Raritan PXE User manual

Raritan PXE
User Guide
Xerus™Firmware v3.4.0
Copyright © 2018 Raritan, Inc.
PXE-1B-v3.4.0-E
January 2018
255-80-0008-00

WARNING! Read and understand all sections in this guide before installing or operating this product.
WARNING! Connect this product to an AC power source whose voltage is within the range specified
on the product's nameplate. Operating this product outside the nameplate voltage range may result
in electric shock, fire, personal injury and death.
WARNING! Connect this product to an AC power source that is current limited by a suitably rated
fuse or circuit breaker in accordance with national and local electrical codes. Operating this product
without proper current limiting may result in electric shock, fire, personal injury and death.
WARNING! Connect this product to a protective earth ground. Never use a "ground lift adaptor"
between the product's plug and the wall receptacle. Failure to connect to a protective earth ground
may result in electric shock, fire, personal injury and death.
WARNING! This product contains no user serviceable parts. Do not open, alter or disassemble this
product. All servicing must be performed by qualified personnel. Disconnect power before servicing
this product. Failure to comply with this warning may result in electric shock, personal injury and
death.
WARNING! Use this product in a dry location. Failure to use this product in a dry location may result
in electric shock, personal injury and death.
WARNING! Do not rely on this product's receptacle lamps, receptacle relay switches or any other
receptacle power on/off indicator to determine whether power is being supplied to a receptacle.
Unplug a device connected to this product before performing repair, maintenance or service on the
device. Failure to unplug a device before servicing it may result in electric shock, fire, personal injury
and death.
WARNING! Only use this product to power information technology equipment that has a UL/IEC
60950-1 or equivalent rating. Attempting to power non-rated devices may result in electric shock, fire,
personal injury and death.
WARNING! Do not use a Raritan product containing outlet relays to power large inductive loads such
as motors or compressors. Attempting to power a large inductive load may result in damage to the
relay.
WARNING! Do not use this product to power critical patient care equipment, fire or smoke alarm
systems. Use of this product to power such equipment may result in personal injury and death.
WARNING! If this product is a model that requires assembly of its line cord or plug, all such
assembly must be performed by a licensed electrician and the line cord or plugs used must be
suitably rated based on the product's nameplate ratings and national and local electrical codes.
Assembly by unlicensed electricians or failure to use suitably rated line cords or plugs may result in
electric shock, fire, personal injury or death.
WARNING! This product contains a chemical known to the State of California to cause cancer, birth
defects, or other reproductive harm.
Safety Guidelines

1. Installation of this product should only be performed by a person who has knowledge and
experience with electric power.
2. Make sure the line cord is disconnected from power before physically mounting or moving the
location of this product.
3. This product is designed to be used within an electronic equipment rack. The metal case of this
product is electrically bonded to the line cord ground wire. A threaded grounding point on the
case may be used as an additional means of protectively grounding this product and the rack.
4. Examine the branch circuit receptacle that will supply electric power to this product. Make sure
the receptacle’s power lines, neutral and protective earth ground pins are wired correctly and
are the correct voltage and phase. Make sure the branch circuit receptacle is protected by a
suitably rated fuse or circuit breaker.
5. If the product is a model that contains receptacles that can be switched on/off, electric power
may still be present at a receptacle even when it is switched off.
Tip 1: The outlet (socket) shall be installed near the equipment and shall be easily accessible.
Tip 2: For detailed information on any Raritan PDU's overcurrent protectors' design, refer to that
model's product specification on Raritan website's PDU Product Selector page
https://www.raritan.com/product-selector .
Safety Instructions

This document contains proprietary information that is protected by copyright. All rights reserved. No
part of this document may be photocopied, reproduced, or translated into another language without
express prior written consent of Raritan, Inc.
© Copyright 2018 Raritan, Inc. All third-party software and hardware mentioned in this document are
registered trademarks or trademarks of and are the property of their respective holders.
FCC Information
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a commercial installation. This equipment generates, uses, and can
radiate radio frequency energy and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. Operation of this equipment in a residential
environment may cause harmful interference.
VCCI Information (Japan)
Raritan is not responsible for damage to this product resulting from accident, disaster, misuse,
abuse, non-Raritan modification of the product, or other events outside of Raritan's reasonable
control or not arising under normal operating conditions.
If a power cable is included with this product, it must be used exclusively for this product.

vi
Contents
Safety Guidelines ii
Safety Instructions iii
What's New in the PXE User Guide xiv
Chapter 1 Introduction 1
Product Models................................................................................................................................. 1
Package Contents............................................................................................................................. 1
Zero U Products ..................................................................................................................... 1
1U Products............................................................................................................................ 1
APIPA and Link-Local Addressing ................................................................................................... 2
Before You Begin.............................................................................................................................. 3
Unpacking the Product and Components.............................................................................. 3
Preparing the Installation Site............................................................................................... 3
Filling Out the Equipment Setup Worksheet......................................................................... 4
Checking the Branch Circuit Rating ...................................................................................... 4
Chapter 2 Rack-Mounting the PDU 5
Rackmount Safety Guidelines .......................................................................................................... 5
Circuit Breaker Orientation Limitation ............................................................................................ 5
Mounting 1U Models Using L-Brackets and Buttons ...................................................................... 6
Mounting Zero U Models Using Two Rear Buttons.......................................................................... 7
Mounting Zero U Models Using L-Brackets and Buttons................................................................ 9
Chapter 3 Initial Installation and Configuration 11
Connecting the PDU to a Power Source ........................................................................................ 11
Connecting the PXE to Your Network............................................................................................. 11
Configuring the PXE ....................................................................................................................... 12
Installing the USB-to-Serial Driver (Optional) .................................................................... 13
Connecting the PXE to a Computer ..................................................................................... 14
Initial Network Configuration via CLI .................................................................................. 15

Contents
vii
Bulk Configuration Methods .......................................................................................................... 18
Installing Cable Retention Clips on Outlets (Optional) .................................................................. 18
Chapter 4 Connecting Environmental Sensor Packages 20
Identifying the Sensor Port............................................................................................................. 21
DPX Sensor Packages .................................................................................................................... 21
Using an Optional DPX-ENVHUB4 Sensor Hub................................................................... 23
Using an Optional DPX-ENVHUB2 cable ............................................................................. 24
Supported Maximum DPX Sensor Distances ...................................................................... 26
DPX2 Sensor Packages .................................................................................................................. 27
DPX3 Sensor Packages .................................................................................................................. 29
Connecting a DPX2 Sensor Package to DPX3 ..................................................................... 30
DX or DX2 Sensor Packages........................................................................................................... 31
Connecting a DPX2 Sensor Package to DX.......................................................................... 33
Using an Optional DPX3-ENVHUB4 Sensor Hub ........................................................................... 34
Mixing Diverse Sensor Types ......................................................................................................... 36
Chapter 5 Using the PDU 40
Panel Components ......................................................................................................................... 40
Power Cord........................................................................................................................... 40
Outlets.................................................................................................................................. 40
Connection Ports.................................................................................................................. 41
LED Display .......................................................................................................................... 42
Reset Button ........................................................................................................................ 45
Circuit Breakers ............................................................................................................................. 45
Resetting the Button-Type Circuit Breaker......................................................................... 45
Resetting the Handle-Type Circuit Breaker........................................................................ 46
Chapter 6 Using the Web Interface 48
Supported Web Browsers .............................................................................................................. 48
Login, Logout and Password Change............................................................................................. 48
Login..................................................................................................................................... 49
Changing Your Password..................................................................................................... 50
Remembering User Names and Passwords ....................................................................... 51
Logout .................................................................................................................................. 51
Web Interface Overview.................................................................................................................. 52
Menu..................................................................................................................................... 54
Quick Access to a Specific Page .......................................................................................... 56
Sorting a List........................................................................................................................ 56
Dashboard ...................................................................................................................................... 57
Dashboard - Inlet I1 ............................................................................................................. 59

Contents
viii
Dashboard - Alerted Sensors .............................................................................................. 61
Dashboard - Inlet History .................................................................................................... 63
Dashboard - Alarms............................................................................................................. 64
PDU................................................................................................................................................. 66
Internal Beeper State .......................................................................................................... 68
Z Coordinate Format............................................................................................................ 68
How the Automatic Management Function Works.............................................................. 69
Inlet................................................................................................................................................. 69
Outlets ............................................................................................................................................ 72
Available Data of the Outlets Overview Page ...................................................................... 73
Individual Outlet Pages ........................................................................................................ 73
OCPs ............................................................................................................................................... 75
Individual OCP Pages........................................................................................................... 76
Peripherals ..................................................................................................................................... 78
Yellow- or Red-Highlighted Sensors ................................................................................... 83
Managed vs Unmanaged Sensors/Actuators ...................................................................... 85
Sensor/Actuator States........................................................................................................ 86
Finding the Sensor's Serial Number................................................................................... 87
Identifying the Sensor Position and Channel ...................................................................... 88
Managing One Sensor or Actuator ...................................................................................... 90
Individual Sensor/Actuator Pages ....................................................................................... 92
Sensor/Actuator Location Example..................................................................................... 97
User Management .......................................................................................................................... 98
Creating Users ..................................................................................................................... 99
Editing or Deleting Users................................................................................................... 103
Creating Roles.................................................................................................................... 105
Editing or Deleting Roles ................................................................................................... 106
Setting Your Preferred Measurement Units ..................................................................... 107
Setting Default Measurement Units.................................................................................. 108
Device Settings ............................................................................................................................. 109
Configuring Network Settings ........................................................................................... 111
Configuring Network Services........................................................................................... 120
Configuring Security Settings............................................................................................ 129
Setting the Date and Time ................................................................................................. 154
Event Rules and Actions .................................................................................................... 158
Setting Data Logging.......................................................................................................... 202
Configuring Data Push Settings ........................................................................................ 203
Monitoring Server Accessibility......................................................................................... 205
Lua Scripts ......................................................................................................................... 209
Miscellaneous .................................................................................................................... 214
Maintenance ................................................................................................................................. 216
Device Information............................................................................................................. 218
Viewing Connected Users .................................................................................................. 220
Viewing or Clearing the Local Event Log........................................................................... 221
Updating the PXE Firmware .............................................................................................. 222
Viewing Firmware Update History..................................................................................... 224

Contents
ix
Bulk Configuration ............................................................................................................. 225
Backup and Restore of Device Settings............................................................................. 232
Network Diagnostics.......................................................................................................... 233
Downloading Diagnostic Information ................................................................................ 234
Rebooting the PXE Device.................................................................................................. 235
Resetting All Settings to Factory Defaults ........................................................................ 235
Retrieving Software Packages Information....................................................................... 236
Chapter 7 Using SNMP 238
Enabling and Configuring SNMP.................................................................................................. 238
SNMPv2c Notifications....................................................................................................... 239
SNMPv3 Notifications ........................................................................................................ 240
Downloading SNMP MIB .............................................................................................................. 243
SNMP Gets and Sets..................................................................................................................... 244
The PXE MIB....................................................................................................................... 244
A Note about Enabling Thresholds.................................................................................... 247
Chapter 8 Using the Command Line Interface 248
About the Interface....................................................................................................................... 248
Logging in to CLI........................................................................................................................... 249
With HyperTerminal........................................................................................................... 249
With SSH or Telnet............................................................................................................. 250
Different CLI Modes and Prompts ..................................................................................... 251
Closing a Local Connection ............................................................................................... 251
Logging out of CLI......................................................................................................................... 251
The ? Command for Showing Available Commands.................................................................... 252
Querying Available Parameters for a Command......................................................................... 252
Showing Information .................................................................................................................... 253
Network Configuration....................................................................................................... 254
PDU Configuration ............................................................................................................. 259
Outlet Information..............................................................................................................259
Inlet Information ................................................................................................................ 260
Overcurrent Protector Information ................................................................................... 261
Date and Time Settings...................................................................................................... 262
Default Measurement Units............................................................................................... 262
Environmental Sensor Information ................................................................................... 263
Actuator Information.......................................................................................................... 264
Environmental Sensor Package Information .................................................................... 265
Inlet Sensor Threshold Information .................................................................................. 266
Inlet Pole Sensor Threshold Information.......................................................................... 267
Environmental Sensor Threshold Information.................................................................. 269
Environmental Sensor Default Thresholds ....................................................................... 270
Security Settings ................................................................................................................ 271

Contents
x
Authentication Settings...................................................................................................... 272
Existing User Profiles ........................................................................................................ 273
Existing Roles..................................................................................................................... 274
EnergyWise Settings .......................................................................................................... 274
Event Log............................................................................................................................ 275
Server Reachability Information........................................................................................ 276
Command History .............................................................................................................. 277
Reliability Data ................................................................................................................... 277
Reliability Error Log...........................................................................................................278
Examples............................................................................................................................ 278
Clearing Information .................................................................................................................... 280
Clearing Event Log............................................................................................................. 280
Configuring the PXE Device and Network.................................................................................... 281
Entering Configuration Mode............................................................................................. 281
Quitting Configuration Mode.............................................................................................. 281
PDU Configuration Commands.......................................................................................... 282
Network Configuration Commands................................................................................... 285
Time Configuration Commands......................................................................................... 304
Checking the Accessibility of NTP Servers ....................................................................... 308
Security Configuration Commands.................................................................................... 308
Outlet Configuration Commands....................................................................................... 328
Inlet Configuration Commands.......................................................................................... 328
Overcurrent Protector Configuration Commands............................................................. 330
User Configuration Commands ......................................................................................... 330
Role Configuration Commands.......................................................................................... 344
Authentication Commands ................................................................................................ 348
Environmental Sensor Configuration Commands ............................................................ 360
Configuring Environmental Sensors' Default Thresholds ................................................ 365
Sensor Threshold Configuration Commands.................................................................... 367
Actuator Configuration Commands................................................................................... 374
Server Reachability Configuration Commands ................................................................. 375
EnergyWise Configuration Commands.............................................................................. 379
Multi-Command Syntax ..................................................................................................... 381
Actuator Control Operations ........................................................................................................ 382
Switching On an Actuator................................................................................................... 382
Switching Off an Actuator .................................................................................................. 383
Example - Turning On a Specific Actuator ........................................................................ 383
Unblocking a User ........................................................................................................................ 383
Resetting the PXE......................................................................................................................... 384
Restarting the PDU ............................................................................................................ 384
Resetting Active Energy Readings..................................................................................... 384
Resetting to Factory Defaults ............................................................................................ 385
Network Troubleshooting............................................................................................................. 385
Entering Diagnostic Mode.................................................................................................. 385
Quitting Diagnostic Mode................................................................................................... 386
Diagnostic Commands....................................................................................................... 386

Contents
xi
Retrieving Previous Commands................................................................................................... 388
Automatically Completing a Command ....................................................................................... 388
Chapter 9 Using SCP Commands 390
Firmware Update via SCP ............................................................................................................ 390
Bulk Configuration via SCP .......................................................................................................... 391
Backup and Restore via SCP........................................................................................................ 392
Downloading Diagnostic Data via SCP ......................................................................................... 393
Appendix A Specifications 396
Maximum Ambient Operating Temperature................................................................................ 396
Sensor RJ-12 Port Pinouts........................................................................................................... 396
RS-485 Port Pinouts..................................................................................................................... 396
Appendix B Equipment Setup Worksheet 398
Appendix C Bulk Configuration or Firmware Upgrade via DHCP/TFTP 402
Bulk Configuration/Upgrade Procedure...................................................................................... 402
Configuration Files ....................................................................................................................... 403
fwupdate.cfg....................................................................................................................... 405
config.txt............................................................................................................................. 408
devices.csv ......................................................................................................................... 410
Creating Configuration Files via Mass Deployment Utility ............................................... 411
Data Encryption in 'config.txt'............................................................................................ 412

Contents
xii
TFTP Requirements...................................................................................................................... 413
DHCP IPv4 Configuration in Windows.......................................................................................... 414
DHCP IPv6 Configuration in Windows.......................................................................................... 424
DHCP IPv4 Configuration in Linux................................................................................................431
DHCP IPv6 Configuration in Linux................................................................................................433
Appendix D Resetting to Factory Defaults 435
Using the CLI Command .............................................................................................................. 435
Appendix E LDAP Configuration Illustration 437
Step A. Determine User Accounts and Roles .............................................................................. 437
Step B. Configure User Groups on the AD Server ....................................................................... 438
Step C. Configure LDAP Authentication on the PXE Device ........................................................ 439
Step D. Configure Roles on the PXE Device................................................................................. 440
Appendix F Updating the LDAP Schema 443
Returning User Group Information.............................................................................................. 443
From LDAP/LDAPS ............................................................................................................ 443
From Microsoft Active Directory........................................................................................ 443
Setting the Registry to Permit Write Operations to the Schema................................................. 444
Creating a New Attribute.............................................................................................................. 444
Adding Attributes to the Class ..................................................................................................... 445
Updating the Schema Cache ........................................................................................................ 447
Editing rciusergroup Attributes for User Members .................................................................... 447
Appendix G RADIUS Configuration Illustration 450
Standard Attributes ...................................................................................................................... 450
NPS Standard Attribute Illustration .................................................................................. 450
FreeRADIUS Standard Attribute Illustration..................................................................... 468
Vendor-Specific Attributes ........................................................................................................... 469
NPS VSA Illustration .......................................................................................................... 469
FreeRADIUS VSA Illustration............................................................................................. 481
AD-Related Configuration ............................................................................................................ 482
Appendix H Additional PXE Information 486
Locking Outlets and Cords........................................................................................................... 486
SecureLock™ Outlets and Cords....................................................................................... 487
Button-Type Locking Outlets............................................................................................. 488

Contents
xiii
MAC Address ................................................................................................................................ 489
Reserving IP Addresses in DHCP Servers ................................................................................... 489
Reserving IP in Windows.................................................................................................... 489
Reserving IP in Linux ......................................................................................................... 491
Sensor Threshold Settings........................................................................................................... 492
Thresholds and Sensor States........................................................................................... 492
"To Assert" and Assertion Timeout ................................................................................... 495
"To De-assert" and Deassertion Hysteresis ..................................................................... 497
Default Voltage and Current Thresholds ..................................................................................... 500
PDView App for Viewing the PXE..................................................................................................502
Saving User Credentials for PDView's Automatic Login................................................... 505
Altitude Correction Factors.......................................................................................................... 507
Unbalanced Current Calculation..................................................................................................508
Ways to Probe Existing User Profiles .......................................................................................... 509
Raritan Training Website.............................................................................................................. 509
Device-Specific Settings............................................................................................................... 510
TLS Certificate Chain.................................................................................................................... 510
What is a Certificate Chain ................................................................................................ 511
Illustration - GMAIL SMTP Certificate Chain..................................................................... 514
Browsing through the Online Help............................................................................................... 517
Appendix I Integration 519
Power IQ Configuration ................................................................................................................ 519
dcTrack ......................................................................................................................................... 519
dcTrack Overview............................................................................................................... 520
Index 521

xiv
The following sections have changed or information has been added to
the PXE User Guide based on enhancements and changes to the
equipment and/or user documentation.
Configuring the PXE (on page 12)
Identifying the Sensor Port (on page 21)
DPX3 Sensor Packages (on page 29)
DX or DX2 Sensor Packages (on page 31)
Supported Web Browsers (on page 48)
Login (on page 49)
Web Interface Overview (on page 52)
Menu (on page 54)
Sorting a List (on page 56)
Dashboard (on page 57)
Dashboard - Inlet I1 (on page 59)
Dashboard - Inlet History (on page 63)
Dashboard - Alarms (on page 64)
PDU (on page 66)
Z Coordinate Format (on page 68)
Individual OCP Pages (on page 76)
Peripherals (on page 78)
Individual Sensor/Actuator Pages (on page 92)
User Management (on page 98)
Creating Users (on page 99)
Creating Roles (on page 105)
Setting Your Preferred Measurement Units (on page 107)
Device Settings (on page 109)
Configuring Network Services (on page 120)
Configuring Security Settings (on page 129)
Creating IP Access Control Rules (on page 130)
Creating Role Access Control Rules (on page 133)
Creating a CSR (on page 137)
Adding Radius Servers (on page 147)
Calendar (on page 156)
Built-in Rules and Rule Configuration (on page 159)
What's New in the PXE User Guide

What's New in the PXE User Guide
xv
Default Log Messages (on page 164)
Available Actions (on page 172)
Placeholders for Custom Messages (on page 191)
Writing or Loading a Lua Script (on page 209)
Manually Starting or Stopping a Script (on page 211)
Modifying or Deleting a Script (on page 214)
Viewing Connected Users (on page 220)
Viewing or Clearing the Local Event Log (on page 221)
Bulk Configuration (on page 225)
Bulk Configuration Restrictions (on page 226)
Customizing Bulk Configuration Profiles (on page 228)
Performing Bulk Configuration (on page 229)
Modifying or Removing Bulk Profiles (on page 231)
Backup and Restore of Device Settings (on page 232)
The ? Command for Showing Available Commands (on page 252)
Querying Available Parameters for a Command (on page 252)
Network Configuration (on page 254)
IP Configuration (on page 254)
IPv4-Only or IPv6-Only Configuration (on page 256)
Network Interface Settings (on page 257)
Security Settings (on page 271)
Authentication Settings (on page 272)
Specifying the Device Altitude (on page 283)
Setting the Maximum Number of Active Powered Dry Contact
Actuators
(on page 285)
Setting the IPv4 Configuration Mode (on page 286)
Setting the IPv4 Preferred Host Name (on page 287)
Setting the IPv4 Address (on page 288)
Setting IPv4 Static Routes (on page 289)
Setting the IPv6 Configuration Mode (on page 290)
Setting the IPv6 Preferred Host Name (on page 291)
Setting the IPv6 Address (on page 292)
Setting IPv6 Static Routes (on page 293)
Configuring DNS Parameters (on page 294)
Enabling or Disabling the LAN Interface (on page 295)

Chapter 1: What's New in the PXE User Guide
xvi
Changing the LAN Duplex Mode (on page 296)
Setting NTP Parameters (on page 305)
Role Configuration Commands (on page 344)
All Privileges (on page 344)
Authentication Commands (on page 348)
Determining the Authentication Method (on page 348)
LDAP Settings (on page 349)
Adding an LDAP Server (on page 350)
Optional Parameters (on page 351)
Illustrations of Adding LDAP Servers (on page 353)
Copying an Existing Server's Settings (on page 354)
Modifying an Existing LDAP Server (on page 354)
Removing an Existing LDAP Server (on page 357)
Radius Settings (on page 357)
Adding a Radius Server (on page 357)
Modifying an Existing Radius Server (on page 358)
Removing an Existing Radius Server (on page 360)
Downloading Diagnostic Data via SCP (on page 393)
fwupdate.cfg (on page 405)
config.txt (on page 408)
devices.csv (on page 410)
Default Voltage and Current Thresholds (on page 500)
PDView App for Viewing the PXE (on page 502)
Saving User Credentials for PDView's Automatic Login (on page 505)
Device-Specific Settings (on page 510)
TLS Certificate Chain (on page 510)
What is a Certificate Chain (on page 511)
Illustration - GMAIL SMTP Certificate Chain (on page 514)
Please see the Release Notes for a more detailed explanation of the
changes applied to this version of PXE.

1
Raritan PXE is an intelligent power distribution unit (PDU) that allows
you to remotely monitor power consumed by IT equipment in the server
room or data center.
The intended use of the PXE is distribution of power to information
technology equipment such as computers and communication
equipment where such equipment is typically mounted in an equipment
rack located in an information technology equipment room.
In This Chapter
Product Models ...........................................................................................1
Package Contents........................................................................................1
APIPA and Link-Local Addressing..............................................................2
Before You Begin.........................................................................................3
Product Models
The PXE comes in several models that are built to stock and can be
obtained almost immediately. Raritan also offers custom models that are
built to order and can only be obtained on request.
Download the PXE Data Sheet from Raritan's website, visit the
Product
Selector page
( http://www.findmypdu.com/ ) on Raritan's website, or
contact your local reseller for a list of available models.
Package Contents
The following sub-topics describe the equipment and other material
included in the product package.
Zero U Products
The PXE device
Mounting screws, brackets and/or buttons
Cable retention clips for outlets (optional)
1U Products
The PXE device
Mounting screws, brackets and/or buttons
Chapter 1 Introduction

Chapter 1: Introduction
2
APIPA and Link-Local Addressing
The PXE supports Automatic Private Internet Protocol Addressing
(APIPA).
With APIPA, your PXE automatically configures a link-local IP address
and a link-local host name when it cannot obtain a valid IP address from
any DHCP server in the TCP/IP network.
Only IT devices connected to
the same subnet can access the PXE using
the link-local address/host name. Those in a different subnet cannot
access it.
Once the PXE can get a DHCP-assigned IP address, it stops using APIPA
and the link-local address is replaced by the DHCP-assigned address.
Scenarios where APIPA applies:
DHCP is enabled on the PXE, but no IP address is assigned to the
PXE.
This may be caused by the absence or malfunction of DHCP servers
in the network.
Note: Configuration by connecting the PXE to a computer using a
network cable is an application of this scenario. See Connecting the
PXE to a Computer
(on page 14).
The PXE previously obtained an IP address from the DHCP server,
but the lease of this IP address has expired, and the lease cannot be
renewed, or no new IP address is available.
Link-local addressing:
IPv4 address:
Factory default is to enable IPv4 only. The link-local IPv4 address is
169.254.x.x/16 , which ranges between 169.254.1.0 and
169.254.254.255.
IPv6 address:
A link-local IPv6 address is available only after IPv6 is enabled on the
PXE. See
Configuring Network Settings (on page 111).
Host name - pdu.local:
You can type
https://pdu.local to access the PXE instead of typing the
link-local IP address.
Retrieval of the link-local address:
Perform the first three steps in the
Initial Network Configuration
via CLI
(on page 15).

Chapter 1: Introduction
3
Before You Begin
Before beginning the installation, perform the following activities:
Unpack the product and components
Prepare the installation site
Check the branch circuit rating
Fill out the equipment setup worksheet
Unpacking the Product and Components
1. Remove the PXE device and other equipment from the box in which
they were shipped. See
Package Contents (on page 1) for a
complete list of the contents of the box.
2. Compare the serial number of the equipment with the number on the
packing slip located on the outside of the box and make sure they
match.
3. Inspect the equipment carefully. If any of the equipment is damaged
or missing, contact Raritan's Technical Support Department for
assistance.
4. Verify that all circuit breakers on the PXE device are set to ON. If not,
turn them ON.
Or make sure that all fuses are inserted and seated properly. If there
are any fuse covers, ensure that they are closed.
Note: Not all PXE devices have overcurrent protectors.
Preparing the Installation Site
1. Make sure the installation area is clean and free of extreme
temperatures and humidity.
Note: If necessary, contact Raritan Technical Support for the
maximum operating temperature for your model. See Maximum
Ambient Operating Temperature
(on page 396).
2. Allow sufficient space around the PXE device for cabling and outlet
connections.
3. Review
Safety Instructions (on page iii) listed in this User Guide.

Chapter 1: Introduction
4
Filling Out the Equipment Setup Worksheet
An Equipment Setup Worksheet is provided in this User Guide. See
Equipment Setup Worksheet (on page 398). Use this worksheet to
record the model, serial number, and use of each IT device connected to
the PDU.
As you add and remove devices, keep the worksheet up-to-date.
Checking the Branch Circuit Rating
The rating of the branch circuit supplying power to the PDU shall be in
accordance with national and local electrical codes.
