Promet Master Series Installation guide

Assembling instructions series Master workbench
1
2. Using bolts М8х16 (and nuts and collars) attach worktop brackets to the stands.
Brackets should be fitted to the first rectangular holes at the top of the stands and aligned
top of the stands.
2
Edition 8, 05.06.18
page 1/6 page 2/6
Worktop M-100/MT-100
Panel WS-100
Frame MF-1
Beam M-90
Drawer M-140
Shelf M-100
Assembling frame MF-1
A
View A
(assembling horizontal and diagonal beams to the stand)
Bolt М6х40
Collar М6 Nut М6
Stand MF-1
Horizontal beam
Diagonal beam
1. Using bolts М6х40 (and nuts and collars), assemble horizontal
and diagonal beams and stands as it’s shown at the picture.
Bottom horizontal beam should be fitted to the 2nd hole of the
stand, top horizontal beam should be fitted to the 2st hole of the
stand at the top.
Bolt М8х16
Collar М8
Nut М8
Worktop bracket
3. Using bolts М8х16 (and nuts and collars) attach floor leg supports (should be ordered
separately). Floor leg supports should be fitted to the first rectangular holes at the bottom
of the stands.
1
Assembling beams M-90
Bolt М8х16
Collar М8
Nut М8
Worktop bracket
Frame MF-1
Beam M-90
Frame MF-1
Beam M-90
Beam M-90
BC
IMPORTANT: do not fix the beams bolts too tight – you will do it later.
After assembling beams tight all the
bolts hard. In case if you assemble
drawer M-140 fix the drawer brackets
(Point 8 of this instruction).

Assembling galvanized steel worktop cover MT-100
page 3/6 page 4/6
3
Assembling worktop M-100/MT-100
Frame MF-1
Worktop M-100/MT-100
Metal plate
Screw 4.2х19
View D
(assembling worktop to the stand)
D
1. Using screws 4.2х19 fix the worktop to the
frames, using metal plates. (View D)
Worktop steel cover
Screw
1. Put the steel cover on the worktop.
2. Fix with the screws.
4
Assembling perforated panel WS-100
1. Using bolts collars and nuts attach the
perforated panel to the brackets.
2. Attach panels and brackets to the
worktop using screws.
Right bracket
Bolt М5х12
Collar М5
Nut М5
Screw
Left bracket
Panel
5
2
1. Fix the beams as it’s shown at the
picture.
2. Fix the beam holders as it’s shown at
the picture.
B
C
Beam holder
Beam
Stand
Stand
Beam

6
page 5/6 page 6/6
7
7
8
2
1
Assembling shelf M-100
E
View E
(attaching shelf supports)
1. Put shelf supports to the stands (View E).
Check the level.
2. Put the shelf M-100 on the supports.
Assembling drawer M-140
Fold at 30°
View F
Fold
Front
panel
fixer
F
F
Front panel
Drawer bottom
Drawer bottom
1. Fold sidewalls of the drawer at 30°, as it’s
shown at the picture.
2. Attach front panel to the drawer
bottom using front panel fixers and
drawer bottom holes. Fold sidewalls of
the drawer.
Fold fixers (View F).
3. Assemble back panel as it is shown at
the picture and attach it to the drawer
bottom with the screws.
Front panel
Drawer bottom
Drawer back panel
Screw
End plug
1
2
Fixer
а) Pull it out till the end
б) Unfold plastic fixer
в) Pull out the part of guide rail totally
Holes for the rail fixers
View G
View H
H
G
Rail fixer
Rail fixer
Assembled drawer
1
2
4. Fix end plugs at it is shown at the picture.
5. Disassembling guide rails:
6. Attaching rail to the drawer
1
2
Drawer brackets
Holes for the rail fixers
Attaching the drawer M-140
1. Attach guide rail part to the bracket as it
is shown at the picture. Unfold fixers with a
screwdriver if needed.
1
2
2. Attach drawer bracket as it is shown at
the picture. Unfold bracket fixers with a
screwdriver if needed. After assembling
brackets (before you attach the drawer)
please fix the brackets to the stands with
the screws using round holes of the
brackets.
Drawer brackets
Worktop M-100/MT-100
Frame MF-1
Shelf M-100
