Rhino Double Vertical Jerry Can Holder with Locking Cable 43151
Important: Please read these instructions carefully prior to installation. Please refer to your tting instruction to ensure that the roof racks
are installed in the correct location. Check the contents of kit before commencing tment and report any discrepancies. Place these
instructions in the vehicle’s glove box after installation is complete.
Recommendations: Maximum Capacity: 45kg/ 99Lbs.
Use only non stretch fastening ropes or straps. Do not overload your Rhino-Rack Pioneer Platform/ Tray or Tradie Tray
and roof bars. Check your vehicle’s roof carrying capacity. Exercise caution when driving off road as vehicle roof height
has been increased. Be aware of increased sensitivity to cross winds.
- Regularly check strap condition for any signs of abrasion. Immediately replace. Do not use a strap that is damaged.
- Only use approved metal or high strength polyethylene jerry cans when transporting fuel.
- Always use the approved colours to identify types of fuel carried.
- Always place fuel behind the driver on the roof or towards the rear of the vehicle.
- Do not overload roof capacity. Always evenly distribute load.
- Remove jerry cans/roof racks when putting vehicle through an automatic car wash.
Caution:
The handling characteristics of the vehicle change when you transport a load on the roof. For safety reasons, we
recommend exercising extreme care when transporting large wind-resisting loads; special consideration must be
taken into account when negotiating corners and under braking.
Note for Dealers and Fitters:
It is your responsibility to ensure instructions are given to the end user or client.
Rhino-Rack
3 Pike Street, Rydalmere,
NSW 2116, Australia. Document No: R478 Fit time: 15min
(Ph) [phone] Prepared By: Kayle Everett Issue No: 01
(Fax) [phone] Authorised By: Chris Murty Issue Date: 01/06/15
These instructions remain the property of RhinoRack Australia Pty. Ltd. and may not be used or changed for any other purpose than intended.
Important Information
Page 1 of 2
CONTROLLED

1
Rhino Double Vertical Jerry Can Holder with Locking Cable 43151
Page 2 of 2
Parts List
1M8 x 16 Hex Bolt 4B019
2M8 Spring Washer 4W019
3M8 X 17 Flat Washer 4W020
4M8 Channel Nut 4N003
5Vertical Jerry Can Holder 1CA1355
6Ratchet Strap 1CA1133
7Locking Cable 1.2m 1 CA1496
8* Pad Lock 1-
9Instructions 1R478
Layout
1.
2.
3.
4.
5.
6.
2
1.
2.
3.
4.
Slide the four channel
nuts into the openings
at the front or rear of
the tray. Push back
into desired position
above one of the trays
crossbars.
3Loop the two parts of the ratchet strap through themselves
to tighten in position on the tray crossbar. Place them on either side of
the Jerry Can Holder.
Loop the Ratchet around the tray
crossbar.
Loop the strap around the
tray crossbar.
When Jerry
Can Holder is
in place, tighten
with a 13mm
wrench.
4Place Jerry Cans into holder. Pull strap through Ratchet and tighten. The
holder can house 2x 10L or 2x 20L Jerry Cans.
Move lever up
and down to
tighten.
5Note: A padlock can be used to
secure the Jerry Cans from theft.
Loop the cable
through a padlock and
secure to the front
of the assembly as
shown.
Tools Required:
13mm Wrench.
*Not Included
8.
7.
Using item 1,2,3 and 4, install four sets of
hardware. Finger tighten.
1.
2.
3.
4.
