USER MANUAL
PORTABLE SPEAKER SYSTEM
WITH BLUETOOTH
X-707

1
X-707
Operation Manual
Technical support: www.real-el.com
ENG
Congratulations on your purchase of the REAL-EL speaker system!
COPYRIGHT
© 2022. ENEL GROUP OU.
This Manual and information contained in are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
1. BUYER RECOMMENDATIONS
ϜUnpack the device carefully. Make sure there are no accessories left in the box. Check up the
GHYLFH IRU GDPDJH LI WKH SURGXFW ZDV GDPDJHG GXULQJ WUDQVSRUWDWLRQ DGGUHVV WKH ԛUP ZKLFK
carried out the delivery; if the product functions incorrectly, address the dealer at once.
ϜCheck up the package contents and availability of the warranty card.
ϜDo not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
ϜBefore installing and using the speaker system, read this Manual carefully and keep it for future
reference.
2. PACKAGE CONTENTS
ϜPortable speaker system with Bluetooth — 1 pc
Ϝ3.5 mm mini-jack to 3.5 mm mini-jack signal cable — 1 pc
ϜUSB to Micro USB power cable — 1 pc
ϜUser manual — 1 pc
ϜWarranty card — 1 pc
1
1
2
2
3
4
CONTENTS
1. BUYER RECOMMENDATIONS .............................................................
2. PACKAGE CONTENTS ......................................................................
3. SAFETY PRECAUTIONS ....................................................................
4. TECHNICAL DESCRIPTION .................................................................
5. CONNECTION AND OPERATION .........................................................
6. TECHNICAL SPECIFICATIONS ...........................................................

2
X-707
Operation Manual
Technical support: www.real-el.com
ENG
3. SAFETY PRECAUTIONS
ϜDo not open the portable speaker system (PSS) and do not perform repairs by yourself. Service
DQGUHSDLUVVKRXOGEHSHUIRUPHGRQO\E\TXDOLԛHGVSHFLDOLVWVDWDXWKRUL]HGVHUYLFHFHQWHUV7KHOLVW
RIDXWKRUL]HGVHUYLFHFHQWHUVLVon www.real-el.com
ϜMake sure that foreign objects do not get inside the holes of the PSS.
ϜProtect the PSS from high humidity, water and dust.
ϜProtect the PSS from heating: do not place it closer than 1 m from a heat source. Do not expose it
to direct sunlight.
ϜDo not use any chemical agents for cleaning. Clean it with dry soft cloth only.
ϜIn case of PSS does not work properly. Please contact place of purchase or service center.
4. TECHNICAL DESCRIPTION
Control panel
"Micro SD card slot
#Indicator
$Charging DC 5V
%AUX: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
&Next track (short press in Player and Bluetooth mode);
V+ : Volume increase button (long press)
'Power ON/OFF.
(Play/Pause button (in Player mode);
TWS: Connect an additional speaker (Bluetooth mode only,
long press)
)Mode: Switching modes button Bluetooth/USB/
Micro SD/AUX
*Previous track (short press in Player and Bluetooth mode);
V- : Volume decrease button (long press)
+USB port
"
+
*
)
%
&
'
(
# $
Special features
ϜBluetooth A2DP secure simple pairing
ϜTWS function. Connect two speakers together
ϜUSB / Micro SD card / AUX input

3
X-707
Operation Manual
Technical support: www.real-el.com
ENG
SD
TF
CARD
POWER
BANK
230 V
5. CONNECTION AND OPERATION
Charging the battery
ϜBefore operation, fully recharge the battery. The charger is not included. Charge this device with a
DC 5V universal charger with output current 2 ƴ
Ϝ Insert the charging cable into the charger connector, connect the other end to the charger, the
charging indicator will be activated.
It is not recommended to leave the device for a long time connected to the charger after it is fully
charged.
Do not charge the speaker at low ambient temperatures. The minimum charge temperature is at
least 10 ° C.
Bluetooth mode
Ϝ Turn the unit into Bluetooth mode with the Mode)button repeatedly. After 2-3 seconds the
device will go into search mode.
Ϝ Select a Bluetooth device search mode on the audio source (mobile phone, tablet, etc.). The
display will show the name "REAL-EL X-707" which need to establish a connection. After a
successful connection, the loudspeaker will sound a signal.

4
X-707
Operation Manual
Technical support: www.real-el.com
ENG
Parameter
Output power (RMS)
Frequency range
Dimension of the speaker drivers
6XSSRUWHG%OXHWRRWK3URԛOHV
Connection types
Power supply
Battery
Bluetooth operation distance
Case material
Dimensions of the product
Weight
Value
8 W
+]
Ø 76 mm
V5.0 + BR + EDR + BLE / A2DP
USB /micro SD /Aux /Bluetooth
86%9'&ƴ
Lithium-ion 1500 mAh, DC 3.7 V
up to 10 m
ABS plastic
287 x 112 x 127 mm
1.25 kg
6. SPECIFICATION
Notes:
Ϝ 7HFKQLFDO VSHFLѷFDWLRQV JLYHQ LQ WKLV WDEOH DUH VXSSOHPHQWDO LQIRUPDWLRQ DQG FDQQRW JLYH
occasion to claims.
Ϝ7HFKQLFDOVSHFLѷFDWLRQVDQGSDFNDJHFRQWHQWVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFHGXHWRWKH
improvement of REAL-EL production.
Playback mode
Ϝ ,QVHUW D 6' FDUG RU 86% ԜDVK GULYH LQWR WKH FRUUHVSRQGLQJ VORW WKH DXGLR WUDFN ZLOO EH SOD\HG
DXWRPDWLFDOO\ ,Q WKH SOD\EDFN PRGH EULHԜ\ SUHVV WKH  RUEXWWRQ WR VHOHFW WKH GHVLUHG
tracks.
ϜPress the " " button to play or pause.
Note: During Bluetooth playback mode, if you insert a SD card or USB, Bluetooth will be turned off
and USB or SD card will play. Press the "Mode)" button to return to Bluetooth mode again.
AUX mode
ϜFor compatible music devices, use an audio cable with the 3.5 mm mini jack supplied in the box.
Connect the cable to the audio input of the AUX and to any audio source with a 3.5 mm mini jackthe
screen will display LINE automatically. Or you can choose this by Mode button.
Note: You must turn off the power button "OFF / ON." If the system is not used for a long time.
TWS Bluetooth connection
ϜTurn on two identical REAL-EL X-707 systems and activate Bluetooth mode.
Ϝ On one system, press and hold the TWS (play / pause) button, then the unit will switch to TWS
mode and beep once. If the two systems are successfully connected, three short beeps will sound.
ϜConnect a Bluetooth audio source to listen.
ϜTo exit TWS mode, press and hold the TWS (play / pause) button.
Note:
This model has the ability to play the AUX input in TWS mode. To do this, you need to connect the
audio source to a system with TWS enabled using the AUX input without a Bluetooth connection.

Manufacturer: ENEL GROUP OU, Harju maakond, Rae vald, Jüri alevik, Aruküla tee 55a, 75301, Estonia.
® Registered Trademark of ENEL GROUP OU. Estonia.
