protech ProX-1630 User manual

USER’S
MANUAL

Copyright Notice
ProX-1630 Socket 370
Half-sized Embedded Card
With VGA / LAN
OPERATION MANUAL
COPYRIGHT NOTICE
This operation manual is meant to assist both Embedded Computer manu-
facturers and end-users in installing and setting up the system. The infor-
mation contained in this document is subject to change without any prior
notice.
This manual is copyrighted August 2000. (Revised Edition: Feb. 26, 2002).
You may not reproduce or transmit in any form or by any means, electronic,
or mechanical, including photocopying and recording.
ACKNOWLEDGEMENTS
All trademarks and registered trademarks mentioned herein are the property
of their respective owners.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual ....................................................... 1-2
1-2 System Specifications ................................................... 1-3
1-3 Safety Precautions ......................................................... 1-6
CHAPTER 2 HARDWARE CONFIGURATION
2-1 Jumper & Connector Quick Reference Table ............... 2-2
2-2 Component Locations ................................................... 2-3
2-3 How to Set the Jumpers ................................................ 2-4
2-4 COM Port Connector .................................................... 2-6
2-5 RS232/422/485 (COM2) Selection ............................... 2-7
2-6 SSD Memory Mapping Selection ................................. 2-8
2-7 Keyboard or PS/2 Mouse Selection .............................. 2-9
2-8 Keyboard or PS/2 Mouse Connector ............................ 2-9
2-9 External Keyboard Connector ....................................... 2-10
2-10 Reset Connector ............................................................ 2-10
2-11 Hard Disk Drive LED Connector .................................. 2-10
2-12 VGA CRT Connector ................................................... 2-11
2-13 CPU Fan Connector ...................................................... 2-12
2-14 External Speaker Connector .......................................... 2-12
2-15 Power Led & Keylock Connector ................................. 2-12
2-16 Floppy Disk Drive Connector ....................................... 2-13
2-17 Hard Disk Drive Connector .......................................... 2-14
2-18 LCD Panel Connector ................................................... 2-15
2-19 Printer Connector .......................................................... 2-16
2-20 Universal Serial Bus Connector .................................... 2-17
2-21 LAN Connector ............................................................ 2-17
2-22 Solid State Disk Connector ........................................... 2-18
2-23 Panel VCC Selection ..................................................... 2-19
2-24 Green Function Connector ............................................ 2-19
2-25 LAN Led Indicator ........................................................ 2-20
2-26 IRQ12 Release Selection ……………………………... 2-20
2-27 Memory Installation ...................................................... 2-21

Contents
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction ................................................................... 3-2
3-2 VGA Driver Utility ....................................................... 3-2
3-3 Flash BIOS Update ....................................................... 3-5
3-4 LAN Drivers Utilities .................................................... 3-7
3-5 Watchdog Timer Configuration .................................... 3-9
CHAPTER 4 GREEN PC FUNCTION
4-1 Power Saving Block Diagram ....................................... 4-2
4-2 CPU Doze Mode ........................................................... 4-2
4-3 System Standby Mode .................................................. 4-2
4-4 System Suspend Mode .................................................. 4-3
CHAPTER 5 AWARD BIOS SETUP
5-1 Introduction ................................................................... 5-2
5-2 Entering Setup ............................................................... 5-3
5-3 The Standard CMOS Setup Menu ................................ 5-4
5-4 The BIOS Features Setup Menu ................................... 5-8
5-5 Chipset Feature Setup ................................................... 5-11
5-6 Power Management Setup ............................................ 5-15
5-7 PNP/PCI Configuration ................................................ 5-18
5-8 Load BIOS Defaults ...................................................... 5-20
5-9 Load Setup Defaults ...................................................... 5-20
5-10 Integrated Peripherals ................................................... 5-21
5-11 Password Setting ........................................................... 5-23
5-12 IDE HDD Auto Detection ............................................. 5-24
5-13 Save & Exit Setup ......................................................... 5-25
5-14 Exit Without Saving ...................................................... 5-26
APPENDIX A EXPANSION BUS
ISA Bus Pin Assignment .......................................................... A-3
APPENDIX B TECHNICAL SUMMARY
Block Diagram ......................................................................... B-2
Interrupt Map ............................................................................ B-3

Contents
RTC & CMOS RAM Map ....................................................... B-4
Timer & DMA Channels Map .................................................. B-5
I/O & Memory Map ................................................................. B-6
APPENDIX C TROUBLE SHOOTING
Trouble Shooting for Error Messages ...................................... C-2
Trouble Shooting for POST Codes .......................................... C-6

Page:1-1
INTRODUCTION
This chapter gives you the information for Prox-1630. It also
outlines the System specifications.
Section includes:
zAbout This Manual
zSystem Specifications
zSafety precautions
Experienced users can skip to chapter 2 on page 2-1
for a Quick Start.
CHAPTER
1

Chapter 1 Introduction
Page: 1-2 Prox-1630 USER
′
S MANUAL
1-1. ABOUT THIS MANUAL
Thank you for purchasing our Prox-1630 Socket 370 Half-sized Embedded
Card with VGA/LAN, which is fully PC / AT compatible. The Prox-1630
provides faster processing speed, greater expandability and can handle
more tasks than before. This manual is designed to assist you how to install
and set up the system. It contains five chapters. The user can apply this
manual for configuration according to the following chapters :
Chapter 1 Introduction
This chapter introduces you to the background of this manual, and the
specifications for this system. The final page of this chapter will indicate
how to avoid damaging this Embedded Card.
Chapter 2 Hardware Configuration
This chapter outlines the component locations and their functions. In the
end of this chapter, you will learn how to set jumper and how to configure
this card to meet your own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the
VGA utilities, LAN utilities and Flash BIOS Update. It also describes the
Watchdog-timer configuration.
Chapter 4 Green PC Function
This chapter explains the Green PC functions concisely.
Chapter 5 Award BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A Expansion Bus
This Appendix introduces you the expansion bus for ISA BUS.
Appendix B Technical Summary
This section gives you the information about the Technical maps.
Appendix C Trouble Shooting
This section outlines the error messages and offers you the methods to
solve the problems.

Chapter 1 Introduction
Prox-1630 USER
′
S MANUAL Page: 1-3
1-2. SYSTEM SPECIFICATIONS
!
!!
!CPU :
Intel® CeleronTM processor in 370-pin socket.
300A/333/366/400/433/466/500/533/566/600/700/733 MHz clock
generator.
Intel® Pentium® III processor in 370-pin socket.
500E/550E/600E/650/700/750/800/850 MHz clock generator.
Auto detect voltage regulator.
!
!!
!MEMORY :
Up to 256MB SDRAM
One 168pin DIMM socket on board.
!
!!
!CACHE :
Depended on CPU (128K/256K Cache).
!
!!
!REAL-TIME CLOCK / CALENDAR :
CMOS data back up from BIOS set or BIOS default.
Dallas DS 12887 Real Time Clock.
!
!!
!BIOS :
Award Flash BIOS for plug & play function.
Easy update 256KB flash EEPROM.
Support Green Function.
Support S/IO Setup.
!
!!
!KEYBOARD AND PS/2 MOUSE CONNECTOR :
Mini DIN connector, support AT Keyboard or PS/2 Mouse by jumper
selection.
One additional 5-pin External keyboard connector.
!
!!
!BUS SUPPORT :
External ISA.
Internal PCI Bus for VGA, LAN, & IDE.

Chapter 1 Introduction
Page: 1-4 Prox-1630 USER
′
S MANUAL
z
zz
zDISPLAY :
Support SVGA for CRT & Panel.
Support 32bits PCI Local Bus.
VGA BIOS combines in 256KB flash ROM together with system BIOS.
Support 15-pin connector 1024 x 768 (256 colors) resolution on SVGA
Monitor.
Integrates 2 Mbytes of SDRAM for the graphics/video frame buffer.
Support 51-pin connector 640 x 480, 800 x 600, 1024 x 768 resolutions on
LCD Panel.
Panel support Color STN, TFT, EL.
Support simultaneous display of CRT & LCD flat Panel.
z
zz
zWATCHDOG :
I / O port 0443H to Enable watchdog.
I / O port 0441H to Disable watchdog.
Time-out timing select 0 / 8 / 16 / 24 / 32 / 40 / 48 / 56 / 64 / 72 / 80 / 88 /
96 / 104 / 112 / 120 sec +/- 25%.
z
zz
zIDE INTERFACE :
One IDE ports, Support Ultra DMA-33, Two Enhanced IDE devices.
z
zz
zFLOPPY DISK DRIVER INTERFACE :
Support up to two Floppy Disk Drives, 3.5" and 5.25" (360K / 720K /
1.2M / 1.44M / 2.88M / LS-120).
z
zz
zDISK-ON-CHIPS SOCKET :
A 32-pin SSD socket on board, supports up to 144MB Disk-on-chips.
z
zz
zUSB CONNECTOR :
Universal Serial Bus Connector on board, supports up to two USB ports.
z
zz
zLAN ADAPTER :
MXIC MX98715 Fast Ethernet
10/100 Base-T PCI-BUS

Chapter 1 Introduction
Prox-1630 USER
′
S MANUAL Page: 1-5
z
zz
zSERIAL PORT :
Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte
FIFOs; COM1:RS-232; COM2:RS-232/422/485.
MIDI Compatible.
Programmable Baud Rate Generator.
z
zz
zPARALLEL PORT :
SPP, ECP, EPP Function.
Bi-directional parallel port.
z
zz
zGREEN FUNCTION :
Software support by BIOS setup.
Hardware support by switch control.
z
zz
zLED INDICATOR :
System power.
Hard Disk access.
LAN LED indicator.
z
zz
zDMA CONTROLLER :
82C37 x 2
z
zz
zDMA CHANNELS :
7
z
zz
zINTERRUPT CONTROLLERS :
82C59 x 2
z
zz
zINTERRUPT LEVELS :
15
z
zz
zOPERATING TEMPERATURE :
0 to 60°C.
z
zz
zSYSTEM POWER REQUIREMENT :
DC Voltage: +5V, minimum +4.75V, maximum 5.25V.
DC Ampere: 15A.
DC Voltage: +12V, minimum +11.4V, maximum 12.6V.
DC Ampere: 500mA.

Chapter 1 Introduction
Page: 1-6 Prox-1630 USER
′
S MANUAL
z
zz
zBOARD DIMENSIONS :
185mm x 122mm
z
zz
zBOARD NET WEIGHT :
0.25 Kilograms.
1-3. SAFETY PRECAUTIONS
Follow the messages below to avoid your systems from damage:
1. Keep your system away from static electricity on all occasions.
2. Stay safe from the electric shock. Don‘t touch any components of this
card when the card is power-on. Always disconnect power when the
system is not in use.
3. Disconnect power when you change any hardware devices. For instance,
when you connect a jumper or install any cards, a surge of power may
damage the electronic components or the whole system.

Page 2-1
HARDWARE
CONFIGURATION
** QUICK START **
Helpful information describes the jumper & connector settings, and
component locations.
This section includes:
zJumper & Connector Quick Reference Table
zComponent Locations
zConfiguration and Jumper settings
zConnector‘s Pin Assignments
CHAPTER
2

Chapter 2 Hardware Configuration
Page: 2-2 Prox-1630 USER
’
S MANUAL
2-1. JUMPER & CONNECTOR QUICK REFERENCE TABLE
COM Connector ................................................... COM1, COM2
RS232/422/485 (COM2) Selection ........................ JP4
SSD Memory Maping Selection ............................ JP6, JP7
Keyboard or PS2 Mouse Selection ........................ JP5
Keyboard or PS2 Mouse Connector ...................... DIN
External Keyboard Connector ............................... EXKB
Reset Connector ..................................................... RST
Hard Disk Drive LED Connector .......................... HDL
VGA CRT Connector ............................................ VGA
CPU Fan Connector ............................................... CPUFAN
External Speaker Connector .................................. SPK
Power LED & Keyboard Connector ...................... KBL
Floppy Disk Drive Connector ................................ FDD
Hard Disk Drive Connector ................................... IDE1
LCD Panel Connector ............................................ LCD
Printer Connector ................................................... PRT
Universal Serial Bus Connector ............................. USB
LAN Connector ..................................................... UTP
Solid-State Disk Socket ......................................... SSD
Panel VCC Selection ............................................. JP2
Green Function Connector ..................................... GRN
LAN LED Indicator ............................................... LED1, LED2
IRQ 12 Release Selection ……………………….. JP8
Memory Installation ............................................... DIMM1

Chapter 2 Hardware Configuration
Prox-1630 USER
’
S MANUAL Page: 2-3
2-2. COMPONENT LOCATIONS
12887
UTP VGA DIN
FDDPRT
LCD
JP1
SSD
DIMM1
440BX
COM 1
EXKB
JP7
440BX
CPUFAN
1
6
5
10
1
8
1
5
6
10
11
3
6
15
3
2
4
5
1
1
2
4
1
COM2
5
2
6
1
KBL
1
16
7
2
IDE1
JP6
7
2
8
19
2
1
RST
1
1
HDL
SPK
1
JP8
LED2
LED1
9
5
JP4 JP5
32
16
1
17
1
1
GRN
USBJP3
JP2
CPU
Socket370
Prox-1630 Connector, Jumper and Component locations

Chapter 2 Hardware Configuration
Page: 2-4 Prox-1630 USER
’
S MANUAL
2-3. HOW TO SET THE JUMPERS
You can configure your board by setting the jumpers. Jumper is consists of
two or three metal pins with a plastic base mounted on the card, and by
using a small plastic "cap", Also known as the jumper cap (with a metal
contact inside), you are able to connect the pins. So you can set-up your
hardware configuration by "opening"or "closing"pins.
The jumper can be combine into sets that called jumper blocks. When the
jumpers are all in the block, you have to put them together to set up the
hardware configuration. The figure below shows how this looks like.
JUMPERS AND CAPS
If a jumper has three pins (for example, labelled PIN1, PIN2, and PIN3),
You can connect PIN1 & PIN2 to create one setting and shorting. You can
either connect PIN2 & PIN3 to create another setting. The same jumper
diagrams are applied all through this manual. The figure below shows what
the manual diagram looks like and what they represent.

Chapter 2 Hardware Configuration
Prox-1630 USER
’
S MANUAL Page: 2-5
JUMPER DIAGRAMS
JUMPER SETTINGS

Chapter 2 Hardware Configuration
Page: 2-6 Prox-1630 USER
’
S MANUAL
2-4. COM PORT CONNECTOR
Two COM port is enhanced in this board namely: COM1 and COM2.
COM1 is for RS-232 while COM2 is selectable for RS-232/422/485.
COM1 : COM1 Connector, DB9 male connector
The COM1 Connector assignments are as follows :
PIN ASSIGNMENT
1DCD
2RX
3TX
4DTR
5 GND
6DSR
7RTS
8CTS
9RI
COM2 : COM2 Connector
The COM2 Connector assignments are as follows :
PIN ASSIGNMENT
RS-232 RS-422 RS-485
1DCDTX-TX-
2RXTX+TX+
3TXRX+RX+
4DTRRX-RX-
5 GND GND GND
6 DSR RTS- NC
7RTSRTS+NC
8CTSCTS+NC
9RICTS-NC
10 NC NC NC

Chapter 2 Hardware Configuration
Prox-1630 USER
’
S MANUAL Page: 2-7
2-5. RS232/422/485 (COM2) SELECTION
JP4 : RS-232/422/485 Selection
COM1 is fixed for RS-232 function only.
COM2 is selectable for RS-232, 422, 485 function.
The jumper settings are as follows :
COM 2
Function RS-232 RS-422 RS-485
Jumper
setting
(pin closed)
Open 1-2
5-6
7-8
9-10
11-12
13-14
15-16
17-18
19-20
1-3
4-6
7-8
9-10
11-12
13-14
15-16
17-18
19-20
Jumper
illustration
*** Manufactory default --- RS-232.

Chapter 2 Hardware Configuration
Page: 2-8 Prox-1630 USER
’
S MANUAL
2-6. SSD MEMORY MAPPING SELECTION
JP6, JP7 : SSD Memory Mapping Selection
A 32-pin SSD socket supports Disk-on-Chip up to 144MB. This PnP
Flash ROM SSD can be install as one of user’s hard disk drive.
The SSD Memory Mapping are as follows:
SSD Memory Map JUMPER SETTINGS
(pins closed)
JP6 JP7 JUMPER
ILLUSTRATION
CC000h-CDFFFh 1-2 3-4
D0000h-D1FFFh 3-4 1-2
D4000h-D5FFFh 3-4 3-4
D8000h-D9FFFh 5-6 1-2
DC000h-DDFFFh 5-6 3-4
E0000h-E1FFFh 7-8 1-2
*** Manufactory default --- CC000h-CDFFFh

Chapter 2 Hardware Configuration
Prox-1630 USER
’
S MANUAL Page: 2-9
2-7. KEYBOARD OR PS/2 MOUSE SELECTION
JP5 : PC/AT Keyboard or PS/2 Mouse Selection
The jumper settings are as follows:
DEVICE
TYPE JUMPER SETTINGS
(pins closed)
JP5
JUMPER
ILLUSTRATION
AT KEYBOARD 3-5
4-6
PS/2 MOUSE 1-3
2-4
*** Manufactory default -- AT Keyboard
2-8. KEYBOARD OR PS/2 MOUSE CONNECTOR
DIN : PC/AT Keyboard or PS/2 Mouse Connector
DIN connector can support PC/AT Keyboard or PS/2 Mouse.
The pin assignments are as follows :
PIN ASSIGNMENT
KEYBOARD PS/2 MOUSE
1 KBDATA MOUSE DATA
2NC NC
3 GND GND
4V
CC VCC
5KBCLK MSCLK
6NC NC
