Rear view safety RVS-920619 User manual

1

Table of Contents
Introduction...................................................................................................3
Safety Information ..................................................................................4-6
Before Beginning Installation...................................................................7
Installation Guide.........................................................................................8
Wiring Camera & Monitor...................................................................9-10
Replacement Installation Diagram........................................................11
Clip-On Installation Diagram .................................................................12
Installing The Monitor..............................................................................13
Monitor Operation ................................................................................... 14
Splitting & Splicing ...................................................................................15
Positioning ...................................................................................................16
Multiplexer ..................................................................................................17
Monitor Dimensions..................................................................................18
Monitor Specifications.............................................................................19
Troubleshooting..........................................................................................20
Warranty.......................................................................................................21
Disclaimer ....................................................................................................22

3
Introduction
Congratulations on purchasing a Rear View Backup Camera
System! With this manual you will be able to properly install and
operate the unit.
The Backup Camera System is intended to be installed as a
supplement aid to your standard rear view mirror that already ex-
ists in your vehicle. The Backup Camera System should not be
used as a substitute for the standard rear view mirror or for any
other mirror that exists in your vehicle.
In some jurisdictions, it is unlawful for a person to drive a
motor vehicle equipped with a TV viewer or screen located
forward of the back of the driver’s seat or in any location that is
visible, directly or indirectly, to the driver while operating the
vehicle.
Please read all of the installation instructions
carefully before installing the product. Improper
installation will void manufacturer’s warranty.

REAR VIEW SAFETY
4
Safety Information
Please read the entire manual and follow the instructions and
warnings carefully. Failure to do so can cause serious damage
and/or injury, including loss of life. Be sure to obey all applica-
ble local traffic and motor vehicle regulations as it pertains to
this product. Improper installation will void manufacturer’s
warranty.
USAGE
•The Rear View Camera System
is designed to help the driver
safely detect people and/or
objects helping to avoid
damage or injury. owever,
you the driver, must use it
properly. Use of this system is
not a substitute for safe,
proper or legal driving.
•Never back up while looking
at the monitor alone. You
should always check behind
and around the vehicle when
backing up, in the same way
as you would if the vehicle
did not have the Rear View
Camera System. If you back
up while looking only at the
monitor, you may cause
damage or injury. Always
back up slowly.
•The Rear View Camera Sys-
tem is not intended for use
during exstensive back-up
maneuvers or backing into
cross traffic or pedestrian
walkways.
•Please, always remember,
the area displayed by the
Rear View Camera System is
limited. It does not display
the entire panorama that is
behind you.

5
Reverse Wi h Confidence™
Safety Information
INSTALLATION
•Electric shock or product
malfunction may occur if
this product is installed
incorrectly.
•Use this product within
the voltage range specified.
Failure to do so can cause
electronic shock or product
malfunction.
•Take special care when
cleaning the monitor.
•Make sure to firmly affix the
product before use.
•If smoke or a burning smell
is detected, disconnect the
system immediately.
•Where the power cable may
touch a metal case, cover the
cable with a friction tape. A
short circuit or disconnected
wire may cause a fire.
• While installing the RVS
System be careful with the
wire positioning in order to
avoid wire damage.
•The RVS System should only
be used when the
vehicle is in reverse.
•Do not watch movies or
operate the monitor while
driving; as it may cause an
accident.
•Do not install the monitor
where it may obstruct drivers
view or obstruct an air bag
device.
•Dropping the unit may cause
possible mechanical failure.

REAR VIEW SAFETY
6
Safety Information
IN NO EVENT S ALL SELLER OR MANUFACTURER BE
LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF
ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM
ANY DEFECTIVE PRODUCT OR T E USE OF ANY PRODUCT.
If you have questions about this product, contact:
Customer Service:
Rear View Safety
1797 Atlantic Avenue
Brooklyn, NY 11233
Tel: [phone]

7
Reverse Wi h Confidence™
Before You Begin Installation
Before drilling please check that no cable or wiring is on the
other side of the wall. Please clamp all wires securely to reduce
the possibility of them being damaged while vehicle is in use.
Keep all cables away from hot or moving parts and electrical
noisy components.
We recommend doing a benchmark test before installation
to insure that all components are working properly.
Step 1: Choose the monitor and camera locations.
Step 2: Install all cables in vehicle, when necessary a 0.8 (20mm)
hole should be drilled for passing camera cable through vehicles
walls. Install split grommets where applicable.
Step 3: Once all cables and wiring have been properly routed,
perform a system function test by temporarily connecting the
system. If the system seems to not be operating properly see
troubleshooting (page 20).

REAR VIEW SAFETY
8
Cable
1. Be sure to position the cable properly. The aviation camera
cable uses aircraft grade connectors which means the camera
cable can be exposed to all weather elements. Do not run the
cable over sharp edges, do not kink the cable and keep away
from OT and rotating parts.
2. Fasten all cables and secure all excess cable.
Replacement Monitor
1. The Mirror Monitor replaces the existing rear view mirror in
vehicle.
2. Replace existing mirror, and adjust mounting angle to allow
optimum driver viewing comfort. (see figure 1.1 on page 11).
Clip-On Monitor
1. The Mirror Monitor attaches to the existing rear view mirror in
vehicle with the pressurized clips on the back of the monitor.
2. Attach monitor to existing miror, and adjust mounting angle to
allow optimum driver viewing comfort. (see figure 1.1 on page
12).
Installation Guide

9
Reverse Wi h Confidence™
Wiring Camera & Monitor
The multiplexer.
•To power the system connect
the power (RED) 12V+ wire to
ignition power and the ground
(BLACK) wire to chassis ground.
•These are the only wires
needed to power the entire
system and all the cameras.
Each camera can be seen at
any time by simply pressing
the power button and using
the V1/2 button to toggle.
•The three positive trigger wires
(BLUE-C 1, W ITE-C 2,
YELLOW-C 3) each represent
one channel and will turn on
their channel when the trigger
wire is energized with 12V.
•"Camera 3" is the designated
backup channel. To have the
the backup camera come on
when you go into reverse, con-
nect the BLUE wire to reverse
power (or any power source
that comes on only in reverse).
•The other channels can simi-
larly be triggered (i.e. side cam-
eras can be triggered by the turn
signals etc.)
•To automatically have camera
and monitor turn ON when vehi-
cle activates, simply twist BLUE
positive trigger 12V+ to Red
Power line 12V+ and wire to ig-
nition power.
Note: This setup will disable
the menu in channel 3. To
access the menu simply move
to channel 1 or 2 and all the
changes will apply to channel
3.
Note: When the blue wire is
active it will have precedence
over the other triggers.
Therefore, if you wish to use
multiple triggers, do not
attach the blue trigger to
constant power.

REAR VIEW SAFETY
10
Wiring Camera & Monitor
•Audio: There is audio on
channels 2 and 3. On channel 3
the blue trigger wire must be
energized (12V) to activate the
audio. On channel 2 the audio
is always on.
•Grid-lines: The grid-lines are
also carried through the blue
wire. To use the grid-lines for
reversing, connect the blue
wire to a reverse power.
•There is a built-in voltage
regulator for our systems which
can handle 12-24 volts. Real
consumption is 10 to 30 Volts.
Note: The camera and
monitor can always be
activated by manually
pushing the power button on
monitor. This is in addition to
utilizing the positive triggers.
Note: If connecting power
directly to battery, the camera
is always ON and therefore can
drain battery. Therefore it is
recommended to connect
power to an ignition switched
accessory power source.

11
Reverse Wi h Confidence™
Replacement Installation Diagram
Figure 1.1 Figure 1.2
Figure 1.3
Replacement Monitor

REAR VIEW SAFETY
12
Clip-On Installation Diagram
Figure 1.1 Figure 1.2
Figure 1.3
Clip-On Monitor

13
Reverse Wi h Confidence™
Installing the Monitor
1
2
3
4
5
66ft Extension Cable
Monitor
1. DC12V-24V (red)
2. Ground (black)
3. Port #3 (blue)
4. Port #2 (white)
5. Port #1 (yellow)
-3 Amp Fuse
ptional
Camera
Available
Video ut
Multiplexer

REAR VIEW SAFETY
14
Monitor Operation
UP
MENU
DOWN
V1/V2
ON/OFF
• Use "BRIG TNESS" "CONSTRAST" "SATURATION" “S ARPNESS" to
adjust the image properties.
• Day/Night Mode: Mode 1 will turn on the Back-lit buttons. Mode 2
will turn on the auto-dim feature on the monitor.
• Name: Change the name of each individual channel.
• Trigger source: Change the channel destination for each trigger.
• Trigger delay: Adjust the delay time on each trigger.
• Distance Grid: Choose what channel the distance grid will display on.
• Grid Position: Move the grid-lines.
• Reset: Reset all settings to factory default.

15
Reverse Wi h Confidence™
Splicing
1. Red - Power (+)
2. Yellow - Video
3. Green - Mirror / Normal Imaging
4. White - Audio
5. Black - Ground (-)
1.
2.
3.
4.
5.

REAR VIEW SAFETY
16
Positioning
General Installation Location

17
Reverse Wi h Confidence™
Multiplexer
Port #1 Port #2 Port #3
or DVD Backup

REAR VIEW SAFETY
18
Monitor Dimensions
Clip-On Monitor
Replacement Monitor

19
Reverse Wi h Confidence™
Monitor Specifications
TFT LCD Digital Monitor
Screen Size Digital 7”
Dot Resolution 800 x 3 (RGB) x 480V
Display Format 16:9
Display Brightness 400cd/m2
Viewing Angle 90° min
Video Input 3 channel
Video Source 1Vp-p, 75Ω
Power Supply DC 12V-24V (+/-10%)
Power Consumption 5W
Operating Temperature -10°C - +65° C
Video System Auto NTSC/PAL
Overall Dimensions 9”Lx 4.5” x 1”D
Weight 400G
Impact Rating 5G
Dot Pitch 0.192 x 0.1805V
Sync System Internal

REAR VIEW SAFETY
20
Troubleshooting
Monitor Displays Blue Screen & Displays No Signal
•Do a hard reset, unplug all
cables and power cables from
multiplexer (silver box) leave
out for 1 minute and then
re-connect them.
•Check to ensure that the con-
nection to the camera is tight.
•Verify camera cable is plugged
into port labeled Backup Camera
• Verify that the blue positive
trigger on power harness is
put to power 12v+.
If the problem still persists, ver-
ify that alternate ports work. If
alternate ports do not work, re-
move Blue Trigger wire from
12V+ and select alternate chan-
nels.
Monitor Will Not Power-Up (no backlight on power button)
•Check fuse
•Check 12v+ to monitor
•Check ground connection
No Image On Screen
•Verify camera is in correct
camera input
•Verify cable is connected to
monitor
•Verify camera is connected to
cable
•Connect known working
camera and cable to monitor.
•Verify Blue trigger is receiving
power
Audio on Camera (optional)
•Verify chosen camera has audio
•Verify volume setting
•Confirm that the Blue audio
trigger is connected to 12v+
