Ricoh Aficio CL5000 Operating manual

Operating Instructions
Maintenance Guide 1
For safety, please read this manual carefully before you use this product and keep it handy
for future reference.
Getting Started
Replacing Consumables and Maintenance Kit
Cleaning and Adjusting the Printer
Appendix
1
2
3
4

Introduction
This manual contains detailed instructions on the operation and maintenance of this machine. To get
maximum versatility from this machine all operators should carefully read and follow the instructions in
this manual. Please keep this manual in a handy place near the machine.
Please read “Safety Information” in this manual before using this machine. It contains important infor-
mation related to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.
Power Source
120 V, 60 Hz, 11 A or more
Please be sure to connect the power cable to a power source as above.
Laser Safety
This machine is considered a CDRH class I laser device, safe for office/EDP use. The machine con-
tains 7 milliwatt, 645 - 660 nanometer wavelength, AlGaInP Laser Diode. Direct (or indirect reflected)
eye contact with the laser beam might cause serious eye damage. Safety precautions and interlock
mechanisms have been designed to prevent any possible laser beam exposure to the operator.
Important
Contents of this manual are subject to change without prior notice. In no event will the company be li-
able for direct, indirect, special, incidental, or consequential damages as a result of handling or oper-
ating the machine.
Caution:
Use of controls or adjustment or performance of procedures other than those specified in this manual
might result in hazardous radiation exposure.
Do not attempt any maintenance or troubleshooting other than that mentioned in this manual. This
printer contains a laser beam generator and direct exposure to laser beams can cause permanent eye
damage.
Two kinds of size notation are employed in this manual. With this machine refer to the inch version.
For good print quality, the supplier recommends that you use genuine toner from the supplier.
The supplier shall not be responsible for any damage or expense that might result from the use of parts
other than genuine parts from the supplier with your office products.

i
TABLE OF CONTENTS
Trademarks.............................................................................................................1
Safety Information ................................................................................................. 2
Safety During Operation............................................................................................. 2
ENERGY STAR Program .......................................................................................6
How to Read This Manual .....................................................................................7
1. Getting Started
Features of this Printer..........................................................................................9
Guide to the Printer ............................................................................................. 10
Exterior: Front View..................................................................................................10
Exterior: Rear View ..................................................................................................11
Inside........................................................................................................................12
Control Panel ...........................................................................................................13
2. Replacing Consumables and Maintenance Kit
Toner Cartridge .................................................................................................... 15
Waste Toner Bottle 1 Type 5000.........................................................................18
Waste Toner Bottle 2 Type 5000.........................................................................20
Fuser Oil Type 5000 ............................................................................................. 22
Development Unit Type 5000 Black/Color.........................................................28
Printing the Test Page..............................................................................................31
Fusing Unit Type 5000/Friction Pad/Paper Feed Roller ...................................34
Replacing the friction pad and the paper feed roller (for Tray 1)..............................35
Replacing the Fusing Unit ........................................................................................ 37
Printer Maintenance Kit Type 3800H
(paper feed rollers for the optional Paper Feed Unit).....................................42
Photo Conductor Unit Type 5000/Dustproof Filters .........................................44
Replacing the dustproof filters..................................................................................45
Replacing the Photoconductor Unit..........................................................................46

ii
3. Cleaning and Adjusting the Printer
Cautions to Take When Cleaning.......................................................................53
Cleaning the Paper Feed Roller and the Friction Pad ......................................54
Cleaning the Paper Feed Roller (for Tray 1) and the Friction Pad...........................54
Cleaning the Paper Feed Rollers (for the Optional Paper Feed Unit)...................... 55
Cleaning the Registration Roller and the Guide Boards..................................57
Cleaning the Dustproof Glass ............................................................................59
Adjusting the Image Density...............................................................................60
Adjusting the Tray Registration ......................................................................... 61
Cleaning and Adjusting the Internal Devices....................................................63
4. Appendix
Consumables .......................................................................................................65
Moving and Transporting the Printer.................................................................68
Moving the Printer ....................................................................................................69
INDEX......................................................................................................... 72

1
Trademarks
Microsoft, Windows and Windows NT are registered trademarks of Microsoft
Corporation in the United States and/or other countries.
IPS-PRINT Printer Language Emulation Copyright© 1999-2000 Oak Technolo-
gy, Inc., All rights reserved.
Other product names used herein are for identification purposes only and might
be trademarks of their respective companies. We disclaim any and all rights in
those marks.
The proper names of the Windows operating systems are as follows:
•Microsoft
®Windows®95 operating system
•Microsoft
®Windows®98 operating system
•Microsoft
®Windows®Millennium Edition (Windows Me)
•Microsoft
®Windows ®2000 Professional
•Microsoft
®Windows ®2000 Server
•Microsoft
®Windows®XP Professional
•Microsoft
®Windows®XP Home Edition
•Microsoft
®Windows NT®Server operating system Version 4.0
•Microsoft
®Windows NT®Workstation operating system Version 4.0
Notes:
Some illustrations in this manual might be slightly different from the machine.
Certain options might not be available in some countries. For details, please con-
tact your local dealer.

2
Safety Information
When using your printer, the following safety precautions should always be fol-
lowed.
Safety During Operation
In this manual, the following important symbols are used:
R
WARNING:
Indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
R
CAUTION:
Indicates a potentially hazardous situation which, if instructions are
not followed, may result in minor or moderate injury or damage to
property.

3
RWARNING:
•It is dangerous to handle the plug with wet hands. Doing this may re-
sult in receiving an electric shock.
•Connect the power cord directly into a wall outlet and never use an ex-
tension cord.
•Disconnect the power plug (by pulling the plug, not the cable) if the
power cable or plug becomes frayed or otherwise damaged.
•Confirm that the wall outlet is near the machine and freely accessible,
so that in event of an emergency, it can be unplugged easily.
•Only connect the machine to the power source described in the man-
ual.
•Avoid multi-wiring.
•Do not damage, break or make any modifications to the power cord.
Do not place heavy objects on it, pull it hard or bend it more than nec-
essary. These actions could cause an electric shock or fire.
•To avoid hazardous electric shock or laser radiation exposure, do not
remove any covers or screws other than those specified in this manu-
al.
•Turn off the power and disconnect the power plug (by pulling the plug,
not the cable) if any of the following conditions exists:
•You spill something into the equipment.
•You suspect that your equipment needs service or repair.
•Your equipment's cover has been damaged.
•Do not incinerate spilled toner or used toner. Toner dust might ignite
when exposed to an open flame.
•Disposal should take place at our authorized dealer or at appropriate
collection sites.
•Dispose of the used toner cartridge in accordance with the local regu-
lation.
•Do not take apart or attempt any modifications to this machine. There
is a risk of fire, electric shock, explosion or loss of sight. If the machine
has laser systems, there is a risk of serious eye damage.
•Do not place the IC2 lithium battery near or into fire, or it will explode
and cause a burn.
•The User Account Enhance Unit installed on the controller board has
a IC2 lithium battery which can explode if replaced incorrectly. Re-
place the User Account Enhance Unit only with the indicated one.

4
RCAUTION:
•Do not eat or swallow toner.
•Keep toner (used or unused) and toner cartridges out of reach of children.
•Protect the equipment from dampness or wet weather, such as rain, snow,
and so on.
•Unplug the power cord from the wall outlet before you move the equipment.
While moving the equipment, you should take care that the power cord will
not be damaged under the equipment.
•When you disconnect the power plug from the wall outlet, always pull the
plug (not the cable).
•Do not allow paper clips, staples, or other small metallic objects to fall inside
the equipment.
•For environmental reasons, do not dispose of the equipment or expended
supply waste at household waste collection points. Disposal can take place
at an authorized dealer or at appropriate collection sites.
•The inside of the machine becomes very hot. Do not touch the parts with a
label indicating "v" (means hot surface). Touching "v" (means hot surface)
could result in a burn.
•The inside of the machine becomes very hot. Do not touch the inner surface
with "n" and "v" labels indicating a hot surface. Touching that surface
could result in a burn.
•Our products are engineered to meet high standards of quality and function-
ality, and we recommend that you only use the expendable supplies avail-
able at an authorized dealer.
•The fusing unit becomes very hot. When installing the new fusing unit, turn
off the printer and wait about 30 minutes. After that, install the new fusing
unit. Not waiting for the unit to cool down can result in a burn.
•Do not pull out the fusing unit forcefully. It may cause the unit to fall and re-
sult in an injury.
•When touching the fusing unit, do not touch any areas other than the handle
as it may cause a burn.
•Do not incinerate the oil bottle. This could cause a fire or an injury.
•Spilt oil is very slippery. If oil is spilt, wipe it up with an alkaline cleaner. Oth-
erwise, the oily surface can create the danger of slipping and an injury.
•Do not open the front cover when the paper tray is pulled out halfway. If you
do, it might cause an injury.
•Do not put an object on the left cover when it is open.
•When replacing the photoconductor unit, hold the handles in beige and
green, and then lift it slowly. Lifting it in an inappropriate manner or handling
it carelessly may cause the unit to drop and result in an injury.

5
RCAUTION:
•Do not put an object on the front cover when it is open.
•When removing misfed paper, do not touch the fusing unit because it could
be very hot.
•To prevent an injury, this printer should be lifted by at least two people.
•When moving the machine, each person should hold the handles that are
located on opposite sides, and then lift it slowly. Lifting it carelessly or drop-
ping it may cause an injury.
•Before installing options, the machine should be turned off and unplugged
for at least an hour. Components inside the machine become very hot, and
can cause a burn if touched.
•When moving the Paper Feed Unit, hold the handles that are located on the
top of the unit, and then lift it slowly. Lifting it carelessly or dropping it may
cause an injury.
•When installing the Duplex Unit, do not release the unit until it is fastened
firmly in place. It may cause the unit to fall and result in an injury.
•When installing the Finisher, be sure to hold the sides of them. If you hold
the bottom, your hands may get caught and injured.
•When moving the Finisher, hold the center of both sides, and then lift it slow-
ly. Lifting it carelessly or dropping it may cause an injury.
•When installing the 4-bin Mailbox, be sure to hold the sides of them. If you
hold the bottom, your hands may get caught and injured.
•When moving the 4-bin Mailbox, hold the center of both sides, and then lift
it slowly. Lifting it carelessly or dropping it may cause an injury.
•Do not touch the inside of the controller board compartment. It may cause a
machine malfunction or a burn.
•Keep the machine away from humidity and dust. A fire or an electric shock
might occur.
•Place the machine on a strong and level surface. Otherwise, the machine
might fall and result in an injury.
•If you use the machine in a confined space, confirm that there is a continu-
ous flow of air.
•The paper tray does not have a stopper. When pulling it out, be careful not
to pull it strongly. If you do, the tray might fall and cause an injury.

6
ENERGY STAR Program
❖
❖❖
❖Low-power Mode (Energy Saver mode)
This printer automatically lowers its power consumption 30 minutes after the
last operation has been completed. To exit Low-power (Energy Saver) mode,
press any key on the control panel. For more information about how to con-
figure Energy Saver mode, see “Using the Control Panel”in the Administrator
Reference on the CD-ROM labeled "Operating Instructions".
❖
❖❖
❖Specifications
As an ENERGY STAR Partner, we have determined
that this machine model meets the ENERGY STAR
Guidelines for energy efficiency.
The ENERGY STAR Guidelines intend to establish an international energy-saving system for
developing and introducing energy-efficient office equipment to deal with environmental is-
sues, such as global warming.
When a product meets the ENERGY STAR Guidelines for energy efficiency, the Partner shall
place the ENERGY STAR logo onto the machine model.
This product was designed to reduce the environmental impact associated with office equip-
ment by means of energy-saving features, such as Low-power mode.
Energy Saver mode Power Consumption 35 W or less
Default Time 30 minutes
Recovery Time 99 seconds or less

7
How to Read This Manual
Symbols
In this manual, the following symbols are used:
R
WARNING:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
R
CAUTION:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, may result in minor or moderate injury or damage to property.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfed or data might be lost.
Be sure to read this.
Preparation
This symbol indicates the prior knowledge or preparations required before op-
erating.
Note
This symbol indicates precautions for operation, or actions to take after misop-
eration.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
[]
Keys that appear on the machine's panel display.
Keys and buttons that appear on the computer's display.
{}
Keys built into the machine's control panel.
Keys on the computer's keyboard.

8

9
1. Getting Started
Features of this Printer
❖
❖❖
❖High Image Quality Best for Photo Print
With the machine's 1,800 ×600 dpi equivalent high resolution, 256 color gra-
dation or 16,700,000 full color CMYK printing is possible. The machine is
great for printing not only general documents or illustrations but also docu-
ments containing digital camera images. Presentation documents, brochures
or fliers can be made more dramatic with full color printing. Also, RPCS, PCL
5c and Adobe PostScript 3 printer languages are supported for a variety of
color print situations.
❖
❖❖
❖High Performance with Fast Printing Speed
The machine prints in full color at 10 ppm (pages per minute) and in mono-
chrome at 36 ppm, which is faster than major monochrome printers. The
printing speed for the black and white part of a document with color and
black and white, which is most commonly printed in offices, is also 36 ppm.
The fast printing speed enables you to save time.
❖
❖❖
❖Space-Saving Desktop Finisher *1 Supported
The Finisher *1 is equipped with useful functions such as electronic collation
and stapling. When used with the Duplex Unit *1 , a variety of output func-
tions are available. The Finisher is compact enough to be mounted on top of
the printer, saving space in the room.
*1 Option
❖
❖❖
❖Versatile Functions of the New Generation Controller
The high-speed 64-bit controller architecture and the RPCS command system
that has been optimized for Windows software have made high-speed print-
ing possible. The locked print function *1 requires the user to enter a pass-
word to print a document. Also, the number of pages being printed can be
monitored by each user *1 . All these functions are provided to improve work
efficiency and support the office/network administrators.
*1 Option

Getting Started
10
1
Guide to the Printer
Exterior: Front View
1. Front Cover
Open this cover when replacing the ton-
er, photoconductor unit, fusing unit,
charger, or waste toner bottle or when re-
moving misfed paper.
2. Power Switch
Use this switch to turn the power on and
off.
3. Control Panel
Contains keys for printer control and a
panel display that shows the printer sta-
tus.
⇒p.13 “Control Panel”
4. Output Tray
Output is stacked here with the print side
down.
5. Upper Right Cover
Open this cover when installing the Inter-
change Unit.
6. Right Cover
Open this cover when removing the mis-
fed paper or installing options.
7. Bypass Tray
Use to print on thick paper, OHP trans-
parencies, custom size paper, as well as
plain paper. Up to 100 sheets of plain pa-
per can be loaded.
8. Bypass Tray Extension
Pull out this extension to load paper
longer than A4/letter Lin the Bypass
Tray.
9. Tray 1
Up to 250 sheets of plain paper can be
loaded.
1
34 56
78
9
2
ZESX701J

Guide to the Printer
11
1
Exterior: Rear View
1. Controller Board
Slide this out when installing the options
such as a Memory Unit, 1394 Interface
Unit or User Account Enhance Unit.
2. Parallel Port
Use a parallel cable to connect the printer
to the host computer.
3. USB Port
Use a USB cable to connect the printer to
the host computer.
Remove USB2.0 Interface Board when
you install optional 1394 Interface Unit or
802.11b Intaerface Unit.
4. Ethernet Port
Use a network interface cable to connect
the printer to the network.
5. Interchange Unit Port
Use the Interchange Unit cable to connect
the printer to the Interchange Unit.
6.
Ventilator and Dustproof Filter (A)
The ventilator helps to keep the compo-
nents inside the printer from overheat-
ing. Do not block the ventilator as it may
cause a printer malfunction due to over-
heating. A dustproof filter is set inside.
7. Ventilator and Dustproof Filter
(B)/Ozoneproof Filter
The ventilator helps to keep the compo-
nents inside the printer from overheat-
ing. Do not block the ventilator as it may
cause a printer malfunction due to over-
heating. A dustproof filter and an
ozoneproof filter are set in a cartridge in-
side.
8. Power Port
Connect the power cable to this port and
the other cable end to the wall outlet.
9. Ventilator
The ventilator helps to keep the compo-
nents inside the printer from overheat-
ing. Do not block the ventilator as it may
cause a printer malfunction due to over-
heating.
10. Left Cover
Open this cover when replacing the de-
velopment unit.
1
7
6
89 10
2
4
3
5
ZESX702E

Getting Started
12
1
Inside
1. Fusing Unit
Fuses the image on paper.
When "Replace Fusing Unit" appears on
the panel display, replace this unit.
2. Fuser Oil Unit
Attach to the fusing unit.
When "Replace Fuser Oil Unit" appears
on the panel display, replace this unit.
3. Photoconductor Unit
Includes a photoconductor belt that pro-
duces images. When "Replace PCU" ap-
pears on the panel display, replace this
unit.
4. Waste Toner Bottle 2
Collects wasted toner.
When "Waste Toner 2 is almost full" or
"Replace Waste Toner Bottle 2" appears
on the panel display, replace the waste
toner bottle 2 with a new one.
5. Waste Toner Bottle 1
Collects wasted toner.
When "Waste Toner 1 is almost full" or
"Replace Waste Toner Bottle 1" appears
on the panel display, replace the waste
toner bottle 1 with a new one.
6. Development Unit
From the top, set the development unit in
the order of black, yellow, cyan and ma-
genta.
When "Replace (color) development
unit" appears on the panel display, re-
place the color of the unit.
7. Toner Cartridge
From the top, set the toner cartridge in
the order of black, yellow, cyan and ma-
genta.
When "Add Toner (color)" appears on the
panel display, replace the color of the
toner cartridge.
1,2
3
5
67
4
ZESX703E

Guide to the Printer
13
1
Control Panel
1. Panel Display
Shows the current status of the printer
and error messages.
2. {
{{
{Job Reset}
}}
}Key
When the printer is online, press this key
to cancel any ongoing print job.
3. {
{{
{On Line}
}}
}Key
Indicates whether the printer is online or
offline.
Press this key to switch between online
and offline.
When the lamp is lit, the printer is online,
enabling data reception from the host
computer.
When the lamp is off, the printer is of-
fline, disabling data reception from the
host computer.
Press this key to return to the ready con-
dition.
4. {
{{
{Form Feed}
}}
}Key
When the printer is offline, press this key
to print all the data left in the printer's in-
put buffer.
You can use this to force the printer to
print the data received in the online sta-
tus when the paper size or type does not
match with the actual set size or type.
5. {
{{
{Menu}
}}
}Key
Press this key to make and check the cur-
rent printer settings.
6. Power Indicator
Power indicator is on while the power
switch is on. Power indicator is off when
the power is turned off or while the print-
er is in Energy Saver mode.
7. Error Indicator
Lights when a printer error occurs. Goes
off when the printer goes in Energy Saver
mode.
8. Data In Indicator
Blinks while the printer is receiving data
from a computer. Stays on when there is
data to be printed.
9. {
{{
{Escape}
}}
}Key
Press this key to return to the previous
condition on the panel display.
10. {
{{
{Enter #}
}}
}Key
Press this key to execute menu items se-
lected on the panel display.
11. {
{{
{U
UU
U}
}}
}{
{{
{T
TT
T}
}}
}Keys
Use these keys to increase or decrease
values on the panel display when making
settings. Keep pressing the key to quick-
en scrolling, and increase or decrease val-
ues on the panel display in units of 10.
On Line Menu
Job Reset
Escape
#Enter Form Feed
Power Error Data In

Getting Started
14
1

15
2. Replacing Consumables
and Maintenance Kit
Toner Cartridge
R
WARNING:
R
CAUTION:
Replace the toner cartridge of the in-
dicated color when the following
message appears on the panel dis-
play.
or
Note
❒The color is displayed for XXXX.
❒If cyan, magenta or yellow toner
runs out, you can print in black
and white using the black toner.
Change the color mode setting to
"Black and White" with the printer
driver.
❒If black toner runs out, printing is
not possible until the black toner
cartridge is replaced.
Reference
For information about printable
number of pages, see p.65 “Con-
sumables”.
A
AA
AOpen the front cover slowly by
pulling down from the two areas
on the left and right.
B
BB
BOpen the green toner cartridge
cover by pinching the lever and
then pulling the handle.
•Do not incinerate spilled toner
or used toner. Toner dust is
flammable and might ignite
when exposed to an open
flame. Disposal should take
place at an authorized dealer
or an appropriate collection
site. If you dispose of the used
toner cartridges yourself, dis-
pose of them according to lo-
cal regulations.
•Keep toner (used or unused) and
the toner cartridge out of reach
of children.
Add Toner
XXXX/XXXX
Toner is Almost
Empty:XXXX
ZEST006J
ZEST999J

Replacing Consumables and Maintenance Kit
16
2
From the top, the toner cartridges
are installed in the order of black,
yellow, cyan, and magenta.
C
CC
CRemove the toner cartridge for
the color you want to replace.
You can remove all four cartridges
in the same way.
Important
❒Do not shake the removed toner
cartridge. The remaining toner
might scatter.
D
DD
DTake out a new toner cartridge
from the box.
Note
❒The black toner cartridge con-
tains more than the other toner
cartridges.
E
EE
EShake the toner cartridge back
and forth 10-12 times.
Important
❒Do not touch the metal contact
point with your fingers.
F
FF
FInsert the new toner cartridge
horizontally, and then slowly
push it in until it stops.
You can install all four cartridges
in the same way.
Important
❒Do not install and remove the
toner cartridges over and over.
This could result in a toner leak.
G
GG
GPut the old toner cartridge that
you removed in step C
CC
Cinto the
box the new toner cartridge came
in.
ZEST413J
ZEST201J
ZEST203J
ZEST004J
