Pro-Form 300 ZLX User manual

CAUT ON
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial Number Decal
(under frame)
Model No. PFEVEX74010.0
Serial No.
Write the serial number in the
space above for reference. USER'S MANUAL
QUEST ONS?
If you have questions, or if there are
missing parts, please contact us:
UK
Call: 08457 089 009
From reland: 053 92 36102
Website: www.iconsupport.eu
E-mail: [e-mail]
Write:
CON Health & Fitness, Ltd.
c/o H Group PLC
Express Way
Whitwood, West Yorkshire
WF10 5QJ
UK
AUSTRAL A
Call: 1-800-237-173
E-mail:
[e-mail]
www.iconeurope.com
Get other manuals https://www.bkmanuals.com

2
WARN NG DECAL PLACEMENT
TABLE OF CONTENTS
WARNINGDECALPLACEMENT ..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSEMBLY ...............................................................................5
HOWTOUSETHEEXERCISEBI E .........................................................11
MAINTENANCEANDTROUBLESHOOTING ...................................................19
EXERCISEGUIDELINES ...................................................................21
PARTLIST ..............................................................................22
EXPLODEDDRAWING ....................................................................23
ORDERINGREPLACEMENTPARTS ..................................................BackCover
RECYCLINGINFORMATION.........................................................BackCover
This product should
always be used on a
level surface.
This product is not
intended for
therapeutic use.
Misuse of this machine
may result in serious
injury.
Read user’s manual
prior to use and follow
all warnings and
instructions.
Do not allow children
on or around machine.
User weight must not
exceed 275 pounds.
Replace label if
damaged, illegible,
or removed.
PROFORM is a registered trademark of ICON IP, Inc.
This drawing shows the location(s) of the warning
decal(s). f a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.
Get other manuals https://www.bkmanuals.com

3
WARN NG: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your exercise bike before using your exercise bike.
CON assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the exercise bike only as described in
this manual.
3. t is the responsibility of the owner to ensure
that all users of the exercise bike are ade-
quately informed of all precautions.
4. The exercise bike is intended for home use
only. Do not use the exercise bike in a com-
mercial, rental, or institutional setting.
5. Keep the exercise bike indoors, away from
moisture and dust. Do not put the exercise
bike in a garage or covered patio, or near
water.
6. Place the exercise bike on a level surface
with at least 2 ft. (0.6 m) of clearance around
the exercise bike. To protect the floor or
carpet from damage, place a mat under the
exercise bike.
7. nspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
8. Keep children under age 12 and pets away
from the exercise bike at all times.
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the exercise bike. Always wear
athletic shoes for foot protection.
10. The exercise bike should not be used by
persons weighing more than 275 lbs.
(125 kg).
11. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. Always keep your back straight while using
the exercise bike; do not arch your back.
13. Over exercising may result in serious injury
or death. f you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
MPORTANT PRECAUT ONS
Get other manuals https://www.bkmanuals.com

4
Thank you for selecting the new PROFORM®300 ZLX
exercise bike. Cycling is an effective exercise for
increasing cardiovascular fitness, building endurance,
and toning the body. The 300 ZLX exercise bike pro-
vides an impressive selection of features designed to
make your workouts at home more effective and
enjoyable.
For your benefit, read this manual carefully before
you use the exercise bike. If you have questions
after reading this manual, please see the front cover
of this manual. To help us assist you, note the product
model number and serial number before contacting
us. The model number and the location of the serial
number decal are shown on the front cover of this
manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Handgrip Pulse Sensor
Seat
Seat Post
Seat Adjustment nob
Leveling Foot
Leveling nob
Wheel
Pedal/Strap
Console
Handlebar
Adjustment nob
Adjustment nob
BEFORE YOU BEG N
Get other manuals https://www.bkmanuals.com

5
M10 x 95mm Patch
Screw (76)–4
M8 x 20mm
Patch Screw (74)–4
M6 x 60mm Bolt Set (51)–1
M4 x 16mm
Screw (90)–8
M4 x 5mm
Bright Screw
(91)–1
M8 Split
Washer (75)–8 M8 Washer
(43)–2
M8 Locknut
(72)–4
M6 x 70mm Bolt Set (50)–1
ASSEMBLY
Assembly requires two persons. Place all parts of the exercise bike in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
n addition to the included tool(s), assembly requires a Phillips screwdriver , an adjustable
wrench , and a rubber mallet .
See the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: f a part is not in the hardware kit, check to see if
it has been preassembled. To avoid damaging parts, do not use power tools for assembly.
Get other manuals https://www.bkmanuals.com

6
1.
Attach the Rear Stabilizer (3) to the Frame (1)
with two M10 x 95mm Patch Screws (76).
1
3
76
1
2. Attach the Front Stabilizer (2) to the Frame (1)
with two M10 x 95mm Patch Screws (76). 2
276
1
To make assembly easier, read the
information on page 5 before you begin.
Get other manuals https://www.bkmanuals.com

7
3
4
6
Adjustment
Holes
1
23
24
75
72
26
91 6
27
3. Loosen the Adjustment nob (27) in the Frame
(1) a few turns.
Orient the Seat Post (6) as shown. Then, pull
the Adjustment nob (27) outward and insert
the Seat Post into the Frame (1). Slide the Seat
Post upward or downward to the desired posi-
tion, and release the Adjustment nob.
Move the Seat Post (6) upward or downward
slightly to make sure that the Adjustment
Knob (27) is engaged in one of the adjust-
ment holes in the Seat Post. Then, tighten the
Adjustment nob.
4. Orient the Seat (23) and the Seat Carriage (24)
as shown.
Attach the Seat (23) to the Seat Carriage (24)
with four M8 Locknuts (72) and four M8 Split
Washers (75).
Next, slide the Seat Carriage (24) onto the Seat
Post (6). Slide the Seat Carriage all the way for-
ward, and tighten the Seat Adjustment nob
(26).
Then, tighten an M4 x 5mm Bright Screw (91)
into the rear of the Seat Post (6).
Get other manuals https://www.bkmanuals.com

8
5. Apply some of the included grease to an M6 x
70mm Bolt Set (50).
Orient the Handlebar (5) and the Upright (4) as
shown.
While a second person holds the Handlebar (5)
near the Upright (4), insert the Extension Wire
(59) upward through the Handlebar.
Tip: Avoid pinching the Extension Wire (59).
Attach the Handlebar (5) to the Upright (4) with
the M6 x 70mm Bolt Set (50) and two M8
Washers (43).
Then, attach an M6 x 60mm Bolt Set (51)
through the lower bracket on the Handlebar (5).
5
59
5
43
43
50
51
51
50
4
Grease
Avoid pinching the
Extension Wire (59)
6
6. The Console (13) can use four D batteries (not
included); alkaline batteries are recommended.
MPORTANT: f the Console has been
exposed to cold temperatures, allow it to
warm to room temperature before inserting
batteries. Otherwise, you may damage the
console displays or other electronic compo-
nents. Remove the indicated screw, remove the
battery cover, insert the batteries into the bat-
tery compartment, and then reattach the battery
cover. Make sure to orient the batteries as
shown by the diagrams inside the battery
compartment.
To purchase an optional power adapter, call
the telephone number on the front cover of
this manual. To avoid damaging the console,
use only a manufacturer-supplied power
adapter. Plug one end of the power adapter
into the receptacle on the console; plug the
other end into an outlet installed in accordance
with all local codes and ordinances.
13
Batteries
Batteries
Screw
Battery
Cover
Get other manuals https://www.bkmanuals.com

9
8
8. Orient the Upright (4) assembly and the Pivot
Cover (12) as shown.
Slide the Pivot Cover (12) upward to the
Handlebar (5). Tip: Bend and flex the Pivot
Cover slightly to slide it over the Handlebar.
Attach the Pivot Cover (12) to the Handlebar (5)
with four M4 x 16mm Screws (90).
Next, pivot the Handlebar (5) until the hole in
the Handlebar is aligned with an adjustment
hole in the Upright (4).
Tighten an Adjustment nob (27) into the
Handlebar (5) and into an adjustment hole in
the Upright (4). Make sure that the
Adjustment Knob is engaged in one of the
adjustment holes.
4
12
90
90
90
27
Hole
Adjustment
Holes
5
7
90
90
7. While another person holds the Console (13)
near the Handlebar (5), connect the wires on
the Console to the Extension Wire (59) and the
Pulse Wire (61).
Insert the excess wire downward into the
Handlebar (5) or upward into the Console (13).
Tip: Avoid pinching the wires. Attach the
Console (13) to the Handlebar (5) with four M4
x 16mm Screws (90).
Avoid pinching
the wires
13
61
59
5
Get other manuals https://www.bkmanuals.com

10
9
10
75
75
75
74
74
58
59
9. Slide the Front Shield Cover (7) upward onto
the Upright (4).
While another person holds the Upright (4) near
the Frame (1), connect the Extension Wire (59)
to the Wire Harness (58).
Insert the Upright (4) into the Frame (1).
Tip: Avoid pinching the wires. Attach the
Upright (4) with four M8 x 20mm Patch Screws
(74) and four M8 Split Washers (75).
Then, slide the Front Shield Cover (7) down-
ward to the Frame (1) and press it into place.
4
7
1
Avoid pinching
the wires
10. Identify the Right Pedal (21), which is marked
with an “R.”
Using an adjustable wrench, firmly tighten the
Right Pedal (21) clockwise into the Right
Crank Arm (19).
Tighten the Left Pedal (not shown) counter-
clockwise into the Left Crank Arm (not shown).
Adjust the strap on the Right Pedal (21) to the
desired position, and press the ends of the
straps onto the tabs on the Right Pedal. Adjust
the strap on the Left Pedal (not shown) in
the same way.
19
Strap
Tab
21
11. Make sure that all parts are properly tightened before you use the exercise bike. Note: Some hard-
ware may be left over after assembly is completed. Place a mat under the exercise bike to protect the
floor or carpet.
Get other manuals https://www.bkmanuals.com
