PURE Move 2520 User manual

1
Thank you for choosing Move 2520. This manual
will get you up and running in no time and
explains how to make the most of Move 2520’s
great features. If you need additional help with
topics not covered in this manual, please visit the
Pure support pages at www.pure.com.

2
Symbols on the product and in the user manual
Potentially serious risk to your personal safety. To avoid possible injury or death, obey all safety
notices with this symbol.
Caution. Read the user manual before use.
Where to switch on or off the product, or put it in standby.
Part
Project
Sub Assembly
Doc Type
Customer
Version
Version Date
106WV
Marley
Rear Housing
Artwork
Pure
1
07/09/2016
History V1 - 1st Issue
Pantone 877C
Colour Spec
5V DC power supply input, 0.8 amps.
ChargePAK M1 safety instructions
1. Read the instructions for ChargePAK use in this document.
2. Only use your ChargePAK with original Pure products. Use only the original Pure
ChargePAK M1.
3. Store ChargePAK in a cool, dry place at normal room temperature. Remove from devices
that will be stored unused for extended periods.
4. Do not puncture, modify, drop, throw, or cause other unnecessary shocks to your
ChargePAK. May present a risk of fire, explosion, or chemical burn if mistreated.
5. Do not dispose of ChargePAK in a fire or incinerator, or leave in hot places such as a motor
car under direct sunlight. Do not store near oven, stove, or other heat source.
6. Do not connect ChargePAK directly to an electrical source, such as a building outlet or
automobile power-point. Do not place into a microwave oven, or any other high-pressure
container.
7. Do not immerse ChargePAK in water or otherwise expose it to liquids.
8. Do not short circuit ChargePAK.
9. Do not use or charge a ChargePAK that appears to be leaking, discoloured, rusty, deformed;
emitting an odour; or is otherwise abnormal.
10. Do not touch a leaking ChargePAK directly; wear protective material to remove and dispose
of it properly immediately.
11. Do not store where children may have access.
12. Dispose of ChargePAK as per normal rechargeable batteries according to the local laws
and regulations of your region. Some batteries may be recycled, and may be accepted for
disposal at your local recycling centre.
13. Attention should be drawn to the environmental aspects of battery disposal.
Safety information
1. Familiarise yourself with all of the safety information and instructions before using the radio.
When passing this radio on to others, please include all documents.
2. The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
If liquid or water is spilled on to the radio, switch it off at the mains immediately, disconnect the
mains plug and contact your dealer.
Never touch the plug or the radio itself with wet hands. Never pull the power cable when
disconnecting the power adaptor from the power supply.
3. The batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as
sunshine, fire or the like
4. Using the radio in rooms or climates with high humidity and temperatures may cause
condensation to form inside the radio, which can damage the radio. Use apparatus in moderate
climates only.
5. Avoid extreme degrees of temperature,either hot or cold. Place the device well away from
heat sources such as radiators or gas/electric fires. No naked flame sources, such as lighted
candles, should be placed on the apparatus
6. The mains power adapter is used as the disconnect device, the disconnect device shall remain
readily operable.
Fit the mains adaptor to an easily accessible socket located near the radio and ONLY use the
mains power adapter supplied.
7. Use only power supplies listed in the user instructions. (Model KSLFB0500080W1UV-1 or
SW0500800-AM).
8. Ensure that the available supply voltage corresponds with the required operational voltage of the
radio before use.
9. Disconnect your radio from the power supply if you will not use your radio for a long period of
time (e.g. if you are going on holiday).
10. Always unplug your radio from the mains socket before cleaning. When cleaning the radio,
do not use any type of abrasive pad or abrasive cleaning solutions as these may damage the
radio’s surface.
11. To reduce the risk of electric shock, do not remove any screws as there are no user-serviceable
parts inside. Refer servicing to qualified personnel.
Damage to hearing can occur with consistent exposure to high volume when using
headphones. Always check the volume level before inserting headphones into your ears.
Use of headphones while operating a vehicle is not recommended and is illegal in some
areas. Stop listening to your Move if you find it distracting while operating any type of
vehicle or performing any other activity that requires your full attention.

3
Contents
4 What’s in the box?
5 Quick guide to Move 2520
6 Getting started
6 Insert the ChargePAK
7 Connect headphones
7 Switch on
7 Select language
7 Autotune
8 Reading the display
9 Using the navigation dial
10 Listening to digital radio
10 Listening to FM radio
11 Favourites
12 Settings
12 Time (12/24h)
12 Language
12 Factory reset
12 Version
12 Update
13 FM stereo
13 Autotune
13 Sleep timer
14 Audio settings
14 Display settings
15 Help and specifications
15 Hints and tips
15 Technical specifications
17 Pure Warranty Statement for Australia

4
What’s in the box?
Move 2520 Noise-isolating headphones
(Plus a choice of small,
medium or large earbuds)
ChargePAK M1 Power adapter
(Attach the appropriate pins for
your region)

5
Quick guide to Move 2520
Display
Navigation dial
See page 9 for information.
Top
Bottom
Micro USB socket
For connecting the mains
adapter or a USB cable (for
software updates).
Lock switch
Slide to lock the navigation dial
and the Select button to prevent
accidental use.
3.5mm socket
For headphones.
Select button

6
Getting started
Insert the ChargePAK
1. Press plastic catch on rear and slide the rear cover and lift off as
shown.
2. Insert ChargePAK M1. It can only be inserted one way, with the
ChargePAK logo facing up.
3. Once ChargePAK M1 is securely inserted, place the rear cover
back on. Press down slightly near the catch while sliding the cover
back on.
Note: Before using Move for the first time, we recommend that you
charge it for at least 3 hours.
Remove ChargePAK M1 if you are storing Move unused for a long
period.
Under normal circumstances your ChargePAK M1 will give you
years of trouble-free use, but as with all rechargeable batteries its
performance will gradually reduce with age. To replace it, visit your
local Pure dealer or buy direct from www.pure.com.

7
Connect headphones
For optimum sound quality and noise
isolation, attach the size of earbuds that best
fit your ears.
Unravel the earphone cable and plug the
headphones into the socket on the bottom
of Move.
Warning: Damage to hearing can occur with
consistent exposure to high volume when
using headphones. Always check the volume
level before using Move.
Note: Because the headphone cable doubles
as an aerial, using headphones with shorter
or asymmetrical cables or using headphones
with volume controls may affect reception.
Switch on
Press Source to switch Move on.
Select language
Turn the navigation dial and press Select to
choose from English, French, German or
Italian.
Autotune
Move will perform an autotune for digital
stations and tune to a station when complete.
The number of stations found is displayed
during an autotune.
Note: An autotune can take up to two
minutes.
DR
ST
Scanning... 32
Move 2520
Language *
English
DR
ST
BBC Radio 2
Now playing: P

8
Reading the display
DR
ST
FM
Bringing you hot
1Xtra - BBC
AM
PM
ST
Stereo signal
DR
Digital radio
FM
FM radio
Volume/mute
Signal strength
Sleep timer
Displayed when the sleep
timer is set
Text area
Displays menus,
settings and station
information
Battery charge level
Animated when charging.
Removed when fully
charged.
Current time
AM/PM
indicator

9
Using the navigation dial
Turn
Press
During normal listening
Turn the dial to adjust the volume level.
When in a menu
Turn the dial to scroll through options.
Select (centre button)
Confirm selections.
Menu
Access options and settings. Press again to
go back one step.
Fav
Press to display the favourites list. Hold to
save a favourite. You can save up to 10 digital
and 10 FM stations as favourites.
Source (also On/Off)
Switch between digital and FM radio. Press to
switch on and hold to switch off.
Stations
Displays the station list in digital radio or
tuning screen in FM.
DR
ST
Volume
25
DR
ST
Digital radio
Settings

10
ST
FM
Listening to digital radio
Tuning
Press Stations to show the station list. Turn
the navigation dial to scroll through stations
and press Select to tune. Press Menu or
Stations to exit.
Listening to FM radio
Tuning
Press Stations to show the FM tuning screen
then use one of the following methods to find
the station you want:
Seek tune
Press left (Stations) or right (Fav) on the
navigation dial to seek to the previous or next
station with a strong signal. Press Select to
exit.
Manual tune
Turn the navigation dial to manually tune to a
frequency. Press Select to exit.
DR
ST
Station list
Absolute
FM tuning
87.50MHz
FM
Scanning
88.30MHz

11
Favourites
Saving a favourite
You can save up to 10 digital and 10 FM
stations as favourites for easy access.
1. Press Fav to show the favourites list.
2. Turn the navigation dial to scroll through
favourites.
3. Press and hold Fav or Select to save the
current station as a favourite. You can
save over existing favourites.
Selecting a favourite
1. Press Fav to show the favourites list.
2. Turn the navigation dial to scroll through
favourites.
3. Press Select to tune.
DR
ST
Favourites
3: Empty
DR
ST
Favourites
3: Absolute
DR
ST
Favourite 3
Stored

12
DR
ST
Settings
Time (12h/24h)
Switch between 12 or 24 hour clock.
Language
Select a menu language from English,
French, German or Italian.
Factory reset
Select Yes to delete all personal settings and
favourites. Restarts with default settings.
Version
Displays the current software version.
Update
Contact Pure technical support
(http://support.pure.com) for more
information on how to update Move 2520 to
the latest software version.
Press Menu, select Settings and choose a setting to adjust:
Time (12h/24h)
24 hour
DR
ST
Language *
English
DR
ST
Factory reset?
<No> Yes
DR
ST
Version
V1.2_M
DR
ST
Update?
<No> Yes

13
FM stereo
(FM radio only)
Press Menu, then select FM stereo and
choose between Stereo or Mono FM
reception. Mono may improve weaker
reception.
ST
FM
FM stereo *
Stereo
Autotune
(Digital radio only)
Press Menu, then select Autotune to search
for new stations and remove those no longer
broadcasting.
DR
ST
Scanning... 32
Sleep timer
1. Press Menu, then select Sleep timer.
2. Turn the navigation dial and press Select
to set the timer for up to 90 minutes or
choose Sleep off to cancel.
The sleep timer icon will appear when a sleep
timer is set.
The sleep timer can be set to switch Move off after a period of time.
DR
ST
Set sleep time
30 minutes
DR
ST
1Xtra - BBC
Bringing you

14
Audio settings
1. Press Menu, then select Audio.
2. Select Bass or Treble.
3. Turn the navigation dial and press Select
to set the level from -6 (low) to 6 (high).
To adjust the bass and treble settings:
DR
ST
Treble
3
Display settings
Backlight
Adjust how long the display backlight stays
on. Choose from Always on, Timed off (after
7 seconds) or Off.
Information
(Digital radio only)
Choose the information shown on the display.
Scrolling text
Provided by the broadcaster.
Signal strength
The clear block indicates reliable reception
level.
Signal quality
From 0 (low) to 100 (high).
Press Menu, select Display and select one of the following options:
DR
ST
Backlight
Always on
DR
ST
Information
Sig. quality

15
Hints and tips
The current value for most settings is indicated on the display by an
asterisk (
*
).
Technical specifications
Radio Radio Digital and FM radio
Frequencies DAB/DAB+, FM radio 87.5-108 MHz
Headphones Noise-isolating, 16 Ohm, 10 mm drivers.
Input Micro USB for power supply and software
upgrade.
Output 3.5mm stereo output for headphones.
Mains power Adapter: Input AC 100 - 240 V~,50/60 Hz;
Output DC 5V , 0.8 A;
Main Unit: DC 5V
Part
Project
Sub Assembly
Doc Type
Customer
Version
Version Date
106WV
Marley
Rear Housing
Artwork
Pure
1
07/09/2016
History V1 - 1st Issue
Pantone 877C
Colour Spec
, 0.8 A
Software version V1.2_M_1RC9
Battery ChargePAK M1 1000mAh.
Dimensions 102 mm x 56 mm x 15 mm
Approvals CE marked.
Compliant with R&TTE (RED 2014/53/EU
after 13th June 2017) and RoHS Directives
(1999/95/EC and 2011/65/EU).
ETSI EN300 401 compliant.
See pure.com for the full Declaration of
Conformity.
Help and specifications

16
Warranty information
Pure International Ltd. warrants to the end user that this product will be
free from defects in materials and workmanship in the course of normal use
for a period of two years from the date of purchase. This guarantee covers
breakdowns due to manufacturing or design faults; it does not apply in cases
such as accidental damage, however caused, wear and tear, negligence,
adjustment, modification or repair not authorised by us. Should you have a
problem with your unit please contact your supplier or contact Pure Support at
http://support.pure.com.
Disclaimer
Pure International Limited makes no representation or warranties with respect to
the content of this document and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Further, Pure International
Limited reserves the right to revise this publication and to make changes in it from
time to time without obligation of Pure International Limited to notify any person or
organization of such revisions or changes.
Trademarks
Move 2520, ChargePAK, Pure, the Pure logo are trademarks or registered
trademarks of Pure International Limited.
Copyright
Copyright © 2017 Pure International Limited. All rights reserved. No part of this
publication may be copied or distributed, transmitted, transcribed, stored in
a retrieval system, or translated into any human or computer language, in any
form or by any means, electronic, mechanical, magnetic, manual or otherwise,
or disclosed to third parties without the express written permission of Pure
International Limited.
Disposal of Waste Electrical & Electronic Equipment
This symbol on the product or on its packaging indicates that this
product should not be treated as household waste. Instead it should
be handed over to a suitable collection point for the recycling of elec-
trical and electronic equipment. By ensuring this product is disposed
of correctly, you will help prevent potential negative consequences
for the environment and human health, which could otherwise be
caused by inappropriate waste handling of this product. The recy-
cling of materials will help to conserve natural resources. For more
detailed information about recycling of this product, please contact
your local council office, your household waste disposal service or
the shop where you purchased the product.

17

104FO_07
www.pure.com
support.pure.com
Pure International Limited
Concept House
Home Park Road
Kings Langley
Herts, WD4 8UD
United Kingdom
http://support.pure.com
