RGBlink DXP D0808 User manual

DXP D0808 Quick Start
VIEWSIZE THE WORLD
Support any in any out
Support independent output switching
Support hot backup
Support infrared remote control
Can read and store up to 24/36 user
scenarios
Automatically recognize the formats
Support EDID management

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
1
CONTENT
Product Introduction...............................................................................................................................2
Packing Configuration............................................................................................................................3
Hardware Orientation..............................................................................................................................4
Front Panel.........................................................................................................................................4
Back Panel .........................................................................................................................................5
Operating Instruction..............................................................................................................................6
Content...............................................................................................................................................6
How to Switch between Input and Output Channel....................................................................7
How to Switch One Input to all Outputs......................................................................................7
How to Read Device Status........................................................................................................8
How to Set LOGO Display when Power on................................................................................8
How to Set the EDID...................................................................................................................8
How to Set the Language...........................................................................................................9
How to Realize Cascade Setting................................................................................................9
How to Set the Machine Address................................................................................................9
How to Realize SignalAuto Take..............................................................................................10
How to Lock the Front Panel ....................................................................................................10
How to Realize Hot Backup......................................................................................................10
How to Save the Preset Input and Output Channel .................................................................11
How to Load the Saved Input and Output Channel..................................................................11
How to Reset the Factory Settings...........................................................................................11
Contact Information...............................................................................................................................12

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
2
Product Introduction
RGBlink strong technical strength determines
the high quality of AVDXP series matrix
switchers. We choose the chips with best
performance, elaborate design for every way
of switchers, to ensure the high quality of
switchers. After rigorous testing,
3G/HD/SD-SDI video signal, optical signal
transmission rate are 2.97Gbps, DVI switchers
signal bandwidth is 2.5 GHz, support HD
digital signal input. VGA switching signal
bandwidth is 450 MHz (-3 db), support
resolution of 2048×1536@60Hz and 1024×
768@120Hz, composite video bandwidth for
100 M (-3 db), fully meet various strict
requirements and high quality occasions.
Products in this series are widely used in large
screen projection display engineering,
electronic teaching, command and control
center, multimedia meetings room, etc.
Switches in this series are equipped with
monochromatic LCD, RS-232 communication
interface, RS422 communication interface
(optional), with outage protect function, can
read and store up to 100 user scenarios, and
special matching control software, can in
conjunction with computer, remote control
system or all kinds of distal control equipment
(such as center console system). The system
is equipped with multiple sets of serial
instructions, compatible with mainstream
matrix of serial instruction set.
System Connection
RGBlink offers solutions to
demanding technical problems.
Any application questions, or
required further information,
please contact with our
customer Support Engineers.
DXP D0808 System Connection Diagram

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
3
Packing Configuration
Note: Chinese Standard,American Standard or European Standard power cord is option.
The color of the screw driver is randomly when packing.
Power Cord
9-pin Serial
Cable
USB Disk
DVI 转HDMI 线
Antistatic Bag
防静电袋
Screw Driver
Certification

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
4
Hardware Orientation
Front Panel
Button Instruction
1~8
Selection button for input and
output channel, and number
choice of save or call saving
modes
LOAD
Load button
MENU
Menu and up arrow button
LED
indicator
Power indicator
NEXT
Down arrow button
Mode indicator
TAKE
Confirm button
Com indicator
ALL
Distributor selection button
IR receiver
Receive the infrared signal
SAVE
Save button
LCD Panel
Show operation menu items

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
5
Back Panel
Input Interface
1
DVI Input DVI-D port
Other Interface
3
RS 232 IN serial communication
interface
4
RS 232 OUT serial communication
interface
5
Switch
6
Power IEC-3 port
Output Interface
2
DVI Output DVI-D port

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
6
Operating Instruction
Content
How to Switch between Input and Output Channel
How to Switch One Input to all Outputs
How to Read Device Status
How to Set LOGO Display when Power on
How to Set the EDID
How to Set the Language
How to Realize Cascade Setting
How to Set the Machine Address
How to Realize SignalAuto Take
How to Lock the Front Panel
How to Realize Hot Backup
How to Save the Preset Input and Output Channel
How to Load the Saved Input and Output Channel
How to Reset the Factory Settings

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
7
How to Switch between Input and Output Channel
User can switch the signals between input and output channel by front panel buttons of
DXP D0808, specific operations are as follows:
1. If choose “AUTO TAKE ON”, push any button on output area on the front panel, for example,
choose [5] as the output channel.
Then push any button on Input area on the front panel, for example, choose [3] as the input
channel, the signal of output channel 5 will be switched to the signal of input 3.
2. If choose “AUTO TAKE OFF”, push any button on output area on the front panel, for
example, choose [5] as the output channel.
Then push any button on input area on the front panel, for example, choose [3] as the input
Channel.After setting, push the [TAKE] button to confirm.
Note: Input channel: The signal that will be switched to output channel.
Output channel: The signal that connected to display device.
The number [1]~[8] means channel 1~8.
How to Switch One Input to all Outputs
1. If choose “AUTO TAKE ON”, push the [ALL] button on the front panel.
Then push any button on input area on the front panel, for example, choose [3] as the input
channel, all the signal of output channel will be switched to the signal of input 3.
2. If choose “AUTO TAKE OFF”, push the [ALL] button on the front panel.
Then push any button on Input area in the front panel, for example, choose [3] as the input channel.
Push the [TAKE] button to confirm, all the signal of output channel will be switched to the signal
of input 3.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
8
How to Read Device Status
1. Push the [MENU] button on the front panel, and enter to the menu items.
2. System default [STATUS] option, if it is not selected, push the [MENU] up arrow button or
[NEXT] down arrow button, and choose [STATUS].
3. Push the [TAKE] button to confirm, user can view the current device status. The first four
screen show each output to the corresponding input channel. The fifth screen shows the
software version, the sixth screen shows the serial number and the seventh screen shows
the machine address.
How to Set LOGO Display when Power on
1. Push the [MENU] button on the front panel, and enter to the menu items.
2. Push the [MENU] up arrow button or [NEXT] down arrow button, and choose [LOGO].
3. Push the [TAKE] button to confirm, and enter to LOGO setting, push the [NEXT] button
to choose “ON” or “OFF”, then push the [TAKE] button to confirm.
How to Set the EDID
1. Push the [MENU] button on the front panel, and enter to the menu items.
2. Push the [MENU] up arrow button or [NEXT] down arrow button, and choose [EDID].
3. Push the [TAKE] button to confirm.
4. Push any button on output area on the front panel, for example, choose [3] as the output channel.
5. Push any button on input area on the front panel, for example, choose [5] as the input channel.
6. Push the [TAKE] to confirm, and the EDID copy finish.
Note: When set the EDID, the output interface must be connected to monitors.

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
Tel: [phone] Fax: [phone]
Email: [email protected] http://www.rgblink.cn
9
How to Set the Language
1. Push the [MENU] button on the front panel, and enter to the menu items.
2. Push the [MENU] up arrow button or [NEXT] down arrow button, and choose [LANGUAGE].
3. Push the [TAKE] button to confirm, and enter to the language setting.
4. Push the [NEXT] button to choose the language, for example, choose “ENGLISH”, then
push the [TAKE] button to confirm.
How to Realize Cascade Setting
1. Push the [MENU] button on the front panel, and enter to the menu items.
2. Push the [MENU] up arrow button or [NEXT] down arrow button, and choose [CASCADE].
3. Push the [TAKE] button to confirm, and enter to the cascade setting. Push the [NEXT]
button to choose “ON” or “OFF”, then push the [TAKE] button to confirm.
How to Set the Machine Address
1. Push the [MENU] button on the front panel, and enter to the menu items.
2. Push the [MENU] up arrow button or [NEXT] down arrow button, and choose [MAC ADDR].
3. Push the [TAKE] button to confirm. Push any one of button [1]~[8] on output area to set the
machine address. Push the [TAKE] button to confirm after setting.
