COMPUTER SAFE

LOGISTIC PROBE

OWNERS MANUAL

Stock Number W2991

On occasion, after printing of our literature is completed, our manufacturers may make changes and/or modifications to merchandise which will not be reflected

in this manual. Although we strive to maintain complete and accurate information, it is possible in some instances, that the product may differ slightly from

printed specifications. Illustrations are intended for reference only. Actual merchandise may vary. Wilmar is not responsible for typographical errors.

Please read these instructions carefully and retain them for future use.

IMPORTANT SAFETY INFORMATION

1. Use only for 6/12/24 Volt automotive circuits.

2. Refer to service manual for circuit diagrams and specic test procedures before use.

3. Keep children away. Children must never be allowed in the work area. Do not let them handle this product.

4. Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust.

5. Wear ANSI approved impact safety goggles when using this product.

6. When working on a vehicle with engine running, be careful of hot or moving engine components.

Keep well clear of moving engine parts.

1. Before use, check to see if the probe is working properly. Connect the Logic Probe clips to the vehicle’s battery. Con-

nect the red clip to the positive (+) terminal and the black clip to the negative (-) terminal. Touch the probe to the positive

(+) battery terminal, the LED should glow red. Touch the probe to the negative (-) terminal, the LED should glow green.

2. Turn the power ”ON” to the component or. circuit to be tested. (The ignition may need to be in the “ON” or “ACCES-

SORY” position, and the engine may need to be running.)

Touch the component or circuit wire with the probe’s tip. The LED will glow red if a positive (+) source is probed or green if a

negative (-) source is probed.

4. If the LED does not glow at all, the probe may not be making contact with the wire, the wiring or component may be

faulty, power may not be reaching the circuit, or the circuit may not be properly grounded.

5. When done, remove the red clip rst then the black clip from battery terminals.

To clean, remove both clamps from the battery. Wipe exterior with a clean damp cloth, and use mild soap or detergent if

necessary. Dry thoroughly. Do not use solvents or immerse in any liquid.

INSTRUCTIONS

VOLTAGE RANGE 6,12 AND 24 VDC

PROBE LENGTH 3-1/2”

WIRE LENGTH 32 in. LONG COILED WIRE (RELAXED)

SPECIFICATIONS

Specifications are subject to change

without notice

MAINTENANCE

1 YEAR LIMITED WARRANTY
