RealFlame 8720 User manual

Model # 8720
LOT#
PO#
Mantel Assembly Instructions
English • Français • Español
Tracey Entertainment Fireplace

Parts List - Liste de Pièces - Lista de Piezas
1
2 3
11
12
13
4
5
6
7
8
9
10
14
14
15
16
17
18 19
20
20 20
20
21
21
Nu./Nú. Description/DescripciónNoir/ blanc en détresse/
Blanco Apenado Cdt./
Cantidad
Negro
Box 1/ Boîte 1/ Caja 1
Box 3/ Boîte 3/ Caja 3
1 Center Base Panel 87200101 87200901 1
2 Left Base Panel 87200102 87200902 1
3 Right Base Panel 87200103 87200903 1
10 Upper Firebox Tri 87200110 87200910 1
11 Center Top Panel 87200111 87200911 1
12 Left Top Panel 87200112 87200912 1
13 Right Top Panel 87200113 87200913 1
15 Center Shelf Panel 87200115 87200915 1
16 Upper Door 87200116 87200916 1
17 Upper Back Panel 87200117 87200917 1
20 Shelf Panel 87200120 87200920 4
4 Left Outside Panel 87200104 87200904 1
5 Right Outside Panel 87200105 87200905 1
6 Left Inside Panel 87200106 87200906 1
7 Right Inside Panel 87200107 87200907 1
8 Left Front Panel 87200108 87200908 1
No. Description Black Distressed White Qty
Reborde Decorativo Superior del Hogar
Panneau supérieur/Panel central de la base
Panneau de base gauche/Panel de Base Izquierda
Panneau de base droit/Panel de Base Derecho
Tablette du centre/Panel de estante central
Moulure supérieure du foyer/
Panneau supérieur central/Panel Central Superior
Panneau supérieur gauche/Panel Superior Izquierdo
Panneau supérieur droit/Panel Superior Derecho
Porte supérieure/Puerta superior
Panneau supérieur arrière/Panel posterior superior
Tablette/Panel de Estante
Panneau avant gauche/Panel Delantero Izquierdo
Panneau extérieur gauche/Panel Exterior Izquierdo
Panneau extérieur droit/Panel Exterior Derecho
Panneau intérieur gauche/Panel interior izquierdo
Panneau intérieur droit/Panel delantero derecho
2

Vis pour butoir de porte/
Tornillo del tope de la puerta
Vis Allen Longue/ Tornillo Allen Largo
4x
38x1x
4x38x
A B C
D E
3 in 1 Bolt
Boulon 3 en 1/ 3 in 1 Bolt
Excenter Fitting
Écrou de blocage décentré/
Excenter Fitting
Long Allen Screw
Vis pour panneau arrière/
Tornillo del panel posterior
Back Panel Screw
Washer
Rondelle/ Arandela
Allen Wrench
Clé Allen/ Llave Allen
16x
3x3x
3x3x
3x
30x
G H
F
I
L
J K
Shelf Panel Support
Support à tablette/
Soporte del panel de estante
Door Stopper
Butoir de porte/
Tope de la puerta
Door Stopper Screw
Vis pour butoir de porte/
Charnière de la porte supérieure
Upper Door Hinge
Handle
Poignée/ Manejar
Handle Screw
Vis de Poignée/ Maneje el Tornillo
H1 H2
Parts List - Liste de Pièces - Lista de Piezas
30x
Nu./Nú. Description/DescripciónNoir/ blanc en détresse/
Blanco Apenado Cdt./
Cantidad
Negro
No. Description Black Distressed White Qty
9 Right Front Panel 87200109 87200909 1
14 Front Panel Decor 87200114 87200914 4
18 Left Door 87200118 87200918 1
19 Right Door 87200119 87200919 1
21 Side Back Panel 87200121 87200921 2
22 Hardware Kit 87200022 87200922 1
Box 3/ Boîte 3/ Caja 3
Panneau avant droit/Panel Delantero Derecho
Panneau central décoratif/
Porte de gauche/Puerta izquierda
Porte de droite/Puerta derecha
Decoración del panel delantero
Panneau latéral arrière/Panel posterior lateral
Ensemble de quincaillerie/Kit de hardware
3
87200022 – Black
87200922 – Distressed White
Hardware Kit-
87200022 – Noir
87200922 –
Quincaillerie-
87200022 – Negro
87200922 – Blanco Apenado
Kit de Hardware-
Blanc en Détresse

1
2
1
2
3
C D
C
D
1
2
3
A
11
1
7
18
19
I
H1
I
H1
I
H2
I
L
I
4
2
1
4x4x
C D
21 3x
I
3x
L
3x
H2
4x
A
H1
x
H2
!
L
I

3
4
18
19
1
J
K
J
K
J
K
7
8
9
14
14
C
D
D
C
5
1
2
4
3
3x3x
K
J
12x12
C D
x
D
C

5
6
1 2
3
4
5
7 8 9
10
B
C
D
C
D
18
4 19
6
1
2
6
5
6x6x
C D
4x
B
A
5

7
8
15
13
12
5 4
7
C
D C
D
20
20
20
20
4
5
7
G
G
1
2
8
7
12x12x
C D
16x
G
7

9
10
17
21
21
F
11
7
15
1
C
D
I
L
1
2
9
10
30x
F
4x4x
C D
9x
I
8
17

9
Installing the 5099 Electric Firebox
Installation Foyer Électrique 5099/ Instalación del Hogar Eléctrico 5099
Step One
Figure 1
From the rear of the mantel insert the firebox into the
opening.
Note: Your mantel may vary slightly from the one depicted
in this illustration.
Par l’arrière du manteau de cheminée, insérer la chambre
de combustion dans l’ouverture.
Note: Votre manteau de la cheminée peut varier
légèrement de celui représenté sur cette illustration.
Inserte el hogar desde la parte posterior del marco para el
hogar.
Nota: Su marco para hogar puede variar levemente del
que se ve en las ilustraciones.
Figure 1
Figure 2
Step Two
Figure 2
Attach the firebox to the back of the mantel with the 2
support plates and 4 wood screws.
Fixer la chambre de combustion au dos du manteau
de cheminée avec les deux plaques de support et les 4
vis à bois fournies avec l’ensemble.
Sujete el hogar a la parte posterior del marco con las
dos placas de soporte y los cuatro tornillos para
madera.
11

Customer Service: 1-800-654-1704 in USA
Service à la clientèle: 1-800-363-6443 in Canada
custserv@realflame.com
Warranty & Return Policies
Real Flame®
7800 Northwestern Ave.
Racine, WI 53406
Warranty
Real Flame® Company warrants Real Flame ventless fireplaces and accessories to be free from
defects in parts and workmanship under normal use and service for a period of 90 days from the
date of purchase. In the event of such defects Real Flame will, at its option, replace the defective
product or refund the purchase price. The foregoing is the exclusive remedy and Real Flame
disclaims all other warranties, including any implied warranty of merchantability or fitness for a
particular purpose. In addition, Real Flame will not be responsible for consequential damages in
excess of the purchase price of the product on which such liability is based. Electric fireplaces carry
a one-year warranty on the electric firebox only.
Return Policy
You may return your purchase within 90 days of receipt. No refunds will be issued for incomplete
or unauthorized returns. All returned products must be 100% complete, adequately packaged in
original packaging and in resalable condition. Products that have been assembled or modified will
not be eligible for return. All items must be returned in their entirety, meaning all items included
must be returned together. No returns or exchanges on discontinued items. Please begin the return
process by contacting the store or company where you bought your Real Flame item.
Replacement Parts
In the event that an item has been lost or damaged, either by the manufacturer or in shipping, you
may request a replacement. Replacement parts are not available for all units and only given at Real
Flame’s discretion. We will assess any damage and find a solution, which could include shipping
you a replacement. No replacements are available for discontinued items or repackaged (open
box) products. Please call Real Flame Customer Service at 800-654-1704 for replacement parts
before returning the damaged item. Please have the following information
(which can be found in your instruction manual) ready before you call Customer Service.
• Model Number of Item
• 4-8 digit Part Number
• Lot Code Number
• Shipping Address
• A picture of the damaged item may be requested. Pictures should be
sent to custserv@realflame.com
Incorrect Order Received
If you received something other than what you ordered, please contact Real Flame Customer
Service at 800-654-1704 within 48 hours of receiving the item.
Please refer to www.Realflame.com for our complete return guidelines and policies.
RF General Warranty_061913
10
