USERʼS MANUAL
Visit our website
www.iconsupport.eu
Model No. PFIVEX79012.0
Serial No. : ___________
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
QUESTIONS ?
If you have questions, or if there are
missing parts, please contact us:
UK
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: [email protected]
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
Whitwood, West Yorkshire
WF10 5QJ
UK
Write the serial number in the
space above for reference.
Serial No Decal

2
TABLE OF CONTENTS
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
MAINTENANCE AND TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
HOW TO OPERATE THE BIKE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
HOW TO MEASURE YOUR PULSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
CONSOLE FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
EXERCISE GUIDELINES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
EXPLODED DRAWINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Last page
WARNING DECAL PLACEMENT
This drawing shows the location(s) of
the warning decal(s). If a decal is miss-
ing or illegible, call the telephone num-
ber on the front cover of this manual
and request a free replacement decal.
Apply the decal in the location shown.
Note: The decal(s) may not be shown
at actual size.
115 Kg
115 Kg
115 Kg
ENGLISH
115 Kg

3
IMPORTANT PRECAUTIONS
WARNING : To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your bike before using it. ICON assumes no
responsibility for personal injury or property damage sustained by or through the use of this
product.
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or
persons with pre-existing health problems.
2. Use this bike only as described in this
manual.
3. It is the responsibility of the owner to ensure
that all users of the bike are adequately
informed of all precautions.
4. The bike is intended for home use only.
Do not use the bike in a commercial,
rental, or institutional setting.
5. Keep the bike indoors, away from
moisture and dust. Place the bike on a
level surface, with a mat beneath it to protect
the oor or carpet. Make sure that there is at
least 3 ft. (0.9 m) of clearance in the front and
rear of the bike and 2 ft. (0.6 m) on each
side.
6. Inspect and properly tighten all parts
regularly. Replace any worn parts
immediately.
7. Keep children under age 12 and pets away
from the bike at all times.
8.The bike should not be used by persons
weighing more than 250 lbs. (115 kg).
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the bike. Always wear athletic
shoes for foot protection while exercising.
10. Hold the handlebars or the upper body arms
when mounting, dismounting, or using the
bike.
11. The pulse sensor is not a medical device.
Various factors may affect the accuracy of
heart rate readings. The pulse sensor is
intended only as an exercise aid in
determining heart rate trends in general.
12. Keep your back straight while using the
bike; do not arch your back.
13. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.

4
BEFORE YOU BEGIN
Thank you for purchasing the ProForm® Sprint
2.0. The bike provides an array of features de-
signed to make your workouts at home more ef-
fective and enjoyable.
For your benet, read this manual carefully be-
fore you use the bike. If you have questions after
reading this manual, please see the front cover of
this manual. To help us assist you, note the prod-
uct model
number and serial number before contacting us.
The model number is PFIVEX79012.0 and the lo-
cation of the serial number decal are shown on the
front cover of this manual.

5
ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and re-
move the packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver and
an adjustable wrench.
As you assemble the exercice bike, use the drawings below to identify small parts. The number in
parentheses below each drawing is the key number of the part, from the PART LIST near the end of
this manual. The number following the parentheses is the quantity needed for assembly.
Note: If a part is not in the hardware kit, check to see if it has been preassembled.

6
STEP 1
Install the Front stabilizer (2) and Rear stabilizer
(3) to the Main frame (1) and xing with the Square
neck bolt (13), Arc washers (14) and Acorn nut
(15).
STEP 2
While another person holds the Upright (4) near
the Frame (1), connect the Extension Wire (21) to
the sensor Wire (16).
Next, connect the Resistance Cable (8) to the Low-
er Cable (17) in the following way:
• See drawing A. Pull upward on the metal bracket
on the Lower Cable (17), and insert the tip of the
Resistance Cable (8) into the wire clip inside the
metal bracket as shown.
• See drawing B. Firmly pull the Resistance Cable
(17) upward and slide it into the top of the metal
bracket as shown.
• See drawing C. Using pliers, squeeze the prongs
on the upper end of the metal bracket together.
Push the Wires (21,16) and the Cables (17, 8)
downward into the Frame (1).
Tip: Do not pinch the wires and cables. Insert the
Upright (4) into the Frame (1). Attach the Upright
with three Screws (18) and three Washers (14).
STEP 3
Put the Pulse wire (27) through the hole of Front
vertical tube (4), then pull out to the top of the Front
vertical tube (4).
Assemble the Handle bar (5) to the Front vertical
tube (4) xing with Bolts(23) and Spring washers
(22).Finally put on the Handle cover (24) to the
handle bar
ABC
9
6
6
9
8
17 17
8Metallic
support
Metallic
support

7
STEP 4
Install the saddle (7) to the Saddle supporting tube (6) with
the Washers (31) and Nylon nuts (32), and then insert the
Saddle supporting tube (6) to the Main frame (1).
Note: You can control the Knob bolt (28) to adjust the ap-
propriate height which is suitable for you.
STEP 5
Assemble the Pedals (10L/R)to the Crank (35L/R).
Note: The right pedal should be xed by clockwise. How-
ever, the left pedal should be xed by counter-clockwise.
STEP 6
Pull out the Extended wire (21) to connect with one of wire
on the Computer (9), and connect the Pulse wires(27) with
rest wires on the Computer. Finally x the computer (9) onto
the top of the Front vertical tube (4) with Screws (34),Wash-
ers (33)
Now, your machine is ready for use.

8
HOW TO ADJUST THE HEIGHT AND THE LATERAL
POSITION OF THE SEAT
For effective exercise,
the seat should be at the
proper height. As you
pedal, there should be a
slight bend in your knees
when the pedals are in
the lowest position. To
adjust the height of the
seat, rst loosen the seat
post knob. Next, pull the
knob, slide the seat post
upward or downward to the desired position, and
then release the knob. Move the seat post upward
or downward slightly to make sure that the knob is
engaged in one of the adjustment holes in the seat
post. Then, tighten the knob.
HOW TO ADJUST THE PEDAL STRAPS
To adjust the pedal straps, rst pull the ends of the
pedal straps off the tabs on the pedals.
Adjust the pedal
straps to the desired
position, and then
press the ends of the
pedal straps onto the
tabs.
HOW TO OPERATE THE BIKE
Pedal
Strap

9
CONSOLE FEATURES
Follow your progress with the display.
The console has one display that show the following
workout information :
Speed—This display shows your pedaling speed,
in kilometer per hour (km/h).
Time—This display shows the elapsed time.
Distance—This display shows the distance you
have pedaled, in kilometers.
Calories—This display shows the approximate
number of calories you have burnt.
Pulse—This display shows your heart rate when
you use the handgrip pulse sensor.
Odometer—This display shows the total distance of
the bike from the rst time you insert the battery.
(changing the batteries will reset this value)
Scan—When you select this display option, the
display will rotate and show the 5 functions (time,
Speed, Distance, Claories and total distance) with
alternance each 4 seconds.
HOW TO USE THE CONSOLE
Make sure that the console has batteries (see page
MAINTENANCE AND TROUBLESHOOTING). If
there is a sheet of clear plastic on the face of the
console, remove it.
1. Turn on the console
To turn on the console, press any button on the
console or simply begin pedaling.
2. Press the buttons :
MODE:
Press this button to choose the value you want to be
displayed.
By holding this button for more than 3 seconds, all
values will be reset.
SET:
Press this button to set the selected values when
not in Scan mode.
Set a value which will countdown on any functions
of time, distance and calorie. when the value will
goes to zero than the computer will alarm for 15
seconds.
RESET:
Press this button to reset the values of time,
distance and calories.
3. Start pedaling and follow your progress with
the display :
While you exercise, the console will display the
selected mode.
4. When you are nished exercising, the console
will automatically turn off.
If the pedals do not move for a few seconds the
console will pause. The console has an “auto-
off” feature. If the pedals do not move and the
console buttons are not pressed for a few minutes,
the power will turn off automatically to save the
batteries.
CONSOLE FEATURES

10
Inspect and tighten all parts of the exercise bike
regularly.
Replace any worn parts immediately.
To clean the exercise bike, use a damp cloth and a
small amount of mild soap.
IMPORTANT: To avoid damage to the console,
keep liquids away from the console and keep the
console out of direct sunlight.
BATTERY REPLACEMENT
If the console display becomes dim, the batteries
should be replaced; most console problems are the
result of low batteries.
The Console requires two 1,5V AA batteries;
alkaline batteries are recommended. Remove the
battery cover from the Console. Insert two batteries
into the Console.
Make sure that the batteries are oriented as shown
by the diagram inside the Console. Then, reattach
the battery cover.
MAINTENANCE AND TROUBLESHOOTING
