Service settings for the PID-temperature regulation
Profitec Pro700
Through the service modus of the PID-display, you have the possibility to customize the parameters of
the attached table according to your customer’s wishes.
Setup
To set up the requested parameters, please proceed as follows:
1. Press + and -simultaneously while the machine is switched off and switch the machine on.
Release the keys only after “F.01” is being displayed. The temperature of either boiler is not
important for programming, as both boilers are inactive during programming.
2. Press -to select the different parameter which are displayed in order. As soon as you have
reached “E3” and have again pressed - you will start with “F.01” once more.
3. Press +in order to progress to the submenu of the currently selected parameter.
4. Quickly press +to increase and -to decrease the desired value.
5. After the set-up of the desired value please wait a short amount of time until the initially se-
lected parameter (e.g. “F.01”) appears again.
6. To change another parameter, start over with step 2 again.
7. Turn off the machine once you have finished programming.
8. Wait at least 10 seconds before switching the machine on again.
9. The programmed values are now saved. Both boilers are activated (successively).

Profitec Pro700
Service settings
Parameter Display Function Explanation
F.01
°F Temperature in degrees Fahrenheit
°C Temperature in degrees Celsius
F.02 2 Activation of the boiler heater brew group Only the brew group is heated
3Activation of the steam/hot water boiler Only the steam/hot water boiler is heated
4Not assigned
5Activation of the heaters for both boilers Both boilers are heated => high wattage!
6Not assigned
7
Activation of the heaters for both boilers, whereby the brew
group boiler is preferred
Steam/hot water boiler will be heated only after the temperature of the
brew group boiler is reached => both boilers are never heated
simultaneously => safes energy
P. X.X Value of the consistent, proportional control Please do not change recommended settings!
I. X.XX Value of the consistent, integral control Please do not change recommended settings!
d. XX.X Value of the consistent, derivative control Please do not change recommended settings!
t1 XX Desired value in the brew group boiler Desired temperature value at the measuring point
t2 XX Desired value in the brew steam/hot water boiler Desired temperature value at the measuring point, max. 128°C
t3 Not assigned
E1 X Temperature difference measuring point to the display Example: 10°C: measuring point 100°C => display 90°C
E2 X Temperature difference measuring point to the display
E3 Not assigned
Recommended Settings
Parameter Display Function Explanation
F.01 °C Temperature in degrees Celsius
F.02 7 Activation of both heaters, whereby the brew group boiler
is preferred
Steam/hot water boiler will be heated only after the temperature of the
brew group boiler is reached => both boilers are never heated
simultaneously => safes energy
P. 2.5 Value of the consistent, proportional control Please do not change recommended settings!
I. 0.02 Value of the consistent, integral control Please do not change recommended settings!
d. 8 Value of the consistent, derivative control Please do not change recommended settings!
t1 93 Desired value in the brew group boiler Desired temperature value at the measuring point
t2 124 Desired value in the brew steam/hot water boiler Desired temperature value at the measuring point, max. 128°C
t3 Not assigned
E1 14 Temperature difference measuring point to the display Example: 10°C: measuring point 100°C => display 90°C
E2 0 Temperature difference measuring point to the display
E3 Not assigned
Error messages
Display Error Source Explanation
A1 Sensor boiler brew group Disconnection, sensor has no contact
A2 Sensor boiler brew group Temperature safeguard (150°C) triggeres, electrical short
A3 Sensor boiler steam/hot water Disconnection, sensor has no contact
A4 Sensor boiler steam/hot water Temperature safeguard (150°C) triggeres, electrical short
A5 Not assigned
A6 Not assigned
