Reebok RBTL16921 User manual

Model No. RBTL16921
Serial No.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this man-
ual for future reference.
Write the serial number in the space
above for future reference.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.– 6 p.m. MST
USER'S MANUAL
®
Patent Pending
Visit our website at
www.reebokhomefitness.com
new products, prizes,
fitness tips, and much more!
®
®

2
®
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
HOW TO USE THE CHEST PULSE SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
TREADMILL OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
REEBOK UNIVERSITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
HOW TO ORDER REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Note: An EXPLODED DRAWING is attached in the center of this manual.
REEBOK and the Vector Logo are registered trademarks and service marks of Reebok. This product is
manufactured and distributed under license from Reebok International.

3
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the treadmill.
1. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
2. Use the treadmill only as described in this
manual.
3. Place the treadmill on a level surface, with at
least eight feet of clearance behind it and two
feet on each side. Do not place the treadmill
on any surface that blocks air openings. To
protect the floor or carpet from damage, place
a mat under the treadmill.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Do not operate the treadmill where aerosol
products are used or oxygen is administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should not be used by persons
weighing more than 300 pounds. Never allow
more than one person on the treadmill at a time.
8. Wear appropriate exercise clothes when
using the treadmill. Do not wear loose clothes
that could become caught in the treadmill.
Athletic support clothes are recommended
for both men and women. Always wear ath-
letic shoes. Never use the treadmill with bare
feet, wearing only stockings, or in sandals.
9. When connecting the power cord (see page 9),
plug the power cord into a surge suppressor
(not included) and plug the surge suppressor
into a grounded circuit capable of carrying 15
or more amps. No other appliance should be on
the same circuit. Do not use an extension cord.
10. Use only a single-outlet surge suppressor that
meets all of the specifications described on
page 9. To purchase a surge suppressor, see
your local REEBOK dealer or call 1-800-806-
3651 and order part number 146148.
11. Failure to use a properly functioning surge
suppressor could result in damage to the con-
trol system of the treadmill. If the control sys-
tem is damaged, the walking belt may change
speed or stop unexpectedly, which may result
in a fall and serious injury.
12. Keep the power cord and the surge suppres-
sor away from heated surfaces.
13. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See
BEFORE YOU BEGIN on page 5 if the tread-
mill is not working properly.)
14. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
15. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
16. The pulse sensors are not medical devices.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensors are intended
only as exercise aids in determining heart
rate trends in general.
17. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord, and move the on/off circuit
breaker to the off position when the treadmill
is not in use. (See the drawing on page 5 for
the location of the on/off circuit breaker.)
18. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 24.)
You must be able to safely lift 45 pounds (20
kg) to raise, lower, or move the treadmill.
19. When folding or moving the treadmill, make
sure that the storage latch is fully closed.
IMPORTANT PRECAUTIONS

20. When using iFIT.com CDs and videos, an
electronic “chirping” sound will alert you
when the speed and/or incline of the treadmill
is about to change. Always listen for the
“chirp” and be prepared for speed and/or in-
cline changes. In some instances, the speed
and/or incline may change before the per-
sonal trainer describes the change.
21. When using iFIT.com CDs and videos, you can
manually override the speed and incline set-
tings at any time by pressing the speed and in-
cline buttons. However, when the next “chirp”
is heard, the speed and/or incline will change
to the next settings of the CD or video program.
22. Always remove iFIT.com CDs and videos from
your CD player or VCR when you are not
using them.
23. Inspect and properly tighten all parts of the
treadmill every three months.
24. Never drop or insert any object into any open-
ing.
25. DANGER: Always unplug the power
cord immediately after use, before cleaning
the treadmill, and before performing the main-
tenance and adjustment procedures de-
scribed in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized service
representative only.
26. The treadmill is intended for in-home use
only. Do not use the treadmill in any
commercial, rental, or institutional setting.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS
4
KEEP HANDS
AND FEET
AWAY FROM
THIS AREA
WHILE THE
TREADMILL IS
IN OPERATION.
The decals shown below have been placed on your treadmill. If a decal is missing,
or if it is not legible, please call our Customer Service Department, toll-free, to
order a free replacement decal (see ORDERING REPLACEMENT PARTS on page
31). Apply the decal in the location shown. Note: The decals are not shown at ac-
tual size.

5
Thank you for selecting the new REEBOK®RX 7200
treadmill. The RX 7200 treadmill combines advanced
technology with innovative design to help you get the
most from your exercise program in the convenience of
your home. And when you’re not exercising, the unique
RX 7200 can be folded up, requiring less than half the
floor space of other treadmills.
For your benefit, read this manual carefully before
using the treadmill. If you have questions after read-
ing this manual, please call our Customer Service
Department toll-free at 1-800-999-3756, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time (ex-
cluding holidays). To help us assist you, please note
the product model number and serial number before
calling. The model number of the treadmill is
RBTL16921. The serial number can be found on a
decal attached to the treadmill (see the front cover of
this manual for the location).
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEGIN
Handrail
Console
Book Holder
Water Bottle Holder*
*No water bottle is included
Key/Clip
On/Off Circuit
Breaker
Walking Belt
Foot Rail
Adjustable Cushioned
Walking Platform
(see page 23)
Power Cord
BACK
RIGHT SIDE
Rear Roller
Adjustment Bolts
Fan
Handgrip Pulse Sensor

6
ASSEMBLY
Assembly requires two people. Place the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until the treadmill is assembled.
Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a
small amount of lubricant may be transferred to the top of the walking belt, the sides of the walking platform, or
the shipping carton. This does not affect treadmill performance. If there is lubricant on top of the walking belt or
on the sides of the walking platform, wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires your own phillips screwdriver , rubber mallet , wire
cutters , and adjustable wrench .
1. For help identifying small parts, refer to the PART
IDENTIFICATION CHART on page 7.
Cut the plastic ties (not shown) from the sides of the
treadmill. With the help of a second person, carefully
raise the Uprights (65) until the Wheels (not shown) are
resting on the floor.
Hold the Book Plate (114) against the back of the
Console Base (117) and the Upright (65) as shown.
Attach the Book Plate with four 3/4” Screws (101).
114
101
65
117 101
1
2. Insert one of the Handrail Extensions (76) into the square
post on the left Upright (65). Make sure that the notch in
the Handrail Extension is in the position shown. Align
the small holes in the Handrail Extension with the holes in
the post. If necessary, use a rubber mallet to fully insert the
Handrail Extension. Attach the Handrail Extension with four
Screws (40).
Identify the Left Foam Grip (62), which has a hole in the
right side. Slide the Left Foam Grip as far as possible onto
the Handrail Extension (76) and the post. (Note: It may be
helpful to apply soapy water to the Handrail Extension.)
Press two Plastic Fasteners (75) into the bottom of the Left
Foam Grip and the Handrail Extension. Note: It may be
helpful to tap on the Plastic Fasteners with a rubber mallet.
Attach the other Handrail Extension (not shown) and the
Right Foam Grip (not shown) to the post on the right
Upright (65) in the same way. Note: There is not a hole in
the side of the Right Foam Grip.
Press a Cup Holder (128) into the Book Plate (114). Press
the other Cup Holder (not shown) into the other side of the
Book Plate.
40
Notch
Hole
40
Post
65
128
114
76
62
75
2

4. Raise the treadmill to the storage position (see HOW TO
FOLD THE TREADMILL FOR STORAGE on page 24).
Have a second person hold the treadmill in the upright posi-
tion. Position the U-base (20) against the base of the
Uprights (65) as shown, with the Bumpers (98) under the
U-base. Finger tighten two 2” Bolts (26) with Base
Washers (129) into the base of the Uprights and the U-
base. Then, attach the U-base with two 3” Bolts (23), two
Base Washers (129), and two Nuts (13). Tip the treadmill
forward if necessary. Tighten the two 2” Bolts.
5. Make sure that all parts are properly tightened before
you use the treadmill. Place a mat beneath the tread-
mill to protect the floor. For your benefit, familiarize your-
self with the information on pages 25 and 26.
13
23
20
98
98
65
4
13
26
55
69
5
70
3
72
68 62
10
Hole
3. (Note: The parts shown in this step may be preassembled
but may need to be adjusted.) With the help of a second
person, raise the Frame (55) and hold it. Insert the Left
Frame Guide (68) into the left side of the Frame. Remove
the Latch Knob (67) from the Latch Pin (72). Make sure
that the Latch Pin Collar (70) and the Spring (69) are on
the Latch Pin. Insert the Latch Pin into the Frame and the
Left Frame Guide. Press the Latch Insert (5) onto the
Frame, with the Latch Pin in the center hole. Tighten the
Latch Knob onto the Latch Pin.
Align the Latch Pin (72) with the hole in the Left Foam
Grip (62) by sliding the Left Frame Guide (68) up or down.
Make sure that the Latch Pin can be inserted fully into the
hole. Hold the Left Frame Guide in place and tighten two
1/2” Screws (10) into the Latch Insert and the Left Frame
Guide. Note: It may be necessary to pull the Latch Knob
(67) to access and tighten the Screws.
67
129
23
7
PART IDENTIFICATION CHART
Use the chart below to identify small parts needed for assembly.
Nut (13)–2
3/4” Screw (101)–4
Base Washer (129)–4
Screw (40)–8
Plastic Fastener
(75)–4
2” Bolt (26)–2
3” Bolt (23)–2
26
129

8
HOW TO PUT ON THE CHEST PULSE SENSOR
The chest pulse sensor consists of two components:
the chest strap and the sensor unit (see the drawing
below). Insert the tab on one end of the chest strap into
one end of the sensor unit, as shown in the inset draw-
ing. Press the end of the sensor unit under the buckle
on the chest strap. The tab should be flush with the
front of the sensor unit.
Next, wrap the
chest pulse sen-
sor around your
chest and attach
the other end of
the chest strap to
the sensor unit.
Adjust the length
of the chest strap,
if necessary. The
chest pulse sen-
sor should be under your clothes, tight against your
skin, and as high under the pectoral muscles or
breasts as is comfortable. Make sure that the logo on
the sensor unit is facing forward and is right-side-up.
Pull the sensor unit away from your body a few inches
and locate the two electrode areas on the inner side
(the electrode areas are covered by shallow ridges).
Using saline solution such as saliva or contact lens so-
lution, wet both electrode areas. Return the sensor unit
to a position against your chest.
CHEST PULSE SENSOR CARE AND MAINTENANCE
• Thoroughly dry the chest pulse sensor after each
use. The chest pulse sensor is activated when the
electrode areas are wetted and the heart rate
monitor is put on; the chest pulse sensor shuts off
when it is removed and the electrode areas are
dried. If the chest pulse sensor is not dried after
each use, it may remain activated longer than nec-
essary, draining the battery prematurely.
• Store the chest pulse sensor in a warm, dry place.
Do not store the chest pulse sensor in a plastic bag
or other container that may trap moisture.
• Do not expose the chest pulse sensor to direct
sunlight for extended periods of time; do not expose
it to temperatures above 122° Fahrenheit (50°
Celsius) or below 14° Fahrenheit (-10° Celsius).
• Do not excessively bend or stretch the sensor unit
when using or storing the chest pulse sensor.
• Clean the sensor unit using a damp cloth—never
use alcohol, abrasives, or chemicals. The chest
strap may be hand washed and air dried.
CHEST PULSE SENSOR TROUBLESHOOTING
The instructions on the following pages explain
how the chest pulse sensor is used with the con-
sole. If the chest pulse sensor does not function
properly, try the steps below.
• Make sure that you are wearing the chest pulse sen-
sor as described at the left. Note: If the chest pulse
sensor does not function when positioned as de-
scribed, move it slightly lower or higher on your chest.
• Use saline solution such as saliva or contact lens
solution to wet the two electrode areas on the
sensor unit. If heart rate readings do not appear until
you begin perspiring, re-wet the electrode areas.
• As you walk or run on the treadmill, position your-
self near the center of the walking belt. For the
console to display heart rate readings, the user
must be within arm’s length of the console.
•The chest pulse sensor is designed to work with
people who have normal heart rhythms. Heart rate
reading problems may be caused by medical
conditions such as premature ventricular contrac-
tions (pvcs), tachycardia bursts, and arrhythmia.
•The operation of the chest pulse sensor can be
affected by magnetic interference caused by high
power lines or other sources. If it is suspected that
this is a problem, try relocating the treadmill.
• The CR2032 battery may need to be replaced (see
page 26).
Chest Strap
Tabs
Sensor Unit
Tab
Sensor
Unit Buckle
HOW TO USE THE CHEST PULSE SENSOR

9
THE PERFORMANT LUBETM WALKING BELT
Your treadmill features a walking belt coated with
PERFORMANT LUBETM, a high-performance lubricant.
IMPORTANT: Never apply silicone spray or other
substances to the walking belt or the walking plat-
form. Such substances will deteriorate the walking
belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
Your treadmill, like any other type of sophisticated
electronic equipment, can be seriously damaged by
sudden voltage changes in your home’s power.
Voltage surges, spikes, and noise interference can
result from weather conditions or from other appliances
being turned on or off. To decrease the possibility of
your treadmill being damaged, always use a surge
suppressor with your treadmill (see drawing 1 at
the right). To purchase a surge suppressor, see
your local REEBOK dealer or call 1-800-806-3651
and order part number 146148.
Use only a single-outlet surge suppressor that is
UL 1449 listed as a transient voltage surge sup-
pressor (TVSS). The surge suppressor must have a
UL suppressed voltage rating of 400 volts or less
and a minimum surge dissipation of 450 joules.
The surge suppressor must be electrically rated
for 120 volts AC and 15 amps. There must be a
monitoring light on the surge suppressor to indi-
cate whether it is functioning properly. Failure to
use a properly functioning surge suppressor could
result in damage to the control system of the
treadmill. If the control system is damaged, the
walking belt may change speed or stop unexpect-
edly, which may result in a fall and serious injury.
This product must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of elec-
tric shock. This product is equipped with a cord having
an equipment-grounding conductor and a grounding
plug. Plug the power cord into a surge suppressor,
and plug the surge suppressor into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Important: The treadmill is not compatible with
GFCI-equipped outlets.
This product is for use on a nominal 120-volt circuit,
and has a grounding plug that looks like the plug illus-
trated in drawing 1 below. A temporary adapter that
looks like the adapter illustrated in drawing 2 may be
used to connect the surge suppressor to a 2-pole
receptacle as shown in drawing 2 if a properly
grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet (drawing 1) can be installed
by a qualified electrician.
The green-colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used it must be held in place
by a metal screw. Some 2-pole receptacle outlet box
covers are not grounded. Contact a qualified elec-
trician to determine if the outlet box cover is
grounded before using an adapter.
DANGER: Improper connection
of the equipment-grounding conductor can
result in an increased risk of electric shock.
Check with a qualified electrician or service-
man if you are in doubt as to whether the
product is properly grounded. Do not modify
the plug provided with the product—if it will
not fit the outlet, have a proper outlet
installed by a qualified electrician.
1
2
Grounded Outlet Box
Grounded Outlet Box
Grounding Plug
Surge Suppressor
Surge Suppressor
Grounding Pin
Adapter
Lug
Metal Screw
Grounded Outlet
Grounding Pin
TREADMILL OPERATION

10
FEATURES OF THE CONSOLE
The treadmill console offers an impressive array of
features designed to make your workouts more
effective.
When the manual mode of the console is selected, the
speed and incline of the treadmill can be changed with
a touch of a button. As you exercise, the console will
display instant exercise feedback. You can even mea-
sure your heart rate using the handgrip pulse sensor or
the chest pulse sensor.
In addition, the console offers six preset workout pro-
grams. Each program automatically controls the speed
and incline of the treadmill as it guides you through an
effective workout. Two pulse programs are also offered.
Each program automatically adjusts the speed and in-
cline of the treadmill to keep your heart rate within a pre-
set range while you exercise.
The console even allows you to create your own work-
out programs and save them in memory for future use.
The console also features new iFIT.com interactive
technology. Having iFIT.com technology is like having a
personal trainer in your home. Using the included audio
cable, you can connect the treadmill to your home
stereo, portable stereo, computer, or VCR and play
special iFIT.com CD and video programs (iFIT.com
CDs and iFIT.com videocassettes are available sepa-
rately). iFIT.com CD and video programs automatically
control the speed and incline of the treadmill as a per-
sonal trainer guides you through every step of your
workout. High-energy music provides added motivation.
To purchase iFIT.com CDs or videocassettes, call
toll-free 1-800-735-0768.
With the treadmill connected to your computer, you
can also go to our Web site at www.iFIT.com and ac-
cess programs directly from the internet. Additional op-
tions are soon to be available. See www.iFIT.com for
more information.
To use the manual mode of the console, follow the
steps beginning on page 11. To use preset programs,
see page 13. To use heart rate programs, see page
14. To create and use custom programs, see pages
16 and 17. To use iFIT.com CD or video programs,
see page 20. To use iFIT.com programs directly
from our Web site, see page 22.
Note: If there is a thin sheet of clear
plastic on the console, remove it.
Clip
Key

11
HOW TO TURN ON THE POWER
Plug in the power cord (see page 9).
Locate the on/off cir-
cuit breaker near the
power cord. Move the
on/off circuit breaker
to the reset position.
Stand on the foot rails of the treadmill. Find the clip
attached to the key (see the drawing on page 10)
and slide the clip onto the waistband of your
clothes. Next, route the cord attached to the clip
under the handgrip pulse sensor, and insert the
key into the console. After a moment, the displays
and various indicators will light. Test the clip by
carefully taking a few steps backward until the
key is pulled from the console. If the key is not
pulled from the console, adjust the position of
the clip.
HOW TO USE THE MANUAL MODE
Insert the key fully into the console.
See HOW TO TURN ON THE POWER above.
Note: Be sure to route the cord attached to the clip
under the handgrip pulse sensor.
Select the manual mode.
When the key is in-
serted, the manual
mode will be selected
and the Manual Control
indicator will light. If a
program has been
selected, press the Program Select button repeat-
edly to reselect the manual mode.
Press the Start button or the Speed
s
s
button to
start the walking belt.
A moment after the but-
ton is pressed, the
walking belt will begin to
move at 1 mph. Hold
the handrails and begin
walking. As you exer-
cise, change the speed of the walking belt as de-
sired by pressing the Speed
t
t
and
s
s
buttons.
Each time a button is pressed, the speed setting
will change by 0.1 mph; if a button is held down,
the speed setting will change in increments of 0.5
mph. To change the speed setting quickly, press
the OneTouch Speed buttons. Note: The console
can display speed and distance in either miles
or kilometers. For simplicity, all instructions in
this section refer to miles.
To stop the walking belt, press the Stop button.
The Time/Segment Time/Pace display will begin
to flash. To restart the walking belt, press the Start
button or the Speed
s
s
button.
Note: The first time the treadmill is used, observe
the alignment of the walking belt, and align the
walking belt if necessary (see page 26).
Change the incline of the treadmill as desired.
To change the incline of
the treadmill, press the
Incline buttons. Each time
a button is pressed, the
incline will change by
0.5%. Note: After the but-
tons are pressed, it may take a moment for the
treadmill to reach the selected incline setting.
Follow your progress with the LED matrix and
the displays.
The LED matrix—When
the manual mode or the
iFIT.com mode is se-
lected, the LED matrix
will show a track repre-
senting 1/4 mile. As you
exercise, the indicators
around the track will light in sequence until you
have completed 1/4 mile. A new lap will then begin.
Time/Segment Time/
Pace display—When the
manual mode or the
iFIT.com mode is se-
lected, this display will
show the elapsed time
and your current pace (pace is measured in min-
utes per mile). The display will change from one
number to the other every few seconds. When a
preset program or a heart rate program is se-
lected, the display will show the time remaining in
the program, the time remaining in the current seg-
ment of the program, and your current pace.
5
4
3
2
1
3
2
1
Reset
Position

12
Pulse/Calories/Fat
Calories display—This
display shows the ap-
proximate numbers of
calories and fat calories
you have burned (see
FAT BURNING on page 29). The display will
change from one number to the other every few
seconds. The display will also show your heart
rate when you use the handgrip pulse sensor (see
step 6 at the right) or the chest pulse sensor (see
page 8).
Distance/Incline/Laps
display—This display
shows the distance that
you have walked, the in-
cline level of the tread-
mill, and the number of
1/4-mile laps you have completed. The display will
change from one number to the next every few
seconds. Note: Each time the incline changes, the
display will show the current incline setting for sev-
eral seconds.
Speed display—This
display shows the speed
of the walking belt.
Note: When the Km/H in-
dicator is lit, the console
will display speed and
distance in kilometers;
when the Km/H indicator
is not lit, the console will
display speed and distance in miles. To change
the unit of measurement, first hold down the Stop
button while inserting the key into the console. An
“E” for English miles or an “M” for metric kilometers
will appear in the Speed display. Press the Speed
s
s
button to change the unit of measurement.
When the desired unit of measurement is selected,
remove the key and then reinsert it.
To reset the displays, press the Stop button, re-
move the key, and then reinsert the key.
Measure your heart rate if desired.
You can measure your heart rate using either the
handgrip pulse sensor (see the instructions below)
or the chest pulse sensor (see page 8).
To use the
handgrip pulse
sensor, first
make sure that
your hands are
clean. Next,
stand on the
foot rails and
place your
hands on the metal contacts on the handgrip
pulse sensor. Your palms should be resting on the
upper contacts and your fingertips should be
touching the lower contacts. Avoid moving your
hands. When your pulse is detected, two dashes
(– –) will appear in the Pulse/Calories/Fat Calories
display, and then your heart rate will be shown.
For the most accurate heart rate reading, con-
tinue to hold the contacts for about 15 sec-
onds.
Turn on the fans if desired.
To use the fans, press the Low or High button. To
turn off the fans, press the Off button. Note: Any
time that the walking belt is stopped for a few min-
utes, the fans will automatically turn off.
When you are finished exercising, remove the
key from the console.
Step onto the foot rails, press the Stop button, and
adjust the incline of the treadmill to the lowest
setting. The incline must be at the lowest setting
when the treadmill is folded to the storage posi-
tion or the treadmill will be damaged. Next, re-
move the key from the console and put it in a se-
cure place. Note: If the displays and various indi-
cators on the console remain lit after the key is
removed, the console is in the “demo” mode.
See page 23 and turn off the demo mode.
When you are finished using the treadmill, move
the on/off circuit breaker near the power cord to
the off position and unplug the power cord.
8
7
6
Sensors

13
HOW TO USE PRESET WORKOUT PROGRAMS
Insert the key fully into the console.
See HOW TO TURN ON THE POWER on page
11.
Select one of the preset workout programs.
When the key is in-
serted, the manual
mode will be selected.
To select a preset
workout program, press
the Program Select but-
ton repeatedly until one
of the Walk, Jog, or Run indicators lights.
When a preset workout program is selected, the
Distance/Incline/Laps display will flash the maxi-
mum incline setting for the program, and the
Speed display will flash the maximum speed set-
ting, for six seconds. The Time/Segment Time/
Pace display will show how long the program will
last.
The LED matrix will
show the first seven
speed settings for the
program. The profiles
on the right side of the
LED matrix show how
the speed and incline
of the treadmill will change during the programs.
Press the Start button or the Speed
s
s
button to
start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings of the program. Hold the handrails
and begin walking.
Each program is divided into several time seg-
ments of different lengths. (The Time/Segment
Time/Pace display will show both the time remain-
ing in the program and the time remaining in the
current segment of the program.) One speed set-
ting and one incline setting are programmed for
each segment. (The same speed and/or incline
setting may be programmed for consecutive seg-
ments.)
The speed setting for
the first segment is
shown in the flashing
Current Segment col-
umn of the LED matrix.
(The incline settings are
not shown in the matrix.)
The speed settings for
the next seven
segments are shown in the seven columns to the
right.
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash and a
series of tones will sound. In addition, if the speed
and/or incline of the treadmill is about to change,
the Speed display and/or the Distance/Incline/
Laps display will flash to alert you. When the first
segment is completed, all speed settings will move
one column to the left. The speed setting for the
second segment will then be shown in the flashing
Current Segment column and the treadmill will au-
tomatically adjust to the speed and incline settings
for the second segment. Note: If all of the indica-
tors in the Current Segment column are lit after the
speed settings have moved to the left, the speed
settings will move downward so that only the high-
est indicators appear in the LED matrix. If some of
the indicators in the Current Segment column are
not lit when the speed settings move to the left
again, the speed settings will move back up.
The program will continue in this way until the
speed setting for the last segment is shown in the
Current Segment column and the Time/Segment
Time/Pace display counts down to zero. The
walking belt will then slow to a stop.
If the speed or incline setting is too high or too low
during the program, you can manually override
the setting by pressing the Speed or Incline but-
tons. Every few times a Speed button is pressed,
an additional indicator will light or darken in the
Current Segment column. (If any of the columns
to the right of the Current Segment column have
the same number of lit indicators as the Current
Segment column, an additional indicator may light
or darken in those columns as well.) Note: If you
manually override the speed or incline setting,
when the next segment begins, the treadmill
will automatically adjust to the speed and in-
cline settings for the next segment.
3
2
1
Current Segment

14
To stop the program temporarily, press the Stop
button. The Time/Segment Time/Pace display will
begin to flash. To restart the program, press the
Start button or the Speed
s
s
button. To end the
program, press the Stop button, remove the key,
and then reinsert the key.
Follow your progress with the displays.
See step 5 on page 11.
Measure your heart rate if desired.
See step 6 on page 12.
Turn on the fans if desired.
See step 7 on page 12.
When the program is finished, remove the key
from the console.
When the program has ended, make sure that
the incline of the treadmill is at the lowest set-
ting. Next, remove the key from the console and
put it in a safe place.Note: If the displays and
various indicators on the console remain lit
after the key is removed, the console is in the
“demo” mode. Refer to page 23 and turn off the
demo mode.
When you are finished using the treadmill, move
the on/off circuit breaker near the power cord to
the off position and unplug the power cord.
HOW TO USE HEART RATE PROGRAMS
Follow the steps below to use a heart rate program.
Note: You must wear the chest pulse sensor (see
page 8) to use a heart rate program.
Put on the chest pulse sensor.
See HOW TO PUT ON THE CHEST PULSE
SENSOR page 8.
Insert the key fully into the console.
See HOW TO TURN ON THE POWER on page
11.
Select a heart rate program.
When the key is in-
serted, the manual
mode will be selected.
To select a heart rate
program, press the
Program Select button
repeatedly until one of the heart rate program indi-
cators lights.
The two profiles on the left side of the LED matrix
show how the target heart rate will change during
the programs. During heart rate program 1, your
heart rate will reach approximately 85% of your
estimated maximum heart rate; during heart rate
program 2, your heart rate will reach approxi-
mately 80% of your estimated maximum heart
rate. Note: Your estimated maximum heart rate is
determined by subtracting your age from 220. For
example, if you are 30 years old, your estimated
maximum heart rate is 190 beats per minute
(220 – 30 = 190).
3
2
1
7
6
5
4
CAUTION: If you have heart prob-
lems, or if you are over 60 years of age and
have been inactive, do not use the heart rate
programs. If you are taking medication regu-
larly, consult your physician to find whether the
medication will affect your exercise heart rate.

15
During heart rate pro-
grams, the LED matrix
will show a graphic that
represents your heart
rate. Each time a heart-
beat is detected, an ad-
ditional peak will ap-
pear.
Enter your age and a maximum speed setting.
When a heart rate pro-
gram is selected, the
word “AGE” and the
current age setting will
flash in the Pulse/
Calories/Fat Calories
display. If you have already entered your age,
simply press the Enter button. If you have not en-
tered your age, press the
s
s
and
t
t
buttons beside
the Enter button to enter your age. Then, press
the Enter button.
After you have entered
your age, the letters
“SPd” and the maxi-
mum speed setting for
the program will flash in
the Pulse/Calories/Fat
Calories display. If desired, press the
s
s
and
t
t
but-
tons beside the Enter button to adjust the maxi-
mum speed setting. When the desired setting is
shown, press the Enter button.
Press the Start button or the Speed
s
s
button to
start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings for the program. Hold the handrails
and begin walking.
Each heart rate program is divided into several time
segments of different lengths. (The Time/Segment
Time/Pace display will show both the time remain-
ing in the program and the time remaining in the
current segment of the program.) One target heart
rate setting is programmed for each segment.
During each segment, the console will regularly
compare your heart rate to the current target heart
rate setting. If your heart rate is too far below or
above the target heart rate setting, the speed of
the treadmill will automatically increase or de-
crease to bring your heart rate closer to the target
heart rate setting. If the speed reaches the maxi-
mum speed setting for the program (see step 4 at
the left) and your heart rate is still too far below
the current target heart rate setting, the incline of
the treadmill will also increase to bring your heart
rate closer to the target heart rate setting.
During the last three seconds of each segment, a
series of tones will sound and the Distance/
Incline/Laps display and the Speed display will
flash.
The program will continue until no time remains in
the program. The walking belt will then slow to a
stop.
If the speed or incline setting is too high or too low
during the program, you can adjust the setting
with the Speed or Incline buttons. However, each
time the console compares your heart rate to the
current target heart rate setting, the speed and/or
incline of the treadmill may automatically change
to bring your heart rate closer to the target heart
rate setting.
If your pulse is not detected during the program,
the letters “PLS” will flash in the Pulse/Calories/
Fat Calories display and the speed and incline of
the treadmill may automatically decrease until
your pulse is detected. If this occurs, refer to the
instructions on page 8.
To stop the program at any time, press the Stop
button. Heart rate programs should not be stopped
temporarily and then restarted. To use a heart rate
program again, reselect the program and start it at
the beginning.
Follow your progress with the displays.
See step 5 on page 11.
Turn on the fans if desired.
See step 7 on page 12.
When the program is finished, remove the key
from the console.
See step 7 on page 14.
8
7
6
5
4

16
HOW TO CREATE CUSTOM PROGRAMS
Insert the key fully into the console.
See HOW TO TURN ON THE POWER on page
11.
Select one of the custom programs.
When the key is in-
serted, the manual
mode will automatically
be selected. To select a
custom program, first
press the Program
Select button repeatedly until one of the custom
program indicators lights.
Note: If the custom program has not yet been
defined, only three columns of indicators will
be lit in the LED matrix. If more than three
columns of indicators are lit, see HOW TO USE
CUSTOM PROGRAMS on page 17.
Press the Start button or the Speed
s
s
button
and program the desired speed and incline
settings.
A moment after the button is pressed, the walking
belt will begin to move. Hold the handrails and
begin walking.
Refer to the LED matrix. Each custom program is
divided into one-minute segments. One speed
setting and one incline
setting can be pro-
grammed for each seg-
ment. The speed set-
ting for the first seg-
ment will be shown in
the flashing Current
Segment column of the
LED matrix. (The in-
cline settings are not shown in the matrix.) To pro-
gram a speed setting and an incline setting for the
first segment, simply adjust the speed and incline
of the treadmill as desired by pressing the Speed
and Incline buttons. Every few times a Speed but-
ton is pressed, an additional indicator will light or
darken in the Current Segment column.
When the first segment of the program is com-
pleted, a series of tones will sound and the current
speed setting and the current incline setting will
be saved in memory. The three columns of indica-
tors will then move one column to the left, and the
speed setting for the second segment will be
shown in the flashing Current Segment column.
Program a speed setting and an incline setting for
the second segment as described above.
Continue programming speed and incline settings
for as many segments as desired; custom pro-
grams can have up to forty segments. When you
are finished with your workout, press the Stop but-
ton twice. The speed and incline settings that you
programmed and the number of segments that you
programmed will then be saved in memory.
When the program has ended, remove the key.
See step 7 on page 14.
4
3
2
1
Current Segment

17
HOW TO USE CUSTOM PROGRAMS
Insert the key fully into the console.
See HOW TO TURN ON THE POWER on page
11.
Select one of the custom programs.
When the key is in-
serted, the manual
mode will automatically
be selected. To select a
custom program, first
press the Program
Select button repeatedly until one of the custom
program indicators lights.
When a custom program is selected, the
Distance/Incline/Laps display will flash the maxi-
mum incline setting for the program, and the
Speed display will flash the maximum speed set-
ting, for six seconds. The Time/Segment Time/
Pace display will show how long the program will
last.
The LED matrix will
show the first seven
speed settings for the
program. Note: If only
three columns of indi-
cators are lit in the
matrix, see HOW TO
CREATE A CUSTOM PROGRAM on page 16.
Press the Start button or the Speed
s
s
button to
start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings for the program. Hold the handrails
and begin walking.
Each custom program is divided into several one-
minute segments. One speed setting and one in-
cline setting are programmed for each segment.
(The same speed and/or incline setting may be
programmed for con-
secutive segments.)
The speed setting for
the first segment is
shown in the flashing
Current Segment col-
umn of the LED matrix.
(The incline settings
are not shown in the
matrix.)
The speed settings for the next seven segments
are shown in the seven columns to the right.
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash, a se-
ries of tones will sound, and the Speed display
and/or the Distance/Incline/Laps display will flash.
When the first segment is completed, all speed
settings will move one column to the left. The
speed setting for the second segment will then be
shown in the flashing Current Segment column
and the treadmill will automatically adjust to the
second speed and incline settings that you pro-
grammed previously.
The program will continue in this way until the
speed setting for the last segment is shown in the
Current Segment column and the last segment
ends. The walking belt will then slow to a stop.
If desired, you can redefine to the program while
using it. To change the speed or incline setting
during the current segment, simply press the
Speed or Incline buttons. When the current segment
is completed, the new setting will be saved in mem-
ory. To increase the length of the program, first
wait until the program is completed. Then, press the
Start button and program speed and incline settings
for as many additional segments as desired.When
you have added as many segments as desired,
press the Stop button twice. To decrease the
length of the program, press the Stop button twice
at any time before the program is completed.
To stop the program temporarily, press the Stop
button. The Time/Segment Time/Pace display will
begin to flash. To restart the program, press the
Start button or the Speed
s
s
button. To end the
program, press the Stop button, remove the key,
and then reinsert the key.
Follow your progress with the displays.
See step 5 on page 11.
Measure your heart rate if desired.
See step 6 on page 12.
Turn on the fans if desired.
See step 7 on page 12.
When the program has ended, remove the key.
See step 7 on page 14.
7
6
5
4
3
2
1
Current Segment

18
HOW TO CONNECT THE TREADMILL TO
YOUR CD PLAYER, VCR, OR COMPUTER
To use iFIT.com CDs, the treadmill must be con-
nected to your portable CD player, portable stereo,
home stereo, or computer with CD player. See pages
18 and 19 for connecting instructions. To use iFIT.com
videocassettes, the treadmill must be connected to
your VCR. See page 20 for connecting instructions. To
use iFIT.com programs directly from our Web site,
the treadmill must be connected to your home com-
puter. See page 19 for connecting instructions.
HOW TO CONNECT YOUR PORTABLE CD PLAYER
Note: If your CD player has separate LINE OUT and
PHONES jacks, see instruction A below. If your CD
player has only one jack, see instruction B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your CD player. Plug your headphones into the
PHONES jack.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3.5mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your CD player. Plug your
headphones into the other side of the Y-adapter.
HOW TO CONNECT YOUR PORTABLE STEREO
Note: If your stereo has an RCA-type AUDIO OUT
jack, see instruction A below. If your stereo has a
3.5mm LINE OUT jack, see instruction B. If your
stereo has only a PHONES jack, see instruction C.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter. Plug
the adapter into an AUDIO OUT jack on your stereo.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your stereo.
C. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3.5mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your stereo. Plug your
headphones into the other side of the Y-adapter.
A
LINE OUT
PHONES LINE OUT
PHONES
B
PHONES
PHONES
Audio
Cable
Head-
phones
A
A
C
PHONES
LINE OUT
B
AUDIO OUT
RIGHT
LEFT
Audio
Cable
Adapter
A
A
C
PHONES
LINE OUT
B
AUDIO OUT
RIGHT
LEFT
Audio
Cable
B
A
C
PHONES
LINE OUT
B
AUDIO OUT
RIGHT
LEFT
Audio
Cable
C
A
LINE OUT
PHONES LINE OUT
PHONES
B
PHONES
PHONES
Audio
Cable
3.5mm
Y-adapter
Headphones
B
3.5mm
Y-adapter
Headphones

19
HOW TO CONNECT YOUR HOME STEREO
Note: If your stereo has an unused LINE OUT jack,
see instruction A below. If the LINE OUT jack is
being used, see instruction B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into the LINE OUT jack on your
stereo.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into an RCA Y-adapter (available
at electronics stores). Next, remove the wire that is
currently plugged into the LINE OUT jack on your
stereo and plug the wire into the unused side of the
Y-adapter. Plug the Y-adapter into the LINE OUT
jack on your stereo.
HOW TO CONNECT YOUR COMPUTER
Note: If your computer has a 3.5mm LINE OUT jack,
see instruction A. If your computer has only a
PHONES jack, see instruction B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your computer.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3.5mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your computer. Plug your
headphones or speakers into the other side of the
Y-adapter.
B
A
LINE OUT
CD
VCR
Amp
LINE OUT
CD
VCR
Amp
LINE OUT
Audio
Cable
Adapter
A
A
PHONES
LINE OUT
B
Audio
Cable
A
B
A
LINE OUT
CD
VCR
Amp
LINE OUT
CD
VCR
Amp
LINE OUT
Audio
Cable
RCA Y-adapter
Wire removed from
LINE OUT jack
B
Adapter
A
PHONES
LINE OUT
B
Audio
Cable
B
3.5mm
Y-adapter
Headphones/Speakers

20
HOW TO CONNECT YOUR VCR
Note: If your VCR has an unused AUDIO OUT jack,
see instruction A below. If the AUDIO OUT jack is
being used, see instruction B. If you have a TV
with a built-in VCR, see instruction B. If your VCR
is connected to your home stereo, see HOW TO
CONNECT YOUR HOME STEREO on page 19.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into the AUDIO OUT jack on your
VCR.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into an RCA Y-adapter (available
at electronics stores). Next, remove the wire that is
currently plugged into the AUDIO OUT jack on your
VCR and plug the wire into the unused side of the
Y-adapter. Plug the Y-adapter into the AUDIO OUT
jack on your VCR.
HOW TO USE IFIT.COM CD AND VIDEO
PROGRAMS
To use iFIT.com CDs or videocassettes, the treadmill
must be connected to your portable CD player, portable
stereo, home stereo, computer with CD player, or
VCR. See HOW TO CONNECT THE TREADMILL TO
YOUR CD PLAYER, VCR, OR COMPUTER on page
18. Note: To purchase iFIT.com CDs or iFIT.com
videocassettes, call toll-free 1-800-735-0768.
Follow the steps below to use an iFIT.com CD or video
program.
Insert the key into the console.
See HOW TO TURN ON THE POWER on page 11.
Select the iFIT.com mode.
When the key is in-
serted, the manual
mode will be selected.
To use iFIT.com CDs or
videocassettes, press
the Program Select but-
ton repeatedly until the iFIT.com indicator lights.
Insert the iFIT.com CD or videocassette.
If you are using an iFIT.com CD, insert the CD into
your CD player. If you are using an iFIT.com video-
cassette, insert the videocassette into your VCR.
Press the PLAY button on your CD player or
VCR.
A moment after the button is pressed, your per-
sonal trainer will begin guiding you through your
workout. Simply follow your personal trainer’s
instructions. Note: If the Time/Segment Time/Pace
display is flashing, press the Start button or the
Speed
s
s
button on the console. The treadmill will
not respond to a CD or video program when the
Time/Segment Time/Pace display is flashing.
During the CD or video program, an electronic
“chirping” sound will alert you when the speed
and/or incline of the treadmill is about to change.
CAUTION: Always listen for the “chirp” and be
prepared for speed and/or incline changes. In
some instances, the speed and/or incline may
change before the personal trainer describes
the change.
4
3
2
1
B
A
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
C
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
Audio
Cable
Adapter
A
B
A
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
C
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
Audio
Cable Adapter
B
Wire removed from
AUDIO OUT jack
RCA Y-adapter
