protech BE-0961 User manual

USER
MANUAL
BE-0961
3.5” SBC with Intel®Celeron® /
AtomTM SoC on Top Side
(Baytrail-M/I) / Dual LAN
BE-0961 M5

BE-0961
3.5” Single Board Computer
COPYRIGHT NOTICE & TRADEMARK
All trademarks and registered trademarks mentioned herein are the
property of their respective owners.
This manual is copyrighted in Mar 2023. You may not reproduce or
transmit in any form or by any means, electronic, or mechanical,
including photocopying and recording.
DISCLAIMER
This user’smanual is meant to assist users in installing and setting up
the system. The information contained in this document is subject to
change without any notice.
CE NOTICE
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required totake
adequate measures.

FCC NOTICE
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment
not expressly approve by the party responsible for compliance could
void your authority to operate such equipment.
CAUTION: Danger of explosion may occur when the battery
is incorrectly replaced. Replace the battery
only with the
same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s
instructions.
WARNING: Some internal parts of the system may have high
electrical voltage. We strongly recommend that only qualified
engineers are allowed to service
and disassemble the
system. If any damages should occur on the system and are
caused by unauthorized servicing, it will not be covered by
the product warranty.

i
Contents
1Introduction ......................................................................................... 1-1
1.1 About This Manual .................................................................... 1-2
2Getting Started .................................................................................... 2-1
2.1 Packing List ............................................................................... 2-2
2.2 BE-0961 Specifications ............................................................. 2-3
2.3 Safety Precautions .................................................................... 2-7
3Hardware Configuration ..................................................................... 3-1
3.1 JUMPER & CONNECTOR QUICK REFERENCE TABLE........ 3-2
3.2 COMPONENT LOCATIONS OF SYSTEM MAIN BOARD ....... 3-3
3.2.1 Top View of BE-0961 ......................................................... 3-3
3.2.2 Bottom View of BE-0961 ................................................... 3-5
3.3 HOW TO SET JUMPERS ......................................................... 3-6
3.4 Setting Connectors and Jumpers.............................................. 3-8
3.4.1 COM PORT (COM1 ~ COM4) ........................................... 3-8
3.4.2 COM2 RS-232/422/485 SELECTION (JP_COM2) ......... 3-10
3.4.3 COM3 & COM4 RI & VOLTAGE SELECTION (JP_COM3,
JP_COM4)....................................................................... 3-11
3.4.4 USB PORT & CONNECTOR (USB10, JUSB1) .............. 3-12
3.4.5 LAN PORT (LAN1, LAN2) ...............................................3-13
3.4.6 VGA PORT (VGA1) ......................................................... 3-14
3.4.7 CLEAR CMOS DATA SELECTION (JP3)........................ 3-14
3.4.8 Auto boot-up after AC returns from power-loss (JP16) ... 3-15
3.4.9 LVDS VCC VOLTAGE SELECTION (JP14) ....................3-15
3.4.10 FRONT PANEL SELECTION (JP17)...............................3-16

ii
3.4.11 POWER CONNECTOR (PWR_CN1).............................. 3-17
3.4.12 SATA & SATA POWER CONNECTOR (SATA1, SATA_PWR1)
......................................................................................... 3-17
3.4.13 DIGITAL I/O CONNECTOR (DIO1) ................................. 3-18
3.4.14 AUDIO CONNECTOR (JAUDIO1) .................................. 3-18
3.4.15 FAN CONNECTOR (FAN1) .............................................3-18
3.4.16 BACKLIGHT CONNECTOR (INV1).................................3-19
3.4.17 BATTERY CONNECTOR (BAT1).................................... 3-19
3.4.18 CFAST VOLTAGE SELECTION (JP7) ............................ 3-19
3.4.19 LVDS CONNECTOR (LVDS1).........................................3-20
4Software Utilities ................................................................................. 4-1
4.1 Introduction................................................................................ 4-2
4.2 Installing Intel®Chipset Software Installation Utility .................. 4-3
4.3 Installation of Utility for Windows 8 / Windows 7....................... 4-4
4.4 INTEL®USB3.0 EXTENSIBLE HOST CONTROLLER
INSTALLATION UTILITY........................................................... 4-5
4.5 Installation Instructions for Windows 7...................................... 4-5
4.6 INTEL®TRUSTED EXECUTION ENGINE INSTALLATION
UTILITY ..................................................................................... 4-6
4.6.1 Installation Instructions for Windows 8 / Windows 7 ......... 4-6
4.7 INSTALLATION OF VGA DRIVER UTILITY.............................. 4-7
4.8 LAN DRIVER UTILITY .............................................................. 4-8
4.9 SOUND DRIVER UTILITY ........................................................ 4-9
5BIOS SETUP ........................................................................................ 5-1

iii
5.1 Introduction................................................................................ 5-2
5.2 Accessing Setup Utility.............................................................. 5-3
5.3 Main........................................................................................... 5-7
5.4 Advanced .................................................................................. 5-9
5.4.1 Advanced – ACPI Settings .............................................. 5-10
5.4.2 Advanced – F81866 Super IO Configuration .................. 5-11
5.4.3 F81866 Super IO Configuration – Serial Port 1 Configuration
......................................................................................... 5-12
5.4.4 F81866 Super IO Configuration – Serial Port 2 Configuration
......................................................................................... 5-13
5.4.5 F81866 Super IO Configuration – Serial Port 3 Configuration
......................................................................................... 5-14
5.4.6 F81866 Super IO Configuration – Serial Port 4 Configuration
......................................................................................... 5-15
5.4.7 Advanced – Hardware Monitor........................................5-16
5.4.8 Advanced - F81866 Watchdog ........................................ 5-17
5.4.9 Advanced – CPU Configuration ......................................5-19
5.4.10 Advanced –IDE Configuration ......................................... 5-22
5.4.11 Advanced – OS Selection ............................................... 5-24
5.4.12 Advanced – CSM Configuration ...................................... 5-25
5.4.13 Advanced – USB Configuration....................................... 5-27
5.5 Chipset .................................................................................... 5-29
5.5.1 Chipset - North Bridge ..................................................... 5-30
5.5.2 Chipset - South Bridge .................................................... 5-33
5.6 Security ................................................................................... 5-37
5.7 Boot ......................................................................................... 5-38
5.8 Save & Exit.............................................................................. 5-41

iv
Appendix A EXPANSION BUS.....................................................A-1
CFAST SLOT PIN ASSIGNMENT ............................................................A-2
Appendix B Technical Summary ................................................B-1
Block Diagram ..........................................................................................B-2
I/O Map .....................................................................................................B-3
Interrupt Map ............................................................................................B-7
Memory Map...........................................................................................B-15
Watchdog Timer Configuration ...............................................................B-17
Flash BIOS Update.................................................................................B-20

BE-0961 SERIES USER MANUAL
Page: 1-1
1 Introduction
This chapter provides the introduction for the BE-0961
system as well as the framework of the user manual.
The following topics are included:
•About This Manual

Chapter 1 Introduction
BE-0961 SERIES USER MANUAL
Page: 1-2
1.1 About This Manual
Thank you for purchasing our BE-0961 with Intel® 4th Gen. AtomTM E3000/N2000
SBC enhanced with VGA/Audio/2LAN/4COM, which is fully PC/AT compatible.
The BE-0961 provides faster processing speed, greater expandability and can handle
more tasks than before. This manual is designed to assist you how to install and set up
the system. It contains four chapters. Users can apply this manual for configuration
according to the following chapters:
The following section describes the structure of this user manual.
Chapter 1 Introduction
This chapter introduces the system as well as the framework of this user manual.
Chapter 2 Getting Started
This chapter describes the package contents and system specifications.
Chapter 3 Hardware Configuration
This chapter describes the locations and functions of the motherboard components.
You will learn how to properly configure the connectors and configuration jumpers on
the motherboard and configure the motherboard to meet your own needs.
Chapter 4 Software Utilities
This chapter indicates you how to set up the BIOS configurations.
Chapter 5 AMI BIOS Setup
This chapter provides BIOS setup information.
Appendix A Expansion Bus
This appendix introduces you the expansion bus for a CFast slot.
Appendix B Technical Summary
This appendix gives you the information about the Technical maps, Flash BIOS
Update and the Watchdog-timer configuration.

BE-0961 SERIES USER MANUAL
Page: 2-1
2 Getting Started
This chapter provides the information for the BE-0961
system. It describes the package contents and outlines the
system specifications.
The following topics are included:
•Package List
•System Specification
•Safety Precautions
Experienced users can go to Chapter 3 System
Configuration on page 3-1 for a quick start.

Chapter 2 Getting Started
BE-0961 SERIES USER MANUAL
Page: 2-2
2.1 Packing List
If you discover any of the items listed above are damaged or lost,
please contact your local distributor immediately.
Item
Q’ty
BE-0961
1
Quick Reference Guide
1
Manual / Driver DVD
1
Mini Jumper (2.0 mm)
6
SATA & SATA Power Y-type Cable (150mm)
1
DC In Power Cable (200mm)
1

Chapter 2 Getting Started
BE-0961 SERIES USER MANUAL
Page: 2-3
2.2 BE-0961 Specifications
•General temperature SKU:
Model
BE-0961RC-30N
BE-0961RC-07N
BE-0961RC-M0N
BE-0961RC-M7N
Operating Temp.

-0°~60°C w/ heatsink
Humidity
Operating/Storage humidity 20~95%
Storage Temp.
-40°C ~85°C
RoHS
RoHS Version.
Dimensions
3.5” SBC Platform, 102mm x 145mm, 1.6mm PCB thickness
CPU
Celeron N2930
(Baytrail-M)
Celeron N2807
(Baytrail -M)
Celeron N2930
(Baytrail -M)
Celeron N2807
(Baytrail -M)
S ATA
1 x SATA II port
N/A
Expansion
Slot/mSATA/
S ATA
1 x half-sized mPCIe
(on bottom side)
1 x half-sized mSATA
(on bottom side)
CFast
1 x CFast Slot (on bottom side)

Voltage level is selected by jumper (Default: 3.3V)
PCH
N/A (integrated in SoC)
BIOS
AMI UEFI BIOS
OS Support list
Windows 10 32/64bit
Windows 8.1 32bit/64bit
Windows 7 32/64 bit

Ubuntu 14.04 32/64bit
Memory Support
1x SO-DIMM socket, supporting 1066/1333 DDR3L memory
up to 8G (non-ECC) (on bottom side)
Display
1x VGA (Rear I/O), resolution: up to 1920x1200@60Hz
1x LVDS (Internal connector), Dual Channel, 24-bit,
resolution are set by customized BOM selection
LVDS connector supports LVDS_VCC 3.3V/5V selectable by
jumper (Default: 3.3V)
LV D S
Backlight
JINV 6-pin connector supports 12V,BLEN, PWM for panel
backlight power/enable/dimming:
PWM’s voltage level is fixed to 3.3V
PWM’s duty cycle can be controlled by Windows built-in
APP

BLEN pin is obtained directly by CH7511
LAN
Dual LAN (2xRJ45 on Rear I/O)
Supports Wake-On-LAN

Controller : 2 x Intel I210-IT (MAC+PHY, PCIe interface )

Chapter 2 Getting Started
BE-0961 SERIES USER MANUAL
Page: 2-4
Sound
Line In / Line Out / Mic In (onboard pin header)
Codec IC: Realtek ALC888 (High Definition Codec)
USB Ports
3 USB ports:
1 x USB 2.0 (Rear I/O)
1 x USB 3.0 (Rear I/O)
1 x USB 2.0 (internal pin header)
Serial Ports
4 COM ports (internal pin header):
COM1: RS-232
COM2: RS-232/422/485, selected by Jumper
COM3: RS-232 w/ 5V/12V/RI selectable by jumper
COM4: RS-232 w/ 5V/12V/RI selectable by jumper
Digital I/O
4bit DI / 4 bit DO 8 bit (internal pin header)
DIO Pin header provides 5V power pin / GND pin
Front Panel
2x5 Pin header: HDD LED / PWR LED / RST BTN / PWR
BTN
Buzzer
N/A
Other Function
1 x 3-pin CPU FAN connector
Power Supply
Supports only DC 12V power input (1x 4 pin power
connector)

Chapter 2 Getting Started
BE-0961 SERIES USER MANUAL
Page: 2-5
•Wide temperature SKU:
Wide temperature
SKU: Model
BE-0961RC-W1N BE-0961RC-W2N
BE
-0961RC-E1N BE-0961RC-E2N
Operati
ng Temp.
-30°e~85°C w/
heatsink
-40°~85°C w/
heatsink
-30°~85°C w/
heatsink
-40°~85°C w/
heatsink
Humidity
Operating / Storage humidity 20~95%
Storage Temp.
-40°~85°C
RoHS
RoHS Version.
Dimensions
3.5” SBC Platform, 102mm x 145mm, 1.6mm PCB thickness
CPU
Atom E3815
(Baytrail-M)
Atom E3825
(Baytrail -M)
Atom E3815
(Baytrail -M)
Atom E3825
(Baytrail -M)
S ATA
1 x SATA II port
N/A
Expansion
S l o t / m S ATA / S ATA
1 x half-sized mPCIe
(on bottom side)
1 x half-sized mSATA
(on bottom side)
CFast
1 x CFast Slot (on bottom side)
Voltage level is selected by jumper (Default: 3.3V)
PCH
N/A (integrated in SoC)
BIOS
AMI UEFI BIOS
OS Support list
Windows 10 32/64bit
Windows 8.1 32bit/64bit
Windows 7 32/64 bit

Ubuntu 14.04 32/64bit
Memory Support
1x SO-DIMM socket, supporting 1066/1333 DDR3L memory
up to 8G (non-ECC) (on bottom side)
Display
1x VGA(Rear I/O), resolution: up to 1920x1200@60Hz
1x LVDS(Internal connector), Dual Channel, 24-bit, resolution
are set by customized BOM selection,
LVDS connector supports LVDS_VCC 3.3V/5V selectable by
jumper (Default: 3.3V)
LV D
S
Backlight
JINV 6-pin connector supports 12V,BLEN, PWM for panel
backlight power/enable/dimming:
PWM’s voltage level is fixed to 3.3V
PWM’s duty cycle can be controlled by Windows built-in APP

BLEN pin is obtained directly by CH7511
LAN
Dual LAN (2xRJ45 on Rear I/O)
Supports Wake-On-LAN
Controller : 2 x Intel I210-IT (MAC+PHY, PCIe interface )
Sound
Line-in / Line-out / MIC-in (onboard pin header)

Codec IC: Realtek ALC888 (High Definition Codec)

Chapter 2 Getting Started
BE-0961 SERIES USER MANUAL
Page: 2-6
USB
Ports
3 USB ports:
1 x USB 2.0 (Rear I/O)
1 x USB 3.0 (Rear I/O)
1 x USB 2.0 (internal pin header)
Serial
Ports
4 COM ports (internal pin header):
COM1: RS232
COM2: RS232/422/485, selected by Jumper
COM3: RS232 w/ 5V/12V/RI selectable by jumper

COM4: RS232 w/ 5V/12V/RI selectable by jumper
Digital I/O
4bit DI / 4 bit DO 8 bit (internal pin header)
DIO Pin header provides 5V power pin / GND pin
Front
Panel
2x5 Pin header: HDD LED / PWR LED / RST BTN / PWR
BTN
Buzzer
N/A
Other Function
1 x 3-pin CPU FAN connector
Power Supply
Supports only DC 12V power input (1x 4 pin power connector)
Power Mode
ATX mode: (default)
Boot-up when AC returns back
Auto boot-up when AC returns back (default)
Non-auto boot-up when AC returns back (selected by jumper)
Way to Boot-Up from S5: (1)Power Button (2)Wake-On-LAN
Way to shut down to S5/S4/S3: (1) Power button
(2) OS command

Supports S0/S3/S4/S5
Battery
2-pin wafer, connected with a cable type BAT

Chapter 2 Getting Started
BE-0961 SERIES USER MANUAL
Page: 2-7
2.3 Safety Precautions
Follow the instructions below to avoid your system from damages:
1. Keep your system away from static electricity on all occasions.
2. Prevent electric shock. Don’t touch any components of this board when it is
powered on. Always disconnect power when the system is not in use.
3. Disconnect power source when you change any hardware devices.
For instance, when you connect a jumper or install any cards, a surge of power
may damage the electronic components or the whole system.

BE-0961 SERIES USER MANUAL
Page: 3-1
3 Hardware Configuration
This chapter contains helpful information about the jumper
& connector settings and component locations.
The following sections are included:
•Jumper & Connector Quick Reference Table
•Main Board Component Locations
•Configuration and Jumper Settings
•Connector Pin Assignments

Chapter 3 Hardware Configuration
BE-0961 SERIES USER MANUAL
Page: 3-2
3.1 JUMPER & CONNECTOR QUICK REFERENCE TABLE
JUMPER / CONNECTOR
NAME
COM Port
COM1, COM2, COM3, COM4
COM2 RS-232/422/485 Selection
JP_COM2
COM3 & COM4 RI & Voltage Selection
JP_COM3, JP_COM4
USB Port & Connector
USB10, JUSB1
LAN Port
LAN1/LAN2
VGA Port
VGA1
Clear CMOS Data Selection
JP3
AT/ATX Power Mode Selection
JP16
Panel Voltage Selection
JP14
Front Panel Selection
JP17
Power Connector
PWR_CN1
SATA Connector
SATA1
SATA Power Connector
SATA_PWR1
Digital I/O Connector
DIO1
Audio Connector
JAUDIO1
System Fan Connector
FAN1
Backlight Connector
INV1
Battery Connector
BAT1
CFAST Voltage Selection
JP7
LVDS Connector
LVDS1

Chapter 3 Hardware Configuration
BE-0961 SERIES USER MANUAL
Page: 3-3
3.2 COMPONENT LOCATIONS OF SYSTEM MAIN BOARD
3.2.1 Top View of BE-0961
WARNING: Always disconnect the power cord when you are
working with connectors and jumpers on the main board.
Make sure both the system and peripheral devices are turned
OFF as sudden surge of power could damage sensitive
components. Make sure BE-0961 is properly grounded.
CAUTION: Observe precautions while handling electrostatic
sensitive components. Make
sure to ground yourself to
prevent static charge while you are working on the
connectors and jumpers. Use a grounding wrist strap and
place all electronic components in any static-shielded
devices.
VGA1
SATA1
LAN1USB10
COM1
1
1
1
1
4
2
JP17 JP16
12
SATA_PWR1
JAUDIO1
PWR_CN1
JP14
INV1
JP3
FAN1
BAT1
SIO
JUSB1
JP7
JP5
DIO1
JP_COM2
JP_COM3 JP_COM4
1
JP20
1
9 10
21
2
1 10
9
10
10210
1 9 1 9 1 9
2
COM4 COM3 COM2
Intel®
4th Gen. Atom™
E3000 / N2000
1
1
2
5
6
1 2
7 8
2
1
1
3
5
6
1
2
1
2
1
6
1
LAN2
1
1
LVDS1
230
29
2

Chapter 3 Hardware Configuration
BE-0961 SERIES USER MANUAL
Page: 3-4
CAUTION: Always touch the motherboard components by
the edges. Never touch components such as a processor by
its pins. Take special cares while you are holding electronic
circuit boards by the edges only. Do not touch the main board
components.
