Quadratec iVault User manual

iVault Radio Locker
Part# 14026.2311 I-VAULT 97-02 TJ
Assembly instructions
Included: Qty. Sheet metal screws 4
Front door 1 Felt pads 2
Body front 1
Body rear 1
Sliding Tray 1
R
STEP 1
Cord Management
NOTE: Insert the desired cord as
shown to keep it from falling out of
t h e d r a w e r a n d b e c o m i n g
unreachable inside the vehicle
dash.
Sliding Tray
A) Begin by instalingl the two strips of felt on the
underside of the head unit as protection for the items
carried in the tray when on rough terrain.
B) Install any cords as desired into the sliding tray and insert
it into the assembly. (Fig 1) See “Cord Management” for
details.
C) Install the front body section onto the rear body section
then insert the head unit and use the 4 sheet metal screws to
hold the assembly together loosely. NOTE: Be sure the
bottoms of the front and rear sections are flush.
D) Now adjust the final position of the radio into the
assembly and tighten the screws on the sides. Position so it
is far enough forward to be easily accessible but not
interfere with the face when installed.
Page 1 rev 1 8/11
Please read all instructions before beginning assembly
Body rear sect.
Body front sect.
Head unit
Fig. 1
Fig. 2
Fig.3
Head unit
Rear sect. body
Front sect. body

Complete assembly
STEP 2
STEP 3
Towel
Screw driver
Carefully insert screw driver under edge of
dash panel as shown using a towel to protect
the surfaces from damage. Pry up the clips
across the top of the dash and move the panel
out of the way to access the screws for the top
of the radio surround.
Use a Philips screw driver to remove the two
screws under the dash panel holding the top of
the radio surround.
Philips screw driver
Installation
Page 2 rev 1 8/11

Step 5
Step 6
Step 4
Use a flat head screw driver to pry the base of
the radio surround loose and remove it. Wrap
the screw driver in a towel to protect the
surround.
Remove the four screws holding the factory
radio in place and remove it. Be careful not
to damage the wiring when unplugging the
harness.
A) Install the completed radio assembly into the dash using the factory mounting locations and hardware.
NOTE: Follow the radio manufacturers instructions for wiring requirements.
B) Re-install the radio surround by pressing the clips into the locations on the dash.
C) Re-install the dash top by pressing the clips into the locations on the dash.
OPERATION
Insert into top slot first
Close bottom second
and then lock
Once face is installed use key to lock in place. Be sure lock is in open position before installing,
do not force face assembly in place. If not properly alligned the face may become difficult to
lock or remove.
Page 3 rev 1 8/11
