RH QUENTIN PENDANT User manual

QUENTIN SMALL OUTDOOR PENDANT OR FLUSHMOUNT
PARTS ENCLOSED: PENDANT ASSEMBLY
FLUSHMOUNT ASSEMBLY
(A) Wire Nuts (2)
(B) Mounting Plate (1)
(C) Mounting Plate Screws (2)
(D) Canopy (1)
(E) Canopy Screws (2)
(F) Quick Link (1)
(G) Chain (1)
(H) Lantern Loop (1)
(I) Extension Arms (4)
(J) Lantern Canopy (1)
(K) Shade Glass (4)
(L) Exterior Shade Hooks (4)
(M) Exterior Shade Screws (4)
(N) Interior Shade Screws (3)
(O) Interior Shade (1)
(P) Square Loop (4)
(M)(M)
(N) (N)
(O)
"J BOX"
(G)
(D) (C)
(B)
(E)
(F)
PENDANT ASSEMBLY
(A)
(H)
(P)
(J) (I)
(K)
(L)
"J BOX"
(A)
FLUSH MOUNT ASSEMBLY
(C)
(B)
(E)
(M)
(M)
(N) (N)
(O)
(P)
(J)
(I)
(K)
(L)

Wipe clean with a soft, dry cloth or static duster. Always avoid the use
of harsh chemicals or abrasive cleaners as they may cause damage to
the fixture’s finish.
IMPORTANT PLEASE READ
WE RECOMMEND INSTALLATION BY A
LICENSED ELECTRICIAN.
SAFETY INSTRUCTIONS:
ASSEMBLY & INSTALLATION:
CARE INSTRUCTIONS:
WARNINGS:
These instructions are provided for your safety. It is very important
that they are read completely before beginning the installation of your
fixture.
This fixture has been rated for up to one (1) 60-watt maximum Type
A medium base bulb or one (1) 7.5-watt LED medium base bulb. To
avoid risk of fire, do not exceed the recommended wattage.
If any special control devices are used with this fixture, follow the
instructions carefully to assure full compliance with N.E.C.
requirements. If there are any questions, contact a qualified electrical
contractor.
2
TOOLS REQUIRED: CHAIN BREAK
PENDANT ASSEMBLY:
1. SHUT OFF ELECTRICAL SUPPLY FROM THE MAIN FUSE BOX/
CIRCUIT BREAKER.
2. Remove all parts from carton. Do not throw away any parts.
3. Remove canopy screws (E) from canopy (D). Remove mounting
plate (B) from canopy (D).
4. Guide wires from “J BOX” through center hole in mounting plate
(B). Affix mounting plate (B) to “J BOX” using mounting screws (C)
provided.
5. Measure desired drop for fixture to hang and add/remove chain
links (G) accordingly. Chain break tool required (not included).
6. Attach quick link (F) to bottom link of chain (G). Lift fixture and
attach loop (H) to quick link (F). Close opening in quick link (F) to
secure fixture. Guide wiring through chain links (G) and center hole
in canopy (D).
7. Make proper electrical connection. Attach ground fixture wire
(GREEN) to either the ground screw on mounting plate (B) or to the
ground wire in the wall outlet box (usually GREEN or COPPER in
color). If attaching to ground wire in outlet box, fasten together
with a plastic wire nut (A) and tightly wrap with electrical tape. IT IS
IMPERATIVE THAT THE OUTLET BOX IN YOUR HOME BE
PROPERLY GROUNDED.
8. Connect the neutral (WHITE or RIBBED BLACK) fixture wire to the
neutral (usually WHITE) wire from the outlet box. Fasten wires
together with a plastic wire nut (A) and tightly wrap connector with
electrical tape.
9. Connect the hot (BLACK or SMOOTH BLACK) fixture wire to the hot
(BLACK) wire from the outlet box. Fasten wires together with a
plastic wire nut (A) and tightly wrap connector with electrical tape.
10. Align screw holes in canopy (D) with holes in mounting plate (B).
Holding canopy over mounting plate (B), thread canopy screw (E)
into canopy (D) and mounting plate (B) to secure fixture to “J BOX.”
11. Hook extension arm (I) onto exterior shade hook (L). Guide hook end
of extension arm (I) into square loop (P). Repeat step for each
extension arm (I).
12. Install one (1) 60-watt maximum Type A medium base bulb or one (1)
7.5-watt LED medium base bulb into socket.
13. Carefully slide shade glass (K) down into slots in exterior shade
frame.
14. Align holes in exterior shade frame with holes in tabs on lantern
canopy (J) and insert exterior shade frame screws (M) to secure
shade to fixture.
15. Insert interior shade (O) into exterior shade. Align interior shade
screws (N) with channels in lantern canopy (J). Turn until interior
shade screws are resting securely in channels of lantern canopy (J).
FLUSHMOUNT ASSEMBLY:
1. Remove parts shown in box of Pendant Assembly illustration.
2. Follow steps 7 through 13 above for flushmount assembly.
QUENTIN SMALL OUTDOOR PENDANT OR FLUSHMOUNT
All wires are connected. When unpacking, be careful not to pull wires
as a bad connection may result. Do not connect electricity until your
fixture is fully assembled. To reduce the risk of fire, electrical shock
or personal injury, always turn off fixture and allow it to cool prior to
replacing the lightbulb. Do not touch bulb when fixture is turned on
or look directly at lit bulb. Keep flammable materials away from the lit
bulb.
This lighting fixture contains lead, a chemical known to the State of
California to cause cancer, birth defects and other reproductive harm.
Wash hands after installing, handling, cleaning, or otherwise touching
this light fixture.
WARNING: This product can expose you to lead, which is
known to the State of California to cause cancer and birth defects or
other reproductive harm. For more information, go to
www.P65Warnings.ca.gov.
THIS IS NOT A TOY AND THE PRODUCT HAS
NO PLAY VALUE.
WARNING: STRANGULATION HAZARD
Keep cord at least 3 ft away from cribs, bassinets, and toddler beds.
Keep out of reach of children under 3.
