Q-See QT5132 User manual

32 Channel DVR | 32 Cams | 700TVL Res | 100ft/80ft Night Vision
QT5132-32N8-3
Cover every angle and know that what you've worked hard for is safe and sound with a 32 channel, real-time surveillance system
from Q-See. The QT5132-32N8-3 is a high capacity system with 30fps recording for a thorough and effective coverage. Let this high
resolution Q-See system watch over all corners of your warehouse and know what happens just as it happens. Easily protect your
multi-level office building with just one system. No matter the need, this superb 32 channel system offers a solution.
The 32 included 700TVL bullet cameras produce clear surveillance images with excellent detail. These cameras, with 756x504
effective pixels, produce sharp, detailed images that are capable of up to 100 feet of night vision to ensure your entire property is
clearly covered both day and night.
This DVR's remote monitoring capabilities keep you connected, enabling you to keep an eye on your home from anywhere at any
time. Simply download the free Q-See Apps and access live or previously recorded video via iPhone, iPad, Android, or Windows
Phone. Instantly receive email alerts with incident snapshots when motion is detected or in the event a camera becomes disabled.
As the frontrunner in innovation, Q-See is the trusted leader in surveillance solutions for home and business, delivering peace of
mind anywhere, anytime.
FEATURES:
• 32 Channel DVR with Real-Time D1 Resolution
• 32 Cameras with 700TV Lines of Resolution
• Bullet Cameras with 100ft of Night Vision
• Dome Cameras with 80ft of Night Vision
• Pre-Installed 3TB Hard Drive
• PC and Mac Compatibility
• Email Alerts with Incident Snapshots
• Free Q-See Apps for iPhone, iPad, Android, and Windows Phone
• HDMI® Port for High Resolution Viewing options with included Standard HDMI® cable
SPECIFICATIONS:
DVR
Model QT5132(DVR)
Video Compression Advanced H.264
Max Hard Drive Storage Supports 2 SATA HDD up to 3 TB each (Not Included)
Backup Via PC, Flash Drive, USB Hard Drive
Power DC 12V / 4A (Adapter Included)
Recording Option NTSC: Full D1: Real Time: 960 FPS (7.5 FPS Per Channel),
Resolution NTSC: Full D1 (704x480),
Recording Mode Motion Detection, Time Schedule, Alarm Trigger, Manual
USB Interface USB Mouse, USB Backup
Video Inputs/Outputs 1 BNC Input(s) / 1 VGA Output(s) / 1 HDMI Output(s) / 1 BNC Output(s) / 1 BNC Spot Put Output(s)
Audio Inputs/Outputs 4 RCA Input(s) / 4 RCA Output(s)
Alarm Sensor Inputs/Outputs 16 Input(s) / 1 Output(s)
Network Interface RJ-45 for Router Connection Enabling Remote Monitoring
Pan/Tilt/Zoom Control 1 RS-485 Connection
Cameras
Camera Model QM7010B

Weatherproof Weatherproof Indoor & Outdoor
Horizontal Resolution 700 TV Lines
Image Sensor 1/3, CMOS, Color
Infrared LEDs 36
Night Vision Range Up to 100 ft
Lens 4.6mm lens 50°-55° field of view
Mount 3-Axis Stands
Camera Cables 60 Feet of Cable with Each Camera
Camera Cables QM7011D
Camera Cables Weatherproof Indoor & Outdoor
Camera Cables 700 TV Lines
Camera Cables 1/4, CMOS, Color
Camera Cables 24
Camera Cables Up to 80 ft
Camera Cables 3.6mm Lens 50° to 55° Field of View
Camera Cables Dome
Camera Cables 60 Feet of Cable with Each Camera
Viewing
NTSC
Live Display Resolution 800x600, 1024x768, 1280x1024, HDMI
Display Modes Single Camera, Split Screen Multi-Camera, Auto-Sequence
Video Search Time, Motion Detection, Alarm Trigger, Manual
Stream Dual Stream
Compatibility
Computer System Support
Windows XP Vista 7 8
Mactonish 10.7 10.8 10.9
Compatible Browsers
Browsers Chrome (w/ IE plugin) Explorer Firefox Safari
Mobile Phone Support
iPhone/ iPad
Android
Windows Phone 7.5/8
www.Q-See.com
