Escalators
Power chairs are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.
Doors
nDetermine if the door opens toward or away from you.
nDrive your power chair gently and slowly forward to push the door open. Or drive your power chair gently
and slowly backward to pull the door open.
Elevators
Modern elevators have a door edge safety mechanism that when pushed reopens the elevator door(s).
nIf you are in the doorway of an elevator when the door(s) begin to close push on the rubber door edge or
allow the rubber door edge to contact the power chair and the door will reopen.
nUse care that pocketbooks packages or power chair accessories do not become caught in elevator doors.
EMI & RFI
Laboratory tests performed by the Food and Drug Administration (FDA) have shown that radio waves can cause unin-
tended motion of electric mobility vehicles. Radio waves are a form of electromagnetic energy (EM). When EM adversely
affects the operation of an electronic device it is called Electromagnetic Interference (EMI) or Radio Frequency Interfer-
ence (RFI). For more information see III. EMI/RFI.
Lift/Elevation Products
If you will be traveling with your power chair you may find it necessary to use a lift/elevation product to aid in transporta-
tion. Pride recommends that you closely review the instructions specifications and safety information set forth by the
manufacturer of the lift/elevation product before using that product.
Motor Vehicle Transport
Currently there are no standards approved for tie-down systems in a moving vehicle of any type to transport a person
while seated in a power chair.

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 11
II. SAFETY
Transfers
Transferring onto and off of your power chair requires a good sense of balance. Always have an attendant or healthcare
professional present while learning to properly transfer yourself.
To eliminate the possibility of injury Pride recommends that you or a trained attendant perform the following tasks before
attempting a transfer:
nTurn the power off. See VIII. Operation.
nEnsure your power chair is not in freewheel mode. See IV. The Jazzy 1133.
nTurn both caster wheels toward the transfer destination to improve power chair stability during transfer.
nMake sure both armrests are flipped up or removed from your power chair.
nFlip the footrest up or move the leg rests aside; this will help to keep your feet from getting caught on the
footrest or the leg rests during the transfer.
nReduce the distance between your power chair and the object you are transferring onto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the footrest. Such use may cause the power chair
to tip and cause personal injury.
Positioning Belts
Your authorized Pride provider therapist(s) and other healthcare professionals are responsible for determining your re-
quirement for a positioning belt in order to operate your power chair safely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! he positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your Jazzy suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Inclement eather Precautions
WARNING! Pride recommends that you do not operate your power chair in icy or slippery conditions
or on salted surfaces (i.e., walks or roads). Such use may adversely affect the performance and
safety of your power chair, resulting in an accident and personal injury.
WARNING! Do not expose your power chair to any type of moisture at any time (rain, snow, mist,
or wash). Such exposure can damage your power chair. Never operate your power chair if it has
been exposed to moisture until it has dried thoroughly.

12 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
Reaching and Bending
Never reach lean or bend while driving your power chair. If it is absolutely necessary to reach lean or bend while seated
on your power chair it is important to maintain a stable center of gravity and keep the power chair from tipping. Pride
recommends that the power chair user determine his/her personal limitations and practice bending and reaching in the
presence of a qualified healthcare professional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by reaching
down between your knees. Movements such as these may change your center of gravity and the weight
distribution of the power chair. his may cause your power chair to tip, possibly resulting in personal injury.
Keep your hands away from the tires when driving.
Batteries
In addition to following the warnings below be sure to comply with all other battery handling information. For more
information about your power chairs batteries see VII. Batteries and Charging.
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that much
weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds. Wash
hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging a frozen
battery may result in personal injury and/or damage to the battery.
Preventing Unintended movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time, turn off
the power. his will prevent unexpected motion from inadvertent joystick contact. his will also eliminate
the possibility of unintended chair movement from electromagnetic (EM) sources. Failure to do so may
result in personal injury.
Prescription Drugs/Physical Limitations
Users must exercise care and common sense when operating a power chair. This includes awareness of safety issues when
taking prescribed or over-the-counter drugs or when the user has specific physical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or if you
have certain physical limitations. Some medications and limitations may impair your ability to operate your
power chair in a safe manner.
Alcohol
The power chair user must exercise care and common sense when operating his/her power chair. This includes awareness
of safety issues while under the influence of alcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this may impair
your ability to operate your power chair in a safe manner.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal injury and/
or damage to the power chair may result.
II. SAFETY

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 13
EMI/RFI
Laboratory tests performed by the Food and Drug Administration (FDA) have shown that radio waves can cause
unintended motion of power chairs. Radio waves are a form of electromagnetic energy. When this energy adversely
affects the operation of an electronic device it is called Electromagnetic Interference (EMI) or Radio Frequency
Interference (RFI).
WARNING! Radio waves may interfere with the control of power chairs.
FREQUENTLY ASKED QUESTIONS FAQS)
The following FAQs summarize what you should know about EMI/RFI. Use this information to minimize the risk
that EMI/RFI will affect your power chair.
here do radio waves come from?
Radio waves are emitted from the antennas of cellular phones mobile two-way radios (such as walkie-talkies)
radio stations TV stations amateur radio (HAM) transmitters wireless computer links microwave sources and
paging transmitters. Radio waves are a form of electromagnetic energy. Because electromagnetic energy is more
intense closer to the transmitting antenna (source of emission) the electromagnetic energy fields from two-way
radios are of special concern to power chair users.
If my power chair is affected by EMI/RFI, what kind of motion should I expect?
This is hard to predict. It would depend on a number of factors:
nStrength of the radio waves
nConstruction of the power chair
nPosition of the power chair (whether it is on level ground or on an incline)
nWhether or not the power chair is in motion
An affected power chairs movement can be erratic. It may move by itself or come to a sudden stop. Furthermore
it is possible for EMI/RFI to unexpectedly release the brakes on a power chair. Some intense sources of EMI/RFI
can even damage the control system of the Jazzy.
Is there any way to know for sure whether radio waves are responsible for the unintended motion of my
power chair?
Unfortunately interference from radio wave sources may be difficult to recognize since the signals from these
sources are invisible and may be intermittent. However the FDA recommends that you report all incidents of
unintended motion or brake release to the power chair manufacturer and if possible note whether there was a radio
wave source nearby at the time of the incident.
Has anyone been hurt from erratic, unintended motion of power chairs?
The FDA has reports of injuries that resulted from the apparent uncontrolled motion of power chairs. However it
is unclear how many of these incidents were actually caused by radio wave interference.
III. EMI/RFI

14 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
Are all power chairs susceptible to EMI/RFI?
Each make and model of chair differs in its ability to resist electromagnetic interference. That is each has a particu-
lar level of immunity to interference measured in volts per meter (V/m). A higher immunity level offers greater
protection. In other words a power chair with a high immunity level is less likely to be affected by a strong radio
source than one with a low immunity level.
hat is the FDA doing about the problem?
The FDA has written to the manufacturers of power chairs and requested that they test their new products to be sure
that they provide a reasonable degree of immunity against EMI/RFI. The letter states that power chairs should have
an immunity of at least 20 V/m. This provides a reasonable degree of protection against the common sources of
EMI/RFI.
The FDA has also requested that these manufacturers clearly label their products with the immunity level or state
that the immunity level is not known. The labeling and informational material supplied with the power chair must
explain what the immunity level means and the labeling or informational material must warn users about the
possibility of EMI/RFI and how to avoid it. In addition the FDA has recommended that manufacturers establish an
educational program to inform users of power chairs and their caregivers about the problems associated with
EMI/RFI and the actions they can take to minimize the risk.
hat can I do to find out if my power chair is likely to be affected by EMI/RFI?
If youve had your power chair for a long time and havent experienced any unintended motion it is not likely that
you will have problems in the future. But it is always possible that problems could arise if you are close to a source
of radio waves. Therefore it is very important to be alert to this possibility. The Jazzy meets or exceeds an immu-
nity level of at least 20 V/m.
hat can I do to reduce the risk that my power chair could be affected by EMI/RFI?
Here are some precautions you can take:
nDo not turn on or use hand-held personal communications devices such as citizens band (CB) radios and
cellular phones while the power chair is on.
nBe aware of nearby transmitters such as radio or TV stations and hand-held or mobile two-way radios and
try not to come close to them. For example if you are in a power chair with an immunity level of 20 V/m you
should remain at least three feet from a hand-held two-way radio and ten feet from a mobile two-way radio.
nBe aware that adding accessories and/or components or modifying the power chair may make it more suscep-
tible to interference from radio wave sources. There is no easy way to evaluate their effect upon the overall
immunity of the power chair.
hat should I do if my power chair moves unexpectedly?
If unintended motion or brake release occurs turn the power chair off as soon as it is safe to do so. Call Pride at
800-424-8205 to report the incident.
III. EMI/RFI

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 15
THE JAZZY 1133
The Jazzy 1133 has three main assemblies: the power base the seat assembly and the controller assembly. See
figures 3 4 5 and 6. Information on the standard seat assembly is in VI. Comfort Adjustments. Information on
the controller assembly is in VIII. Operation.
Figure 3. The Jazzy 1133
SEATBACK
ARMRESTS
CONTROLLER
ASSEMBLY
BODY SHROUD
ANTI-TIP WHEELS
DRIVE WHEEL
CASTER WHEEL
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOTREST
SEAT BASE
IV. THE JAZZY 1133
SEATBACK
RELEASE LEVER

16 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
IV. THE JAZZY 1133
JAZZY 1133 SPECIFICATIONS
Suspension: Full suspension with Active-Trac
Drive Wheels: 14 in., pneumatic (solid tires are optional
Caster Wheels: 8 in., solid, rear articulating
Anti-tip Wheels: 6 in., solid, front mounted
Maximum Speed: Programmable up to 5 mph
Brakes: Intelligent Braking, electronic regenerative, disc park brake
Ground Clearance: 3.5 in.
Turning Radius: 21.25 in.
Overall Size: Length: 41 in.
Width: 24.5 in.
Seating Options: Medium Back (standard
Synergy (optional
Versa Tilt (optional
High Back (optional
Reclining (optional
Drivetrain: Two motor, mid-wheel
Batteries: Two 12-volt, NF-22 batteries
Range: Up to 25 miles
Battery Charger: 3-amp, onboard
Off-board (optional
Electronics: 50-amp P & G VSI Controller
Weight Capacity: 300 lbs.
Component Weights: Right Power Base Frame: 46 lbs.
Left Power Base Frame: 49 lbs.
Front Battery Box: 42 lbs. (w/ NF-22 battery
Back Battery Box: 49 lbs. (w/ NF-22 battery
Total Power Base Weight: 181 lbs. (w/ batteries
Medium-Back Seat: 33 lbs.
Batteries: 38 lbs. each
Warranty: Lifetime limited warranty on frame
Two-year warranty on electronics
Eighteen-month warranty on drive motors

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 17
Figure 4. Jazzy 1133 Power Base Assembly — Seat Removed
Figure 5. Jazzy 1133 — Front of Power Base
BACK SEAT TOWERS
BACK BATTERY BOX
FRONT SEAT TOWERS
MAIN CIRCUIT
BREAKER AMMETER
ONBOARD CHARGER
AC POWER CORD
RECEPTACLE CHARGER FUSE(S)
ONBOARD BATTERY
CHARGER (INSIDE FRONT
BATTERY BOX)
IV. THE JAZZY 1133
BACK SEAT-FRAME BAR
FRONT SEAT-FRAME BAR
FRONT BATTERY BOX
FRONT BATTERY BOX

18 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
The Power Base Assembly
The power base assembly consists of the right and left frame assemblies the front and back battery boxes and the
seat bars. See figures 4 5 and 6. The battery boxes provide connectivity for the controller the onboard battery
charger and the batteries. The front battery box contains the onboard charger the ammeter the onboard charger AC
power cord receptacle and the main circuit breaker. The back battery box contains the controller connector and the
charger inhibit connector.
Ammeter: The ammeter displays the chargers current output in amps. See VII. Batteries and Charging.
Onboard Charger AC Power Cord Receptacle: This is where the AC power cord plugs into the onboard charger.
The AC power cord plugs into a standard wall outlet.
Charger Fuse(s): The charger fuse protects the ammeter from overload during charging. A spare fuse is included.
Main Circuit Breaker: The main circuit breaker is a safety feature built into your power chair. When the batteries
and the motors are heavily strained (e.g. from excessive loads) the main circuit breaker trips to prevent damage to
the motors and the electronics. If the circuit breaker trips allow your power chair to rest for approximately one
minute. Then push in the circuit breaker reset button turn on the controller and continue normal operation. If the
main circuit breaker trips repeatedly contact your authorized Pride provider.
Controller Connector: This is where the controller connects to the battery the motors and the motor brakes. The
standard controller connector is shown.
Charger Inhibit Connector: The controller is equipped with a charger inhibit. The charger inhibit enables the
onboard battery charger to disable the controller during charging. The charger inhibit connector is coded with
colored dots. The dots are positioned so that you can align the flat side of the male connector with the flat side of
the female connector before making the connection.
CAU ION! Failure to properly align the connectors can result in damage to the controller, the
onboard charger, and the connectors.
Figure 6. Jazzy 1133 — Back of Power Base
CONTROLLER CONNECTOR
CHARGER INHIBIT
CONNECTOR
MOTOR/BRAKE
ASSEMBLY
LEFT MOTOR
CONNECTOR RIGHT MOTOR
CONNECTOR
MOTOR/BRAKE
ASSEMBLY
IV. THE JAZZY 1133
BACK BATTERY
BOX GRIP
BACK BATTERY BOX
LEFT BATTERY BOX
RELEASE LEVER RIGHT BATTERY BOX
RELEASE LEVER

Jazzy1133Owner’sManualRevB03-03 www.pridemobility.com 19
Manual Freewheel Levers
For your convenience your power chair is equipped with two manual freewheel levers - one for each motor/brake
assembly. See figure 7. These levers allow you to disengage the drive motors and maneuver the chair manually.
WARNING! Do not use your power chair while the drive motors are disengaged unless you are in
the presence of an attendant! Do not disengage the drive motors when your power chair is on an
incline. he chair could roll down on its own, causing injury!
To engage or disengage the drive motor:
1. Pull the manual freewheel lever up to engage the drive motor.
2. Push the manual freewheel lever down to disengage the drive motor.
CAU ION! It is important to remember that when your power chair is in freewheel mode, the
electronic braking system is disengaged.
NOTE: If a lever is difficult to move in either direction, rock your power chair back and forth slightly. The levers
should then move to the desired position.
Figure 7. Jazzy 1133 Manual Freewheel Lever (right side shown)
MANUAL FREEWHEEL LEVER
MOTOR/BRAKE ASSEMBLY
IV. THE JAZZY 1133

20 www.pridemobility.com Jazzy1133Owner’sManualRevB03-03
DISASSEMBLY
You can disassemble your Jazzy 1133 into six pieces (seat not shown) for easy transport. See figure 8.
NOTE: Assembly is the reverse of disassembly.
Figure 8. Jazzy 1133 — Power Base Components
V. DISASSEMBLY
WARNING! Some power chair components are heavy. You may need assistance to lift or carry
them. Please refer to IV.  he Jazzy 1133 for specific component weights before you disassemble
the power chair.
1. Make sure that the power chair is in drive mode. See IV. The Jazzy 1133.
2. Unplug the controller and charger inhibit connectors from the back battery box. See figure 6.
3. Push the seatback release lever down and fold down the seatback. The seatback release lever is located on the
right side of the seat. See figure 3.
BACK BATTERY BOX FRONT BATTERY BOX
FOOTREST
RIGHT POWER BASE
ASSEMBLY LEFT POWER BASE
ASSEMBLY
BATTERY
BOX HANDLE
BATTERY
BOX HANDLE
BATTERY
BOX GRIP
