protech ProX-1635LF User manual

USER’S
MANUAL
ProX-1635LF
ForSocket370
Half-sizeCPUCard
WithVGA/LAN
Prox-1635LF M2

Copyright Notice
Prox-1635LF Socket 370
Half-size Embedded Card
With VGA / LAN
OPERATION MANUAL
COPYRIGHT NOTICE
This operation manual is meant to assist both Embedded Computer
manufacturers and end users in installing and setting up the system. The
information contained in this document is subject to change without any notice.
This manual is copyrighted January 2004. You may not reproduce or transmit in
any form or by any means, electronic, or mechanical, including photocopying
and recording.
ACKNOWLEDGEMENTS
All trademarks and registered trademarks mentioned herein are the property of
their respective owners.
CE NOTICE
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

Copyright Notice
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void your
authority to operate such equipment.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual ....................................................... 1-2
1-2 System Specification ..................................................... 1-3
1-3 Safety Precautions ......................................................... 1-6
CHAPTER 2 HARDWARE CONFIGURATION
2-1 Jumper & Connector Quick Reference Table ............... 2-2
2-2 Component Locations ................................................... 2-3
2-3 How to Set the Jumpers ................................................ 2-5
2-4 COM Port Connector ………………………………… 2-7
2-5 RS232/422/485 (COM2) Selection ............................... 2-8
2-6 PS/2 Mouse Connector …………….....................…... 2-9
2-7 Keyboard or PS/2 Mouse Selection .......................…... 2-9
2-8 External Keyboard Connector ....................................... 2-10
2-9 Reset Connector ............................................................ 2-10
2-10 ATX Power Button ………………............................... 2-10
2-11 AT/ATX Function Selection …………………………. 2-11
2-12 Hard Disk Drive LED Connector …..………………… 2-12
2-13 EXTSMI Connector …………………………………. 2-12
2-14 VGA Connector ...................................…………….... 2-13
2-15 Floppy Disk Drive Connector ...................................... 2-14
2-16 Hard Disk Drive Connector .......................................... 2-15
2-17 Printer Connector …………………………………….. 2-16
2-18 CPU Fan Connector ………………………………….. 2-17
2-19 ATX Signal Connector ……………..………………… 2-17
2-20 Wake-on-LAN Connector ……….…………………… 2-17
2-21 Universal Serial Bus Connector …………..………….. 2-18
2-22 Reset/NMI/Clear Watchdog Selection ………………. 2-19
2-23 LAN Connector …………………..…………………... 2-20
2-24 Power Connector ……………………………………. 2-20
2-25 IRDA Connector ……………………..………………. 2-21
2-26 Clear CMOS Data Selection …………………………. 2-21
2-27 Memory Installation ……………….…………………. 2-22
2-28 INTB/SERIRQ Selection …………………………….. 2-22

Contents
2-29 PPCI Connector ………………………………………. 2-23
2-30 CPU Speed Selection ………………………………… 2-24
2-31 LCD Connector ………………………………………. 2-25
2-32 Inverter Connector ……………………………………. 2-26
2-33 Power LED Connector ……………………………….. 2-26
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction …………................................................... 3-2
3-2 VIA 4 in 1 Service Pack Driver 3-2
3-3 VGA Driver Utility ………………………………….. 3-3
3-4 Flash BIOS Update ....................................................... 3-4
3-5 LAN Driver Utility …................................................... 3-6
3-6 USB2.0 Software Installation Utility ………………… 3-8
3-7 Watchdog Timer Configuration .................................... 3-9
CHAPTER 4 AWARD BIOS SETUP
4-1 Introduction ................................................................... 4-2
4-2 Entering Setup ............................................................... 4-3
4-3 The Standard CMOS Setup ………............................... 4-4
4-4 The Advanced BIOS Features ....................................... 4-8
4-5 Advanced Chipset Features ........................................... 4-11
4-6 Integrated Peripherals …............................................... 4-13
4-7 Power Management Setup ............................................ 4-18
4-8 PNP/PCI Configuration …............................................. 4-22
4-9 PC Health Status ……................................................... 4-24
4-10 Frequency/Voltage Control ........................................... 4-25
4-11 Load Fail-Safe Defaults ................................................ 4-26
4-12 Load Optimized Defaults .........................................…. 4-26
4-13 Password Setting …………………………………….. 4-27
4-14 Save & Exit Setup ......................................................... 4-28
4-15 Exit Without Saving ………………………………… 4-29
APPENDIX A EXPANSION BUS
ISA Bus Pin Assignment .......................................................... A-2

Contents
APPENDIX B TECHNICAL SUMMARY
Block Diagram ......................................................................... B-2
Interrupt Map ............................................................................ B-3
RTC & CMOS RAM Map ....................................................... B-4
Timer & DMA Channels Map .................................................. B-5
I/O & Memory Map ................................................................. B-6
APPENDIX C TROUBLE SHOOTING
Trouble Shooting for Error Messages ...................................... C-2
Trouble Shooting for POST Codes .......................................... C-8

Page:1-1
INTRODUCTION
This chapter gives you the information for Prox-1635LF. It also
outlines the System specifications.
Section includes:
zAbout This Manual
zSystem Specifications
zSafety precautions
Experienced users can skip to chapter 2 on page 2-1
for a Quick Start.
CHAPTER
1

Chapter 1 Introduction
Page: 1-2 Prox-1635LF USER
′ S MANUAL
1-1. ABOUT THIS MANUAL
Thank you for purchasing our Prox-1635LF Socket 370 Half-Size ISA CPU
Card with VGA/ LAN/CF Card, which is fully PC / AT compatible. The Prox-
1635LF provides faster processing speed, greater expandability and can
handle more tasks than before. This manual is designed to assist you how to
install and set up the system. It contains four chapters. The user can apply this
manual for configuration according to the following chapters :
Chapter 1 Introduction
This chapter introduces you to the background of this manual, and the
specifications for this system. The final page of this chapter will indicate how
to avoid damaging this Embedded Card.
Chapter 2 Hardware Configuration
This chapter outlines the component locations and their functions. In the end
of this chapter, you will learn how to set jumper and how to configure this
card to meet your own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the VGA
Utility, LAN Utility, and Flash BIOS Update. It also describes the Watchdog-
timer configuration.
Chapter 4 Award BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A Expansion Bus
This Appendix introduces you the expansion bus for ISA BUS.
Appendix B Technical Summary
This section gives you the information about the Technical maps.
Appendix C Trouble Shooting
This section outlines the error messages and offers you the methods to solve
the problems.

Chapter 1 Introduction
Prox-1635LF USER ′ S MANUAL Page: 1-3
1-2. SYSTEM SPECIFICATIONS
zCPU :
Intel® CeleronTM / Pentium® III/ Tualatin/ C3 processors in 370-pin socket
566MHz ~ 1GHz clock generator
Auto detect voltage regulator
zMEMORY :
Up to 1GB DDR
One 184-pin DIMM socket on board
zCACHE :
Built-in CPU
zREAL-TIME CLOCK / CALENDAR :
Built-in VIA VT8235
zBIOS :
Phoenix-Award PnP, Firmware HUB BIOS memory size 4MB, with VGA
BIOS
Easy update 256KB flash EEPROM
Support Green Function.
Support S/IO Setup.
zKEYBOARD AND MOUSE CONNECTOR :
Mini DIN connector, support for keyboard or PS/2 mouse.
One additional 5-pin external keyboard connector
zBUS SUPPORT :
External PPCI Bus
zDISPLAY :
Build in VIA CLE266.
Support CRT, 24bits TTL Panel.
Onboard 15-pin CRT connector, support resolutions up to 1600 x 1200.
Onboard 41-pin connector on TTL Panel.

Chapter 1 Introduction
Page: 1-4 Prox-1635LF USER
′ S MANUAL
zWATCHDOG :
I / O port 0443H to Enable watchdog.
I / O port 0441H to Disable watchdog.
Watchdog function is selectable for Reset or NMI function.
Time-out timing select 0 / 8 / 16 / 24 / 32 / 40 / 48 / 56 / 64 / 72 / 80 / 88 / 96 /
104 / 112 / 120 sec +/- 25%.
zIDE INTERFACE :
One enhanced IDE port, support Ultra DMA-33/66/100.
One channel, support up to four devices.
zFLOPPY DISK DRIVER INTERFACE :
Support up to two Floppy Disk Drives, 3.5" and 5.25" ( 1.2M / 1.44M /
2.88M).
zUSB CONNECTOR :
Universal Serial Bus Connector, support up to four USB 2.0 ports.
zLAN ADAPTER :
Single port, VIA 6103 PHY Chip
10/100 Base-TX Ethernet, support Wake-on-LAN
zCF Card Connector :
Compact Flash connector on board with second IDE, support type II CF.
zSERIAL PORT :
Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte
FIFOs;
COM1 is fixed as RS-232; COM2 selectable for RS-232/422/485.
MIDI Compatible
Programmable Baud Rate Generator
zPARALLEL PORT :
SPP, ECP, EPP Function.
Bi-directional parallel port.
zGREEN FUNCTION :
Software supported by BIOS setup.
Hardware supported by switch control.

Chapter 1 Introduction
Prox-1635LF USER ′ S MANUAL Page: 1-5
zHARDWARE MONITORING FUNCTION :
CPUFAN
CPU Temperature
Auto Detect Voltage
zIRDA :
One Infrared port
zLED INDICATOR :
Hard Disk access
Power Indicator
zDMA CONTROLLER :
82C37 x 2
zDMA CHANNELS :
7
zINTERRUPT CONTROLLERS :
82C59 x 2
zINTERRUPT LEVELS :
15
zOPERATING TEMPERATURE :
0 to 60°C.
zINPUT POWER REQUIREMENT :
DC Voltage: +5V, minimum +4.75V, maximum 5.25V.
DC Ampere: 15A.
DC Voltage: +12V, minimum +11.4V, maximum 12.6V.
DC Ampere: 500mA.
zBOARD DIMENSIONS :
185mm x 122mm
zBOARD NET WEIGHT :
0.28 Kilograms.

Chapter 1 Introduction
Page: 1-6 Prox-1635LF USER
′ S MANUAL
1-3. SAFETY PRECAUTIONS
Follow the messages below to avoid your systems from damage:
1. Keep your system away from static electricity on all occasions.
2. Stay safe from the electric shock. Don‘t touch any components of this card
when the card is power-on. Always disconnect power when the system is
not in use.
3. Disconnect power when you change any hardware devices. For instance,
when you connect a jumper or install any cards, a surge of power may
damage the electronic components or the whole system.

Page 2-1
HARDWARE
CONFIGURATION
** QUICK START **
Helpful information describes the jumper & connector settings, and
component locations.
This section includes:
zJumper & Connector Quick Reference Table
zComponent Locations
zConfiguration and Jumper settings
zConnector‘s Pin Assignments
CHAPTER
2

Chapter 2 Hardware Configuration
Page: 2-2 Prox-1635LF USER
′ S MANUAL
2-1. JUMPER & CONNECTOR QUICK REFERENCE TABLE
COM Connector .................................................… COM1, COM2
RS232/422/485 (COM2) Selection ........................ JP3
Keyboard or PS/2 Mouse Connector ……………. DIN1
Keyboard or PS/2 Mouse Selection ……………... JP4
External Keyboard Connector …………………… EXKB1
Reset Connector ..................................................... JP8 (1,2)
ATX Power Button ……………….…………...… JP11 (5,7)
AT/ATX Function Selection ……………………..
……………………. JP8 (3,4), JP13, JP9
Hard Disk Drive LED Connector .......................... JP11 (2,4,6,8)
EXTSMI Connector …………………………… JP11 (1,3)
VGA Connector ………......................................... VGA1
Floppy Disk Drive Connector ................................ FDD1
Hard Disk Drive Connector ................................... IDE1
Printer Connector ................................................... LPT1
CPU Fan Connector ............................................... FAN2
ATX Signal Connector ………………………….. JP10
Wake-On-LAN Connector ………………………. WOL1
Universal Serial Bus Connector ............................. JP5, JP6
NMI/Reset/Clear Watchdog …………………..…. JP8
LAN Connector ..................................................... UTP1
Power Connector ………………………………… PW1
IrDA Connector …………………………………. IRDA1
Clear CMOS Data Selection …………..……..….. JP1
Memory Installation ............................................... DIMM1
INTB/SERIRQ Selection ……………………….. JP7
PPCI Connector ……………….………………… PPCI
CPU Speed Selection ……………………………. JP2
LCD Connector ………………………………….. LCD1
Inverter Connector ………………………………. JP15
Power LED Connector ………………………….. PW_LED1

Chapter 2 Hardware Configuration
Prox-1635LF USER ′ S MANUAL Page: 2-3
2-2. COMPONENT LOCATIONS
Prox-1635LF Connector, Jumper and Component locations – Front View

Chapter 2 Hardware Configuration
Page: 2-4 Prox-1635LF USER
′ S MANUAL
Prox-1635LF Connector, Jumper and Component locations – Rear View

Chapter 2 Hardware Configuration
Prox-1635LF USER ′ S MANUAL Page: 2-5
2-3. HOW TO SET THE JUMPERS
You can configure your board by setting the jumpers. Jumper is consists of
two or three metal pins with a plastic base mounted on the card, and by using
a small plastic "cap", Also known as the jumper cap (with a metal contact
inside), you are able to connect the pins. So you can set-up your hardware
configuration by "opening"or "closing"pins.
The jumper can be combined into sets that called jumper blocks. When the
jumpers are all in the block, you have to put them together to set up the
hardware configuration. The figure below shows how this looks like.
JUMPERS AND CAPS
If a jumper has three pins (for example, labelled PIN1, PIN2, and PIN3), You
can connect PIN1 & PIN2 to create one setting and shorting. You can either
connect PIN2 & PIN3 to create another setting. The same jumper diagrams are
applied all through this manual. The figure below shows what the manual
diagram looks like and what they represent.

Chapter 2 Hardware Configuration
Page: 2-6 Prox-1635LF USER
′ S MANUAL
JUMPER DIAGRAMS
JUMPER SETTINGS

Chapter 2 Hardware Configuration
Prox-1635LF USER ′ S MANUAL Page: 2-7
2-4. COM PORT CONNECTOR
There are two COM port enhanced in this board namely: COM1 & COM2.
COM1 is fixed for RS-232, while COM2 is selectable for RS-232/422/485.
COM1 : COM1 Connector
The COM1 Connector assignments are as follows:
PIN ASSIGNMENT
1 DCD
2 RX
3 TX
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
COM2 : COM2 Connector
The COM2 Connector assignments are as follows:
PIN ASSIGNMENT
RS-232 RS-422 RS-485
1 DCD TX- TX-
2 RX TX+ TX+
3 TX RX+ RX+
4 DTR RX- RX-
5 GND GND GND
6 DSR RTS- NC
7 RTS RTS+ NC
8 CTS CTS+ NC
9 RI CTS- NC
10 NC NC NC
COM1

Chapter 2 Hardware Configuration
Page: 2-8 Prox-1635LF USER
′ S MANUAL
2-5. RS232/422/485 (COM2) SELECTION
JP3 : RS-232/422/485 Selection
COM2 is selectable for RS-232, 422, 485 function.
The jumper settings are as follows :
COM 2
Function Jumper Setting (pin closed) Jumper
Illustration
RS-232
Open
RS-422
1-2, 5-6, 7-8, 9-10
11-12,13-14,15-16
17-18, 19-20
RS-485
1-3, 4-6, 7-8, 9-10
11-12,13-14,15-16
17-18, 19-20
*** Manufactory default --- RS-232.
