RAIS Visio 70 RD User manual

1
Arranging ceramic logs - Visio 70 RD & T
It is very important that you follow this when positioning ceramic “logs” and the
 emberslayerinthereplace.Failuretocarrythisoutcorrectlywillcausethereplace
 tonotburnoptimallyandsoottooccur.
OPSTILLINGSAFSTANDE
ARRANGING CERAMIC ”LOGS” - VISIO 70 RD & T

2
OPSTILLINGSAFSTANDE – OVN MED DREJEFOD
IMPORTANT INFORMATION: CERAMIC “LOGS” AND THE EMBERS LAYER
NB!
The measurements on the following photos are taken from the edge of the base plate.See
photobelow.
cmcm
Important information: Ceramic “logs” and the embers layer
When arranging ceramic “logs” and the embers layer in the combustion chamber, it is important
that they do not cover the pilot ame and its thermocouple, and ember material must not be
placed under the pilot guard.Boththermocouplesmustbekeptfreeoftheemberslayer.
Donotcovertheholesinthemainburner(shownbytheredcircles).
  Pilotame  Secondthermocoupleforthemainburner
NB!
Please note that there should be a small intermediary space between the “logs” that lie on
theburnersandbetweenthesurroundinglogs,sothereisspacefortheamesinbetween
them.Ifthereisnotspacefortheames,thereplacewillnotburnoptimallyandsootmay
form.

3
OPSTILLINGSAFSTANDE – OVN MED DREJEFOD
1. Startbysecuringtwoburnersinthereplace’sbaseplate.
123456
Visio 70 RD & T
Youwillndtheseceramiclogsinthepackage:
Procedure:
ARRANGING CERAMIC ”LOGS” AND EMBERS
Note the small bump
on the right side
Note the placement
ofthepilotame!Start
from the opposite side,
as shown in the picture
NB! Fornatural gas and city gas please position the
secondary burners as described in the installation manual
onpage28.
ForLPG gas the secondary burners are delivered with two
rowsofholes,andcanbeplacedasbothrightandleftburner.

4
ARRANGING CERAMIC ”LOGS” AND EMBERS
2. Nowstartfromtheoppositesideofthepilotame-seephoto1onpreviouspage.
Positionlogno.6asshowninthepicture.
3.  Positionlogno.5asshowninthepicture.Nowtheremaininglogsmustbepositionedfrom
theoppositeside-gotothesamesideasthepilotame.
6
5
3 cm3 cm 7 cm7 cm 6 cm6 cm
2 cm2 cm
3 cm3 cm

5
ARRANGING CERAMIC ”LOGS” AND EMBERS
4. Fromtheoppositesidelogno.4ispositionedasshowninthepicture.
5. Thenpositionlogno.3restingonlogno.4asshowninthepicture.
4
3
12 cm12 cm
7 cm7 cm
1 cm1 cm
7 cm7 cm
11 cm11 cm

6
ARRANGING CERAMIC ”LOGS” AND EMBERS
6. Nowtheglassstonesshouldbespreadoutinthegasreplace.Meassureout5dlofglass
stonesinameassuringcup.
7. Spreadouttheglassstones(5dlintotal)oneachsideofthegasreplace-overtheLED
lights.Itisimportantthattheglassstonesarespreadoutinathinlayerthatcoverstheholes
inthebottomofthereplace.

7
ARRANGING CERAMIC ”LOGS” AND EMBERS
8. Nowmeassureout2,5lofembers(amixofthegreyandblackchips).
9. Spreadtheembers acrossboththeglassstonesandthebaseplatewiththeholes.
Placethelamentsonthepilotarea.
NB! Itisextremelyimportantthat
you do not cover the pilot area and
the holes there(seepage2).

8
ARRANGING CERAMIC ”LOGS” AND EMBERS
10.  Positionlogno.1(withtherecess)overtherightburner.
11.  Positionlogno.2(withtherecess)overtheleftburner.
1
2

9
13. Afterpositioningthelastlogsinthereplace,itisimportantthatthesecondaryburnersare
adjustedtowardseachother.Seedrawingbelow(thereplaceisseenfromthetop).
ARRANGING CERAMIC ”LOGS” AND EMBERS
12. Ensurethatlogsinthecombustionchamberdonottouchlogno.1andlogno.2.There
shouldbespacebetweenthem.
16. Mounttheglassesagain.
ScantheQRcodetoseeavideoofhowtomounttheglass.
