protech prox BC-K201 User manual

Ver. Q1
All Rights Reserved. Copyright 2021
Packing Checklist
BC-K201
BC-K201 BC-K201
Specifications System View
BC-K201 x 1
HEX CU BOSS for M.2 x 1
Fillister Head Screw for M.2 x 1
Driver/Manual DVD x 1
This Quick Reference Guide x 1
Mini Jumper (2 mm) x 6
88
6
428.20
310.10
Front View
Top View
Rear View Unit: mm
Quarter View
I/O Panel View
If you discover any item below damaged or lost,
please contact your vendor.
BC-K201
Quick
Reference
Guide
System
CPU Support LGA1200 socket for Intel®10th Gen. Core™ i9 / i7 / i5 / i3 /
Pentium®/ Celeron®desktop CPU / Xeon®W-1200 server CPU
CPU List Xeon®: W-1290E(TE), W-1270E(TE), W-1250E(TE)
10th CoreTM: i9-10900E(TE), i7-10700E(TE), i5-10500E(TE),
i3-10100E(TE)
Pentium®: G6400E, G6400TE / Celeron®: G5900E, G5900TE
Chipset Intel®W480E / Q470E / H420E
Memory Support Up to 4 x DDR4 2933MHz DIMM(H420E SKU only 2 DIMM)
Power Supply ATX 300W Power Supply
O.S. Support Windows®10 IoT Enterprise
Dimensions (WxHxD) 480 x 88 x 310.1mm (with handle)
428.2 x 88 x 310.1 mm (without handle)
Certificate CE / FCC
I/O Ports
Drive Bay for Storage 2 x 2.5” HDD/SSD (default) or 1 x 3.5” HDD
1 x Slim ODD
USB 6 x USB (front I/O)
Serial Ports 2 x COM, COM2: RS232/422/485 auto flow control (front I/O)
LAN Dual LAN (2 x RJ45, front I/O)
LAN1: Intel®PHY 219LM (GbE)/LAN2: Intel®LAN 211AT (GbE)
System Fan 2 x 80x80 mm System Fan / 3 x Air Filter
Keyboard/Mouse 1 x PS/2 Combo connector for keyboard & mouse (rear I/O)
Audio Mic In / Line In / Line Out (front I/O)
Expansion Slots PCIeX16 Riser Card + PCIeX16 Extended Card (1 set)
(option) PCIeX4 to PCI Riser Card or PCIeX4 Riser Card
Display
Flexible Display W480E/Q470E: 1 x VGA, 2 x DP, support triple independent display
H420E: 1 x VGA, 2 x DP, support dual independent display
VGA 1 x VGA up to 1920 x 1200 @60Hz
DisplayPort 2 x DP (rear I/O) up to 4096 x 2304 @60Hz (Default)
Others
Notification LED 1 x Power LED / 1 x HDD LED
Power / Reset Button 1 x Power Button / 1 x Reset Button
Environment
Operating Temp. 0°C ~ 40°C (32°F ~ 104°F)
Storage Temp. -20°C ~ 80°C (-4°F ~ 176°F)
Humidity 20% ~ 90% (non-condensing)
HDD LED
Reset Button
Power LED
Power Button
Audio
Connector
PS/2 KB/
Mouse Combo
COM2
COM1
DP
VGA 4 x USB
Port
RJ45 10/100/1000
LAN Connector
Power Supply
USB 2.0

Jumper Setting
BC-K201
All Rights Reserved. Copyright 2021
Safety Precaution
Industrial Rack Mount System
CAUTION! Danger of explosion may occur if the battery is replaced incorrectly. Replace batteries only with the same or equivalent type
recommended by the manufacturer. Dispose the used batteries according to the manufacturer’s instructions.
1
+12V
JPCOM3/4 Port RI & Voltage
Selection
RI
(default)
2
65
1 2
+5V
65
1 2
65
1 2
Buzzer
AUDIO1
LAN_USB2 LAN_USB1
DP1 & DP2
VGA1
COM2
COM1
KB_MS_USB1
CPU_FAN1
ATX_PWR2
1 4
1
2
12V GND
12V GND
3
4
JSPK1
1
1
40
PCI_E4
PCI_E3
PCI_E2
PCI_E1
PCH
USB1
1
1011
20
USB2 USB3
1
10
2
9
1
10
2
9
1
1
JP3
M_PCIE1
JFP1
2
9
JSPI1
JAUDIO1
1
1
20
2
19
1 2
19 20
1
6
510
COM5 COM3
COM6 COM4
5
10
1
6
5
10
1
10
1
6
55
10
1
M2_SSD1
DIMM1
DIMM2
DIMM3
DIMM4
Battery
SATA6 SATA4 SATA1
SATA5 SATA3 SATA2
17 17 17
71 71 71
ATX_PWR3
12
24
1
13
JDIO1
1
219
20
SYS_FAN1 1
4
SYS_FAN2 1
3
JPCOM3 JPCOM4
12
56
12
5 6
1
JCMOS1
JPMUX1
1
1JP_AT1
Intel®10th
Gen. CPU
(LGA1200)
JP1
JI2C1
JI2C2
4
1
4
1
JLPC1
1 2
15 16
17 18
51 52
JP2
1
M5
M4
PCH Configuration / Recovery
Selection
1
(default)
Normal Configure
11
Recovery
1
MCU Override Manual
(default)
Flash Descriptor Override
Selection
1
Standby Normal
(default)
USB Power Selection
1 1
Hardware Power Failure
Selection
(default)
Disable Enable
1
Clear CMOS Data
Selection
(default)
Normal
1
Clear CMOS
1
LAN2 M_PCIE1
(default)
Mini PCIe / LAN2 Selection
11
1JP5
The following messages are safety reminders on how to protect your system
from damages, and thus help you extend the life cycle of the system.
1. Check the Line Voltage
The operating voltage for the power supply should be ATX 300W;
otherwise, the system may be damaged.
2. Environmental Conditions
Place your BC-K201 on a sturdy, level surface. Be sure to allow
enough room on each side to have easy access.
Avoid moving the system rapidly from a hot place to a cold place or
vice versa because condensation may come from inside of the system.
Place BC-K201 against strong vibrations, which may cause hard disk
failure.
3. Handling
Do not turn the system upside down. This may cause the hard drive
to mal-function.
Do not allow foreign objects to fall into this product.
If water or other liquid spills into this product, unplug the power cord
immediately.
4. Good Care
When the outside of the case is stained, remove the stain with neutral
washing agent with a dry cloth.
If dust has been accumulated on the outside, remove it by using a
special made vacuum cleaner for computer.
CAUTION!
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Dispose of used batteries
accordingto the manufacturer’s instructions.
WARNING!
Some internal parts of the system may have high electrical voltage. Therefore we
strongly recommend qualified engineers open and disassemble the system.
