Raw Thrills Fast and Furious Arcade User manual

90-12-825 040-00086-01 REV 4
Fast and Furious Arcade
Operator’s Manual
Fast & Furious Arcade © 2022 Universal City Studios LLC. All Rights Reserved.
Software © 2022 Raw Thrills, Inc.

This Page Left
Blank
Intentionally

Fast and Furious Arcade
3 | P a g e
Table of Contents
OPERATION ..................................................................................................................................................5
TRANSPORTING .............................................................................................................................................5
HANDLING COMPONENTS ...............................................................................................................................5
DISCONNECT POWER .....................................................................................................................................5
GROUNDING.................................................................................................................................................5
ELECTRICAL SHOCKS.......................................................................................................................................5
MONITOR ....................................................................................................................................................5
VOLTAGE......................................................................................................................................................5
POWER CORD ...............................................................................................................................................5
SURGE SUPPRESSOR.......................................................................................................................................6
WATER AND OTHER LIQUID SOURCES ...............................................................................................................6
CONNECTORS................................................................................................................................................6
COMPUTER...................................................................................................................................................6
VENTILATION ................................................................................................................................................6
HAZARD TO EPILEPTICS...................................................................................................................................6
MANUAL......................................................................................................................................................6
SPECIFICATIONS.............................................................................................................................................7
Product Specifications..................................................................................................................................8
ELECTRICAL POWER .......................................................................................................................................8
TEMPERATURE ..............................................................................................................................................8
HUMIDITY ....................................................................................................................................................8
DIMENSIONS.................................................................................................................................................8
Fuse Replacement Guide .............................................................................................................................8
12V POWER DISTRIBUTION.............................................................................................................................8
Setup.............................................................................................................................................................9
SAFETY NOTICE .............................................................................................................................................9
UNPACK MATERIALS ......................................................................................................................................9
REQUIRED TOOLS ..........................................................................................................................................9
CABINET ASSEMBLY .....................................................................................................................................10
Lower Monitor Installation .................................................................................................................10
Top Monitor Mounting Bracket Installation.......................................................................................11

Fast and Furious Arcade
4 | P a g e
Top Monitor Hanger Bracket Installation ...........................................................................................12
Top Monitor Assembly Installation.....................................................................................................13
HDMI/AC Cables and Monitor Rear Cover Plate Installation..............................................................14
Cabinet Joiner Bracket Installation .....................................................................................................15
Motion Cabinet Installation ................................................................................................................16
CARD READER INSTALLATION AND SETUP.........................................................................................................17
CHECK ELECTRICAL SETTINGS.........................................................................................................................18
STARTUP GAME ..........................................................................................................................................18
SAMSUNG MONITOR SETTINGS......................................................................................................................19
Diagnostic and Adjustments ......................................................................................................................20
BASIC FUNCTIONAL TEST ON INITIAL POWER UP...............................................................................................21
TEST MENUS ..............................................................................................................................................22
Main Menu..........................................................................................................................................22
Diagnostics..........................................................................................................................................23
Pricing Adjustments (Cash) .................................................................................................................24
Pricing Adjustments (Tokens) .............................................................................................................25
Pricing Adjustments (Swipes)..............................................................................................................26
Game Settings.....................................................................................................................................27
System Settings...................................................................................................................................28
Audits ..................................................................................................................................................29
Resets Menu .......................................................................................................................................30
Volume................................................................................................................................................31
Calibration...........................................................................................................................................32
Utilities................................................................................................................................................33
System Information.............................................................................................................................34
CHOOSING THE RIGHT PRICING ADJUSTMENTS FOR YOUR LOCATION ...................................................................35
PC HARDWARE ...........................................................................................................................................36
PC HARD DRIVE RECOVERY...........................................................................................................................37
Troubleshooting .........................................................................................................................................38
Technical Support.......................................................................................................................................43
Electrical and Mechanical Illustrations......................................................................................................44

Fast and Furious Arcade
5 | P a g e
Safety
Operation
Before operating game, read this manual. Failure to properly install and operate this game could result in
malfunction or accident. Operate the game in accordance with the manual.
Transporting
The cabinet is very heavy. Because the monitor is high, the cabinet is also very top-heavy. Use appropriate
care when moving or transporting cabinet. It contains fragile glass and electronic components. Avoid rough
handling.
Handling Components
Many components are extremely sensitive to handling, environmental and Electrostatic Discharge (ESD)
events—especially the computer. Do not handle it roughly. Before servicing, call your distributor and inquire
about the PC warranty. Use proper ESD procedures when servicing. Protect components from harmful
environmental conditions, such as extreme temperatures, excessive moisture or other damaging effects.
Disconnect Power
Always turn the power off and unplug the unit before servicing or making adjustments unless otherwise
instructed. Installing or repairing components while power is on can damage the components and void the
warranty.
Grounding
Avoid electrical shock. Do not plug in AC power until you have inspected and properly grounded the unit.
Only plug into a grounded, three-wire outlet. Do not use a “cheater” plug or cut off the ground pin on the line
cord.
Electrical Shocks
There is no isolation transformer in the cabinet. Disconnect AC power before servicing. However, be aware
that lethal voltages can remain in the electronic components even when AC power is disconnected. Use
extreme caution when servicing. Verify that there is a working ground connection. If the unit sustains water
damage, cease using it immediately and unplug AC power.
Monitor
The monitor contains no user serviceable parts. Do not attempt to service the monitor.
Voltage
Each game is manufactured for a specific AC voltage. Before applying power, verify that the AC voltage
matches the game’s specified voltage rating.
Power Cord
If the power cord is damaged or lost, replace it with an identical cord as supplied by the manufacturer or an
authorized service agent.

Fast and Furious Arcade
6 | P a g e
Surge Suppressor
It is recommended that you plug your game’s power cord into a surge suppressor to help protect from power
surges that may damage sensitive electronic components.
Water and Other Liquid Sources
Do not install game near sprinkler or other water jet sources. Do not use water jet to clean game. Keep
minimum clearance behind game and wall for proper ventilation but also prevent access of liquid from spills
and sprays from entering ventilation holes.
Connectors
When servicing machine, ensure all connectors mate properly. If connectors do not slip in easily, do not force
them. Connectors are often keyed and only connect one way. Check for correct orientation.
Computer
The computer contains sensitive components, including a hard drive. Do not handle it roughly. Call your
distributor before servicing its internal components. Ask about warranty information as it relates to the PC.
Cycle AC power on or off with the cabinet power switch.
A dongle has been inserted into one of the USB ports. This is required for game play.
Do not remove the dongle except for troubleshooting purposes.
Ventilation
It is critical that the game is installed in a manner that allows for proper ventilation and air flow. Game must be
installed such that there is a minimum amount of clearance between the wall or another game to allow good air
circulation through the game cooling fans and vents.
Hazard to Epileptics
A small portion of the population has an epileptic condition that may cause seizures. Affected persons
experience seizures while watching some television pictures or playing certain video games. People who have
not had seizures may still have an undetected epileptic condition. If anyone in your family has experienced
epilepsy symptoms (seizures or loss of awareness), consult your physician before using video games. While
children play video games, a parent should observe. Be alert to the following symptoms: dizziness, altered
vision, eye or muscle twitching, involuntary movements, loss of awareness, disorientation or convulsions. If
you or your child experiences these symptoms, discontinue use immediately and consult your physician.
Manual
Keep this manual available and ready for use. If the game fails to function properly, turn off the machine and
unplug the AC line cord. Contact your local distributor. You may not reproduce this document or any of its
contents without written authorization from Raw Thrills, Inc.

Fast and Furious Arcade
7 | P a g e
Specifications
For reasons such as performance, this product’s specifications may change without notice. Federal patent,
copyright and other intellectual property laws protect the content, devices and design of the game and its
equipment.
CAUTION
•This machine features moving parts and should only be serviced by a trained and experienced
technician.
•Disconnect all power and air supply before servicing the machine.
•Keep area around the machine clear and free of objects that present a trip hazard. Allow for
plenty of room for players to safely enter and exit the machine.
•Observe ALL of the following guidelines to prevent injury, accident, or damage.
oMaximum of one person on the machine at any time.
oIf a player fatigues or experiences motion sickness or is unable to continue the game for
any reason, stop the game motion immediately by pressing the MOTION STOP button.
Allow the person to rest and exit the game with assistance if needed.
oRemain seated for the entire duration of the game. Do not stand or exit while the game is
moving. Press the MOTION STOP button before exiting the game.
oKeep hands and legs inside the game at all times while in motion. Remain in the game
until game comes to a complete stop.
oDo not attempt to reach for objects on the floor or near the game when it is moving. Stay
clear and stand at a safe distance while game is in motion.
oSmall children should always be accompanied by a parent or guardian.
•The machine is equipped with safety features which the operator and the player need to be
familiar with:
oMOTION STOP button is located on the left side of the seat pedestal, under the dash. This
button will stop the motion feature once pressed.
oBellows around the moving part of the machine prevent access between the base and the
moving part. Make sure that the bellows are not damaged or showing signs of excessive
wear that could lead to failure. Replace the bellows when this occurs. Use only
tamperproof screw fasteners as specified.
oThe machine is designed so that there is no unintended movement in the absence of a
logic signal as might be experienced during a power outage. Make sure that the machine
is safe to operate before turning power back ON.
•Critical parts should be maintained and inspected regularly for safe operation. If those critical
parts are damaged, broken, or installed incorrectly, replace them, or install correctly. Use only
manufacturer’s specified parts for continued safety and reliability. Contact your distributor to
order replacement parts.

Fast and Furious Arcade
8 | P a g e
Product Specifications
Electrical Power
MULTIPLE POWER SUPPLY ENTRIES
Warning: Before obtaining access to terminals, all supply circuits must be disconnected.
Attention: Avant d’accéder aux bornes, tous les circuits d’alimentation doivent être déconnectés.
United States, Canada (ETL)
Voltage: 120VAC / 60 Hz
Operating AC Current: 20 Amps (10 Amps per entry)
International (CE)
Voltage: 230VAC / 50Hz
Operating AC Current: 10 Amps (5 Amps per entry)
Temperature
50° F to 104° F
(10° C to 40° C)
Humidity
Must not exceed 95% relative humidity
Dimensions
8’10 ¾”H x 4’9 ¼”W x 9’11 ¼”D (271.15cm H x 145.42cm W x 302.90cm D)
Approximate weight 1100lbs. (500kg)
Single cabinet setup recommended minimum floor space requirement:
10’H x 8’1 ¼”W x 15’3 ½”D (304.8cm H x 247.015cm W x 466.09cm D) ***see pg. 46 for diagram***
Twin cabinet setup recommended minimum floor space requirement:
12’H x 12’10 ½”W x 15’3 ½”D (365.76cm H x 483.87cm W x 466.09cm D) ***see pg. 48 for diagram***
Fuse Replacement Guide
NOTE: FOR CONTINUED PROTECTION AGAINST FIRE AND ELECTRICAL DAMAGE, USE ONLY SPECIFIED FUSE
TYPE AND VALUE.
12V Power Distribution
Please see unit for specified fuse labeling.
Abbreviations:
5A 250V
5A, 250VAC Fast Acting 3AG Fuse
Littlefuse 0312005.MXP (or equivalent)

Fast and Furious Arcade
9 | P a g e
Setup
Safety Notice
Installing this product requires three individuals able to lift heavy objects safely. Two 6-foot step ladders
(minimum height) are required as part of the installation process. Make sure that you are familiar with the
manual contents, game setup, and operations before you begin the installation process. Do not push or pull
on the decorative items such as the monitor bracket or spoiler to move the game. Doing so can damage the
decorative items. Be aware of your surroundings and individuals around you during the installation process
for your safety and the safety of others. Work only in an area with sufficient lighting and a clean level surface.
Unpack Materials
1. Place the shipping crate(s) on a flat, stable surface.
2. Cut the banding straps and remove the cardboard lids.
3. Lift off the large cardboard containers surrounding the cabinet assembly and remove any shipping
cleats.
4. Remove the keys from the front dash.
5. Check for shipping damage to the following:
•Monitor(s)
•Monitor bracket
•Cabinet decals
6. Check the AC line cords for visible signs of damage.
Pay particular attention to the plug and line cord insulation.
Required Tools
•Drill Driver
•Phillips Bit
•T-15 Tamper Resist Torx Bit
•T-20 Tamper Resist Torx Bit
•T-27 Tamper Resist Torx Bit
•Ratcheting Wrench
•7/16” Socket
•13mm Socket
•(2) 6ft Step Ladders (Minimum Height)

Fast and Furious Arcade
10 | P a g e
Cabinet Assembly
CAUTION
UNDER NO CIRCUMSTANCES SHOULD THIS GAME BE OPERATED UNLESS ALL INSTALLATION PROCEDURES
HAVE BEEN COMPLETED AND ALL SAFETY FEATURES HAVE BEEN POSITIVELY TESTED AND ARE FULLY
FUNCTIONAL!
*****It is recommended that the main cabinet be moved to or very near its desired operational location
before beginning any of the setup tasks (see pg. 46 (Single Game) or pg. 48 (Twin Games) for footprint
measurements).*****
Lower Monitor Installation
1. Remove the upper and lower back doors from the cabinet.
2. Unpack monitor and use packaging to stand monitor in an upright position on the floor.
3. Insert the (4) spacers (fig. a DETAIL A below) included with the monitor mounting kit into the (4)
mounting holes on the back of the monitor. ***These spacers must be used to maintain a proper air
space and keep the monitor from overheating.***
4. Set monitor up onto cabinet ledge, line up with mounting slots in cabinet and hold monitor to face of
cabinet as shown (fig. a below).
5. Use (4) 8Mx65MM screws (fig. a DETAIL A below), with (1) washer on each screw to secure monitor.
Do not tighten screws until final setup is completed, minor adjustments may be required if setting up
multiple linked games.
6. Plug AC cord into AC socket and install the HDMI-DVI cable into HDMI 1 at rear of monitor and the
DVI port on the graphics card at rear of PC.
7. Set the upper/lower monitor cross bracket on top of the cabinet with channel capturing the top of
the lower monitor and secure using (4) #8 wood screws (fig. a below).
fig. a

Fast and Furious Arcade
11 | P a g e
Top Monitor Mounting Bracket Installation
The upper monitor assembly weighs approximately 95 lbs. and the installation requires a minimum of three
people, using two 6-foot step ladders (minimum height). It is strongly recommended that the game NOT be
moved with the monitor installed in the operational (upright) position.
1. Set top monitor mounting bracket in position on top of the main cabinet, align 2” hole and (4) slots
in bracket with the holes in the top of the cabinet. Hold in place while finger tightening (4) ¼-20 x 1”
screw, lock and flat washer into holes in top of cabinet (fig. b Detail B below).
2. Securely tighten after all assembly is complete.
fig. b

Fast and Furious Arcade
12 | P a g e
Top Monitor Hanger Bracket Installation
1. Unpack remaining monitor and lay face down on a soft surface.
2. Install the standoff spacers into the (4) mounting holes in the back of the monitor (fig. c below).
3. Set hanger bracket in the position shown so the top mounting holes line up with the upper standoffs
(fig. c below).
4. Insert (2) 8Mx50MM screws, flat and lock washer (fig c below) and tighten hanger bracket to
monitor securely. ***DO NOT OVERTIGHTEN***
fig. c
Completed Assembly
fig. d

Fast and Furious Arcade
13 | P a g e
Top Monitor Assembly Installation
1. Using (2) people, hang the top monitor hanger over the top mounting bracket and lower the bottom
of the monitor into the channel below (fig. e below).
2. Install the lower (2) standoff spacers into the lower holes in the back of the monitor (fig. e below).
3. Install (2) remaining 8Mx50MM screws, flat and lock washer (fig. e below) and tighten monitor to
bracket securely. ***DO NOT OVERTIGHTEN***
4. ***IMPORTANT STEP*** Install (2) ¼-20x1” screws, flat and lock washers (fig. e below) to the top of
the bracket to secure the upper monitor assembly.
fig. e

Fast and Furious Arcade
14 | P a g e
HDMI/AC Cables and Monitor Rear Cover Plate Installation
1. Plug AC cord into AC socket on the rear of top monitor and feed AC cable down through the 2”
center hole in top of cabinet (fig. f below).
2. Install HDMI cable to top monitor in HDMI 1 and feed through side slot and center hole in cabinet
top (fig. f below). Connect to the HDMI port on the video card at rear of PC.
3. Install the rear cover plate with ¼-20 x ½ screws, and flat washers provided (fig. f Detail C below).
fig. f

Fast and Furious Arcade
15 | P a g e
Cabinet Joiner Bracket Installation
1. Install the joiner bracket to main cabinet with (4) ¼-20 x 2” screws, flat and lock washers. (fig. g
Detail D below).
2. Set the cover plate to the side, it is not needed at this time.
fig. g

Fast and Furious Arcade
16 | P a g e
Motion Cabinet Installation
fig. h
1. Push motion base assembly flush with the joiner bracket (fig. h above).
2. Connect all matching cable and air hose connections inside of the pan of the joiner bracket.
3. Install (4) ¼-20 x 1” screws, flat and lock washers to secure the motion base to the cabinet joiner
bracket and main cabinet (fig. i Detail A below).
4. With the cabinet in the desired location, set all leg levelers on the cabinet and motion base in the
down position.
5. Use supplied (8) ¼-20 x ½” screws, lock and flat washers (fig. i Detail B below) to secure the cover
plate to the joiner bracket.
fig. i

Fast and Furious Arcade
17 | P a g e
Card Reader Installation and Setup
Due to the rising popularity of aftermarket debit card systems for cashless or coinless operation of
amusement machines (i.e. Embed, Intercard, Semnox), this Fast & Furious Arcade cabinet is equipped with
UCL compatible harnessing to ensure that the installation process is easier and less prone to miswiring.
UCL, or Universal Card Link, is a debit card standard established by the American Amusement Machine
Association. Visit https://coin-op.org/standardization/ for the latest UCL standard and manual information.
The UCL connections on the game use pins 1, 2, 6, 8, and 9. The other pins are unused. Each UCL connector
can supply up to 1A at 12VDC.
You can choose to use 1 card reader in the pricing adjustments section of the test menu. It is recommended
to use 1 card reader for best results and player access.
There is (1) supplied connection, located on the driver cabinet assembly behind the dash plate to the right of
the steering wheel. It is recommended that the card reader be mounted to the bottom right corner of the
dash, using the provided UCL connector and provided mounting holes. ***See pg. 45 for mounting
instructions***

Fast and Furious Arcade
18 | P a g e
Check Electrical Settings
1. Verify the voltage in the nearest AC outlet.
2. Verify the AC outlet ground connection is present and working.
***Recommended: Game on dedicated breaker to prevent capacity overload (20A@120VAC,
10A@230VAC)***
***Recommended: UPS (Uninterruptible Power Supply)***
Startup Game
1. Plug the two line cords into an AC outlet (Recommended: plug the line cords into a dedicated
breaker to prevent capacity overload (20A@120VAC, 10A@230VAC)).
2. Turn the main cabinet power switches on (there are two switches, GAME and COMPRESSOR).
3. Calibrate the steering (follow onscreen prompts).
4. Calibrate the gas and brake pedals (follow onscreen prompts)
5. Calibrate the motion platform (follow onscreen prompts)
6. Calibrate the camera (follow onscreen prompts).
***MACHINE IS NOT OPERATIONAL WITHOUT FIRST CALIBRATING THE HARDWARE***
7. Verify the game and all components are operating normally. See Basic Functional Test on Initial
Power Up in the Diagnostics and Adjustments section for the recommended procedure.
8. Complete the monitor setup for both monitors (next page).

Fast and Furious Arcade
19 | P a g e
*****IMPORTANT*****
PLEASE FOLLOW INSTRUCTIONS TO SET UP MONITORS
SAMSUNG MONITOR SETTINGS
Model #QB65B
STEP 1: Verify game is connected to monitor in HDMI IN 1 at rear of both monitors (top monitor
connects to HDMI port on video card at rear of PC, bottom monitor connects to DVI port on video card
at rear of PC).
STEP 2: Power on GAME cabinet and MONITORS, wait about 30 seconds.
1. Installation Type: Basic Setup
2. Language: English (Select “Hello”)
3. Wireless Connection: SKIP <right arrow>
4. Display Orientation: Landscape
5. PlayVia: Magicinfo: SKIP
6. Connection to Magicinfo server: SKIP
7. Set Date/Time
8. Set PIN: Save the PIN in a secure place as this will be needed in STEP 5 (below)
9. Select Done
STEP 3: Press the “SOURCE” button on the remote. Navigate to “HDMI 1.”
STEP 4: Press “MENU” on the remote to enter the settings menu.
STEP 5: Verify the settings below, navigating with the remote:
•SYSTEM
oPOWER CONTROL
▪AUTO POWER ON: ON
▪MAX POWER SAVING: OFF
▪STANDBY CONTROL: OFF
▪POWER BUTTON: POWER ON ONLY
oAUTO SOURCE SWITCHING
▪AUTO SOURCE SWITCHING: OFF
oSECURITY –Enter PIN from STEP 2.8 (above)
▪BUTTON LOCK: ON

Fast and Furious Arcade
20 | P a g e
Diagnostic and Adjustments
The Service Button Panel has four buttons, three of which can navigate the menu system.
The control panel buttons can also advance through test menu screens.
Navigating the Test Menu
Button
Action
TEST (Not in Test Menu)
Enters Test Menu
TEST (In Test Menu)
Selects Highlighted Option
SERVICE (On Main Menu)
Exits Test Menu
SERVICE (Not on Main Menu)
Cancels Selection
VOLUME UP/Tunes Button
Move Up
VOLUME DOWN/View Button
Move Down
Start Buttons
Selects Highlighted Option
Stop Motion Button
Return to Previous Screen
When in the Pricing Menu, an on-screen message acknowledges changes or when you exit a selection
without making a change.
