QTX Light LUX-LD30W User manual

USER MANUAL
LUX-LD30W LED MOVING HEAD
150.447UK

User Manual
– LUX LD30W 150.447UK
2
LUX-LD30W LED MOVING HEAD – For indoor use only
1. General Introduction :
With a powerful 30W white LED this moving head has the equivalent light output of a 150W halogen
bulb, yet uses approx. 20% of the power. It is has 5 modes of operation including 2 auto, 2
sound-to-light and DMX512. The light also features an 8 colour wheel and a choice of 7 different
gobos that can be auto rotated to create a variety of effects. Each shape or pattern can also be
strobed via DMX or as part of the internal programs. Perfect for installations in bars, nightclubs,
stage shows and concerts.
Features :
Very high power 30W white LED (50,000 hrs)
8 selectable colours
7 selectable gobos
More vivid colours than equivalent halogen fixtures
Manual focus adjustment to sharpen the image and spot over a large distance
DMX in/out connections via 3-pin XLR
10 channel DMX, colour select, gobo, select, rotation, strobe, pan, tilt, pan and tilt speed,
pan fine, tilt fine, and reset
Master and slave modes
Strobe speed adjustable
Auto/sound activated
Fan cooled
Lightweight high quality casing with special coating for extra protection
2. Package Contents :
Please check the contents to ensure that the product has been received in good condition.
Light x 1unit
User’s Guide x 1pcs
Power Cord x 1pcs
If you find any accessory is missing or the lighting has arrived with any problems, please contact
your local dealer at once. Do not try to fix this item yourself or you will lose the warranty. Please
keep the original package and invoice for any possible replacement or returned demand.
Caution! Please read this manual carefully before operating!
Damage caused by misuse is not covered by the warranty!
ranty

User Manual
– LUX LD30W 150.447UK
3
3. Installation :
Every person involved with the installation, operation and maintenance of this device should be
qualified and follow the instructions of this User Guide. We recommend that this product is not
used for audience scanning. When you connect to the main power supply the device will illuminate
and the light effect will change with music when in sound activated mode.
4. Caution! To prevent Mortal Electrical Risk and Long Life Operation :
For your safety, please kindly pay attention to all of the warnings listed below:
Always plug in the power plug last and disconnect from the mains, when the device is not in use
or before cleaning.
Do not install and operate the device in rain or extreme heat, moisture or dusty environments.
This device is for indoor use only and in a dry environment.
Do not switch on immediately but wait until it reaches to room temperature, if the device has
been exposed to drastic temperature fluctuations.
Do not shake the device and avoid brute force when installing or operating
Do not spread the smoke or bubble of effect machine directly to the device.
Do not use the device during thunderstorms and please disconnect the power.
Do not use solvents or aggressive detergent to clean the device. Use a soft and clean cloth.
Do not modify the device or the connected power cord without authorization.
Use appropriate safety-rope for safety.
Do not stare to the light.
The symbol determines the minimum distance from lighted objects. The minimum
distance between light-output and the illuminated surface must be more than 0.1m.
6. Connect with power supply - The ground wire must be connected :
Use the plug to connect to the main power supply as following.
Line
Connection
International signal
Brown
cathode
L
Blue
anode
N
Yellow /Cyan
Ground wire
7. Quick Trouble Shooting :
7.1 if the unit is not functional – Check if main power is on and fuse.
7.2 if the unit is not reacting to music – check the unit is in “Snon” mode on the display.
8. Replacing Fuse :
Disconnect from the main power supply first, then remove the fuse holder above the IEC Socket to
reveal the fuse. Replace the correct fuse rating as stated on lighting or user guide. Then, lock the fuse
holder cover back into place.

User Manual
– LUX LD30W 150.447UK
4
9. General Maintenance :
To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining frequency. As a general rule, fixtures should be
cleaned at least twice a month. Dust build-up reduces light output performance and can cause
overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure to power off
fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust collected
on external vents and internal components. Clean all glass when fixture is cold with a mild solution to
the cloth or tissue, and drag dirt and grime to the outside of the lens. Gently polish optical surface until
they free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequently depends on the environment in which the fixtures operates:
damp, smoky or particularly dirty surroundings can require cleaning fluid. Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
10. Mounting instruction :
The fixture may be mounted in any position provided there is adequate room for ventilation.
It is important never to obstruct the fan or vents pathway. Mount the fixture using a clamp.
Adjust angle of the fixture loosening both knobs and tilting the fixture. After finding desired
position, retighten both knobs.
When selecting installation location, take into consideration lamp replacement access and
routine maintenance. Safety cables must always be used.
Never mount in places where the fixture will be exposed to rain, high humidity, extreme
temperatures changes or restricted ventilation.

User Manual
– LUX LD30W 150.447UK
5
11. Layout for the LUX LD-30W :

User Manual
– LUX LD30W 150.447UK
6
12. Digital Display Setting & Function :

User Manual
– LUX LD30W 150.447UK
7
13. DMX Controlling :
Function & Value
Channel 1
Colour Gobo Wheel 7 Colour
000-017 White
018-033 Red
034-050 Yellow
051-067 Cyan
068-084 Green
085-101 Orange
102-107 Purple
108-127 Blue
128-192 Colour scroll clockwise fast to slow
193-255 Colour scroll anti clockwise slow to fast
Channel 2
6 Gobo wheel + Spot
000-020 Spot
021-041 Gobo 1
042-062 Gobo 2
063-083 Gobo 3
084-104 Gobo 4
105-119 Gobo 5
120-127 Gobo 6
128-192 Gobo scroll clockwise fast – slow
193-255 Gobo scroll anti clockwise slow - fast
Channel 3
Gobo rotation
000 No rotation
001-127 Clockwise fast to slow
128-255 Anti clockwise slow to fast
Channel 4
Dimmer + Strobe
000 Closed
001-115 0-100% Dimmer
116-243 Strobe slow to fast
244-255 Open
Channel 5
Pan rotating
Channel 6
Tilt rotating
Channel 7
Pan & Tilt speed
000-255 Fast to slow
Channel 8
Pan fine 16bit
Channel 9
Tilt fine 16bit
Channel 10
Reset
000 – 149 No action
150-200 Electronic reset
14. Disposal :

User Manual
– LUX LD30W 150.447UK
8
Please disposal of the unserviceable device according to the current statutory requirements.
15. Technical specification :
Voltage : AC 230V 50~60Hz
LED Type : Φ10, Angle : 30°
LED : 1 x 30W White LED
LED Life: Upto 50,000 hours
Fuse : 2A
Lux: 850 @3m
Power Consumption: 54W
Beam Angle: 12 degrees
Dimensions : 345 X 340 X 435mm
Weight: 6.8kg
Note: This product conforms to Laser and LED Safety standard BSEN60825-1 2007
