INSTALLATION GUIDE FOR HAZ8406EK,
HAZ8407EK and HAZ8409EK
CARE AND MAINTENANCE
SAFETY INFORMATION Released Date: 2021-10-12
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at
www.quoizel.com.
Please read and understand this entire manual before attempting to assemble, install or operate the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the circuit breaker box or the main fuse box.
• RISK OF FIRE - Use bulbs specified by the markings and/or labels on the fixture.
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
• Turn off electricity to fixture before replacing the bulb(s).
TOOLS REQUIRED
PACKAGE CONTENTS
AFixture Body
x 1
MOUNTING HARDWARE
Glass Shade
x1
B
Socket Collar
[pre-assembled
to Fixture Body]
x1
C
AA Inner Backplate
x 1 BB Mounting Screw x2 CC Wire Connector x 3 DD Outlet Box Screw x2

- of 2 -2
INSTALLATION
1
Install Inner Backplate
2
Wiring
White wire from supply White from fixture
Black (or red) wire from supply Black from fixture
Ground wire from supply
Ground wire
from fixture
Green ground screw
3
Install Fixture Body
4
Install Glass Shade
Your installation is now complete! Restore electricity and save this sheet for future reference.
5
Install Bulb
BULB BASE TYPE
Medium (E26)
BULB TYPE
TYPE A
100W
MAX
Install the correct bulb referring to
fixture markings and/or labels for
maximum wattage.
Recommended Bulb Type (not
included):
6
Apply Caulking
ECxterior aulk
ECxterior aulk
ECxterior aulk
* Note: Do NOT caulk the bottom of the backplate to
allow moisture to escape.
