Ricoh Aficio 1515 User manual

Model S-C2
(Machine Code: B129/B130/B168/B169)
SERVICE MANUAL
9 March 2004
Subject to change

1
!IMPORTANT SAFETY NOTICES
PREVENTION OF PHYSICAL INJURY
1. Be sure that the power cord is unplugged before disassembling or
assembling parts of the copier or peripherals.
2. The wall outlet should be near the copier and easily accessible.
3. Note that electrical voltage is supplied to some components of the copier
and the paper tray unit even while the main power switch is off.
4. If you start a job before the copier completes the warm-up or initializing
period, keep hands away from the mechanical and electrical components
until job execution has started. The copier will start making copies as soon
as warm-up or initialization is finished.
5. The inside and the metal parts of the fusing unit become extremely hot while
the copier is operating. Be careful to avoid touching those components with
your bare hands.
HEALTH SAFETY CONDITIONS
Toner and developer are nontoxic, but getting either of these into your eyes may
cause temporary eye discomfort. Try to remove with eye drops or flush with
water. If material remains in eye or if discomfort continues, get medical attention.
OBSERVANCE OF ELECTRICAL SAFETY STANDARDS
The copier and its peripherals must be installed and maintained by a customer
service representative who has completed the training course on those relevant
models.
LITHIUM BATTERIES
Incorrect replacement of lithium battery(s) on the FCU may pose risk of
explosion. Replace only with the same type or with an equivalent type
recommended by the manufacturer. Discard used batteries in accordance with
the manufacturer’s instructions.
SAFE AND ECOLOGICAL DISPOSAL
1. Do not incinerate toner bottles or used toner. Toner dust may ignite suddenly
if exposed to an open flame.
2. Dispose of used toner, developer, and organic photoconductors in
accordance with local regulations. (These are nontoxic supplies.)
3. Dispose of replaced parts in accordance with local regulations.

2
LASER SAFETY
The Center for Devices and Radiological Health (CDRH) prohibits the repair of
laser-based optical units in the field. The optical housing unit can only be repaired
in a factory or at a location with the requisite equipment. The laser subsystem is
replaceable in the field by a qualified Customer Engineer. The laser chassis is not
repairable in the field. Customer engineers are therefore directed to return all
chassis and laser subsystems to the factory or service depot when replacement of
the optical subsystem is required.
!WARNING
Use of controls not specified in this manual, or performance of
adjustments or procedures not specified in this manual, may result in
hazardous radiation exposure.
!WARNING FOR LASER UNIT
WARNING: Turn off the main switch before attempting any of the
procedures in the Laser Unit section. Laser beams can cause
serious damage to eyes.
CAUTION MARKING:
B130R934.WMF
Symbols and Abbreviations
This manual uses the symbols and abbreviations shown below.
Symbol Meaning
☛"See," "Refer to"
!Clip ring
"Screw
#Connector
SEF Short Edge Feed
LEF Long Edge Feed
$Core Technology manual

i
TABLE OF CONTENTS
1. INSTALLATION........................................................................... 1-1
1.1 INSTALLATION REQUIREMENTS........................................................... 1-1
1.1.1 ENVIRONMENT .............................................................................. 1-1
1.1.2 MACHINE LEVEL ............................................................................ 1-2
1.1.3 MINIMUM OPERATIONAL SPACE REQUIREMENTS ................... 1-2
1.1.4 POWER REQUIREMENTS.............................................................. 1-3
1.2 COPIER .................................................................................................... 1-4
1.2.1 ACCESSORY CHECK..................................................................... 1-4
Basic Model.......................................................................................... 1-4
MFP Model........................................................................................... 1-4
Copier/Facsimile Model........................................................................ 1-5
Copier/Printer/Scanner Model.............................................................. 1-5
1.2.2 INSTALLATION PROCEDURE........................................................ 1-6
1.3 PAPER TRAY UNIT................................................................................ 1-12
1.3.1 ACCESSORY CHECK................................................................... 1-12
1.3.2 INSTALLATION PROCEDURE...................................................... 1-12
1.4 PAPER TRAY UNIT HEATER ................................................................ 1-14
1.4.1 ACCESSORY CHECK................................................................... 1-14
1.4.2 INSTALLATION PROCEDURE...................................................... 1-15
1.5 DOCUMENT FEEDER............................................................................ 1-20
1.5.1 ACCESSORY CHECK................................................................... 1-20
1.5.2 INSTALLATION PROCEDURE...................................................... 1-21
1.6 PRINTER SCANNER UNIT .................................................................... 1-25
1.6.1 ACCESSORY CHECK................................................................... 1-25
1.6.2 INSTALLATION PROCEDURE...................................................... 1-26
1.7 POSTSCRIPT 3...................................................................................... 1-31
1.8 IEEE 1284/IEEE 1394/BLUETOOTH INTERFACE ................................ 1-32
1.9 WIRELESS LAN ..................................................................................... 1-33
1.9.1 ACCESSORY CHECK................................................................... 1-33
1.9.2 INSTALLATION PROCEDURE...................................................... 1-33
1.10 BLUETOOTH........................................................................................ 1-36
1.10.1 ACCESSORY CHECK ................................................................. 1-36
1.10.2 INSTALLATION PROCEDURE.................................................... 1-36
2. PREVENTIVE MAINTENANCE ................................................... 2-1
2.1 PM TABLES.............................................................................................. 2-1
2.2 HOW TO CLEAR THE PM COUNTER..................................................... 2-2
3. REPLACEMENT AND ADJUSTMENT........................................ 3-1
3.1 PRECAUTIONS........................................................................................ 3-1
3.1.1 GENERAL........................................................................................ 3-1
3.1.2 LITHIUM BATTERIES...................................................................... 3-1
3.1.3 HALOGEN-FREE CABLE................................................................ 3-1
3.2 SPECIAL TOOLS AND LUBRICANTS ..................................................... 3-2

ii
3.3 EXTERIOR COVER AND OPERATION PANEL ...................................... 3-3
3.3.1 PLATEN COVER ............................................................................. 3-3
3.3.2 REAR COVER ................................................................................. 3-3
3.3.3 COPY TRAY .................................................................................... 3-4
Reassembling ...................................................................................... 3-4
3.3.4 SCALE PLATE................................................................................. 3-4
3.3.5 OPERATION PANEL AND UPPER COVERS ................................. 3-5
3.3.6 RIGHT DOOR .................................................................................. 3-6
3.3.7 BYPASS TRAY ................................................................................ 3-6
3.3.8 PLATEN COVER SENSOR ............................................................. 3-7
3.4 SCANNER UNIT....................................................................................... 3-8
3.4.1 EXPOSURE GLASS ........................................................................ 3-8
Non-ADF machines.............................................................................. 3-8
ADF-equipped machines...................................................................... 3-8
3.4.2 LENS BLOCK .................................................................................. 3-9
3.4.3 EXPOSURE LAMP, LAMP STABILIZER BOARD ........................... 3-9
3.4.4 SCANNER MOTOR ....................................................................... 3-10
3.4.5 SCANNER HP SENSOR ............................................................... 3-10
3.4.6 SCANNER ALIGNMENT ADJUSTMENT....................................... 3-11
3.5 FUSING .................................................................................................. 3-12
3.5.1 FUSING UNIT ................................................................................ 3-12
3.5.2 EXIT SENSOR............................................................................... 3-12
3.5.3 HOT ROLLER STRIPPER PAWLS................................................ 3-13
3.5.4 HOT ROLLER & FUSING LAMP ................................................... 3-14
3.5.5 THERMO-SWITCH AND THERMISTOR....................................... 3-15
3.5.6 PRESSURE ROLLER.................................................................... 3-16
3.5.7 ADJUSTING NIP BAND................................................................. 3-17
3.5.8 DUPLEX MOTOR .......................................................................... 3-18
3.5.9 CONTACT-RELEASE SOLENOID ................................................ 3-18
3.6 PCU AND QUENCHING LAMP .............................................................. 3-19
3.6.1 PCU ............................................................................................... 3-19
3.6.2 QUENCHING LAMP ...................................................................... 3-20
3.7 TONER SUPPLY CLUTCH..................................................................... 3-21
3.8 HIGH-VOLTAGE POWER SUPPLY BOARD ......................................... 3-21
3.9 EXHAUST FAN AND MAIN MOTOR...................................................... 3-22
3.9.1 EXHAUST FAN.............................................................................. 3-22
3.9.2 MAIN MOTOR................................................................................ 3-22
3.10 PAPER FEED ....................................................................................... 3-23
3.10.1 PAPER FEED ROLLER AND FRICTION PAD ............................ 3-23
3.10.2 PAPER END SENSOR ................................................................ 3-23
3.10.3 REGISTRATION SENSOR.......................................................... 3-24
3.10.4 BYPASS PAPER END SENSOR................................................. 3-24
3.10.5 BYPASS FEED ROLLER............................................................. 3-25
3.10.6 BYPASS FEED CLUTCH AND FRICTION PAD.......................... 3-26
3.10.7 PAPER FEED AND REGISTRATION CLUTCHES...................... 3-27
3.11 IMAGE TRANSFER.............................................................................. 3-28
3.11.1 TRANSFER ROLLER .................................................................. 3-28
3.11.2 ID SENSOR AND DUPLEX ROLLER .......................................... 3-28
3.11.3 DISCHARGE PLATE ................................................................... 3-29

iii
3.12 CONTROLLER BOX AND BICU........................................................... 3-30
3.13 LASER UNIT......................................................................................... 3-32
3.13.1 LOCATION OF CAUTION DECAL............................................... 3-32
3.13.2 PSU ............................................................................................. 3-33
3.13.3 LASER UNIT................................................................................ 3-34
3.13.4 LD UNIT AND POLYGON MIRROR MOTOR.............................. 3-34
3.14 ADJUSTING COPY IMAGE AREA ....................................................... 3-35
3.14.1 PRINTING.................................................................................... 3-35
Adjusting Registration ........................................................................ 3-35
Adjusting Blank Margin ...................................................................... 3-36
Adjusting Main-Scan Magnification .................................................... 3-36
3.14.2 SCANNING .................................................................................. 3-37
Adjusting Registration ........................................................................ 3-37
Adjusting Magnification ...................................................................... 3-37
Standard White Density Adjustment................................................... 3-38
3.14.3 ADF IMAGE ADJUSTMENT ........................................................ 3-39
4. TROUBLESHOOTING................................................................. 4-1
4.1 SERVICE CALL CONDITIONS................................................................. 4-1
4.1.1 SUMMARY....................................................................................... 4-1
4.1.2 SC CODE DESCRIPTIONS............................................................. 4-2
4.2 ELECTRICAL COMPONENT DEFECTS................................................ 4-11
4.2.1 SENSOR/SWITCH OPEN ERRORS ............................................. 4-11
4.2.2 BLOWN FUSE CONDITIONS........................................................ 4-12
4.3 LED DISPLAY......................................................................................... 4-12
4.3.1 BICU .............................................................................................. 4-12
5. SERVICE TABLES...................................................................... 5-1
5.1 SERVICE PROGRAM............................................................................... 5-1
5.1.1 USING SP AND SSP MODES......................................................... 5-1
Starting SP Mode................................................................................. 5-1
Starting SSP Mode............................................................................... 5-2
Selecting Programs.............................................................................. 5-2
Specifying Values................................................................................. 5-2
Activating Copy Mode .......................................................................... 5-2
Quitting Programs/Ending (S)SP Mode................................................ 5-2
5.1.2 SP MODE TABLES–BASIC MODEL ............................................... 5-3
SP1-XXX (Feed) .................................................................................. 5-3
SP2-XXX (Drum).................................................................................. 5-5
SP4-XXX (Scanner) ............................................................................. 5-9
SP5-XXX (Mode)................................................................................ 5-13
SP6-XXX (Peripherals) ...................................................................... 5-16
SP7-XXX (Data Log) .......................................................................... 5-17
SP8-XXX (History) ............................................................................. 5-20
5.1.3 SP MODE TABLES–OTHER MODELS ......................................... 5-22
SP1-XXX (Feed) ................................................................................ 5-22
SP2-XXX (Drum)................................................................................ 5-24
SP4-XXX (Scanner) ........................................................................... 5-28
SP5-XXX (Mode)................................................................................ 5-33

i
v
SP6-XXX (Peripherals) ...................................................................... 5-46
SP7-XXX (Data Log) .......................................................................... 5-47
SP8-XXX (History) ............................................................................. 5-51
5.1.4 ID SENSOR ERROR ANALYSIS (SP2-221).................................. 5-61
5.1.5 MEMORY CLEAR.......................................................................... 5-62
Basic Model and Other Models .......................................................... 5-62
Exceptions.......................................................................................... 5-62
Initializing Memory Data..................................................................... 5-62
Executing Memory Clear on Basic Model .......................................... 5-63
Executing Memory Clear on Other Models ........................................ 5-63
5.1.6 INPUT CHECK (SP5-803) ............................................................. 5-64
Conducting Input Check..................................................................... 5-64
Input Check Table.............................................................................. 5-64
5.1.7 OUTPUT CHECK (SP5-804) ......................................................... 5-65
Conducting Output Check .................................................................. 5-65
Output Check Table ........................................................................... 5-65
5.1.8 SERIAL NUMBER INPUT (SP5-811-001) ..................................... 5-66
Specifying Characters ........................................................................ 5-66
Serial Number and NVRAM ............................................................... 5-66
5.1.9 NVRAM DATA UPLOAD/DOWNLOAD (SP5-824/825) ................. 5-67
Overview ............................................................................................ 5-67
NVRAM Upload (SP5-824-001) ......................................................... 5-67
NVRAM Download (SP5-825-001)..................................................... 5-68
5.1.10 FIRMWARE UPDATE PROCEDURE FOR BASIC MODEL ........ 5-69
5.1.11 TEST PATTERN PRINT (SP5-902-001)...................................... 5-70
Executing Test Pattern Printing.......................................................... 5-70
Test Patterns...................................................................................... 5-70
5.1.12 SMC PRINT (SP5-990)................................................................ 5-71
5.2 FIRMWARE UPDATE PROCEDURE..................................................... 5-72
5.2.1 HANDLING SD CARD ................................................................... 5-72
5.2.2 FIRMWARE UPDATE PROCEDURE ............................................ 5-72
5.2.3 NVRAM DATA UPLOAD/DOWNLOAD.......................................... 5-76
Uploading NVRAM Data .................................................................... 5-76
Downloading SD Card Data ............................................................... 5-77
5.3 USER TOOLS......................................................................................... 5-78
6. DETAILED SECTION DESCRIPTIONS....................................... 6-1
6.1 PAPER PATH ........................................................................................... 6-1
6.2 DRIVE LAYOUT ....................................................................................... 6-2
6.3 BLOCK DIAGRAM: PCBS AND COMPONENTS ..................................... 6-3
6.4 IMAGE PROCESSING STEPS FOR EACH MODE.................................. 6-4
6.5 LD SAFETY SWITCHES .......................................................................... 6-5
6.6 IMAGE TRANSFER CURRENT ............................................................... 6-6
6.7 IMAGE FUSING AND PAPER EXIT ......................................................... 6-7
6.7.1 OVERVIEW...................................................................................... 6-7
6.7.2 HOT ROLLER DRIVE ...................................................................... 6-8
Mechanism........................................................................................... 6-8
Contact/Release Control ...................................................................... 6-8

v
6.7.3 PRESSURE ROLLER...................................................................... 6-9
6.7.4 PRESSURE RELEASE.................................................................... 6-9
6.7.5 SEPARATION.................................................................................. 6-9
6.7.6 FUSING TEMPERATURE CONTROL........................................... 6-10
Control Process.................................................................................. 6-10
Target Temperature ........................................................................... 6-10
Temperature Transition...................................................................... 6-10
Overheat Protection ........................................................................... 6-11
6.8 DUPLEX UNIT ........................................................................................ 6-12
6.8.1 IMPORTANT COMPONENT.......................................................... 6-12
6.8.2 DUPLEX PRINTING PROCESS.................................................... 6-12
6.9 ENERGY SAVER MODES OF BASIC MACHINES................................ 6-15
Overview ............................................................................................ 6-15
AOF.................................................................................................... 6-16
Timers ................................................................................................ 6-16
Recovery............................................................................................ 6-16
6.10 ENERGY SAVER MODES OF MFP MACHINES ................................. 6-17
Overview ............................................................................................ 6-17
AOF.................................................................................................... 6-17
Timers ................................................................................................ 6-19
Recovery............................................................................................ 6-19
PERIPHERALS
DOCUMENT FEEDER (B696)
1. REPLACEMENT AND ADJUSTMENT..................................B696-1
1.1 EXTERIOR COVER............................................................................ B696-1
1.2 ORIGINAL TABLE .............................................................................. B696-1
1.3 ROLLER ............................................................................................. B696-2
1.3.1 PICKUP ROLLER ...................................................................... B696-2
1.3.2 FEED ROLLER.......................................................................... B696-3
1.3.3 SEPARATION ROLLER ............................................................ B696-3
1.4 ADF MOTOR ...................................................................................... B696-4
1.5 FEED CLUTCH................................................................................... B696-6
1.6 SENSOR............................................................................................. B696-6
1.7 ADF EXPOSURE GLASS................................................................... B696-8
1.8 ADF CONNECTION BOARD.............................................................. B696-8
2. DETAILED DESCRIPTIONS .................................................B696-9
2.1 OVERVIEW ........................................................................................ B696-9
2.1.1 MECHANICAL COMPONENT ................................................... B696-9
2.1.2 ELECTRICAL COMPONENT................................................... B696-10
2.1.3 DRIVE LAYOUT....................................................................... B696-11
2.2 CIRCUIT CONNECTION .................................................................. B696-12
2.3 ORIGINAL DETECTION ................................................................... B696-12

vi
2.4 PAPER TRANSPORT....................................................................... B696-13
2.4.1 PICK-UP AND FEED ............................................................... B696-13
2.4.2 SEPARATION.......................................................................... B696-13
2.4.3 REGISTRATION ...................................................................... B696-13
2.5 CORRECTION.................................................................................. B696-14
2.5.1 WHITE LEVEL CORRECTION ................................................ B696-14
2.5.2 SHADING CORRECTION........................................................ B696-14
2.6 UNIT OPEN SWITCH AND GUIDE OPEN SENSOR ....................... B696-14
SPECIFICATIONS.................................................................... SPEC-1
1. GENERAL SPECIFICATIONS.............................................................SPEC-1
1.1 COPIER .......................................................................................SPEC-1
1.2 FAX..............................................................................................SPEC-3
1.3 PRINTER AND SCANNER ..........................................................SPEC-3
1.4 ADF..............................................................................................SPEC-3
2. SUPPORTED PAPER SIZE ................................................................SPEC-4
2.1 ORIGINAL PAPER SIZE..............................................................SPEC-4
2.2 PAPER FEED ..............................................................................SPEC-5
3. MACHINE CONFIGURATION .............................................................SPEC-6
3.1 BASIC MODEL (B129).................................................................SPEC-6
3.2 COPIER/PRINTER/SCANNER MODEL (B169)...........................SPEC-7
3.3 COPIER/FAX MODEL (B168)......................................................SPEC-8
3.4 MFP MODEL (B130)....................................................................SPEC-9
4. OPTION .............................................................................................SPEC-10
4.1 PRINTER/SCANNER UNIT .......................................................SPEC-10
4.2 ADF............................................................................................SPEC-10
4.3 PAPER FEED UNIT.................................................................SPEC-10

9 March 2004 INSTALLATION REQUIREMENTS
1-1
Installation
1. INSTALLATION
!
!!
!CAUTION
Before installing an optional unit, do the following:
1. If there is a fax unit on the machine, print out all messages stored in the
memory, all user-programmed items, and a system parameter list.
2. If there is a printer option on the machine, print out all data in the
printer buffer.
3. Turn off the main switch and disconnect the power cord, the telephone
line, and the network cable.
1.1 INSTALLATION REQUIREMENTS
1.1.1 ENVIRONMENT
–Temperature and Humidity Chart–
1. Temperature Range: 10°C to 32°C (50°F to 89.6°F)
2. Humidity Range: 15% to 80% RH
3. Ambient Illumination: Less than 1,500 lux (Do not expose to direct sunlight.)
4. Ventilation: Room air should turn over at least 3 times/hr/person
5. Ambient Dust Less than 0.1 mg/m3
6. Do not install the machine where it will be exposed to direct sunlight or to direct
airflow (from a fan, air conditioner, air cleaner, etc.).
7. Do not install the machine where it will be exposed to corrosive gas.
8. Place the machine on a firm and level base.
9. Do not install the machine where it may be subjected to strong vibration.
Humidity
10°C
(50°F)
27°C
(80.6°F)
32°C
(89.6°F)
15%
54%
80%
Temperature
Operation range
B046I512.WMF

INSTALLATION REQUIREMENTS 9 March 2004
1-2
1.1.2 MACHINE LEVEL
Front to back: Within 5 mm (0.2") of level
Right to left: Within 5 mm (0.2") of level
1.1.3 MINIMUM OPERATIONAL SPACE REQUIREMENTS
Place the machine near the power source, providing clearance as shown.
NOTE: 1) The 750-mm front space indicated above is sufficient to allow the paper
tray to be pulled out. Additional space is required to allow an operator to
stand at the front of the machine.
2) Actual minimum space requirement for left, rear, and right sides is
10mm (0.4") each, but note that this will not allow room for opening of
the bypass tray, right door, platen cover, or ADF unit.
B046I130.WMF
A
: Front – 750 mm (29.6")
B: Left – 100 mm (3.9")
C: Rear – 105 mm (4.1")
D: Right – 230 mm (9.0")
[C]
[D]
[B]
[A]
450 mm (17.7")
468 mm (18.4")

9 March 2004 INSTALLATION REQUIREMENTS
1-3
Installation
1.1.4 POWER REQUIREMENTS
!CAUTION
1. Make sure that the wall outlet is near the machine and easily accessible.
After completing installation, make sure the plug fits firmly into the
outlet.
2. Avoid multi-wiring.
3. Be sure to ground the machine.
Input voltage:
North America: 110 – 120 V, 60 Hz, 8 A
Europe: 220 – 240 V, 50/60 Hz, 4 A
Image quality guaranteed at rated voltage ±10%.
Operation guaranteed at rated voltage ±15%.

COPIER 9 March 2004
1-4
1.2 COPIER
1.2.1 ACCESSORY CHECK
Basic Model
Description Q’ty
1. General Settings Guide (-17, -21, -29)............................................... 1
2. Copy Reference (-17, -21, -29) .......................................................... 1
3. EU Safety Sheet (-22, -24, -26, -27) .................................................. 1
4. NECR (-17, -21, -27, -29)................................................................... 1
5. Paper Size Decal ............................................................................... 1
6. Brand Decal (-22, -29) ....................................................................... 1
MFP Model
Description Q’ty
1. General Settings Guide (-17, -21, -29)............................................... 1
2. Copy Reference (-17, -21, -29) .......................................................... 1
3. Facsimile Reference <Basic Features> (-17, -21, -29) ...................... 1
4. Facsimile Reference <Advanced Features> (-17, -21, -29) ............... 1
5. Printer Setup Guide (-17, -21, -29)..................................................... 1
6. CD-ROM (Printer Reference/Scanner Reference) (-17, -21, -29) ...... 1
7. CD-ROM (Driver: Printer/Scanner) (-21, -22, -24, -26, -27, -29) ........ 1
8. CD-ROM (Driver: Utility)..................................................................... 1
9. EU Safety Sheet (-22, -24, -26, -27) .................................................. 1
10. NECR (-17, -21, -27, -29)................................................................. 1
11. Paper Size Decal ............................................................................. 1
12. Modular Cable (-17) ......................................................................... 1
13. Handset Bracket (-17) ...................................................................... 1
14. Facsimile Panel Decal (-17, -21, -29)............................................... 1
15. Ferrite Core...................................................................................... 1
16. Brand decals (-22, -29) .................................................................... 1
NOTE: Retain the handset bracket. The optional handset kit does not include the
bracket.

9 March 2004 COPIER
1-5
Installation
Copier/Facsimile Model
Description Q’ty
1. General Settings Guide (-17, -21, -29).................................... 1
2. Copy Reference (-17, -21, -29) ............................................... 1
3. Facsimile Reference <Basic Features> (-17, -21, -29) ........... 1
4. Facsimile Reference <Advanced Features> (-17, -21, -29) .... 1
5. EU Safety Sheet (-22, -24, -26, -27) ....................................... 1
6. NECR (-17, -21, -27, -29)........................................................ 1
7. Paper Size Decal .................................................................... 1
8. Modular Cable (-17) ................................................................ 1
9. Handset Bracket (-17)............................................................. 1
10. Facsimile Panel Decal (-17, -21, -29).................................... 1
11. Brand decals (-22) ................................................................ 1
NOTE: Retain the handset bracket. The optional handset kit does not include the
bracket.
Copier/Printer/Scanner Model
Description Q’ty
1. CD-ROM (Driver: Printer/Scanner) (-22, -24, -26)................. 1
2. CD-ROM (Driver: Utility)........................................................ 1
3. EU Safety Sheet ................................................................... 1
4. NECR (-27) ........................................................................... 1
5. Paper Size Decal .................................................................. 1
6. Ferrite Core........................................................................... 1
7. Brand decals (-22) ................................................................ 1

COPIER 9 March 2004
1-6
1.2.2 INSTALLATION PROCEDURE
!CAUTION
Make sure that the copier remains unplugged during installation.
1. Remove the strips of tape.
2. Remove the bags [A][B][C] holding the
included accessories.
NOTE: Accessories vary according to
models.
3. Remove the spacing wedge [D].
4. Remove the System Parameter
Report [E] and keep it in a safe
place.
NOTE: You need this report for
adjustment or
troubleshooting.
B130I901.WMF
B130I902.WMF
[C]
[A]
[B]
[D]
[E]

9 March 2004 COPIER
1-7
Installation
5. Remove the three scanner lock
pins. (A tag is hanging from each
pin.) To remove: Grasp the base
of the pin [A], turn the pin 90
degrees, and pull it down and out.
6. Remove the tags from the pins.
7. Break each pin off the base [A].
8. Discard the pin part [B].
9. Set each base [A] back into its original hole, turning it 90°to lock it into place.
(Be sure to do this for all three pins.)
10. When installing a DF-equipped
model, raise the DF upper guide [C]
and remove the protective paper
[D] at the feed unit. Then lower the
guide.
11. Open the platen cover [E] and
remove the protective paper [F]
covering the exposure glass. Then
close the platen cover.
B046I106.WMF
B046I107.WMF
[E]
[F]
[C]
[D]
[A]
[B]

COPIER 9 March 2004
1-8
12. Open the front door [A].
13. Lift lever [B], press in on latch [C]
and pull the bottle holder [D] out.
(You do not need to pull it
completely out of the machine.)
14. Take a new bottle of toner, and
shake it several times.
15. Remove the outer cap [E].
NOTE: Do not remove the inner
cap [F].
16. Load the bottle on the holder.
NOTE: Do not forcefully turn the
toner bottle on the holder.
After you turn on the main
power switch, the copier
sets the bottle in place.
17. Push the bottle holder back into the
machine.
18. Press the latch [G] down to lock the
holder.
B046I112.WMF
B046I301.WMF
[C]
[B] [D] [A]
[E]
[F]
[G]

9 March 2004 COPIER
1-9
Installation
19. Remove the padding [A].
20. Pull the tabbed strips [B] out of
the PCU.
21. Close the front door.
22. Pull out the paper tray, and
remove the tape [C] securing
the end fence in the
compartment.
23. Push the bottom plate [D] down.
24. Load the paper.
25. Adjust the side fences. If you load the paper shorter than A4, set the end fence
[E] in position.
B130I903.WMF
B046I119.WMF
[C]
[D]
[E]
[A]
[B]

COPIER 9 March 2004
1-10
26. Push the tray back in the copier.
27. Attach the appropriate Brand Decal
to the center of the front door [A] if
necessary.
28. Attach the appropriate tray number
decal and paper-size decal to the
paper tray [B].
29. Install optional units (if any).
30. Attach the ferrite core to the
network cable when connecting
the cable.
31. Connect a telephone line as
necessary.
32. Plug in the machine and turn on
the main power switch.
B046I515.WMF
B130I909.WMF
[A]
[B]
[C]

9 March 2004 COPIER
1-11
Installation
33. Select the language used in the operation panel as necessary (!>
Language).
34. Make a full size copy, and check if the side-to-side and leading edge
registrations are correct. If they are not, adjust the registrations.
The following steps are for the MFP model, the copier/facsimile model, and the
copier/printer/scanner model only:
35. Activate the SP mode.
36. Select Copy SP 5-302-002 (Time) and specify the time difference.
37. Quit the SP mode.
38. Activate the User Tools (!).
39. Specify the date and time (System Settings > Timer Settings > Set Date/Set
Time).
40. Quit the User Tools.
41. Activate the SP mode.
42. Select Copy SP5-307.
43. Specify the daylight-saving-time settings.
44. Quit the SP mode.
