AE300
INTEGRATED VOICE ALARM SYSTEM
EN54-16 EN54-4
OPERATING and INSTALLATION MANUAL

2

3
1. INTRODUCTION
The AE300 voice alarm system is a device for signalling in case of fire, designed according to EN Standards 54-16 and
54-4 It is an integrated, monolithic system with a single casing containing the voice alarm system blocks and the
power supply unit with backup batteries The system can play back recorded alarm messages through the monitored
contact inputs, or an operator can speak directly through a microphone integrated in the front panel, or from a
remote emergency microphone workstation
The system also has inputs for a service microphone workstation, background music diffusion, contacts for playing
back generic messages, as well as an Ethernet port
Depending on the model, the system has (or does not have) a backup amplifier
2. SAFETY NOTES AND ARNINGS
•This device must be installed in accordance with UNI Standard EN54-32:2015 and serviced only by qualified
personnel.
•This manual must be read and understood before commissioning the device.
•This device is set-up for operation using mains voltage within the 230 V +10% -15% range and 48V backup
batteries with 7.2A/h capacity.
•It is necessary to strictly follow the instructions in Par. 4.p “Connection to the mains power supply and
earthing”
•The device is protected by fuses on the main power supply (230V) and on the backup power supply (48V
battery). The fuses, respectively indicated as F1 and F2, are present on the power supply card. F1=T3.15AH,
F2=T8AH
•All connections must be made with device off.
•The end of a stranded conductor must not be terminated with a soft solder in the points in which the
conductor is subjected to a contact pressure (e.g. the header of the wirings which go to the cable seal
terminals must not be tin-plated but terminated with a crimping ferrule.)
•The installer is responsible for setting up a 6A-C6 circuit breaker (in appropriate electrical panel) dedicated
to this device. The circuit breaker must be placed in an easily accessible position. The circuit breaker must
bear the words “VOICE ALARM SYSTEM – DO NOT S ITCH-OFF”
•In order to avoid the risk of electric shocks, when accessing the inside of the device you must disconnect
the power supply network (230V). It is also necessary to disconnect the battery as there is a DANGEROUS
ENERGY LEVEL inside the machine (in particular to fastons J6 and J7).
•Do not expose the device to humidity or rain or any other liquid. Keep the device away from objects or
containers with liquid that could be accidentally poured inside, through the ventilation slots.
•Install the device in a cool, ventilated place and away from heat sources.
•Install the device so as not to obstruct the ventilation slots.
•Connect only batteries with the rated voltage and capacity described in this manual.
•Do not reverse the polarity of the batteries.
•The batteries must have a casing with flammability class HB or better
•hen installing the device, be very careful not to damage the electronic card with tools (pliers,
screwdrivers, etc...).

4
3. MAIN FEATURES, FUNCTIONS ITH REQUIREMENT AND ACCESSORY FUNCTIONS.
•Integrated, single-zone (1 zone max) voice alarm system, with class D power amplifiers and power supply unit with primary source
(230Vac network) and backup source (48V batteries)
•ARM Cortex M3 processor, DSP 16bit 48Khz
•Controlled dynamic microphone on front panel; microphone capsule continuity monitoring, cable cut and short-circuit
•Key or password to access the machine functional levels
•Alarm and generic messages, recorded on uSD card Contents monitored by system processor
•Class D power amplifiers, power 300W
•2 Speaker lines (line A and line B) with 100V constant voltage with transformer coupling
•Independent monitoring of the speaker lines (A+B) with direct measurement of AC voltage and current at 18Khz and FFT analysis
•2 Contact inputs with line monitored for alarm message activation (interruption and cable cut)
•8 contact inputs (not monitored) to activate generic and service messages
•3 open-collector outputs for reporting the machine status: alarm and fault The open-collector outputs must only be connected to
circuits operating at SELV voltage
•Input for remote emergency microphone workstation with monitored connection
•Input for generic microphone workstation for service messages
•RS485 port (reserved for future use)
•Ethernet port for remote communication (reporting of status, configuration, audio streams)
•Power supply unit according to Standard EN54-4 with main source (230Vac); backup source (48Vdc battery); temperature, battery
impedance and battery charger status monitoring
•Comprehensive user interface for a straightforward configuration
The following figure schematically shows the connections outside the system
VA 301
Postazione
di chiamata
Postazione
di Emergenza
Sorgente Sonora
LINEA A
Contatto Allarme
Contatto Evacuazione
LINEA B
CENTRALE
ANTI INCENDIO
SUBWOOFER
Attivo
Contatti Fault/Alarm /Disablement
RS 485
Ethernet
8x Contatti per messaggi generici
Call
workstation
Emergency
workstation
FIRE
-
FIGHTING
STATION
Alarm Contact
Evacuation Contact
Fault/Alarm/Disablement Contacts
8 Contacts for generic messages
Sound Source
LINE A
LINE B
SUBWOOFER
Active
AE300

5
Front panel
The front panel of the machine has the user interface through which you can manage the system and view its status
At the top, the LEDs synthetically report the machine statuses:
•Green LED - PO ER: indicates that the machine is on and operating
•Red LED – VOICE ALARM: indicates that a voice alarm or evacuation message is being played back
•Yellow LED – FAULT ARNING: indicates that the machine, a loudspeaker line or a connection to the system is faulty
•Yellow LED – DISABLEMENT : indicates that the monitoring of one or more machine functions has been deactivated
In the central part, the display shows the details on the machine status and, through the keyboard, you can access the internal menus
Bottom-right of the user panel, the ALARM and WARNING buttons manually activate alarm or evacuation messages To activate these alarm
messages, or access the machine functions in the menus, you must login at access level 2 with the key (bottom-left) or by entering a password in
the appropriate menu
Finally, there is a PTT microphone on the machine front panel for issuing speakerphone alarm and evacuation messages To activate the
microphone, you must login at access level 2 (with key or password), then press the key on the side of the microphone to speak

6
4. INSTALLATION AND MAINTENANCE
The system must be installed by qualified personnel and in accordance with UNI Standard EN54-30
Unpack the device, loosen the two screws on the right of the front panel and rotate the door on the pins on the left side
Inside are the machine electronics composed of three or four cards, depending on the model (with or without backup amplifier)
4.a all mounting
Fix the device to the wall with wall plugs and screw through the holes on the bottom of the container, indicated in the figure below by arrows:
Use suitable type wall plugs according to the characteristics of the wall and with load from 0 30 to 0 65 kN The device must be fixed to the wall
by qualified personnel
4.b Connection of the speaker lines
The terminals for connection to the speaker lines are located top-right on the main board, just below the fairlead window Connect the
loudspeaker lines to 100V as shown in the figure The overall load applied to the two lines must not exceed 300W
When wiring the loudspeaker lines, be very careful not to short-circuit the two poles between them. If the loudspeaker lines are in short-
circuit, the system is not able to play back any alarm message, even if the fault is reported on the user interface.
J10 – Line A output 1 – 100V +
2 – 100V -
Output at 100V constant voltage for loudspeaker line A
Power levels: 100Vac nom, 300Wrms nom, Rmin=34Ohm
Use cable with min section 1 5 mm, max 2 5 mm
J10 – Line B output 1 – 100V +
2 – 100V -
Output at 100V constant voltage for loudspeaker line B
Power levels: 100Vac nom, 300Wrms nom, Rmin=34Ohm
Use cable with min section 1 5 mm, max 2 5 mm
MAINBOARD
POWER SUPPLY UNIT
J9 – 100V LINE A J10 – 100V LINE B
LINE A
LINE B

7
4.c Subwoofer output
The system has a line output for an active subwoofer
Connect the active subwoofer to the mainboard terminal shown in the figure If the subwoofer is not used, leave this output disconnected
SUBWOOFER
Attivo
Massa
Lienea Sub
12
J9 - Subwoofer
1 - Line Sub
2 - GND
J9 – subwoofer line
output
1 – SUB OUT
2 - GND
Line output to active subwoofer with roll-off at 120Hz The output is only active during
playback of the background music applied to input J4 (line input) and is silenced during
the voice alarm status
Power levels: 1 0Vrms, Ro=100ohm
Use shielded cable with min section 0 5 mm
4.d Status outputs
The system has three status signal outputs These open collector outputs require a pull-up resistor that can be omitted if the pull-up is already
present inside the equipment to which these outputs are connected (e g smoke and fire signalling station)
The following figure shows the connection of the outputs to a smoke-fire signalling station with pull-up resistors
CENTRALE
ANTI-INCENDIO
(Ingressi)
10 Komh
GND
+12V max
14
J8 - Output contacts
0,5A max open coll.
1 - GND
2 - ALARM
3 - FAULT
4 - DISABLE
J8 – Open-collector
status outputs
1 – GND
2 – ALARM
3 – FAULT
4 – DISABLEMENT
Each output supports up to 0 5Adc and voltage up to 12V
Do not directly connect the outputs to direct power supply!
Use cable with min section 0 5 mm, max 2 5 mm
Sub Line
Ground
Sub Line
Active
FIRE-FIGHTING
STATION (Inputs)

8
4.e Generic messages activation contacts
The system has 8 unsupervised inputs for activating the generic and service messages recorded on uSD memory card Each message is activated
by closing its ground input, as shown in the figure below
The playback of the message is activated by a pulse Releasing the contact after shorting it to ground has no effect, but the message will be
played till its end When a message is being played, a second pulse will stop the player
Generic messages have predefined priorities: message n has a priority over message n+1.
Example:
•When message 2 is played, the closing of contact 1 will stop message 2 and start message 1
•When message 2 is played, the closing of contact 2 will stop message 2
•When message 2 is played, the closing of contact 3 is ignored
This said, message 8 will has the lowest priority, but message 1 has the highest
Each contact is active only if an associated audio file is stored in the uSD card
1 9
J7 - Attivazione messaggi generici
1 - Comune GND
2 - messaggio 1
3 - messaggio 2
4 - messaggio 3
5 - messaggio 4
6 - messaggio 5
7 - messaggio 6
8 - messaggio 7
9 - messaggio 8
J7 – Unmonitored
contact inputs for
service messages
activation
1 – GND
2 – Message 1
3 – Message 2
4 – Message 3
5 – Message 4
6 – Message 5
7 – Message 6
8 – Message 7
9 – Message 8
Each input is active for closure to ground, protected up to +42V compared to GND
Use cable with min section 0 5 mm, max 2 5 mm
J7 – Generic messages activation
1 – Common GND
2 – Message 1
3 – Message 2
4 – Message 3
5 – Message 4
6 – Message 5
7 – Message 6
8 – Message 7
9
–
Message 8

9
4.f Alarm messages activation monitored contacts
The system has two monitored dry contact inputs to trigger the EVACUATE and ALARM (alert) messages that are stored in the uSD
card The connection foresees two resistors as described in the figure below configuration of these inputs is described in the
dedicated menu As a factory default, both inputs will trigger their respective message at the opening of the contact and the
playback will continue cyclically as long as the input is open Playback will stop at the closing of the contact
These inputs, that are typically activated by the fire alarm control panel are monitored against short circuit and cable cut: in this
case, the system will trigger a fault warning
J6 – Alarm messages
activation monitored
contact input
EVACUATION
1 – CONT 1 P
2 – CONT1 N
ALARM
3 – CONT 2 P
4 – CONT2 N
Connect the resistors (supplied in the accessory bag) on each pair of contacts as shown in
the figure The resistors must be placed at the end of the cable, from the smoke and fire
signalling station side
Refer to the CONF ALARM INPUT MODE menu for the properties and configuration of the
input contacts
The inputs of the alarm messages are, by default, configured for normally closed contacts
Use cable with min section 0 5 mm, max 2 5 mm
If you do not intend to use the remote activation of messages, you cannot leave these terminals open without the device reporting a fault
Therefore, connect two resistors directly on the mainboard terminal so that the device does not signal a connection fault
2,2 Kohm
2,2 Kohm
14
J6 - Ingresso monitorati
1-2 - Evacuazione
3-4 - Allarme
J6 – Monitored input
1-2 – Evacuation
3
-
4
-
Alarm
J6 – Monitored input
1-2 – Evacuation
3-4 – Alarm

10
4.g Generic announcement microphone workstation
The system has an input for a microphone workstation for generic announcements, that is not evacuation and voice alarm announcements The
terminal shown in the figure has a balanced microphone input and a priority contact input
The microphone input for generic announcements also has +48V phantom power supply that can be activated from the menu
Priority
Mic P
Mic N
Mic Comune
Mic
1 5
J5 - Postazione microfonica Paging
1 - 2 Contatto priority
3 - Mic +
4 - Comune
5 - Mic -
J5 – Mic paging input 1 – GND contact
2 – Priority
3 – MIC P
4 – MIC GND
5 – MIC N
Input for microphone paging workstation for generic announcements 48V Phantom
power supply that can be activated from menu: common mode on pin 1 and 3 compared
to pin 2
Power levels: 1 0Vrms max, Ri=600Ohm
Active contact for closure to ground, protected up to +42V compared to GND
Use cable with 0 5 mm min and 2 5 mm max section on priority contact
Use shielded cable with 0 5 mm min section on audio input
J5 – Paging microphone workstation
1 – 2 Priority contact
3 – Mic+
4 – Common
5 – Mic-

11
4.h Music/line input
The system has a line input for connection to an audio source for background music diffusion
You can connect both sources with balanced output and sources with unbalanced output The following figures describe the connections
Audio P
Audio N
Massa
13
J4 - Background
music
1 - Ingresso +
2 - Comune
3 - Ingresso -
SORGENTE AUDIO
USCITA BILANCIATA
For the connection of audio sources with unbalanced output, connect the positive to terminal 1, the source ground to terminal three and leave
the central terminal free
Audio P
Massa
13
J4 - Background
music
1 - Ingresso +
2 - Comune
3 - Ingresso -
SORGENTE AUDIO
USCITA SBILANCIATA
J4 – Line input for audio
sources
1 – Audio P
2 –
Common/Ground
3 – Audio N
Balanced line input, transformer insulated Used for background music diffusion
Power levels: 0 8Vrms @ 0dB, Ri=100Kohm
Use shielded cable with min section 0 5 mm
4.h Emergency microphone workstation
The system has a RJ45 input for connection to remote emergency microphone workstations and monitored according to Standard EN54-16
Connect the microphone workstation to socket rJ45 through a UTP CAT5 cable The connection between the two RJ45 pins to the cable end
must be 1-to-1
CAT5
intestato RJ45
AUDIO SOURCE
BALANCED OUTPUT
J4 – Background music
1 – Input +
2 – Common
3 – Input -
Ground
AUDIO SOURCE
BALANCED OUTPUT
J4 – Background music
1 – Input +
2 – Common
3 – Input -
Ground
CAT5
headed RJ45

12
J3 – External emergency
mic workstation port
1 – Audio P
2 – Audio Gnd
3 – Audio N
4 – GND
5 – +24Vdc
6 – GND
7 – COMM P
C – COMM N
RJ45 Connector for connection to external emergency microphone workstation This
connector carries both the audio signals and data link from and to the external
microphone workstation Connection is monitored and the system reports a fault in case
the communication with the microphone workstation is lost due to short-circuit or cable
cutting
Proprietary connection for connection to the dedicated microphone workstations only
Use 8-pole UTP CAT5 cable, 4 pairs Head the RJ45 connectors 1-to-1
4.i RS485 Serial connection
The system implements an RS485 communication port for connection to remote devices with dialogue through protocol, described in the
specific manual The following figure describes the connection between the AE300 and an external device, through RS485 port The jumper to
terminate the line is located behind the terminal With the jumper inserted, the line is terminated With the jumper not inserted, the line is not
terminated
Massa
A B
DISPOSITIVO REMOTO
Porta RS485
13
J4 - Rs485 Bus
1 - Rs485 A
2 - Rs485 B
3 - GND
Jumper
Terminazione linea
J2 – RS485 1 – RS485 A
2 – RS485 B
3 - Ground
Port RS485 not insulated
Standard power levels ANSI TIA/EIA-485
Use shielded cable with min section 0 5 mm
4.l Ethernet port
The ethernet port allows connecting the system to a company data network, or a dedicated data network, to remotely monitor the machine and
connect several machines in a hierarchical manner
ETHERNET SWITCH 10:100
Ethernet port Standard pinout Ethernet port 10/100 Base T insulated with coupling to connector built-in transformers
Use UTP CAT5 cable
REMOTE DEVICE
RS485 Port
Line Termination Jumper
Ground

13
4.m Emergency microphone installation
The device is equipped with microphone for emergency announcements, located on the front panel of the device
This microphone is monitored against faults (cable cutting, short-circuit and interruption of the microphone capsule)
Take the PTT microphone from the accessory bag, identify the round connector on the front panel This connector is equipped with a key which
determines the direction of insertion (see photo below)
Insert the microphone connector and secure it to the machine body with the appropriate ring nut, then place the microphone on the
appropriate hook
N B The device does not operate without the presence of the emergency microphone If the emergency microphone is missing, the relevant
fault is signalled on the user interface
4.n uSD memory card
The housing for the uSD memory card containing the recorded messages is located on the left side of the mainboard Before extracting or
inserting the card, activate the appropriate DISABLEMENT function of the uSD from the menu
The port-card connector is of a push-push type: to extract the card, push the uSD fully into the connector until you hear a “click”, then release
and extract the card
Insert the card with the contacts facing down and push until you hear a “click ”

14
4.o Installing and connecting batteries
The system provides the use of 4 12V 7 2A/h batteries connected in series to achieve rated 48V Install the batteries in the bottom space, on the
bottom of the container left of the toroidal transformer
The following figure shows the battery connection to the electronic card of the power supply unit
The power supply unit card is located bottom-right, between the two toroidal transformers
The faston terminals + and - 48V are on the bottom of the card
Connect the four batteries in SERIES (+ on -) with the faston-faston jumpers in the accessory bag
Connect the negative terminal of the battery pack to faston – on the power supply unit card
Take the anti-spark cable from the accessory bag and make sure that the two connectors are NOT engaged; the connection between the
batteries and the card must take place with this connector OPEN
Connect one end to the battery positive terminal and the other to the +48V terminal on the power supply unit card
Close the connector only after connecting the cable to the batteries and the card
When closing the connector the machine remains in stand-by and does not turn on
A two-pole white connector identified with “BATT TEMP PROBE” is located to the right of the fuse-holder Engage the temperature probe in the
connector and apply it to one of the batteries using adhesive tape
BATTERIA 12V 7A/h
BATTERIA 12V 7A/h
BATTERIA 12V 7A/h
BATTERIA 12V 7A/h
BATTERIA
BATTERIA
BATTERIA
BATTERIA
+
+
+
+
-
-
-
-
+-
Morsetto
sonda
Sonda Temperatura
Batterie
SCHEDA ALIMENTATORE
Cavo anti-spark
MAINBOARD
POWER SUPPLY UNIT
BATTERY
BATTERY
BATTERY
BATTERY
PO ER SUPPLY UNIT CARD
Anti-spark cable
Probe
terminal
Battery Temperature Probe
Battery
Battery
Battery
Battery

15
4.p Connection to the mains power supply and earthing
The terminal for the 230V mains power supply and earthing connection is located top-right, near the breakaway slot for cable inlet The Figure
here below shows the LINE, EARTH and NEUTRAL connections
LN
ATTENTION: Make the mains and earthing connections as shown in the above figure.
For the connection to the power mains, provide a 6A-C6 circuit breaker dedicated to the equipment; this must be placed in an easily accessible
position
Use cables with a section of 1 5 mm for both the mains power supply and earthing
Make sure that the signal cables, and the low voltage cables in general, do not accidentally touch the mains voltage points These are the
terminals for connection to the mains voltage, and the areas marked with the symbol inside the device
4.q Powering the system
After making and checking all connections, close the jumper on the anti-spark cable connecting the battery positive to the power supply unit
card (see 4 n), then activate the circuit breaker
The system display indicates “POWER ON” and so begins the switch-on sequence
4.r Monitor loudspeaker volume
The trimmer for adjusting the monitor loudspeaker volume on the front panel of the device is located on the bottom of the mainboard
(indicated by the arrow in the figure) Enable the playback of any message (see specific menu), then rotate the trimmer to obtain the desired
volume
4.s Clock battery replacement
The battery-holder for the buffer battery of the internal clock and calendar is located on the bottom of the mainboard Although these batteries
have a very long life, we recommend replacing them every 24 months
To avoid having to reset date and time, you can replace the battery with the system on and powered
Batteria
CR 2032
Battery

16
4.t Device maintenance
a) Periodically clean the device with a dry cloth
b) Periodically check that the ventilation openings are not obstructed
c) Periodically check the wiring and connections
d) Periodically check the efficiency of the earthing connection
e) Replace the Pb-Gel batteries every 4 years with units having the same voltage and capacity
f) Replace the CR2032 battery of the internal clock (see par 4q) every 4 years

17
5. MENU DESCRIPTION
6.1 Status Description
The system is designed to manage different operating conditions which, according to Standard EN54, are identified in four statuses The system
status is displayed by the LEDs on the front panel of the system and of the remote emergency microphone workstations
QUIET Status:
Operating condition “at rest”, without faults, no playback of voice alarms and no active “disablements ” Only the
diffusion of background music or generic messages (not alarm ones) is allowed When the system is in the quiet
status only the green LED is lit on the front panel of the unit, to indicate that the system is powered
ALARM Status (VOICE ALARM):
Operating condition where a pre-recorded or speakerphone voice alarm is being issued from the emergency
microphone workstation It can be activated via an external device connected to one of the supervised contacts, or
from an emergency microphone workstation While a voice alarm is issued, the system turns on the red LED to
indicate the voice alarm status The green LED remains on to indicate that the system is powered
The display will show a POP-UP window indicating the source of the voice alarm in progress
FAULT Status (FAULT ARNING):
Operating condition indicating the presence of at least one fault detected by the internal diagnostic system The
status indication is accompanied by a fault intermittent acoustic signal (buzzer) and the yellow LED lighting up on
the unit panel The green LED remains on to indicate that the system is powered
The display will show a POP-UP window indicating the number of detected faults and a brief description
DISABLEMENTS Status:
Operating condition in which the functions of one or more system sections are disabled
Even the faults related to the disabled section are suspended since safety functions are deactivated This condition
allows operating on the system without turning it off and without the fault condition (FAULT WARNIGS) being
activated
The display will show a POP-UP window indicating the number of active “disablements” and a brief description of
the section(s)
NOTE: Operating conditions may also occur simultaneously The LEDs corresponding to the active conditions will light up on the front panel and
the display will show a POP-UP window indicating which and how many events are active If the number of events exceeds the number of rows
of the POP-UP window, indications will cyclically scroll on the display In this case you can view entries using the UP and DOWN arrows

18
6.2 Main Screen
In the absence of warnings, the main screen shows the following information:
•System time: shows the current system time; for the system events to be properly recorded, this should
be always updated It is also important to verify that seconds are regularly counted, otherwise the system
CPU may be locked
•Current access level: A key indicates the current access level 1, 2 or 3
•System status: The “System OK” text indicates that the system is operating
In case of a fault, a POP-UP window will appear indicating the number of active faults, the presence and
number of “disablements” and if an alarm message is in progress
Icons
Current access level: a key positioned bottom-left of the display indicates the current access level: 1, 2 or 3
Message playback with active repeat rules In case alarm or evacuation messages are played back, an icon with
two alternate arrows may appear to indicate the presence of rules in the number of repetitions of the current
message The rules impose a minimum number of reproductions and/or a maximum number of reproduction
cycles
Fault of one of the two lines A or B with volume increase In case of line fault with redundant A&B line, an icon
will appear to indicate that the “non-faulty” line is working with an indicated volume increase
Mute on With mute on, an icon with the loudspeaker crossed is displayed to indicate that the mute is active
During the playback of a pre-recorded or voice message you can activate the “MUTE” function by pressing the
appropriate button on the front panel; when on, an icon with a crossed loudspeaker appears on the display
To deactivate, simply press the appropriate button again and mute will be removed
NOTE: as per EN54-16, when “Mute” is activated during the playback of a pre-recorded message, the output is
muted only at the end of the message itself to avoid compromising its intelligibility Likewise, when mute is
removed, the message will be played back at the end of the reproduction cycle Mute activation while an
emergency microphone is “speaking” is immediately effective
Warning on In case of a system event, a flashing triangle appears to attract the user’s attention The warning is
removed when you access the “System Logs” system event menu, which lists the system events

19
6.3 Menu Description And Navigation
Using the keyboard on the front panel
From the home screen where the display shows the general status, press OK to access the menu
structure.
The OK key in the sub-menus is used to confirm the selection of the element pointed by the navigation
arrow.
Use the U and DOWN keys to scroll the list of menus and sub-menus.
ress OK to access the menu or sub-menu pointed by the navigation arrow.
ress BACK to go back to the previous menu or cancel the selection of a function. Repeatedly pressing
the BACK key from any workstation returns to the main screen.
Alternatively, you can access the selected menu or sub-menu by pressing the RIGHT key, and go back to
the previous menu or sub-menu by pressing the LEFT key.
The main menu is structured in the form of a list in which the functional parts of the system are managed:
Menu tree
•Line & Amplifiers Management of Diffuser lines and amplifiers
•Power supply & Battery Management of primary power supply (220V) and secondary (Battery)
•Fire microphone Management of the emergency microphone workstations
•Recorded messages & SD Management of pre-recorded messages on micro-SD card
•Input contacts Management of contacts to launch messages
•Ethernet Management of ethernet connection
•System status & Conf System configuration
•Volumes Volumes configuration
•Message Scheduler Configuration of hourly programming of pre-recorded messages
•System Logs Display of system events
•Access level login User authentication

20
LINE & AMPLIFIERS Menu
The Line & Amplifiers menu allows you to view and manage the status of amplifiers
and speaker lines They appear in the form of a list and can be scrolled using the UP
and DOWN arrows Each amplifier and speaker line is linked to the summary status:
Status of the amplifiers:
DISABLED  Disabled (Disablement)
ABSENT  Not installed
FAULT  Faulty
WARNING  Pre-alarm condition
OK  Running
Status of the lines:
DISABLED  Disabled (Disablement)
NOT IN USE  Not in use
NO CALIB  Impedance not calibrated
FAULT  Faulty
OK  Running
The system works with a Main amplifier and a possible Back p amplifier Both the
main amplifier and the backup amplifier, if installed, are monitored to ensure
effectiveness; in case of a faulty main amplifier, the backup amplifier automatically
takes over, if installed
For details of the status of the amplifiers you can select from the list and press OK to
access the Main amplifier detail / Back p amplifier detail screen that indicates the
status in detail In particular, the display shows the type of amplifier selected and its
operating status:
Func: Connected / Active  Connected to the load and active
Connected / Powerdown  Connected to the load and in energy saving
mode
Disconneted / Powerdown Disconnected from the load and in energy
saving mode
The system works with a single line of speakers that can be managed in single or
double mode, also called A&B mode The content diffused via speakers is unique in
both single-line and double-line mode, A&B line The difference between the two
modes is the possibility, in A&B mode, to manage a fault on the speaker line and
recover the lost sound pressure by transferring power on the line that is still operating
In the event of a fault, e g short-circuit, of the single-mode speaker line (not A&B), the
system isolates the line to avoid damaging the amplifier, making it impossible to
diffuse any contents On the contrary, if the line of speakers was wired in double
mode, alternating a line A speaker with a line B speaker and homogeneously
distributing the speakers on the surface to be sonorised; in the event of a fault on one
of the two lines, e g short-circuit, the system isolates the faulty line and increase the
volume of the remaining line so as to recover the lost sound pressure
