Richmond GTR064 User manual

1
Rev 20A
Sliding Gate Opener User Manual
Model: GTR064
WARNING
Instructions must be read before beginning installation. Please follow these instructions carefully, incorrect
installation could affect gate operation. If you require more information, please contact
Richmond Wheel & Castor Co on 1300 474 246
When mounting and positioning the motor ensure that the power cable is unplugged. The motor cover will need to
be removed to mount the motor to the mounting plate. Any changes to the settings of the gate motor can only be
made by a licensed electrician.
Gate in closed position
Gate in open position
Viewed from inside the property
Please Note: This motor runs on AC Power as standard but can also be operated by DC Battery Backup or Solar Power.

2
Rev 20A
Optional Accessories Available:
Additional Remotes (GTR179): Spare/Additional remotes for the automatic gate kit, these will need
to be paired to the motor.
Wireless Keypad (GTR180): Allows secure access through the gate used with a user set code.
Hard Wire Keypad (GTR199): Allows secure access through the gate used with a user set code.
Warning Light (GTR198): Alerts people near the gate and users that the gate is in operation.
Solar Kits Available: Solar panels and more available to get this gate kit running on solar power.
Please contact your nearest authorised dealer for compatible solar panels in your state/region.

3
Rev 20A
Contents:
Gate Opening Default Setting Information…………………………………….………4
General Safety………………………………………………….………………...…….…..5
Parts List…………………………………………………….………………………………6
Technical Specifications………………………………………….………………………7
Motor Installation
Before you start……………………………………………………….………….…8
Tools Required / Example Sliding Gate Setup…………….…….………………9
Step 1 –Gate Preparation……………………………………...…...……………10
Step 2 –Motor Pad Footing.………………………………...………………...…10
Step 3 - Motor Position Installation………….………………..……………….…11
Step 4 –Drilling Holes for Anchor Bolts……………...……………….....……...11
Step 5 –Fitting the Mounting Plate & Motor……………………………..……..12
Step 6 –Gear Rack & Motor Alignment…………………….…………………...13
Step 7 –Limit Travel Stops……………………………………………………….15
Step 8 –Powering the Motor………………………………………………….….17
Step 9 –Testing the Limit Travel Stops………………………….……………...18
Programming and Wiring
Control Board Diagrams…………………………………………….………….…19
Dip Switch Adjustment………………………………………….…………………20
Further Settings and Programming…………………………….……………..…21
Connecting Infrared Photocells……………………………….………………….26
Battery/Solar Connection……..…………………………….…………………….27
Adding optional functions to your gate
Automatic close function ………………………………………………………...22
Connecting Infrared Photocells (sold separately) …………………………….26
Adding a keypad (sold separately)………………………………………..22 & 24
Connecting Battery Backup (sold separately) …………………………….……27
Connecting Solar Power (sold separately) ………………………………….…28
Maintenance……………………………………………………………...………………..29
Troubleshooting…………………………………………………….….…………………30
Clearing and Pairing Remotes……………………………………….…………………31
Additional Drawings and Diagrams………………………………….…………..……32

4
Rev 20A
Gate Opening Default Setting Information:
The gate motor will open the gate to the right-hand side as its default setting (refer to fig 1).
Before Installing: Test the motor by plugging it into a power source and pressing the remote. You will see the motor
cog turn.When it stops, press the remote again to see it turn in the opposite direction. This will give you an understanding
of the way in which the motor will move the gate.
Note: Ensure that the motor is unplugged before proceeding with installation. Please keep fingers away from the
motor cog whilst it is turning.
If your gate needs to open from the other direction (to the left, refer to fig 2) your motor needs to be mounted
on the left-hand side as shown, a licensed electrician will need to switch DIP SWITCH 5 from OFF to ON (refer
to page 22) and swap over the CL & OP lines on the J10 terminal (refer to page 24).
Any works done to the motor must be completed whilst the power is off, and the motor is unplugged
Press the first/top button on the
remote.
The motor cog will turn counter-
clockwise, moving the gate frame.
The gate will then move in the set
direction. Default: right-hand open.
Left-Hand Opening:
Motor mounted on the
left-hand side
Fig 2
Fig 1
Default operation:
Motor mounted on the
right-hand side

5
Rev 20A
Thank you for choosing this sliding gate opener. Please read the manual carefully before assembling and
using it. Do not leave out the manual if you send this product to a third party. This product complies with
the recognised technical standards and safety regulations. Our company has the right to change this
manual without prior notice.
General Safety:
Warning: Incorrect or improper use of this product can cause damage to persons, animals or
properties.
•Please ensure that the input voltage used matches with the supply voltage of gate opener (AC240V
50Hz).
•All modifications to wiring or electrics, and any adjustment or maintenance to 240VAC MUST be done
by a qualified electrician.
•To avoid damaging gas, power or other underground utility lines, contact the relevant authority
BEFORE digging.
•All potential hazards and exposed pinch points of the gate must be eliminated or guarded prior to
installation of this gate motor.
•Never mount any device that operates the gate motor where the user can reach over, under, around or
through the gate to operate the controls. These must be placed at least 1.8m from any moving part of
the moving gate.
•Ensure power plug is disconnected from the power socket during installation or maintenance.
•Keep remote control and other control devices out of children’s reach, in order to avoid unintentional
activation.
•Never allow anyone to hang onto the gate while moving.
•Please ensure a warning sign provided is fitted to the structure.
•To ensure safety, before installing the main motor, mount a Gate End Stop (GTR017) and a Gate Stopper
(GTR017 or GTR018) at each end of the rail to prevent the gate travellingoff the track.
•If required, install infrared photocells (GTR096, sold separately) to detect obstructions and prevent
injury or damage.
•Instruct all users about the control systems provided and the manual opening operation in case of
emergency.
•Ensure that the power cable is connected to a RCD protected weatherproof power outlet installed by a
qualified electrician.
•Do not install the product in an explosive atmosphere or where there is any danger of flooding.
•This product was exclusively designed and manufactured for the use specified in the present
documentation. Any other use not specified in this documentation could damage the product and be
dangerous.
•Only use original parts for any maintenance or repair operation. Richmond Wheel & Castor Co declines
all responsibility with respect to the automation safety and correct operation when other supplier’s
components are used.
•Do not modify the automation components, unless explicitly authorised by Richmond Wheel & Castor
Co.
•The user must avoid any attempt to carry out any works or repairs on the motor, and should always
request the assistance of qualified personnel.
•This motor is suitable for use on one sliding gate only.
•Anything which is not expressly provided for in these instructions is not allowed and will void warranty.
•Dispose of all packing materials (plastic, cardboard, polystyrene etc.) according to current guidelines.
Keep plastic bags and polystyrene out of children’s reach.
Please save these instructions for future use.

6
Rev 20A
Parts List:
No.
Name
Quantity
1
Main motor
1
2
Motor Mounting Plate
1
3
Manual release keys
(These keys are needed
during power outage, keep
on hand)
2
4
Remote controls
(factory paired to motor)
2
5
Gate Warning Signage
(must be fitted to gate)
1
6
In the accessories box you
will find the items below:
1
6a
Magnetic limit travel stops
and mounting brackets
(one for opening, and one
for closing)
1 small bracket
(A) and 1 large
bracket (B),
and 2 magnets
6b
Limit switch mounting plate
screws M6X18
4
6c
M12 x 100mm masonry
anchor bolts
(Drill bit size: M12
masonry)
4
6d
Motor mounting set screws
M8 x 50mm, spring & flat
washers
4
B
A

7
Rev 20A
Technical Specifications:
Model
GTR064
Power supply
240V/50Hz
Motor power
170W
Gate moving speed
16-18m/min
Maximum weight of gate
1000 Kg
Remote control distance
Up to 30m
Remote control mode
Single button mode
Limit switch
Magnetic limit switch
Noise
Up to 58dB
Working duty
S2, 20min (20 minutes continuous operation)
IP Rating
IP54
Maximum Remote
Controls to be paired
25
Frequency
433.92 MHz
Working temperature
-20°C ~ +70°C
Package weight
12.5Kg

8
Rev 20A
Motor Installation:
Before you start
•The GTR064 Sliding Gate Automatic kit is suitable for powering the opening and
closing motion of gates up to 1000kg in weight, and up to a length of 8m.
•Gate motion is achieved by the rotating cog of the gate motor driving the gear rack fitted to
the moving gate (sold separately).
•The gate motor requires you to press the remote control once to open, and once again to
close. This is a safety feature to ensure safe operation.
•The gate motor itself must be fitted within private property, never externally to a
property’s boundary.
•This premium motor has a range of optional accessories which can be added, such as solar
power, battery backup, infrared photocells, exit wands, and warning light.
Power Supply: The GTR064 requires 1 x 10Amp AC240V 50Hz power supply (RCD Protected
Weatherproof PowerPoint). The GTR064 comes complete with a power lead and plug that is 1m long. If
you do not have a suitable RCD protected weatherproof power point within 1m of the gate motor you will
need to consult a licenced electrician .
Any works done to the motor must be completed whilst the power is off and the motor is
unplugged.
Any modifications/alterations/works to the 240V AC power components must only be
completed by a licensed electrician for your state/country.
Please Note:
Your weatherproof power outlet should be no more than 1m from the electric gate motor.
If your weatherproof power outlet is more than 1m from the gate motor, you will require a
licensed electrician to fit a new power cable.
Any excess cable length should be cable tied and secured out of the way of moving objects.

9
Rev 20A
For Installing Your Gate Motor, You Will Need:
•Power drill
•Tape measure
•Level
•12mm Masonry Drill Bit (for the 4 motor masonry anchor bolts)
•Socket and Spanner Set
•Phillips Head Screwdriver
Example Sliding Gate Setup:
If you require any gate hardware, contact Richmond Wheel & Castor Co or an authorised reseller.
Gate Guide
Rollers
Gate Track and
Track Wheels
Gate
Stopper
Gate End
Catch

10
Rev 20A
Please ensure that the motor power cable is not plugged in at any stage before Step 8
Step 1 - Gate Preparation Before Adding
Your Sliding Gate Motor:
•Ensure that the sliding gate is correctly installed.
•The gate is horizontal and level and the gate can glide back and forth smoothly when
moved by hand before installing the Automatic Gate Opener.
•Wheels and guide rollers should rotate easily and be free from dirt/grime.
•Track should be flat, level and firmly affixed.
•Any misalignment in the gate will affect performance of the automatic gate opener.
The gate should slide smoothly by hand before attempting to install the gate opener.
Step 2 - Motor Pad Footing (If Required):
•The motor pad footing requires an area of no less than 450mm long x 300mm wide
and a minimum depth of 200mm (Standard requirement).
•Ensure surface is level and parallel to the driveway
Mounting Plate Dimensions:

11
Rev 20A
Step 3 - Motor Position installation:
•Insert the key and open the manual release bar to put the motor into manual mode,
and check that the motor cog rotates freely by hand (As per Fig 15).
•Place the motor and motor mounting plate on the concrete pad.
•Make sure the distance between the gate motor cog and gear rack position are
aligned.
•Mark all four corners of the mounting plate on the concrete pad using a pencil, chalk
or similar, to ensure the mounting plate is in the correct position before drilling.
•Remove motor from the mounting plate.
Step 4 - Drilling holes for anchor bolts:
•Mark the (4) positions for your anchor bolts ready for drilling (refer to Fig 5).
•Remove Mounting plate.
•Using a M12 masonry drill bit, drill holes to a minimum depth of 120mm (Fig 6).
Mark anchor bolt positions
Fig 5
Fig 6
Mark
corners
of the
mounting
plate with
a pencil,
chalk, or
similar.
Sliding Gate Frame
Fig 4
Fig 3

12
Rev 20A
Step 5 - Fitting mounting Plate & Motor:
•Fit motor mounting plate back into place and fit and tighten anchor bolts (as per
figures 7 and 8).
•Fit motor back on mounting plate, ensuring the power cord is positioned into the end
slot of the mounting plate in the direction of the power point, making sure there are no
pinch points (as per fig 9).
•Slide rubber grommet along the power lead and into the end slot of the mounting
plate (as per figures 10 & 11).
•Bolt motor to the mounting plate using the M8 x 50mm bolts with spring and flat
washers provided and tighten as required (as per figure 12).
Fig 9
Fig 10
Fig 11
Fig 12
Insert the M8 x 50mm bolts
(Part 6d), spring washers, and flat
washers provided through motor
housing and screw into welded
nut on the baseplate.
Hand-tighten set screws before
final adjustment of motor.
Tighten bolts using
spanner or socket set
Fig 7
Fig 8

13
Rev 20A
Please ensure that the motor power cable is not plugged in at any stage before Step 8
Step 6 - Gear Rack & Motor Alignment:
•Insert the key and open the manual release bar to put the motor into manual mode,
and check that the motor cog rotates freely by hand (as per fig 15).
•Ensure that the gate drive cog has a minimum clearance of 1-2mm along the entire
length of gear rack fitted to the gate (as per Fig 13)
•Ensure cog and rack are correctly aligned. Under no circumstances should the gate
motor drive cog carry any weight of the gate. It is the task of the gate castors or
wheels to carry the weight of the gate. (As per Fig 14)
•If the gate doesn’t slide freely by hand, adjust gear racks height accordingly until the
full length of gate slides freely by hand.
At this stage of final assembly, the cover is removed (not shown) and the power cable is still unplugged.
To put the gate motor into manual mode, insert the key and open the manual release bar as shown.
In manual mode, the gear can turn freely, and the gate can be operated by hand.
Fig 15
Gear rack correctly aligned at 90° to the
motor cog
Gear rack misaligned. Do not attempt to
use if misaligned.
Fig 13
Fig 14

14
Rev 20A
Fig 16
Please Note:
The warning
signage provided
(Part 5) must be
displayed on the
frame of your
automatic gate
at all times.
Fig 17

15
Rev 20A
Step 7 - Magnetic limit switch
stops Installation:
Included in your gate motor kit are two
magnetic limit travel stops which must be
fitted to the gear rack on your gate to ensure
safe operation.
The magnetic limit travel stops are designed
to set the desired opening and closing
position of your gate.
These limit travel stops activate when the
magnets travel past a magnetic limit switch
sensor under the motor cover (refer to Fig 19
& 20). See page 32 for an image of the
magnetic limit switch sensor.
Please note: gates can open and close in different positions due to different weights of gates, terrains,
slopes (uphill or downhill). The distance the gate will travel after triggering the magnetic limit switch
may vary.
Setting the limit travel stops:
Closed Position
•Position gate 150-200mm back from the
gate end catch closed position. This will help
in making sure you do not slam the gate into
the gate end catch.
•Position Magnetic Limit Travel Stop B
(LARGER) central to the magnetic limit
switch sensor on the motor (as per fig 19).
•Tighten locking screws provided.
Open Position
•Position gate 150-200mm back from the
gate stopper open position.
•This will help in making sure you do not
slam the gate into the gate stopper.
•Position Magnetic Limit Travel Stop A
(SMALLER) central to the magnetic limit
switch sensor on the motor (as per fig 20).
•Tighten locking screws provided.
To Reset: When setting new limit stop positions please ensure that you turn the power off and then
on again. Turning the power off will reset the limit travel stop memory, allowing for new limit travel
stop positions to be recognised by the motor.
Refer to Step 9 for testing and adjusting the limit travel stops.
Fig 18
Fig 19
Fig 20

16
Rev 20A
Note: The default setting is right side open.
Magnetic Limit Travel Stop B (LARGER) should be positioned at the closed position.
Magnetic Limit Travel Stop A (SMALLER) should be positioned at the open position.
A
B
Fig 21
Fig 22
Fig 23
Fig 24
Fig 25
If the limit travel
stops are more
than
20mm away from
the magnetic limit
switch sensor the
limit switch may
not activate.

17
Rev 20A
Step 8 - Powering the Motor:
•Ensure that the outer cover has been fitted and fastened back onto the motor
housing.
•Before powering up the motor make sure the gate can travel by hand in manual
mode (key unlocked).
•Slide the gate to between the middle of the posts, approximately.
•Lock the key (key locked) in readiness for automatic mode.
•Plug the power cord into an approved RCD protected weatherproof outlet.
•Remote controls (Part 4) included in this kit are factory paired ready for use.
Note:
•The default setting is opening to the right.
•Press the remote control and the gate will open until the magnetic limit travel stop
passes the magnetic limit switch sensor. Press the remote control again and the
gate will close.
•Soft start/soft stop function - The GTR064 is set by default to provide the soft
start/soft stop function. We recommend this default position is always maintained.
Your motor is now set up for basic remote-control operation. To set further functions
and settings, see pages 19-32

18
Rev 20A
Step 9 –Testing and Adjusting the Magnetic Limit Travel Stops:
Testing the closed position
•Ensure motor is plugged in as per step 8 and the gate is in the open position.
•Press remote (remotes included in kit are factory paired to the motor). The gate
will begin to close.
•The gate will stop when the magnetic limit travel stop reaches the magnetic limit
switch sensor during closing (refer to figs 19 and 20).
•When the gate stops, measure the distance remaining between the gate and the
desired closed position.
•You have now determined the closed position of the gate when the travel limit
stop passes the magnetic limit switch sensor.
•Adjust the magnetic limit travel stop from the measurement you have taken to
get your desired closed position. The ideal closed final position for the gate
frame is 10-15mm from the closed gate end catch (GTR019).
Testing the open position
•Press remote.The gate will begin to open.
•The gate will stop when the magnetic limit travel stop reaches the magnetic limit
switch sensor during opening (refer to figs 19 and 20).
•When the gate stops, measure the distance remaining between the gate and the
desired open position.
•You have now determined the open position of the gate when the travel limit stop
passes the magnetic limit switch sensor.
•Adjust the magnetic limit travel stop from the measurement you have taken to
get your desired open position. The ideal open final position for the gate frame is
10-15mm from the gate stopper (GTR017).
To Reset:
When setting new limit stop positions please ensure that you turn the power off for at least 15
seconds and then on again. Turning the power off will reset the limit stop memory, allowing for
new limit travel stop positions to be recognised by the motor.
Fig 26

19
Rev 20A
Programming and Wiring:
Control board wiring diagram 01
Any works to the 240V AC must only be performed by a licensed electrician.
Ensure power is off before any modifications are made.
Fig 27

20
Rev 20A
Programming and Wiring:
Control board wiring diagram 02
Fig 28
Please refer to
page 24 & 25
for added
description of
terminals
Other manuals for GTR064
2
Table of contents
Other Richmond Gate Opener manuals

Richmond
Richmond GTR211 User manual

Richmond
Richmond GTR181 User manual

Richmond
Richmond GTR064 User manual

Richmond
Richmond GTR062 User manual

Richmond
Richmond GTR064 User manual

Richmond
Richmond GTR502 User manual

Richmond
Richmond GTR500 User manual

Richmond
Richmond GTR058 User manual

Richmond
Richmond GTR156 User manual

Richmond
Richmond GTR099 User manual
Popular Gate Opener manuals by other brands

Chamberlain
Chamberlain SCS200 Installation

Eagle Access Control Systems
Eagle Access Control Systems X9S Installation & owner's manual

Dea
Dea REV Operating instructions and warnings

Nice
Nice Apollo 4300SW manual

Apollo
Apollo 3500 Operator's manual

Nice
Nice ROBUS RB600 Instructions and warnings for installation and use
