QTX Light MW-36W User manual

WWW.QTXLIGHT.COM
MW-36W
TRI Colour Moving head User Manual
50.450UK

User Manual – MW-36 150.450UK
2
MW-36W Tri-colour moving head: For indoor use only
. General Introduction :
This moving head features 36 x 3W Tri-colour LEDs, replacing the more
conventional method of RG colour mixing. Each LED can produce any colour
of light right through the visible spectrum resulting in the brightest and best
colour mixing available by LEDs on the market today. It features 2 auto and
sound-to-light modes and either 10 or 14 DMX channels which can be
programmed with any universal DMX controller, making it ideal for creating
the right atmosphere any entertainment venues.
Features :
36 x 3W tri-colour LEDs
DMX in/out connections via 3-pin XLR
Ultra bright producing rich colour
Auto and sound activated programs
12 channel DMX (Colour mode, RG 0 - 100%, shutter, dimmer,
Pan, tilt, pan/tilt speed, pan fine, tilt fine
Fan cooled
Mounting bracket supplied
We recommend that this product is used within the guidelines
HSG95
Caution! Please read this manual carefully before
operating! Damage caused by misuse
is not covered by the warranty!
User Manual – MW-36 150.450UK
11
4. Disposal :
Please disposal of the unserviceable device according to the current
statutory requirements.
5. Technical specification :
Voltage : 230Vac, 50Hz LED Type : 3W Tri colour
LED : 36 x 3W Tri LED LED Life: 10,000 Hours
Fuse : F5A LUX: 1730 @ 2m
Power Consumption: 120W Beam Angle: 25°
Dimensions : 285 x 280 x 345mm
Weight: 7kg
Note: Conforms to Laser and LED Safety standard SEN60825-1 2007
Manual copywrite protected by QTX Light

User Manual – MW-36 150.450UK
10
167-178 Red + Green from bright to dim
179-190 Green + lue from dim to bright
191-202 Green + lue from bright to dim
203-214 lue + Red from dim to bright
215-226 lue + Red from bright to dim
227-238 Red + Green from dim to bright
239-250 Red + Green from dim to bright
250-255 RG 100% output
000-029 No function
030-050 lamp closed with Pan and tilt running
051-069 Reposition
070-079 No function
080-109 Working auto system 1
110-139 Working auto system 2
140-169 Sound to light mode 1
170-199 Sound to light mode 2
Channel 2
200-255 No function
User Manual – MW-36 150.450UK
3
2. Package Contents :
Please check the contents to ensure that the product has been received in
good condition.
Light x 1 User’s Guide x 1 IEC Lead x 1
If you find any accessory is missing or the lighting has arrived with any
problems, please contact your local dealer at once. Do not try to fix this item
yourself or you will lose the warranty. Please keep the original package and
invoice for any possible replacement or returned demand.
3. Installation :
Every person involved with the installation, operation and maintenance of this
device should be qualified and follow the instructions of this User Guide. We
recommend that this product is not used for audience scanning and should be
used within the guidelines of radiation of lasers used for display purposes
“HSG95”. When you connect to the main power supply the device will
illuminate and the light effect will change with music when in sound activated
mode.
0. Mounting instruction :
The fixture may be mounted in any position provided there is adequate room
for ventilation. It is important never to obstruct the fan or vent pathway.
Mount the fixture using a clamp. Unscrew the safety screws underneath the
device and fix a G-Clamp to the fixture. After finding desired position tighten
the G-Clamp. When selecting installation location, take into consideration
routine maintenance. Safety cables must always be used. Never mount in
places where the fixture will be exposed to rain, high humidity, extreme
temperatures changes or restricted ventilation.

User Manual – MW-36 150.450UK
4
4. Caution :
For your safety, please kindly pay attention to all of the warnings below:
Always plug in the power plug last and disconnect from the mains, when
the device is not in use or before cleaning.
Do not install and operate the device in rain or extreme heat, moisture
or dusty environments.
This device is for indoor use only an din a dry environment.
Do not switch on immediately but wait until it reaches to room
temperature, if the device has been exposed to drastic temperature
fluctuations.
Do not shake the device and avoid brute force when installing or
operating
Do not spread the smoke or bubble of effect machine directly to the
device.
Do not use the device during thunderstorms and please disconnect the
power.
Do not use solvents or aggressive detergent to clean the device. Use a
soft and clean cloth.
Do not modify the device or the connected power cord without
authorization.
Use appropriate safety-rope for safety.
Do not stare to the light.
The symbol determines the minimum distance from lighted
objects. The minimum distance between light-output and the
illuminated surface must be more than 0.5m.
User Manual – MW-36 150.450UK
9
4. DMX Controlling :
DMX Channel Function & Value
Channel 000-255 PAN Scan (0° - 540°)
Channel 2 000-255 Tilt Scan (0° - 280°)
Channel 3 000-255 PAN Fine (16 IT)
Channel 4 000-255 Tilt Fine (16 IT)
Channel 5 000-255 Pan & Tit speed (Fast - Slow)
000-006 No function
007-065 Strobe from (Slow to fast)
066-069 No function
070-128 Thunder strobe (Slow to fast)
129-132 No Function
133-191 right strobe (Slow to fast)
192-195 No Function
Channel 6
196-255 Dimmer strobe (Slow to fast)
Channel 7 000-255 Master dimmer
Channel 8 000-255 Red brightness 0-100%
Channel 9 000-255 Green brightness 0-100%
Channel 0 000-255 lue brightness 0-100%
000-006 No function
007-044 Eight fixed colours
045-049 No function
050-094 Eight colours changing jumping (9 classes)
095-099 No function
100-149 Eight colours changing gradually (Slow to fast)
150-154 No function
Channel
155-166 Red + Green from dim to bright

User Manual – MW-36 150.450UK
8
3. Display controls:
DISPLAY FUNCTION
Addr A00 -A50 (503)
DMX address
Yes
PAN
No
Reverse Pan movement
Yes
Tilt
No
Reverse Tilt movement
At0 Auto program 1
At02 Auto program 2
Sn0 Sound to Light program 1
Sn02 Sound to Light program 2
dnCo Dmx control mode
PLAY
Slae Slave function
CH0 Channel Select
MAN
d00 DMX address
dSIP For when fixture is mounted upside
down dISP
dISP For when fixture is floor standing
Resets the fixture
rESt
oFAn Yes Turns the fan off after 60 seconds
when the LEDS are off
No Leaves the fan on all the time
User Manual – MW-36 150.450UK
5
6. Connect with power supply:
Use the plug to connect to the main power supply as following.
Line Connection International signal
rown Live L
lue Neutral N
Yellow /Green Earth E
7. Quick Trouble Shooting :
7.1 if the unit is not functional – Check if main power is on and fuse.
7.2 if the unit is not reacting to music – check the unit is in “M-SO” mode on
the display.
8. Replacing Fuse :
Disconnect from the main power supply first, then remove the fuse holder
above the IEC Socket to reveal the fuse. Replace the correct fuse rating as
stated on lighting or user guide. Then, lock the fuse holder cover back into
place.
9. General Maintenance :
To maintain optimum performance and minimize wear, fixtures should be
cleaned frequently. Usage and environment are contributing factors in
determining frequency. As a general rule, fixtures should be cleaned at least
twice a month. Dust build-up reduces light output performance and can cause
overheating. This can lead to reduced lamp life and increased mechanical
wear. e sure to power off fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush
to remove dust collected on external vents and internal components. Clean all

User Manual – MW-36 150.450UK
6
glass when fixture is cold with a mild solution to the cloth or tissue, and drag
dirt and grime to the outside of the lens. Gently polish optical surface until
they free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be
carried out periodically to optimize light output. Cleaning frequently depends
on the environment in which the fixtures operates: damp, smoky or
particularly dirty surroundings can require cleaning fluid. Always dry the parts
carefully. Clean the external optics at least every 20 days.
User Manual – MW-36 150.450UK
7
. Layout for the 50.450UK:
1. DMX Input
2. AC Power input
3. Power switch on/off
4. DMX Output
2. Digital Display Setting & Function :
FUN: Function menu or withdraw the last menu
ENTER: Confirms the functions you select.
UP: Increase one step each time.
DOWN: Decrease one step each time.
