RACOM RAy3 User manual

User manual / Safety
.
RAy3 Microwave Link
.
fw 1.0.x.x
8/21/2018
version 0.1
www.racom.eu
RACOMs.r.o. •Mirova1283•59231NoveMestonaMorave•CzechRepublic
Tel.:[phone]•Fax:[phone]•E-mail: [e-mail]

Table of Contents
List of documentation .......................................................................................................................... 5
1. Safety, environment, licensing ......................................................................................................... 7
1.1. Frequency ............................................................................................................................ 7
1.2. Safety distance ..................................................................................................................... 7
1.3. Professional installation ........................................................................................................ 8
1.4. RoHS and WEEE compliance .............................................................................................. 9
1.5. Liability for Defects and Safety Instructions ......................................................................... 9
1.6. Important Notifications ........................................................................................................ 10
1.7. Warranty ............................................................................................................................. 10
1.8. EU Declaration of Conformity ............................................................................................. 12
1.9. FCC authorization of transmitters ....................................................................................... 15
1.10. Country of Origin Declaration ........................................................................................... 16
Index .................................................................................................................................................. 17
A. Revision History ............................................................................................................................ 19
3© RACOM s.r.o. – RAy3 Microwave Link

4

List of documentation
This manual consists of several parts which must be downloaded separately:
•Quick start 1
Basic information for starting a line
•Hardware 2
Product description, Accessories, Installation, Technical parameters
•Configuration 3
Web Client configuration, Command Line Interface
•Safety 4
Safety, environment, licensing
Other manuals:
•Microwave Link RAy25- User manual
User manual RAy2-10, RAy2-11, RAy2-17, RAy2-18, RAy2-24
•Microwave Link RAy26- Channel arrangements
Detailed tables of RAy2 frequencies
•Microwave Link RAy11, 17, 247
User manual RAy11, RAy17, RAy24
•Microwave Link RAy108
User manual RAy10
Datasheets:
•RAy2 - Datasheet9
•RAy - Datasheet10
•RAy - SCADA Backbone11
Application notes:
•RAy - Application notes12
1http://wp.racom.eu/eng/products/m/ray2/start/index.html
2http://wp.racom.eu/eng/products/m/ray2/hw/index.html
3http://wp.racom.eu/eng/products/m/ray2/conf/index.html
4http://wp.racom.eu/eng/products/m/ray2/safe/index.html
5http://www.racom.eu/eng/products/m/ray/index.html
6http://www.racom.eu/eng/products/m/ray2tab/index.html
7http://www.racom.eu/eng/products/m/ray17/index.html
8http://www.racom.eu/eng/products/m/ray/index.html
9http://www.racom.eu/download/hw/ray/free/eng/00_letaky/ray-dsA3-en.pdf
10 http://www.racom.eu/download/hw/ray/free/eng/08_ray1/datasheet_RAY_en.pdf
11 http://www.racom.eu/download/hw/ray/free/eng/08_ray1/leaflet_RAY_scada_en.pdf
5© RACOM s.r.o. – RAy3 Microwave Link
List of documentation

Contents of the box
• 2 pc RAy2
•2pcCable bushing set, connectors
• 1 pc Grease marked "SILIKONOVE MAZIVO"
12 http://www.racom.eu/eng/products/m/ray/app/index.html
RAy3 Microwave Link – © RACOM s.r.o.6
List of documentation

1. Safety, environment, licensing
1.1. Frequency
RAy2 microwave links designed for operation in licensed bands must be used in accordance with license
issued by the Telecommunications Authority for the area the device is operating in.
RAy2 microwave links must comply with the maximum permitted radiated power (EIRP) in accordance
with conditions of the given country.
1.2. Safety distance
Safety distances with respect to the US health limits of the electromagnetic field intensity
are in the Minimum Safety Distance tables below, calculated for different antennas and
RAy power levels.
Tab. 1.1: Minimum Safety Distance 11 GHz
+24 dBm RF power10.700 – 11.700 GHzRAy2-11
Distance where the FCC limits is met for
Gain G
[dBi]
Parabolic antennaAntenna code Occupational /
Controlled Exposure
[cm]
General Population /
Uncontrolled Exposure
[cm]
6014029.0ø 380 mmJRMA – 380 – 10/11Ra
13029036.0ø 650 mmJRMA – 650 – 10/11Ra
16036038.0ø 900 mmJRMB – 900 – 10/11Ra
24054041.5ø 1200 mmJRMB – 1200 – 10/11Ra
+13 dBm RF power10.700 – 11.700 GHzRAy2-11
Distance where the FCC limits is met for
Gain G
[dBi]
Parabolic antennaAntenna code Occupational /
Controlled Exposure
[cm]
General Population /
Uncontrolled Exposure
[cm]
306029.0ø 380 mmJRMA – 380 – 10/11Ra
5011036.0ø 650 mmJRMA – 650 – 10/11Ra
6014038.0ø 900 mmJRMB – 900 – 10/11Ra
9020041.5ø 1200 mmJRMB – 1200 – 10/11Ra
ver. 1.0
7© RACOM s.r.o. – RAy3 Microwave Link
Safety, environment, licensing

Tab. 1.2: Minimum Safety Distance 18 GHz
+24 dBm RF power17.700 – 19.700 GHzRAy2-18
Distance where the FCC limits is met for
Gain G
[dBi]
Parabolic antennaAntenna code Occupational /
Controlled Exposure
[cm]
General Population /
Uncontrolled Exposure
[cm]
12026034.8ø 400 mmJRMB – 400 – 17R
18040038.6ø 680 mmJRMB – 680 – 17R
24053041.0ø 900 mmJRMB – 900 – 17R
36080044.6ø 1200 mmJRMB – 1200 – 17R
+13 dBm RF power17.700 – 19.700 GHzRAy2-18
Distance where the FCC limits is met for
Gain G
[dBi]
Parabolic antennaAntenna code Occupational /
Controlled Exposure
[cm]
General Population /
Uncontrolled Exposure
[cm]
408034.8ø 400 mmJRMB – 400 – 17R
5012038.6ø 680 mmJRMB – 680 – 17R
7015041.0ø 900 mmJRMB – 900 – 17R
11023044.6ø 1200 mmJRMB – 1200 – 17R
ver. 1.1
Tab. 1.3: Minimum Safety Distance 24 GHz
+10 dBm RF power24.000 – 24.250 GHzRAy2-24
Distance where the FCC limits is met for
Gain G
[dBi]
Parabolic antennaAntenna code Occupational /
Controlled Exposure
[cm]
General Population /
Uncontrolled Exposure
[cm]
307036.8ø 400 mmJRMB – 400 – 24Ra
6012041.7ø 680 mmJRMB – 680 – 24Ra
7015044ø 900 mmJRMB – 900 – 24Ra
9020046ø 1200 mmJRMB – 1200 – 24Ra
ver. 1.0
1.3. Professional installation
RAy2 units are only intended for installation by professionally trained people and in locations not ac-
cessible to the public. Installation and servicing must be carried out by personnel with appropriate
technical training and knowledge of potential hazards.
RAy2 units shall be installed according to local Electrical Safety Codes.
RAy3 Microwave Link – © RACOM s.r.o.8
Safety, environment, licensing

It is the responsibility of the installer to ensure that all building and safety codes are met and that the
installation is fully completed and equipment properly secured.
1.4. RoHS and WEEE compliance
This product is fully compliant with the European Parlament's 2011/65/EU RoHS
(Restriction of Certain Hazardous Substances in Electrical and Electronic
Equipment) and 2012/19/EU WEEE (Waste Electrical and Electronic Equipment)
environmental directives.
Used equipment must be collected separately, and disposed of properly. Racom
has instigated a programme to manage the reuse, recycling, and recovery of
waste in an environmentally safe manner using processes that comply with the
WEEE Directive.
Battery Disposal - This product may contain a battery. Batteries must be disposed of properly, and may
not be disposed of as unsorted municipal waste within the European Union. See the product document-
ation for specific battery information. Batteries are marked with a symbol, which may include lettering
to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point.
1.5. Liability for Defects and Safety Instructions
Please read these safety instructions carefully before using the product:
• Liability for defects does not apply to any product that has been used in a manner that conflicts with
the instructions contained in this operator manual, if the case in which the radio modem is packed
has been opened, or if the equipment has been tampered with.
• The radio equipment can only be operated on frequencies stipulated by the body authorised by the
radio operation administration in the respective country and cannot exceed the maximum permitted
output power. RACOM is not responsible for products used in an unauthorised way.
• Equipment mentioned in this operator manual may only be used in accordance with instructions
contained in this manual. Error-free and safe operation of this equipment is only guaranteed if this
equipment is transported, stored, operated and controlled in the proper manner. The same applies
to equipment maintenance.
•In order to prevent damage to the radio modem and other terminal equipment the supply must always
be disconnected upon connecting or disconnecting the cable to the radio modem data interface. It
is necessary to ensure that connected equipment has been grounded to the same potential.
• Only the undermentioned manufacturer is entitled to repair any devices.
• Should the RAy2 unit be used with accessories other than those recommended, Racom takes no
responsibility for any malfunction caused by the use of such accessories. Using unsuitable accessor-
9© RACOM s.r.o. – RAy3 Microwave Link
Safety, environment, licensing

ies (e.g.cable connectors) can result in mechanical damage to RAy2 internal connectors, allow the
penetration of water inside the unit, or reduce the efficiency of internal surge protection circuits.
1.6. Important Notifications
The sole owner of all rights to this operating manual is the company RACOM s. r. o. (further referred
to under the abbreviated name RACOM). All rights reserved. Drawing written, printed or reproduced
copies of this manual or records on various media or translation of any part of this manual in foreign
languages (without written consent of the rights owner) is prohibited.
RACOM reserves the right to make changes to the technical specification, in the product function, to
terminate production of this product or to terminate its service support without previous written notific-
ation of customers.
Conditions of use of this product software abide by the license mentioned below. The program distributed
by this license has been freed with the purpose to be useful, but without any specific guarantee. Under
no circumstances is the author or another company or person responsible for secondary, accidental
or related damages resulting from application of this product.
The producer does not provide the user with any kind of guarantee providing assurances of suitability
and usability for his application. Products are not developed, designed or tested for utilization in devices
directly affecting the health or life functions of persons or animals, nor as a part of another important
device, and does not provide guarantees if the product has been used in these aforementioned devices.
RACOM Open Software License
Version 1.0, November 2009
Copyright (c) 2001, RACOM s.r.o., Mírová 1283, Nové Město na Moravě, 592 31
Everyone can copy and spread word-for-word copies of this license, but no changes are permitted.
The program (binary version) is freely available on http://www.racom.eu. This product contains open
source or other software originating from third parties subject to GNU General Public License (GPL),
GNU Library / Lesser General Public License (LGPL) and / or further author licences, declarations of
responsibility, exclusion and notifications. Exact terms of GPL, LGPL and some further licences are
mentioned in the source code packets (typically the files COPYING or LICENSE). You can obtain ap-
plicable machine-readable copies of source code of this software under GPL or LGPL licences on ht-
tp://www.racom.eu. This product also includes software developed by the University of California,
Berkeley and its contributors.
1.7. Warranty
RACOM supplied parts or equipment ("equipment") are covered under warranty for inherently faulty
parts and workmanship for a warranty period as stated in the delivery documentation from the date of
dispatch to the customer. The warranty does not cover custom modifications to software. During the
warranty period RACOM shall, on its option, fit, repair or replace ("service") faulty equipment, always
provided that malfunction has occurred during normal use, not due to improper use, whether deliberate
or accidental, such as attempted repair or modification by any unauthorised person; nor due to the
RAy3 Microwave Link – © RACOM s.r.o.10
Safety, environment, licensing

action of abnormal or extreme environmental conditions such as overvoltage, liquid immersion or
lightning strike.
Any equipment subject to repair under warranty must be returned by prepaid freight to RACOM direct.
The serviced equipment shall be returned by RACOM to the customer by prepaid freight. If circumstances
do not permit the equipment to be returned to RACOM, then the customer is liable and agrees to reim-
burse RACOM for expenses incurred by RACOM during servicing the equipment on site. When
equipment does not qualify for servicing under warranty, RACOM shall charge the customer and be
reimbursed for costs incurred for parts and labour at prevailing rates.
This warranty agreement represents the full extent of the warranty cover provided by RACOM to the
customer, as an agreement freely entered into by both parties.
RACOM warrants the equipment to function as described, without guaranteeing it as befitting customer
intent or purpose. Under no circumstances shall RACOM's liability extend beyond the above, nor shall
RACOM, its principals, servants or agents be liable for any consequential loss or damage caused directly
or indirectly through the use, misuse, function or malfunction of the equipment, always subject to such
statutory protection as may explicitly and unavoidably apply hereto.
11© RACOM s.r.o. – RAy3 Microwave Link
Safety, environment, licensing

1.8. EU Declaration of Conformity
EU DECLARATION OF CONFORMITY
ver. 1.0
www.racom.eu
RACOM s.r.o. | Mirova 1283 | 592 31 Nove Mesto na Morave | Czech Republic
Tel.: [phone] | Fax: [phone] | E-mail: [email protected]
Radio equipment type RAy2-10
frequency range B
10.125 - 10.675 GHz
Manufacturer RACOM s.r.o.
Mirova 1283, 592 31 Nove Mesto na Morave, Czech Republic
This declaration of conformity is issued under the sole responsibility of the manufacturer.
The radio equipment described above is in conformity with the Directive 2014/53/EU of the European
Parliament and of the Council on the harmonisation of the laws of the Member States relating to the
making available on the market of radio equipment and repealing Directive 1999/5/EC.
Harmonised standards used for demonstration of conformity:
Spectrum EN 302 217-2-2 V2.2.1
EMC EN 301 489-1 V1.9.2
EN 301 489-4 V2.1.1
Safety EN 60950-1:2006, A11:2009, A1:2010, A12:2011, A2:2013
Signed for and on behalf of the manufacturer:
th
Nove Mesto na Morave, 8 of June 2017
Jiri Hruska, CEO
Radio SW
FW ver. 0.2.10.0
Fig. 1.1: EU Declaration of Conformity for RAy2-10
RAy3 Microwave Link – © RACOM s.r.o.12
Safety, environment, licensing

EU DECLARATION OF CONFORMITY
ver. 1.0
www.racom.eu
RACOM s.r.o. | Mirova 1283 | 592 31 Nove Mesto na Morave | Czech Republic
Tel.: [phone] | Fax: [phone] | E-mail: [email protected]
Radio equipment type RAy2-11
RAy2-18
Manufacturer RACOM s.r.o.
Mirova 1283, 592 31 Nove Mesto na Morave, Czech Republic
This declaration of conformity is issued under the sole responsibility of the manufacturer.
The radio equipment described above is in conformity with the Directive 2014/53/EU of the European
Parliament and of the Council on the harmonisation of the laws of the Member States relating to the
making available on the market of radio equipment and repealing Directive 1999/5/EC.
Harmonised standards used for demonstration of conformity:
Spectrum EN 302 217-2-2 V2.2.1
EMC EN 301 489-1 V1.9.2
EN 301 489-4 V2.1.1
Safety EN 60950-1:2006, A11:2009, A1:2010, A12:2011, A2:2013
Signed for and on behalf of the manufacturer:
th
Nove Mesto na Morave, 8 of June 2017
Jiri Hruska, CEO
Radio SW
FW ver. 0.2.10.0
Fig. 1.2: EU Declaration of Conformity for RAy2-11, RAy2-18
13© RACOM s.r.o. – RAy3 Microwave Link
Safety, environment, licensing

EU DECLARATION OF CONFORMITY
ver. 1.0
www.racom.eu
RACOM s.r.o. | Mirova 1283 | 592 31 Nove Mesto na Morave | Czech Republic
Tel.: [phone] | Fax: [phone] | E-mail: [email protected]
Radio equipment type RAy2-17
RAy2-24
Manufacturer RACOM s.r.o.
Mirova 1283, 592 31 Nove Mesto na Morave, Czech Republic
This declaration of conformity is issued under the sole responsibility of the manufacturer.
The radio equipment described above is in conformity with the Directive 2014/53/EU of the European
Parliament and of the Council on the harmonisation of the laws of the Member States relating to the
making available on the market of radio equipment and repealing Directive 1999/5/EC.
Harmonised standards used for demonstration of conformity:
Spectrum EN 300 440-2 V1.4.1
EMC EN 301 489-1 V1.9.2
EN 301 489-3 V1.6.1
EN 301 489-4 V2.1.1
Safety EN 60950-1:2006, A11:2009, A1:2010, A12:2011, A2:2013
Signed for and on behalf of the manufacturer:
th
Nove Mesto na Morave, 8 of June 2017
Jiri Hruska, CEO
Radio SW
FW ver. 0.2.10.0
Fig. 1.3: EU Declaration of Conformity for RAy2-17, RAy2-24
RAy3 Microwave Link – © RACOM s.r.o.14
Safety, environment, licensing

1.9. FCC authorization of transmitters
FCC verification
RAy2-11 and RAy2-18-C were verified for compliance according to CFR 47 part 101 [see §101.139(a)].
FCC comment -
according to §101.141 and considering the low spectral efficiency the following modulations are not
allowed in RAy2-11:
ModulationBandwidth
QPSK2.5 MHz
QPSK3.75 MHz
QPSK5 MHz
QPSK, 16-QAM, 32-QAM10 MHz
QPSK30 MHz
QPSK40 MHz
Except during anomalous signal fading. During anomalous signal fading, licensees may adjust to a
modulation specified in their authorization if such modulation is necessary, to allow the licensees to
maintain communications, even if the modulation does not comply with the capacity and loading require-
ments -101.141 (3).
FCC compliance
RAy2-24 complies with CFR 47 part 15.
FCC IDFCC partCode
SQT-RAY2-2415RAy2-24
15© RACOM s.r.o. – RAy3 Microwave Link
Safety, environment, licensing

1.10. Country of Origin Declaration
Country of Origin Declaration
Producer: RACOM s.r.o.
Address: Mirova 1283, 592 31 Nove Mesto na Morave, Czech Republic
VAT No: CZ46343423
We, the manufacturer, hereby declare that Country of Origin of the RAy microwave links
and its accessories is the Czech Republic, EU.
Nove Mesto na Morave,
Jiri Hruska, CEO
10 of June 2016
www.racom.eu
RACOM s.r.o. • Mirova 1283 • 592 31 Nove Mesto na Morave • Czech Republic
Tel.: [phone] • Fax: [phone] • E-mail: [email protected]
Part Number Description
RAy2-10 Unit RAy2-10, 2× Gb Eth
RAy2-11 Unit RAy2-11, 2× Gb Eth
RAy2-17 Unit RAy2-17, 2× Gb Eth
RAy2-18 Unit RAy2-18, 2× Gb Eth
RAy2-24 Unit RAy2-24, 2× Gb Eth
ver. 1.2
Fig. 1.4: Country of Origin Declaration
RAy3 Microwave Link – © RACOM s.r.o.16
Safety, environment, licensing

Index
B
box contens, 6
D
declaration of conformity, 12
declaration of origin, 16
E
environment, 7
F
FCC
authorization, 15
L
licensing, 7
R
RoHS and WEEE, 9
S
safety, 7
distance, 7
17© RACOM s.r.o. – RAy3 Microwave Link

18

Appendix A. Revision History
2018-08-20Revision 1.0
First issue
19© RACOM s.r.o. – RAy3 Microwave Link
Revision History
