Car Solutions QVI-LVTX-1CH-V7 User manual

Release date : 2012.10.08
model : QVI-LVTX-1CH-V7 / product code : LVTX-1CH-1201-005
Car Video Interface
for
Dodge/Chrysler
User Manual
www.car-solutions.com
[email protected]
Car-Solutions.com

Contents
2
1. Before installation
1.1 Main specification
1.2 Features
1.3 System diagram
1.4 Components
1.5 Exterior
4
3
5
6
7
2. SETUP
2.1 DIP switch
2.2 Remote controller
2.3 Original buttons in car
2.4 OSD (on screen display)
2.5 FACTORY mode
2.6 Rear view parking guide line
2.7 Remote controller button
2.8 DVD, DTV model selection
8
9
10
4. Troubleshooting 20
13
11
12
14
16
3. Installation
3.1 Installation diagram
3.2 Cautions on installation
3.3 Installation
17
18
19
www.car-solutions.com
[email protected]
Car-Solutions.com

1.1 Main specification
3
1. Input Spec. (MULTI VIDEO INTERFACE)
- 1 x Analog R, G, B, C sync
- 1 x CVBS(REAR CAMERA) Input. (Rear camera source)
- 3 x A/V (NTST & PAL) Input.
- 1 x LCD Input (Car system Input)
2. Output Spec.
- 2 X CVBS OUTPUT (Video Out for installing Headrest monitor)
- 1 x Audio OUTPUT
- 1 X LCD OUTPUT(LCD Operation)
3. Power Spec.
- Input Power : 8VDC ~ 18VDC
- Consumption Power : 3WATT (in maximum level)
4. Mode change
- Input Video skip : able to skip each input source via adjusting DIP switch
- Control by using the remote controller
- Able to switch modes via using the original buttons(navigation)
www.car-solutions.com
[email protected]
Car-Solutions.com

1.2 Features
4
DVD, DTV control via registering values of the buttons on the remote controller (only
for models including remote controller
Plug & Play (the LVDS cable offered)
Control of position of the DVD, navigation image
Mode switch via original button
Compatible Cars
- Dodge Charger 2011~
- Fiat Freemont
- Dodge Journey
- Chrysler 300C
www.car-solutions.com
[email protected]
Car-Solutions.com

1.3 System diagram
5
A/V
OUT
HEADREST
MONITOR
LCD
In/Out
MCU
VIDEO
CIRCUIT
VIDEO MUX
POWER
CIRCUIT
A/V1
A/V2
CVBS
(Rear Camera)
Power Input
(+8VDC~+18VDC)
DIP S/W NAVI
Remote Control Switch for source toggle
DVD
DMB
RGB Input
A/V3
RGB Touch Input
OEM Button (Can Signal)
www.car-solutions.com
[email protected]
Car-Solutions.com

1.4 Components
6
POWER cable (24P) * 1ea AV cable * 1ea
TOUCH OUT cable * 1ea
REAR CAMERA POWER cable * 1ea Remote control * 1ea
(HPOWER0011) (HARETC0002) (HAVCAB0002) (REMOTE0001)
IR cable * 1ea
MODE cable * 1ea
RGB cable * 1ea
(HARETC0001)
(HNAVIC0004)
(HIRCAB0002)
(HTOUCH0004)
Touch sub board* 1ea
Sub board* 1ea
TOUCH IN cable* 1ea
(HTOUCH0013)
LVDS cable * 1EA
(HLVDSC0014)
LCD cable * 1EA
(HLCDCA0007)
FFC cable* 1ea
(FFCABL0023)
www.car-solutions.com
[email protected]
Car-Solutions.com

1.5 Exterior
7
Dimension
Horizontal length 147mm
Vertical length 91mm
Height 27mm
⑧
⑤
⑥⑦
①②③④
①LED
②POWER/CAN/RGB
④REAR CAMERA
⑤AV(IN/OUT)
⑥DIP SWITCH
⑦TOUCH OUT TO NAVI
⑧LVDS OUT
③RGB IN-2 ⑨
⑪LCD-OUT
⑨LVDS-IN
⑩LED
⑩⑪
⑫⑬
⑫TOUCH IN/OUT
⑬LCD-IN
www.car-solutions.com
[email protected]
Car-Solutions.com

2.1 DIP switch
8
#PIN function DIP S/W selection
1 RGB INPUT skip ON : Skipping RGB Mode
OFF : RGB Display
2 A/V 1 skip ON : Skipping A/V 1
OFF : A/V1 Display
3 A/V 2 skip ON : Skipping A/V 2
OFF : A/V2 Display
4 A/V 3 skip ON : Skipping A/V 3
OFF : A/V3 Display
5 N.C
6 N.C
7 Rear Mode ON : External Rear Camera
OFF : OEM Rear Camera
8 N.C
※ON : DOWN, OFF : UP
※DIP S/W usage
- Input mode to intend to use
: A/V3(DVD)
- Rear view camera : installation on CVBS4
- When the original navigation is NOT installed
▷DIP S/W : 1 OFF
▷DIP S/W : 2,3 ON (input mode skip)
▷DIP S/W : 4 OFF (A/V3 available)
▷DIP S/W : 7 ON (External Real Camera
available)
2.1 DIP switch
www.car-solutions.com
[email protected]
Car-Solutions.com

2.2 Remote controller
9
Key Function
POWER & PIP Not for use
MENU OSD implementation
OK Making a selection
▲Move upward
▼Move downward
◀Move leftward, press 2 seconds long-Factory
mode implementation
▶Move rightward, press 2 seconds long-Factory
Mode implementation-Factory mode Reset
www.car-solutions.com
[email protected]
Car-Solutions.com

2.3 Original buttons in car
10
Mode Switching
Driver can switch
modes with the this button.
Press long : mode switch
Press short : return to
main image
DTV channel up
DTV channel
down
※User can find this button from back of the steering wheel(Chrysler has buttons as same place)
www.car-solutions.com
[email protected]
Car-Solutions.com

2.4 OSD (on screen display)
11
- BRIGHTNESS
- CONTRAST
- SATURATION
- HUE
- SHARPNESS
- USER IMAGE : To choose a option
among 4 prepared color shade.
OSD menu: Press ”MENU” button on the remote controller.
OSD
- LANGUAGE : To change the language
displaying on navigation, DVD, CMMB
OSD menu (select 1 among English or
Chinese)
- TRANS : Transparency control of the OSD
background
- H_POSITION : Horizontal movement of
the OSD window
- V_POSITION : Vertical movement of the
OSD window
UTIL
- FACTORY RESET : To reset all the
values about navigation, DVD screen
to factory default. (NOT available for
reset of the position value of images,
only for functions inside OSD menu)
Analog RGB
Video
Analog RGB
Video
Analog RGB
Video
www.car-solutions.com
[email protected]
Car-Solutions.com

2.5 Factory mode
12
- H-POSITION : Control over horizontal movement of screen
- V-POSITION : Control over vertical movement of the screen
- AVOUT SELECT : DEFAULT, AV1, AV2, AV3
Factory mode: press ◀button 2 seconds long.
PARK
- PARK ENABLE : Setup of rear view parking guide line
- PARK SETUP : Control over position of rear view parking guide line
(Refer to page13.)
- REAR SELECT : To select whether to use Can or Lamp
- SAFE ENABLE : To select whether to use SAFE function
(NOT to allow watch video while driving) or not
UTIL
- IR MEMORY : To register value of buttons on the remote controller
(Refer to page14~15.)
- DVD TYPE : Setup for the type of DVD (Refer to page16.)
- DTV TYPE : Setup for the type of DMB (Refer to page16.)
- FACTORY RESET : To reset all the value in factory mode
www.car-solutions.com
[email protected]
Car-Solutions.com

2.6 Rear view parking guide line
13
①Register the value needed on the “PARK ENABLE” as “ON” in the PARK
section as shown left. (default –ON)
②If you get rear gear after setup, parking guide line will appear on
screen as shown left. Now that you push “OK” button, you can see “H-POS”
on the left of screen. Then adjust horizontal position of the guide line.
③After adjusting horizontal position, press “OK” on the remote controller.
Then you can see “V-POS” on the left of screen. At that time you can
adjust vertical position of the guide line.
Factory mode: press ◀button 2 seconds long.
www.car-solutions.com
[email protected]
Car-Solutions.com

2.7.1 Remote controller button
14
①First of all, press ◀button on remote controller 2
seconds long. Then you can access to the FACTORY
mode. And go to IR MEMORY, UTIL.
There are two options in IR MEMORY as shown above;
DTV and DVD.
Then you select AV source that you want to set
among them.
②This is a window for register of DVD’ s remote
controller button value. At the moment just select a
menu that you want to save.
(Select “DTV in options of IR MEMORY” if you want to
save values of DTV’ s remote controller. And follow
the instruction below.)
Instruction>
a. Select “POWER” in OSD menu, then press “OK” on
remote controller. (as shown above)
b. If the marked area flickers as shown above, press
“POWER” button on the remote controller of DVD
that you want to use. (continued in the next page)
Registering value of remote controller buttons?
When you want to control DVD and DTV via touch screen (using OSD menu) with other models besides already
registered option-SANYO and NECVOX, you can register value of DVD and DTV’ s remote controller which you
have. Then you can control DVD and DMB via touch screen.
>>>
www.car-solutions.com
[email protected]
Car-Solutions.com

2.7.2 Remote controller button
15
Instruction> continued…
c. The values that you registered will appear as green
text in the marked area on pressing the button. And
the values will be saved automatically.
d. Register remain buttons’ value in OSD menu like
the above-mentioned.
③After register, select “INPUT” in OSD menu and
press “OK”. Then you can see confirmation window
as shown above. At the moment, if you choose
“YES”, all the values that you entered will be saved.
If you select “NO”, the values won’t be saved.
(If data is saved, DVD TYPE and DMB TYPE will be
changed to “USER” automatically.)
If you see “SUCCESS” on screen, the data is saved
clearly and you can control DVD via touch screen.
BUT, you MUST change the option in
DVD(DMB)/UTIL/FACTORY to “USER”. (Refer to
page18.)
>>>
www.car-solutions.com
[email protected]
Car-Solutions.com

2.8 DVD, DTV model selection
16
UTIL –DVD/DTV TYPE
If DVD/DTV type that you want to use is not NECVOX or SANYO, you have to register values of the remote
controller that you want to use in the “IR MEMORY” section and set the “DVD TYPE”/”DTV TYPE” to “USER”.
Unless you do this process after saving the data, you can NOT control DVD/DTV via touch screen.
DVD TYPE : NEC/SANYO, DV-108, SANYO-1, SANYO-2, USER
DTV TYPE : PIONEER/PANASONIC, USER,
※If you enter data in ”IR MEMORY” section in FACTORY mode, “DVD TYPE”/ “DMB TYPE” will automatically be saved to “USER”.
DVD TYPE DTV TYPE
www.car-solutions.com
[email protected]
Car-Solutions.com

3.1 Installation diagram
17
LED
DIP S/W
POWER/CAN/RGB R-CAM A/V(IN/OUT)
VIDEO INTERFACE
TOUCH OUT
TO NAVI
LVDS
OUT
navigation
Touch cable
Offered LVDS cable
IR-AV2 (DVD)
AUX-ON (N.C)
CAN-L
CAN-H
IR-AV3 (DTV)
IR-AV1 (NAVI)
PARKING (SAFE)
REAR
OPT2 (N.C)
MODE : Toggle S/W
IR
PB12 (N.C)
GPIO-ZO : MMI
GND
ACC
RGB
AV1 AV2 AV3
REAR C
Audio L
Audio R
AV/OUT Video
X+
Y+
X-
Y-
REAR (12V OUT)
GND
LCD
BOARD
Original FFC
cable
SUB TOUCH
BOARD
TOUCH
IN/OUT
OEM IN
Offered Touch cable
Touch screen
The back of monitor
SUB BOARD
LCD-OUT
LCD-IN
TOUCH
IN/OUT
LVDS IN
Offered LCD cable
OEM OUT
Offered FFC cable
www.car-solutions.com
[email protected]
Car-Solutions.com

3.2 Cautions on installation
18
Ignition key should be taken off before starting installation, interface power connection must be the last step
in installation.
Power cable should be separated when connecting interface.
Should be no any electronic devices or magnetic pole around installation place.
All steps of installation should be done by well-trained specialist.
Dismantling without manufacturer’s permission can not be guaranteed, (No permission to break attached
label on the board.)
Kindly check all parts are in the box, when receiving the product, if anything missing, inform to the supplier or
manufacturer.
According to our sales policy, any problems caused by user’s mistake, careless can not be guaranteed.
www.car-solutions.com
[email protected]
Car-Solutions.com

3.3 Installation
19
1. Offered LVDS Cable connect to LVDS-IN in Sub-board
2. After dividing original LCD cable from the back of monitor, and connect with LCD-IN in sub-board
3. Offered LCD cable connect with LCD-OUT in sub-board and the marked point from the back of monitor
※The Power of Interface connect with accessory Power in the car
Offered LVDS cable
1. Connect LVDS Cable
Offered LCD cable
COMMNAD
Original LCD cable
①②
③
www.car-solutions.com
[email protected]
Car-Solutions.com

3.3 Installation
20
2. Connecting CAN cable respectively
The LCD cable in the back of monitor connect with offered powercable
Connect CAN-H cable (green+brown) enclosed in our package with the original CAN-H cable (White+Blue).
And connect CAN-L cable (green) enclosed in our package with the original CAN-L cable (White+Yellow).
CAN-Low
CAN-High
Power Cable
www.car-solutions.com
[email protected]
Car-Solutions.com
