Quoizel LOM8408ABA User manual

-of-13
INSTALLATION GUIDE FOR LOM8408ABA,
LOM8408 9 9MBK, LOM840 ABA, LOM840 MBK
LOM84 ABA and MBK11 LOM8411
CARE AND MAINTENANCE
SAFETY INFORMATION Released Date: 2021-08-19
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at
www.quoizel.com.
Please read and understand this entire manual before attempting to assemble, install or operate the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the circuit breaker box or the main fuse box.
• RISK OF FIRE - Use bulbs specified by the markings and/or labels on the fixture.
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
• Turn off electricity to fixture before replacing the bulb(s).
TOOLS REQUIRED
PACKAGE CONTENTS
Crossbar Assembly
x1
AA
CFixture Body
x 1
MOUNTING HARDWARE
Glass Shade
x1
D
Wire Connector
x3
CC Outlet Box Screw
x2
DD
Alternate
Mounting Screw
x2
BB
ALock Ball
x 1
BArm
x 1
Socket Collar
[pre-assembled to
Fixture Body]
x1
E

-of-23
INSTALLATION
1
Install Arm
2
34
Install Fixture Body
5
Install Glass Shade
6
Install Bulb
1
2
Install Inner Backplate
(2) Alternative Screws
*Alternative screws are provided to
replace pre-assembled mounting screws
if necessary.
Wiring
White wire from supply White from fixture
Black (or red) wire from supply Black from fixture
Ground wire from supply
Ground wire
from fixture
Green ground screw
Install correct bulb referring tothe
fixture markings and/or labels for
maximum wattage.
Recommended Bulb Type (not
included):
BULB BASE TYPE
Medium (E26)
BULB TYPE
TYPE A
100W
MAX

-of-33
ECxterior aulk
INSTALLATION
Your installation is now complete! Restore electricity and save this sheet for future reference.
7
Apply Caulking
ECxterior aulk
ECxterior aulk
* Note: Do NOT caulk the bottom of the backplate to allow moisture to escape.
ECxterior aulk
ECxterior aulk
ECxterior aulk
