PUR PQC3R0 User manual

© 2020 All rights reserved.
PUR is a registered trademark used under license from Helen of Troy Limited.
200807
Owner’s Manual
PQC3RO
PQC4RO
PQC5RO
Under Sink Quick-Connect
Reverse Osmosis Filtration Systems

1
Table of Contents:
Conditions for Operation:
Safety Precautions:
• You must follow the guidelines to install this system. Check with your Province/State and local public works department for
plumbing and sanitation codes.
• If house water line pressure is over the maximum 100 psi (pounds per square inch), install a pressure regulator in the water
supply line before this system.
• System is for cold water use only and must be protected against freezing, which can damage the unit and cause water leakage.
• Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the
system. System certified for cyst reduction may be used on disinfected water that may contain filterable cysts.
• Make sure the water supply conforms to the specification guidelines. If the water supply conditions are unknown, consult your
local municipal water company or health department about the quality and the list of contaminants in your local water supply.
• When using the system for the first time, or after prolonged non-use (such as a vacation longer than one week), the system
should be flushed thoroughly.
• This system contains replaceable filter cartridges with a limited service life.
Supply Water Pressure Limits............................................... 40 - 100 psi (276-689 kPa)
Supply Water Temperature Limits ........................................ 40 - 113°F (4.4 -45°C)
Maximum Water pH Limits .................................................. 4-10
Maximum Total Dissolved Solids (TDS) ................................ 2,000 ppm
Maximum Water Hardness at 6.9 pH ................................... 10 gpg
Maximum Iron / Manganese / Hydrogen Sulfide .................. 0.2/0/0 mg/L
Maximum Chlorine in Supply Water ..................................... 2.0 ppm
Automatic shut-off control .................................................. Yes
Safety Precautions ..................................................................1
Conditions for Operation ..........................................................1
Package Contents ....................................................................2
Tools Required for Installation ................................................2
System Layout and Components .........................................3 - 5
Installation Instructions....................................................6 - 11
* Installing Quick-Connect Filter......................................6
* Un-installing Quick-Connect Filter ................................6
* Connecting to Cold Water Line.......................................7
* Drilling the Faucet Hole .................................................7
* Installing the Air Gap Faucet.........................................8
* Installing the Saddle Drain Clamp.................................9
* Mounting RO Unit Under Sink ........................................9
* Mounting the Ball Valve Onto Storage Tank.................10
* Connecting the Water Lines.........................................10
* Connecting the Tubes Using Quick-Connect Fittings ...10
* Refrigerator Hook-up (Optional) ..................................11
Start-up Instructions..............................................................11
Periodic System Maintenance..........................................11 - 12
RO Membrane Replacement...................................................12
GAC Polishing Filter Replacement (PQC5RO only) ..................13
Troubleshooting Guide............................................................14
Performance Data Sheet..................................................15 - 16
Replacement Parts List...................................................17 - 19
Warranty.................................................................................20

2
Package Contents:
Item Description QTY
A2 Unit Assembly 1
Item Description QTY
A3 Unit Assembly 1
Item Description QTY
A1 Unit Assembly 1
Item Description QTY
B Air Gap Faucet Set 1
C Inlet Valve Set 1
D Saddle Drain Clamp Set 1
E Tank Ball Valve 1
F Storage Tank 1
G Mounting Screw 2
H 6’ of 1/4” Blue Tubing 1
I 6’ of 1/4” Yellow Tubing 1
J 6’ of 1/4” Black Tubing 1
K 6’ of 1/4” Red Tubing 1
L 6’ of 3/8” Black Tubing 1
M Installation, Use & Care Guide 1
A1 A2
PQC3RO PQC4RO
PQC3RO
ACCESSORIES KIT
PQC4RO
PQC5RO
F.E.
H. I. J. K. L.
C. D.
G.
M.
Tools Required for Installation:
Safety
Goggles
Adjustable
Wrench
Pliers Phillips
Screwdriver
Utility Knife Measuring
Tape
Drill and Bits
(1/4”, 3/8” & 1-1/4” hole saw)
B.
A3
PQC5RO

3
Reverse Osmosis System Layout and Components:
PQC3RO
Filter Stage Part Number Description Service Life Filter Color Code
1st PQCCRB Carbon Block Filter 6 Months Green Dot
2nd PQCROM Reverse Osmosis Membrane 24 Months Blue Dot
3rd PQCCRB Carbon Block Filter 6 Months Green Dot
Replacement Parts
1/4" Yellow
Storage Tank
Auto Shut-Off Valve
Drain Flow
Regulator
1/4" Black
Valve
Drain
Clamp
Drain Cold
Water
Supply
3/8"
Black
1/4" Red
1/4" Blue
1st
Stage 2nd Stage 3rd Stage
Faucet

4
Reverse Osmosis System Layout and Components (continued):
PQC4RO
Filter Stage Part Number Description Service Life Filter Color Code
1st PQCSED Sediment Filter 6 Months Yellow Dot
2nd PQCCRB Carbon Block Filter 6 Months Green Dot
3rd PQCROM Reverse Osmosis Membrane 24 Months Blue Dot
4th PQCCRB Carbon Block Filter 6 Months Green Dot
Replacement Parts
1/4" Yellow
Storage Tank
Auto Shut-Off Valve
Drain Flow
Regulator
1/4" Black
Valve
Drain
Clamp
Drain Cold
Water
Supply
3/8"
Black
1/4" Red
1/4" Blue
1st
Stage 2nd Stage 3rd Stage 4th Stage
Faucet

5
Reverse Osmosis System Layout and Components (continued):
PQC5RO
Filter Stage Part Number Description Service Life Filter Color Code
1st PQCSED Sediment Filter 6 Months Yellow Dot
2nd PQCCRB Carbon Block Filter 6 Months Green Dot
3rd PQCCRB Carbon Block Filter 6 Months Green Dot
4th PQCROM Reverse Osmosis Membrane 24 Months Blue Dot
5th PROPF Granular Activated Carbon (GAC) Polishing Filter 6 Months N/A
Replacement Parts
1/4" Yellow
Storage Tank
Auto Shut-Off Valve
Drain Flow
Regulator
1/4" Black
Valve
Drain
Clamp
Drain Cold
Water
Supply
3/8"
Black
1/4" Red
1/4" Blue
1st
Stage 2nd Stage 3rd Stage 4th Stage
5th Stage
Faucet

6
Installation Instructions:
All RO Systems have been pre-assembled and tested at the factory. To check or replace the filter(s), the following steps need to be
implemented:
Installing the Quick-Connect Filter (See Figure 1):
Un-installing the Quick-Connect Filter (See Figure 2):
Figure 1
Figure 2
1/4
45˚
1. Unlock the Locking Tab by sliding it from the right to the left
side of the slot to ‘Unlock’ Position.
2. Lift the Filter Top Section into the Head. Turn the Filter about
1/4 turn in the direction as shown in figure 1 until it stops.
3. Slide the Locking Tab from left to right of the slot to ‘Lock’
position.
1. Unlock the Locking Tab by sliding it from the right to the left of
the slot to ‘Unlock’ Position.
2. Turn the Filter in the direction as shown in figure 2 about 1/4
turn until it comes out of the head.
NOTE: The Filter Head can be swung forward to assist in
the filter installation/removal.
CAUTION: Some water will drip during filter removal so
use a tray to catch any spillage.
CAUTION: Do not attempt to turn the Filter Housing while
in the ‘Lock’ position. It may damage the system and
cause leaks.
1/4
45˚

7
CAUTION: Do not drill through a countertop that is more than 1” thick.
CAUTION: Do not attempt to drill through a tiled, marble, granite or
similar countertop. Consult a plumber or the countertop manufacturer
for advice or assistance
CAUTION: When drilling through a countertop make sure the area
below the drilling area is free of wiring and piping. Make certain that
you have ample room to make the proper connection to the bottom of
the Faucet.
CAUTION: Do not attempt to drill through an all-porcelain or
porcelain-coated sink. For applications on these types of sinks we
recommend using the sprayer hole or mounting the Faucet through the
countertop. Otherwise consult a plumber or manufacturer for advice or
assistance.
1. Line the bottom of the sink with newspaper to prevent shavings, parts, or
tools from falling down the drain.
2. Place masking tape over the area to be drilled to help prevent scratches if
drill bit slips.
3. Mark point with a center punch. Use a 1/4” drill bit to drill a pilot hole.
4. Use a 1-1/4” hole saw to enlarge the hole. Smooth rough edges with a file.
Installation Instructions (continued):
1. Turn off the cold water supply by turning off the shut-off valve under the
sink. If the cold water line does not have a shut-off valve under the sink,
turn off the main water line in the house. Place a tray or towel under the cold
water line to catch any excess water.
2. Turn on the cold water faucet and allow all the water to drain from the line.
On a single handle faucet, the hot water may have to be turned off to prevent
any hot water cross over.
3. Loosen nut and separate cold water braided flex line from the kitchen cold
water faucet shank. Attach Inlet Valve to the faucet shank using the Rubber
Washer. Reinstall the flex line onto the Inlet Valve and tighten with an
adjustable wrench.
4. Insert 1/4” Tubing over the Guide Tube of the Inlet Valve. Tighten the
Compression Nut with an adjustable wrench.
CAUTION: The water supply to your unit MUST be from the
COLD WATER LINE. Hot water will damage your filtration system.
The Drinking Water Faucet should be positioned with function, convenience and
appearance in mind. An adequate flat area is required to allow the Faucet to rest
securely. Check the underside of the location for interference. Most sinks have
a pre-drilled 1-1/4" diameter hole designed for spray hoses. The Drinking Water
Faucet may be installed using this hole. If the pre-drilled hole cannot be used,
or is in an inconvenient location, it will be necessary to drill a 1-1/4” hole in the
sink or through the countertop next to the sink for the Faucet.
Connecting to Cold Water Line (See Figure 3 and 4):
Drilling the Faucet Hole (See Figure 5):
Figure 3
Figure 5
Inlet
Valve
Rubber
Washer
Rubber
Washer
Compression
Nut
Guide Tube
Figure 4
1/4”
Red
Tubing
Inlet
Valve
Guide Tube
1-1/4”
1/4”

8
Air Gap Window
Installation Instructions (continued):
CAUTION: The use of an Air Gap Faucet is generally required by
plumbing code in US and Canada. Ensure installation meets all
necessary plumbing codes in your location. The Air Gap Faucet
will prevent waste water from contaminating the RO filters if there
is a blockage in the drain line.
1. Remove Stem Nut on the Faucet.
2. Slide the Chrome Plate and Black Rubber Washer onto the Faucet Stem.
3. Connect the 1/4” Black Drain Tube up to the 1/4” fitting on the Air Gap
Faucet.
4. Then connect the 3/8” Black Tubing to the 3/8” fitting on the Air Gap
Faucet.
5. The Chrome Plate, Rubber Washer and Faucet Body are installed above the
sink or countertop.
6. Feed the 3/8” and 1/4” Black Tubing through the pre-drilled hole in the
sink/counter.
7. Place the Faucet through the drilled faucet hole, then add Spacer,
Securing Plate, Star Lock Washer and Stem Nut.
8. Tighten Stem Nut firmly while aligning the Faucet in the desired location.
9. Gently slide Faucet Compression Nut down over the 1/4” Blue Tubing,
followed with the Ferrule. Then push the Insert into the end of the Tubing.
10. Firmly push the Tubing into the stem of Faucet until it stops. Hand-screw
the Compression Nut onto the threads of the stem. Tighten with a wrench.
NOTE: Make sure the tubing is pushed all the way to the end of the
fitting
NOTE: The 3/8” Black Drain Tube goes by gravity feed to the
Saddle Drain Clamp connection. Make sure there are no kinks,
loops, or sharp bends in the 3/8” black tubing. Failure to make a
straight line to the drain may result in reject water leaking through
the air gap in the faucet onto the countertop or below the faucet.
Figure 6
Figure 7
Figure 8
Installing Air Gap Faucet (See Figure 6, 7 and 8):
Chrome Plate
Chrome Plate
Rubber Washer
Rubber Washer
Securing
Plate
Insert
Ferrule
Compression
Nut
1/4" Blue
Tubing
Lock Washer
Push in the
tube to the
end (3/4")
Stem Nut
Countertop
Countertop
Spacer
1/4" Black
Drain Line
to Air Gap
3/8" Black
Drain Line
from Air Gap

9
Installation Instructions (continued):
1. Attach the Saddle Drain Clamp to the vertical section of the drain pipe,
about 2 inches above the drain trap.
2. Using the fittings hole of the Saddle Drain Clamp as a guide, drill a 1/4”
hole through one side of the drainpipe.
CAUTION: Do not penetrate through the opposite side of the pipe.
3. Remove the Drain Clamp from the drainpipe and enlarge the hole with a
3/8” drill bit. Use a file to remove rough edges from the drilled hole.
4. Squarely cut the end of the 3/8" Black Tube. Insert the Tube through the
Saddle Drain Clamp quick-connect fitting about 1” past the inside wall of
the Saddle Drain Clamp.
5. Make sure the Black Rubber Gasket is adhered to the inside wall of the
Saddle Drain Clamp and place the Saddle Drain Clamp assembly over the
drainpipe. Insert 3/8” black tube into the drilled hole. Tighten the Clamp.
1. Position the RO unit on the back or right walls under the sink. Make sure to allow ample space for the installation and
plumbing connections. To change the filter cartridges, 2” of clearance is required underneath the filter housings.
2. Install mounting screws at least 15-3/4” from cabinet floor. Leave 1/4” space between the head of the screw and the wall
to slip bracket onto the screws. Then tighten the screws to secure the system.
Installing the Saddle Drain Clamp (See Figure 9 and 10):
Mounting the RO Unit Under the Sink:
CAUTION: Do not overtighten the screws, it may crack the Clamp.
CAUTION: The 3/8” Black Drain Tube must be as SHORT and
STRAIGHT as possible to the Saddle Drain Clamp, making a
downward slope from the faucet to the Saddle Drain Clamp to
allow for proper drainage. This is a gravity fed line and if there is
any bend or dip in the Tubing, the rinse water will not flow into the
drain properly. Water may back up and come out the Air Gap Hole
in the Faucet.
Figure 9
Figure 10
System Dimensions
PQC3RO PQC4RO
PQC5RO
Never
Mount
Here
Black Rubber
Gasket
Drain Clamp
Front Plate
Drain
Clamp
Back
Plate
3/8" Black
Drain Tubing Drain
Pipe
Mount
Drain
Valve
Here
14"
10" 11-1/2"
7-7/8"
15-1/4"15-1/4"
15-3/4"
2" Clearance2" Clearance

10
Installation Instructions (continued):
CAUTION: Before cutting the supplied tubing, measure the distance
between the components.
All Tubing is color-coded for ease of installation.
1/4” Black: Connects the waste water from the RO Membrane to the
Air Gap Faucet Intake Line.
1/4” Red: Connects the Inlet Valve of the cold water supply to the
inlet of the system.
1/4” Yellow: Connects the RO Membrane to the Storage Tank.
1/4” Blue: Connects the outlet of the system to the Faucet.
3/8” Black: Connects the Faucet to the Saddle Drain Clamp.
Note: Reference the diagram on page 3, 4 or 5 for color and
connection point on the RO System.
1. Connect the Ball Valve to the water Storage Tank thread on the upper side
of the Tank. Make sure the Black Rubber Gasket sits flat. Tighten the valve
but do not overtighten.
2. Connect the 1/4” Yellow Tubing to the Ball Valve. Push the Tubing in all
the way to make sure it is properly seated.
3. Turn the Ball Valve off.
1. Remove the Blue Horseshoe Clip from the Collet.
2. Pull out and discard the Colored Plug by pushing the Collet inward and holding with your fingers.
3. Insert Tubing into the Collet. Full engagement is 11/16” length of the Tubing into the Fitting for 1/4” Tubing, and 3/4” length
for 3/8” Tubing.
NOTE: Ensure the Tubing is pushed all the way into the backstop.
4. Re-install the Blue Horseshoe Clip into the Collet.
Connecting the Water Lines:
Connecting the Tubes Using Quick-Connect Fittings (See Figure 13, 14 and 15):
Mounting the Ball Valve Onto Storage Tank (See Figure 11 and 12):
Figure 11
Figure 12
Each plumbing connection point has a Colored Plug to match the color of the
tubing for simple installation reference. Discard plugs after the tubing has been installed.
Quick-connect fittings are used throughout the system. To ensure an optimal seal, tubing should be cut with the end square.
An angled cut or distortion of the tubing will not provide a proper seal and may cause leaks.
Figure 13 Figure 14 Figure 15
Backstop
Full engagement length
O-Ring
Horseshoe Clip Collet
Rubber
Gasket
Storage Tank
Storage Tank
Closed Open
1/4"
Yellow
Tubing
Ball Valve
Remove
Protective
Cap

11
Installation Instructions (continued):
Periodic System Maintenance:
Start-up Instructions:
Install 1/4” polypropylene plastic tubing if your refrigerator is within 25 ft. of your RO unit. Do not use copper tubing for RO product
water. If the refrigerator is over 25 ft from the RO Unit it is recommended to use 3/8” tubing. Install a tee in the blue tubing
between the outlet of the system and the faucet. It is recommended to install a ball valve in the line to your ice maker to allow
pressure to increase sufficiently in the storage tank for the ice maker solenoid valve to operate properly. Leave the ball valve in the
closed position until the tank is full after the start-up procedure is completed.
Depending on which model was purchased the chart below will assist with replacement of filters. The replacement filter can be
obtained online at www.ghpgroupinc.com or at the retail store where the system was purchased.
NOTE: If you have connected your RO system to a refrigerator/ice maker, make sure the ice maker is off. Do not
allow water to flow to the ice maker until flush is complete and the tank has been allowed to fill completely.
Connection from the RO to the icemaker system should have an inline valve installed before the icemaker so it
can easily be closed to prevent water flowing to the ice maker during start-up and periodic maintenance.
Your RO tank must be allowed to fill up fully for the ice maker system to work properly.
NOTE: You will not have filtered water immediately. It will take 2 hours to
completely fill the Storage Tank to create liberal flow from the RO Faucet.
1. Turn Inlet Valve and Storage Tank Ball Valve both in open position.
2. Ensure the RO Faucet is closed.
3. Slowly open the cold water supply valve that you closed at the beginning
of the installation process.
4. Water pressure will start to build up in the RO system in about 2 hours as
pressure builds in the Storage Tank. Carefully inspect all Fittings and
Connections. Check for leaks and fix if any are found.
5. You must fill and purge a minimum of 2 tanks of RO water before it is ready
for consumption.
6. After purging, your RO system is ready for use.
Refrigerator Hook-Up (optional):
Storage Tank Ball Valve
Closed Open
Model # Filter Replacement Kit
Replace every 6 months
RO Membrane
Replace every 24 months
PQC3RO PQCCRBKIT (contains: 2x PQCCRB) PQCROM
PQC4RO PQC4ROKIT (contains: 2x PQCCRB, 1x PQCSED) PQCROM
PQC5RO PQC5ROKIT (contains: 2x PQCCRB, 1x PQCSED, 1x PROPF) PQCROM

12
Periodic System Maintenance (continued):
RO Membrane Replacement:
Filters must be replaced periodically. This will protect the RO Membrane from being destroyed by chlorine and also prevent the
Filters from plugging with sediment. Refer to page 11 for the replacement schedule.
NOTE: Place a tray or towel under the RO system to catch any water drips before uninstalling the filter sumps.
For Model PQC3RO:
1. Refer to “Un-installing the Quick-Connect Filter” on page 6 to remove the 1st Stage Filter (leftmost of the system).
2. Then, remove the 3rd Stage Filter (rightmost of the system).
3. Discard the Filters in a proper manner.
4. Refer to “Installing the Quick-Connect Filter” on page 6 to install the new Filters in the reverse order: Install the 3rd-Stage
Filter first, then the 1st Stage Filter.
5. Go to step 6.
For Model PQC4RO:
1. Refer to “Un-installing the Quick-Connect Filter” on page 6 to remove the 1st Stage Filter (leftmost of the system).
2. Then, remove the 2nd and 4th Stage Filters.
3. Discard the Filters in a proper manner.
4. Refer to “Installing the Quick-Connect Filter” on page 6 to install the new Filters in the reverse order: Install the 4th Stage
Filter first, then the 2nd Stage Filter and then the 1st Stage Filter.
5. Go to step 6.
For Model PQC5RO:
1. Refer to “Un-installing the Quick-Connect Filter” on page 6 to remove the 1st Stage Filter (leftmost of the system).
2. Then, remove the 2nd and 3rd Stage Filters.
3. Refer to “GAC Polishing Filter Replacement” on page 13, to remove the GAC Polishing Filter.
4. Discard the filters in a proper manner.
5. Refer to “Installing the Quick-Connect Filter” on page 6 to install the new Filters in the reverse order: Install the GAC
Polishing filter first, then the 3rd and 2nd Stage Filters, and then the 1st Stage Filter last.
6. Turn off the Ball Valve of the Storage Tank and turn the RO Faucet open by lifting the handle upward. The water begins to
trickle out (it will come out very slow). It is possible to confirm that the RO Membrane is working by collecting and measuring
water dripping from the RO Faucet with RO Tank Valve closed. This is the RO Membrane production rate (approx 80-150mL/
min). Allow to drip for 15 minutes.
7. Close the RO Faucet and then open the Ball Valve of the Storage Tank.
The RO system is ready for use!
The RO Membrane must be replaced as stated. The Membrane is critical for effective reduction of certification claims. Refer to
page 11 for the replacement schedule.
Remove the Membrane:
1. Refer to “Un-installing the Quick-Connect Filter” on page 6 to remove the RO Membrane Housing.
2. Discard the Housing in a proper manner.
Install the Membrane:
1. Refer to “Installing the Quick-Connect Filter” on page 6 to install a new RO Membrane Housing.
2. Follow “Start-up Instructions” on page 11 to purge the system before using.

13
GAC Polishing Filter Replacement (PQC5RO only):
1. Turn off the Inlet Valve.
2. Close the Ball Valve of the Storage Tank.
3. Open the RO Faucet to release the
pressure in RO system.
Removing the Expired GAC Polishing Filter:
1. Remove the Blue Horseshoe Clip securing the 1/4” Blue Tubing in the quick-connect on the expired GAC Polishing Filter. Then
disconnect the Blue Tubing by pushing in the Collet and pulling out the Blue Tubing.
2. Repeat the same procedure to remove 1/4” White Tubing from the other end of the GAC Polishing Filter.
3. Pull off the expired GAC Polishing Filter from the plastic Filter Mounting Brackets that are attached to the metal Filter Housing
Bracket.
Installing the New GAC Polishing Filter:
1. Remove the outer packaging from the new GAC Polishing Filter. Place the new Filter onto the plastic Filter Mounting Brackets.
2. Connect the 1/4” Blue Tubing back into the outlet of the Filter. Replace the Blue Horseshoe Clip to secure the Tubing.
3. Connect the 1/4” White Tubing into the inlet of the Filter. Replace the Blue Horseshoe Clip to secure the Tubing.
4. Follow steps 7 - 8 of “Periodic System Maintenance” on page 11.
Flow Direction
GAC Polishing Filter
Filter Housing Bracket
1/4"
White
Tubing
1/4"
Blue
Tubing
Water
Inlet Water Outlet

14
Troubleshooting Guide:
Problem Possible Cause Solution
Milky colored water Air in system It’s a normal occurrence during initial start-up of the system. This milky
color will disappear during normal use within 1 to 2 weeks.
Noise from faucet
Air gap of the Faucet Normal sound with an Air Gap Faucet when the RO system is producing
RO water.
Location of Saddle Drain Clamp Relocate the drain to a horizontal location.
Restriction in drain line Clear blockage that is sometimes caused by debris from garbage disposal
unit or dishwasher.
Slow water production
Low water pressure The systems require min 40 psi incoming water pressure. A booster pump
may be needed in low water area.
System has just started up Normally it takes up to 2 hours to fill the Storage Tank.
Low air pressure in the Storage Tank Add air pressure to the Tank. The pressure should be 5 to 7 psi when the
Tank is empty.
Crimp in Tubing Check Tubing - Straighten or repair as necessary.
Clogged Pre-Filters Replace Pre-Filters.
Fouled Membrane Replace the Membrane.
Offensive water taste or smell
GAC Polishing Filter is depleted Replace the GAC Polishing Filter.
Fouled Membrane Replace the Membrane.
Sanitizer not flushed out Drain the Storage Tank and refill it. Repeat to discard 3 tanks of water.
No drain water Clogged Drain Flow Regulator Replace the Drain Flow Regulator.
Water leak from the Faucet Air Gap
Hole
3/8” black tubing plugged, restricted
or incorrectly connected to drain line
Eliminate restriction or plug. Check the drain line is routed properly, not
clogged or crimped.
Water leak at thread fittings Fitting not tightened Tighten Fittings as necessary.
Water leak at quick-connect
fittings
Tubing not cut squarely Cut the Tubing end square.
Tubing not pushed in all the way Push the Tubing in all the way.
Tubing nicked or outer surface finish is
not smooth
Pull the Tubing out of the Connector, cut off problem area and reinsert the
Tubing into the connector.
Water leak at sump
connection
Sump not locked in the correct position Turn the sump into the 'Lock' position.
O-ring missed or damaged Check the O-rings and replace if necessary.
Should service be required or you have any questions regarding how to use your PUR product, please contact Customer Service at:
1-877-447-4768 or [email protected]

15
Reverse Osmosis Drinking Water System
Model: PQC3RO, PQC4RO and PQC5RO
The system must be installed and operated in accordance with manufacturer’s recommended procedures and guidelines.
Failure to follow the instructions may result in leakage, malfunction and will void warranty.
Read the performance data (on page 16) and compare the capability of the system with your actual water treatment needs. It
is recommended that, before installing the system, you have your water supply tested to determine your actual water treatment
needs.
Arsenic Fact Sheet
This system has been tested for the treatment of water containing pentavalent arsenic (also known as As(V), As(+5) or Arsenate)
at concentration of 0.30 mg/L or less. The systems reduce pentavalent arsenic, but may not reduce other forms of arsenic. These
systems are also to be used on the water supplies containing a detectable free chlorine residual or own water supplies that have
been demonstrated to contain only pentavalent arsenic. Treatment with Chloramine (combined chlorine) is not sufficient to ensure
complete conversion of trivalent arsenic to pentavalent arsenic.
Arsenic is a naturally occurring contaminant found in many ground waters. There are two forms of arsenic: Pentavalent Arsenic
[also called as As(V), As(+5) or Arsenate] and Trivalent Arsenic [As (III), As (+3) and Arsenite]. Although both forms are potentially
harmful to human health, trivalent arsenic is considered more harmful than pentavalent arsenic.
Arsenic in water has no color, taste or odor. It must be measured by a lab test. Public water utilities must have their water tested
for arsenic. You can get the results from your water utility. If you have your own well, you can have the water tested. The local
health department or state environmental health agency can provide a list of certified labs.
RO systems do not remove trivalent arsenic from water very well. RO systems are very effective at reducing pentavalent arsenic. If
you have free chlorine residual in contact with your water supply for at least one minute, the trivalent arsenic will be converted to
pentavalent arsenic and reduced by RO systems. Other water treatment chemicals, such as ozone and potassium permanganate,
will also change trivalent arsenic to pentavalent arsenic. A combined chlorine residual (also called chloramine) may not convert
all the trivalent arsenic. If you get your water from a public water utility, contact the utility to find out if free chlorine or combined
chlorine is used in the water system.
The system requires regular replacement of all filters to maintain proper operation. Depending on usage and influent water quality,
the sediment and carbon filters should be changed at least annually and the RO Membrane should be replaced every 2 years.
Variation of chlorine, sediment or TDS levels may affect replacement frequency.
Performance Data Sheet:

16
Performance Data Sheet (continued):
The PQC3RO and the PQC4RO have been tested and certified by NSF International according to NSF/ANSI 42, 58 and CSA B483.1.
The PQC5RO has been tested and certified by NSF International according to NSF/ANSI 58 and CSA B483.1 for the reduction of the
substances listed below.
The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the
permissible limit for water leaving the system, as specified in NSF/ANSI 58. While testing was performed under standard laboratory
conditions, actual performance may vary.
Performance Claims for PQC3RO, PQC4RO and PQC5RO
Substance
Average Influent
Challenge
Concentration
Maximum Allowable
Product Water Level
Percent Reduction
Requirement
Tested Performance
Product Water Level
1
Percent Reduction
1
NSF Standard 42
Chlorine
(PQC3RO & PQC4RO post filter only) 2.0 mg/L ± 10% ≥ 50% 91.8%
Particulate Class III
(PQC3RO & PQC4RO post filter only) 10,000/mL ≥ 85% 99.9%
NSF Standard 58
Arsenic (Pentavalent) 0.30 mg/L ± 10% 0.010 mg/L 0.007 mg/L 99.2%
Barium 10.0 mg/L ± 10% 2.0 mg/L 0.43 mg/L 97.6%
Cadmium 0.03 mg/L ± 10% 0.005 mg/L 0.0014 mg/L 98.1%
Chromium (Hexavalent) 0.30 mg/L ± 10% 0.10 mg/L 0.009 mg/L 98.5%
Chromium (Trivalent) 0.30 mg/L ± 10% 0.10 mg/L 0.010 mg/L 96.7%
Copper 3.0 mg/L ± 10% 1.3 mg/L 0.1 mg/L 98.7%
Fluoride 8.0 mg/L ± 10% 1.5 mg/L 0.4 mg/L 95.7%
Lead 0.15 mg/L ± 10% 0.010 mg/L 0.005 mg/L 96.6%
Radium 226/228 25 pCi/L ± 10% 5 pCi/L 5 pCi/L 80%
Selenium 0.10 mg/L ± 10% 0.05 mg/L 0.002 mg/L 97.9%
TDS 750 ± 40 mg/L 187 mg/L 25 mg/L 96.7%
Cyst ≥ 50,000 /mL 99.95% 99.99%
Turbidity 11 ± 1 NTU 0.5 NTU < 0.1 NTU > 99.1%
Daily Production Rate: 20.3 gpd
Efficiency:
2
14.97%
Recovery:
3
27.81%
Manufactured and warranted by GHP Group Inc.
USA: 6440 W. Howard St. Niles, IL 60714-3302
Canada: 271 Massey Rd. Guelph, Ontario, N1K 1B2
Tested by NSF International according to NSF/ANSI Standard 42, 58 and CSA B483.1.
Efficiency rating means the percentage of the influent water to the system that is available to the user as reverse osmosis treated water under operating
conditions that appropriate typical daily usage.
Recovery rating means the percentage of the influent water to the membrane portion of the system that is available to the user as reverse osmosis
treated water when the system is operated without a storage tank or when the storage tank is bypassed.
1
2
3

17
Replacement Parts List:
Item Description Part #
1 Storage Tank VWC10006
2 Tank Ball Valve VWC10005
3 Saddle Drain Clamp Set VWC10004
4 Air Gap Faucet Set VWC10003
5 Flow Restrictor, 300 mL VWC10011
Item Description Part #
6 Carbon Block Filter PQCCRB
7 Reverse Osmosis Membrane PQCROM
8 1/4" QC One-way Elbow VWC10009
9 Inlet Valve Set VWC10001
10 Auto Shut-off Valve VWC10010
2
3
5
6
8
5
6
8
10
9
9
4
910
11 10
1
7
1
2
12
7
11
3
4
2
3
1
5
109
676
4
8
PQC3RO

18
Replacement Parts List:
Item Description Part #
1 Storage Tank VWC10006
2 Tank Ball Valve VWC10005
3 Saddle Drain Clamp Set VWC10004
4 Air Gap Faucet Set VWC10003
5 Auto Shut-off Valve VWC10010
6 Inlet Valve Set VWC10001
Item Description Part #
7 Flow Restrictor, 300 mL VWC10011
8 1/4" QC One-way Elbow VWC10009
9 Sediment Filter PQCSED
10 Carbon Block Filter PQCCRB
11 Reverse Osmosis Membrane PQCROM
2
3
5
6
8
5
6
8
10
9
9
4
910
11 10
1
7
1
2
12
7
11
3
4
2
3
1
5
109
676
4
8
PQC4RO

19
Replacement Parts List:
Item Description Part #
1 Storage Tank VWC10006
2 Tank Ball Valve VWC10005
3 Saddle Drain Clamp Set VWC10004
4 Air Gap Faucet Set VWC10003
5 GAC Polishing Filter PROPF
6 Auto Shut-off Valve VWC10010
Item Description Part #
7 Flow Restrictor, 300 mL VWC10011
8 Sediment Filter PQCSED
9 Carbon Block Filter PQCCRB
10 Reverse Osmosis Membrane PQCROM
11 Inlet Valve Set VWC10001
12 1/4" QC One-way Elbow VWC10009
2
3
5
6
8
5
6
8
10
9
9
4
910
11 10
1
7
1
2
12
7
11
3
4
2
3
1
5
109
676
4
8
PQC5RO
