PRO SIGNAL PSG3533 User manual

PSG3533
4x4 HDMI MATRIX EXTENDER 4K 60Hz 70m
1
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

WHAT’s IN THE BOX
OVERVIEW
IMPORTANT SAFETY INFORMATION
• 1x HDMI Matrix Transmitter
• 4x HDMI Receivers
• 1x 12V 3A Power Supply Unit
• 1x Remote Control
• 1x IR Sender
• 1x IR receiver
• 1x User Manual
• 2x Mounting brackets and screws
• 1x Terminal block
1. HDMI input indicators (1-4)
2. Switch: to select HDMI input (1-4)
3. Power indicator
4. IR receiving window
5. DC12V power input
6. Ethernet control
7. RS-232 serial port
8. IR input (local)
9. EDID DIP switch
10. IR outputs (1-4)
11. HDMI inputs (1-4)
12. RJ45 outputs (1-4)
13. HDMI local outputs (1-4)
Please read these instructions carefully before use and retain for future reference.
Transmitter
When using electrical appliances basic safety precautions should always be followed.
• To prevent fire or shock hazard, do not expose this product to rain or moisture.
• For indoor use only.
• Check that the power supply matches the mains voltage.
• Only use the power supply provided or one of identical specification.
• Ensure adequate ventilation and do not obstruct ventilation slots.
• Do not hot-plug any HDMI, network or IR connections. Always power off.
FEATURES
2
• This product is a 4×4 HDMI matrix extender over network cable, with 4 HDMI inputs, 4
RJ45 outputs and 4 HDMI loop-out.
• 4 HDMI outputs send the high-definition audio/video signals to 4 UHD displays at the
local site.
• At the same time, 4 RJ45 outputs transmit and extend the audio/video signals to 4
UHD displays at 70 meters range via 4 receivers using Cat6/6a/7 cable.
• RS-232 control, Ethernet control, button control and remote control make for easy
switching/setting the input and output.
• Zero latency transmission.
• Support resolution up to 4K@60Hz.
• The receiver can extract the digital audio from the transmitter through the S/PDIF port.
• Support IR passback (20~60kHz).
• Support PoC, only the transmitter needs to be powered by PSU.
• Support EDID management, button control, remote control, ethernet control and
RS232.
• Lightning protection, surge protection and ESD protection.

1. Reset button
2. Audio switch: a second audio
output from the HDMI source
(S/PDIF side) or an audio output
from the TV on the receiving end
(ARC side)
3. RJ45 input
4. Power/Signal indicator: when there
is power and no HDMI signal, the
indicator will flash, when there is
HDMI signal, the indicator will light
solid blue
5. DC12V power input (only if PoC is
not used. PSU not supplied)
6. Digital audio signal output
7. HDMI output
8. IR input
Receiver
3

4
INSTALLATION
Requirements
• An HDMI source device with HDMI OUTPUT interface, DVD, PS3, STB, PC etc.
• A display device with HDMI INPUT port, SDTV, HDTV, projector etc.
• Network cables UTP/STP Cat6/Cat6A/Cat7 network cables, to IEEE-568B.
• Please make sure all devices you wish to connect have been powered off.
• Connect the source devices to the HDMI input ports of the transmitter with HDMI
cables.
• If using HDMI loop-out, connect the display devices to the HDMI output ports of the
transmitter with HDMI cables.
• Use Cat6/6A/7 cables to connect the RJ45 ports of the transmitter and receivers.
• Connect the display devices to the HDMI outputs of the receivers with HDMI cables.
• If using IR passback and/or local IR control, the 4 x IR blaster extension cables
should be connected to the IR output port of the transmitter,
• Plug the IR-TX extender into the IR-IN port of the transmitter. Direct the extender head
towards the remote control sensor on the source device.
• Plug the 4 x IR-RX extenders into the IR-IN port of the receivers. Direct the sender
head such that it can receive signals from the remote control for your source device.
• Connect the 12V 3A PSU supplied with the HDMI switch to the transmitter power
input jack and connect to a mains outlet and turn the power on. The Power LED will
illuminate.
• Power on the source and receiving devices.
4

5
OPERATION
RS-232 control
• Baud rate: 9600
• Data bits: 8
• Stop character: 1 Parity: none
Ethernet control
• Connect the Ethernet port to the Ethernet (e.g. PC) with a network cable for TCP/IP
control.
• Logging in via IP address: 192.168.1.200 (if you cannot open this address in your
browser, please try a different browser) will take you to the following screen:-
Operation
Mode 1
HDMI
Input 1
HDMI
Input 2
HDMI
Input 3
HDMI
Input 4
HDMI Output 1 PS11R PS12R PS13R PS14R
HDMI Output 2 PS21R PS22R PS231R PS24R
HDMI Output 3 PS31R PS32R PS33R PS34R
HDMI Output 4 PS41R PS42R PS43R PS44R
HDMI Output
1/2/3/4 PAIR PA2R PA3R PA4R
1. Output order
2. Select the corresponding HDMI input content for the output
3. It will be applied to all outputs if HDMI Input is selected here
4. Press OK to confirm

Operation
Mode 2
Return
Value
Reset Device restart
Recover Restore device factory setting
PAPXPXPXPX
Prex 1 2 3 4
Content for output port HDMI 4
Content for output port HDMI 3
Content for output port HDMI 2
Content for output port HDMI 1
PAPXPXPXPX
PA is the command prex, and the “X” of PX can be any number from 1 to 4.
P1 represents HDMI 1 source content for output, P2 represents HDMI 2 source
content for output, and so on to P4.
E.g. PAP3P1P4P2 represents:
Output port HDMI 1 outputs content from input port HDMI 3
Output port HDMI 2 outputs content from input port HDMI 1
Output port HDMI 3 outputs content from input port HDMI 4
Output port HDMI 4 outputs content from input port HDMI 2
PAXXXR is the command to read the status of all interfaces; after sending the
command, OKPXPXPXPX is displayed, where X is 1 to 4; if the command sent is
incorrect, ERR appears.
EDID settings
The product has 16 built-in EDID states, which can be set to switch the output resolution
through the DIP switch. The DIP switch up for “1” and down for “0”.
Dip Switch Status
Resolution Information
1234
00004K@60Hz 2CH
10004K@60Hz 5.1CH
01004K@60Hz 7.1CH
0 0 1 0 4K@60Hz HDR 7.1CH
00014K@30Hz 2CH
11004K@30Hz 5.1CH
10104K@30Hz 7.1CH
1 0 0 1 4K@30Hz HDR 7.1CH
01101080p@60Hz 2CH
01011080p@60Hz 5.1CH
00111080p@60Hz 7.1CH
6

Dip Switch Status
Resolution Information
1234
11101080i@60Hz 2CH
11011080i@60Hz 2CH
10111080i@60Hz 7.1CH
0111 1080p@60Hz HDR 7.1CH
1111
1. Read only the EDID
that was first connected
to the output
2. Connect 4 outputs
at the same time, only
read the EDID of HDMI
1 output
7
MAINTENANCE
• Clean the outside casing with a soft cloth lightly moistened with mild soap and water.
Never use any abrasive or solvents.
Remote Control / Front Panel Buttons
• The remote control replicates the buttons on the front panel and both can be used
to direct each of the 4 inputs to any of the four output displays.
• If the remote loses effective range the battery may require replacement.
• Pull out the battery holder and replace the battery noting the correct polarity.
• The remote uses 3V CR2025 coin type battery.

INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Waste batteries
can be returned to any waste battery recycling point which are provided by most battery retailers.
Contact your local authority for details of recycling schemes in your area.
Made in China
PO Box 13362 Dublin 2
PR2 9PP
Man Rev 1.0
8
SPECIFICATIONS
Transmitter Rceivers
HDMI version HDMI 2.0
HDCP version HDCP 2.2, HDCP 1.4
Transmission distance IEEE-5688 standard CAT6/CAT6A/CAT7 ≤70m
Video bandwidth 600MHz (18Gbps)
Resolution supported 3840×2160@24/25/30/50/60Hz, 4096×2160@24/25Hz,
1080i@50/60Hz, 1080p@50/60Hz, 720p@50/60Hz,
576i@50Hz, 576p@50Hz, 480i@60Hz, 480p@60Hz,
3440×1440, 2560×1440, 2560×1080, 2048×1080,
1920×1440, 1280×960, 1280×800, 1280×768,
1680×1050, 1360×768, 1366×768, 1600×900, 1024×768,
800×600
HDR10 Supported
HDMI loop-out Supported -
IR passback Unidirectional supported
S/PDIF audio separation -Supported
EDID DIP switch Supported -
Audio format supported LPCM/DTS-HD/DTS-Audio
Dolby Digital 5.1CH/Dolby Atmos
Input TMDS signal 0.5~1.2Vp-p
Input DDC Signal 5Vp-p
Power over cable (PoC) TX to RX
I/O interface HDMI IN ×4
HDMI Loop Out ×4
3.5mm jack ×4 (IR)
HDMI OUT ×1
RJ45 IN ×1
3.5mm jack ×1 (IR)
S/PDIF OUT ×1
RJ45 OUT ×4
RJ45 ×1 (Ethernet)
3-Pin RS-232
EDID DIP switch
HDMI interface Type-A 19 Pins, Female
Dimensions (W x D x H) 411 x 147 x 29mm 105.5 x 102.5 x 20mm
Weight 15250g 243g
Power supply DC12V/3A
Working temperature -20oC~60oC
Storage temperature -30oC~70oC
Humidity 0~90%RH (No Condensation)
Protection ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV)
Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
