ProFusion SHAG-L02F User manual

Industrial
Fan Forced Heater
Stop
Please read and understand this manual before any assembly
or use of this product.
Before beginning assembly of product, make sure all parts
are present.
Customer Service: 1-888-538-0082 / [email protected]
Instruction Manual
Industrial Fan Forced Heater
Model No. SHAG-L02F

Industrial Fan Forced Heater
2
Table of Contents
Technical Specifications
Model : SHAG·L02F
Voltage :
:
240/208 VAC
Frequency 60 Hz
Watt : 4800W/3600W
2
3
5
5
6
6
7
Technical Specifications
Important Instructions
Parts of the Heater
Grounding and Operating Instructions
Cleaning and Maintenance
Storage
Troubleshooting

3
Industrial Fan Forced Heater
Important Instructions
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO
REDUCE RISK OF FIRE, ELECTRICAL SHOCK AND INJURY TO PERSONS OR PROPERTY, INCLUDING THE
FOLLOWING:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep
combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 ft.
(0.9 meters) from the front and top of the heater and keep them away from the sides and rear. Ensure
a minimum clearance of 5.5 inches (14 cm) from both sides and rear of heater to adjacent walls. Keep
the rear grille away from walls or drapes so as not to block the air intake.
3. Extreme caution and reasonable supervision is necessary when any heater is used by or near children,
invalids or pets and whenever the heater is left operating and unattended.
4. Always unplug heater when not in use. To disconnect, grip plug and pull from wall outlet. Never yank
on cord.
5. To disconnect the heater, turn controls to "OFF" (), then remove the plug from outlet.
6. Do not operate any heater with a damaged cord or plug or after the heater malfunctions or has been
dropped or damaged in any manner. Return heater to an authorized service facility for examination,
electrical or mechanical adjustment or repair.
7. Do not use outdoors.
8. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never
locate heater where it may fall into a bathtub or other water container.
9. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or the like. Do not route
cord under furniture or appliances. Arrange cord away from trac area where it will not be tripped
over. Route the cord so that it will not be walked on, or pinched by furniture.
10. Connect to properly grounding outlets only. Check heater voltage and amperage on the back of the
heater to make sure it agrees with the electric service supplied.
11. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an
electric shock, fire or damage to the heater.
12. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft
surfaces, like a bed, where openings may become blocked.
13. Use this heater only as described in this manual. Any other use not recommended by the manufacturer
may cause fire, electric shock, injury to persons or other damage to property.
14. This heater draws 23.3 Amps during operation. Be sure to use a dedicated 240VAC, 30A circuit for the
heater.
PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS HEATER.
NOTE: There may be a trace of smoke or odor when unit is first operated. Do not be alarmed. This indicates
that a drop of oil fell on the heating coil during the manufacturing process. It will quickly evaporate and
should not re-occur.
Make sure that the room in which the appliance is located is well ventilated during this operation. It is normal
for the appliance to emit small cracking sounds when you turn it on for the first time. Do not be alarmed.

4
Industrial Fan Forced Heater
SAVE THESE INSTRUCTIONS.
CAUTION: This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
PET OWNERS WARNING: The health of some small pets including birds are extremely sensitive
to the fumes produced during the first-time use of many appliances. These fumes are not harmful
to humans but we recommended that you do not use your heater around birds and small pets
during its initial use until the manufacturing corrosion coatings burn o.
WARNING: NOT FOR HOUSEHOLD USE. THIS IS A FLOOR HEATER ONLY.
RISK OF FIRE, DO NOT USE AS A RESIDENTIAL OR HOUSEHOLD HEATER
15. It is normal for the heater's plug and cord to feel warm to the touch. A plug or cord which becomes
hot to the touch or becomes distorted in shape may be a result of a worn electrical outlet. Worn
outlets or receptacles should be replaced prior to further use of the heater. Plugging heater into a
worn outlet/receptacle may result in overheating of the power cord or fire.
16. Ensure the heater is on a stable, secure floor surface to eliminate the potential of tipping it over.
17. Be sure that the plug is fully inserted into appropriate receptacle. Please remember that receptacles
also deteriorate due to aging and continuous use: check periodically for signs of overheating or
deformations evidenced by the plug. Should this occur, do not use the receptacle if deteriorated.
CALL your electrician.
18. Check that neither the appliance nor the power cable has been damaged in any way during
transportation.
19. Make sure that no pieces of polystyrene or other packaging material have been left between one
element of the appliance and another. It may be necessary to pass over the appliance with a vacuum
cleaner.
20. When switching on the appliance for the first time, you may notice a slight odor which is normal with
new electrical appliances. Allow odor to dissipate by running appliance at full power for about ten
minutes. Make sure that the room in which the appliance is located is well ventilated during this
operation. This heater draws 23.3 Amps during operation. To prevent overloading a circuit, do not
plug the heater into a circuit that already has other appliances working.
21. Do not run in locations when the heater will be left unattended for long periods of time. (For example
- in an unoccupied summer cottage).
22. Do not use attachments or filters. They are not recommended.
23. Always plug heater directly into a wall outlet/receptacle. Never use with an extension cord or
relocatable power tap (outlet power strip). A heater has hot and arcing or sparking parts inside. Do
not use it in areas where gasoline, paint, or flammable liquids are used or stored.
24. A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or
flammable liquids are used or stored.

5
Industrial Fan Forced Heater
Your heater is equipped with a thermostat:
1. Turn the unit on by turning the thermostat dial away from the OFF position ().
2. Once the room reaches the desired temperature, slowly turn the Thermostat Control knob counter
clockwise until you hear a "click". This sets the heater to cycle ONIOFF to maintain the desired
heating temperature for energy eciency.
3. To completely shut unit OFF, turn the thermostat dial to the OFF position () and unplug the heater.
Parts of the Heater
1. Carry handle
2. Housing
3. Safety grille
4. Heating element
5. Thermostat control
6. Plug (NEMA #6-30P)
Grounding and Operating Instructions
IMPORTANT: THIS HEATER IS FOR USE ON THE FLOOR ONLY.
Prior to operating the heater, ensure the electrical receptacle is of the configuration and capacity
appropriate for the heater. See receptacle configuration in OPERATING INSTRUCTIONS. This heater is for
use on 240 volts. The cord has a plug as shown in #6. No adapter is available for this blade configuration,
and none should be used. The type of receptacle is a 240 volt grounding receptacle (NEMA 6-30R). When
properly installed, it provides a ground connection through the cord to the heater to protect the operator
from electric shock.
Receptacle: NEMA #6-30R 250V 30 Amps Plug: NEMA #6-30P 250V 30 Amps
1
2
3
4
5
6

6
Industrial Fan Forced Heater
CAUTION: DO NOT ALLOW WATER TO RUN INTO THE INTERIOR OF THE HEATER AS THIS
COULD CREATE A FIRE OR ELECTRIC SHOCK HAZARD, DAMAGING THE UNIT.
Cleaning and Maintenance
Before any cleaning, make sure that:
1. The heater is turned OFF.
2. Disconnect power supply at source by removing plug from power outlet.
3. Your heater is now ready for cleaning.
Regular Cleaning:
1. Do not use cleaning liquid or other chemicals to spray on the unit.
2. Interior dust can often be removed by using a vacuum cleaner with a crevice tool attachment.
3. To clean enclosure, use a clean, soft and lightly damp cloth to gently wipe o the dirt from the surface
of the unit. Be sure not to wet the heating element and the switches. Allow the unit to dry completely
before using it.
Storage
1. Perform the cleaning procedures described in "Cleaning/Maintenance".
2. Wipe all parts to dry.
3. Pack the heater in a plastic bag and store it in a cool, dry place.

7
Industrial Fan Forced Heater
Troubleshooting
If your heater fails to operate, please follow these procedures:
PLEASE DO NOT ATTEMPT TO OPEN OR REPAIR THE HEATER YOURSELF.
DOING SO COULD CAUSE DAMAGE OR PERSONAL INJURY.
Overheat protection has temporarily
deactivated the heater.
A drop of oil fell on the heating coil
during the manufacturing process. It
will quickly evaporate and should not
occur again.
Unit is not
heating.
The heater is
creating a
burning smell.
Turn the heater OFF; unplug it and ALLOW IT
TO COOL. Inspect and remove any objects on
or adjacent to the heater. Wait 30 minutes
before plugging unit back in.
Room temperature has been
warmed up to thermostat setting.
To increase the room temperature, adjust
thermostat control knob to a higher setting by
turning clockwise.
Ensure room in which heater is situated is
well ventilated.
Check & ensure there are no
combustible materials within 0.9
meters (3 feet) surrounding the heater.
Remove any combustible items from
the heater.
Problem Probable Cause Solution
Heater is not plugged into a 240V
grounding outlet/receptacle.
Ensure unit is in OFF position (). Plug in unit
and attempt to turn on again.
Breaker/Fuse has been tripped. • Check your electrical box to confirm the
breaker has not been blown. This may
occur if the receptacle is shared between
other high consumption appliances.
• Ensure unit is in the OFF position (). Plug
in unit and attempt to turn on again.
Ensure a minimum clearance of
5.5 inches (14 cm) from both sides and
rear of heater to adjacent walls.
Reposition the heater so there is enough
space around the heater to the adjacent
walls.
