PROAIM P-A21-J User manual

Proaim Alphabet 21ft Jib Crane
(P-A21-J)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permied by
the applicable copyright statutes or in wring by the Publisher.
I N S T R U C T I O N M A N U A L
For Demonstration only

Proaim Alphabet 21 Jib Crane 2
INTRODUCT ION
Camera Cranes are quite important tools in the world of lmmaking especially when you want to
add visual interest to your shots. To achieve this, Proaim introduced Alphabet 21 Jib Crane
Package that is highly stable and gets easily integrated into your shoong style. Along with this,
we also kept it lightweight, compact and quick to assemble so that you can use it in various
shoong scenarios.
IN THE BOX
Please inspect the contents of your shipped package to ensure you have received all that is
pictured and listed below.

Proaim Alphabet 21 Jib Crane 3
• Install the Hub (Secon 2 of Jib) into bowl of your 100 mm tripod stand and ghten the hub
with center locking knob.
ASSEMBLING JIB SECTIONS
21

Proaim Alphabet 21 Jib Crane 4
• Loosen the provided knob at the end of secon 2 to slide the bars of secon 3 into the end of
secon 2 .
• Then ghten both the secons together
using the provided knobs.
ASSEMBLING JIB SECTIONS
2. Secon 2a with 2, 2b with 2a, 2c with 2b & 1 with 2c :
ASSEMBLING CABLE GUIDE AND SUPPO RT ROD
• Aach cable guide to cable guide clamp on 2nd secon properly. Loosen the knob, ahead of
cable guide clamp in order to aach cable guide support rod to it.
34
55
76

Proaim Alphabet 21 Jib Crane 5
ASSEMBLING CABLES
• Now aach one end of 14.5 blue cable to blue hook on back side of jib (secon 3 ) and the
other end of blue cable to blue hook on front secon of jib (secon 1).
2. Secon 2a with 2, 2b with 2a, 2c with 2b & 1 with 2c :
For aaching these secons follow the same steps as menoned above.
ASSEMBLING CABLE GUIDE AND SUPPO RT ROD
• Aach cable guide to cable guide clamp on 2nd secon properly. Loosen the knob, ahead of
cable guide clamp in order to aach cable guide support rod to it.
• Reghten the knob to secure
properly.
899
10 11
12

Proaim Alphabet 21 Jib Crane 6
ASSEMBLING CABLES
• Now aach one end of 14.5 blue cable to blue hook on back side of jib (secon 3 ) and the
other end of blue cable to blue hook on front secon of jib (secon 1).
• Now aach one end of 14.3 red cable to red hook on back side of jib (secon 3 ) and align
the red cable to the cable guide from top.
• Similarly aach the second blue
cable and align both the blue cables
to the side of support rod.
13 14
15
16 17

Proaim Alphabet 21 Jib Crane 7
• Then, aach the other end of red cable
to red hook on front secon of jib
(secon 1).
ADJUSTIN G THE WIRE TENSIO NE R
• The wires have the screw-in wire
adjustment system in order to adjust the
wire tension to level the jib .
• The jib arm can be locked (lng) with
the help of this knob.
18
19
20

Proaim Alphabet 21 Jib Crane 8
• Insert the weight rod & weights (not supplied) to both ends and secure with the help of
closers.
• The central fork has free hole to aach LCD mount bracket (not included) .
• The camera plate can be lted upwards & downwards with the help of provided handle.
21 22
23 24
25 26

Proaim Alphabet 21 Jib Crane 9
• Camera can be mounted directly on the head plaorm with the help of provided chuknut.
MOUNTING CAMERA O N HEA D PLATFORM
27 28
29

Proaim Alphabet 21 Jib Crane 10
Balancing Chart
12ft jib
Length: 12 
Camera Plate Length: 0.8 
Length without Camera Plate: 10.3 
Length with camera Plate: 11.1  (Complete Length)
Camera Weight Without Camera 1KG 15Kg
Counter Weight No need counter weight, it
is balanced with weight
rod whose weight is 3.2 kg
Weight rod +
1.5kg
22.5Kg
15ft jib
Length: 15 
Camera Plate Length: 0.8 
Length without Camera Plate: 13.72 
Length with camera Plate: 14.52  (Complete Length)
Camera Weight Without Camera 1KG 15Kg
Counter Weight 7Kg (7 + 2.25)=9.2Kg 41Kg
18ft jib
Length: 18
Camera Plate Length: 0.8 
Length without Camera Plate: 17.15 
Length with camera Plate: 17.95  (Complete Length)
Camera Weight Without Camera 1KG 15Kg
Counter Weight 16Kg (16 + 3.5)=19.5Kg 68.5Kg

Proaim Alphabet 21 Jib Crane 11
21ft jib
Length: 21 
Camera Plate Length: 0.8 
Length without Camera Plate: 20.6 
Length with camera Plate: 21.4  (Complete Length)
Camera Weight Without Camera 1KG 15Kg
Counter Weight 28Kg (28+4.2)=32.2Kg 91Kg
YOUR PROAIM ALPHABET 21FT JIB CRANE
ALL DRESSED UP AND GOOD TO GO
(SHOWN WITH OPTIONAL ACCESSORIES)

Proaim Alphabet 21 Jib Crane 12
WARRANTY
We oer a one year warranty for our products from the date of purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we
donot supply or from mishandling in transit, accident, misuse, neglect, lack of care of the
product , or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
best to help you out.
