Network Guide
Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use, be sure to read the
Safety Information in the "Copy Reference" before using the machine.
Functions Available over a Network
Connecting the Network Cable to the Network
Setting Up the Machine on a Network
Windows Configuration
Using the Printer Function
Configuring the Network Interface Board Using a Web Browser
Appendix
1
2
3
4
5
6
7

Introduction
This manual contains detailed instructions and notes on the operation and use of this machine. For your
safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy
place for quick reference.
Important
Contents of this manual are subject to change without prior notice. In no event will the company be li-
able for direct, indirect, special, incidental, or consequential damages as a result of handling or oper-
ating the machine.
Two kinds of size notation are employed in this manual. With this machine refer to the metric version.
Trademarks
Microsoft®, Windows®and Windows NT®are registered trademarks of Microsoft Corporation in the
United States and/or other countries.
Other product names used herein are for identification purposes only and might be trademarks of their
respective companies. We disclaim any and all rights to those marks.
The proper names of the Windows operating systems are as follows:
• The product name of Windows®98 is Microsoft®Windows 98.
• The product name of Windows®Me is Microsoft®Windows Millennium Edition (Windows Me).
• The product names of Windows®2000 are as follows:
Microsoft®Windows®2000 Advanced Server
Microsoft®Windows®2000 Server
Microsoft®Windows®2000 Professional
• The product names of Windows®XP are as follows:
Microsoft®Windows®XP Professional
Microsoft®Windows®XP Home Edition
• The product names of WindowsTM Server 2003 are as follows:
Microsoft®WindowsTM Server 2003 Standard Edition
Microsoft®WindowsTM Server 2003 Enterprise Edition
Microsoft®WindowsTM Server 2003 Web Edition
Note:
Some illustrations in this manual might be slightly different from the machine.

i
Manuals for This Machine
The following manuals describe the operational procedures of this machine. For
particular functions, see the relevant parts of the manual.
Note
❒Manuals provided are specific to machine type.
❒Adobe Acrobat Reader is necessary to view the manuals as a PDF file.
❖General Settings Guide
Explains User Tools settings, and Address Book procedures such as register-
ing fax numbers, e-mail addresses, and user codes. Also refer to this manual
for explanations on how to connect the machine.
❖Network Guide (this manual)
Describes procedures for configuring the machine and computers in a net-
work environment.
❖Copy Reference
Explains Copier functions and operations. Also refer to this manual for expla-
nations on how to place originals.
❖Printer/Scanner Reference
Describes system settings, functions, troubleshooting and operations for the
machine's printer and scanner function.
❖Other Manuals
• Manuals for This Machine
•SafetyInformation
• Quick Reference Copy Guide
• Quick Reference Printer / Scanner Guide

ii
TABLE OF CONTENTS
Manuals for This Machine ......................................................................................i
How to Read This Manual .....................................................................................1
1. Functions Available over a Network
Using the Printer....................................................................................................3
Network TWAIN Scanner.......................................................................................4
2. Connecting the Network Cable to the Network
Confirming Connection .........................................................................................5
Connecting to the Ethernet Interface .........................................................................6
3. Setting Up the Machine on a Network
User Tools Menu (Interface Settings) ..................................................................7
Printer.........................................................................................................................7
Network TWAIN Scanner ...........................................................................................7
Network Configuration................................................................................................8
Settings You Can Change with User Tools................................................................9
4. Windows Configuration
Configuring TCP/IP ..............................................................................................11
Configuring a Windows 98SE / Me Computer..........................................................11
Configuring a Windows 2000 Computer ..................................................................11
Configuring a Windows XP Computer......................................................................12
Configuring a Windows Server 2003 computer........................................................12
Configuring a Windows NT 4.0 Computer................................................................13
5. Using the Printer Function
Printing with a Print Server.................................................................................15
Printing without a Print Server ...........................................................................16
Using TCP/IP Port Type P10001 .............................................................................16
Using Standard TCP/IP Port ....................................................................................17
Using LPR Port ........................................................................................................17
Using the IPP Port....................................................................................................18
6. Configuring the Network Interface Board Using a Web Browser
Features ................................................................................................................19
Settings You Can Change Using a Web Browser .............................................20
Configuring the Network Interface Board Using...............................................21

iii
7. Appendix
Using DHCP..........................................................................................................23
SNMP.....................................................................................................................24
Error Messages on the Display ..........................................................................25
Messages without Code Numbers ...........................................................................25
Messages with Code Numbers ................................................................................26
Specifications.......................................................................................................27
INDEX......................................................................................................... 28

iv

1
How to Read This Manual
Symbols
In this manual, the following symbols are used:
R
WARNING:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
R
CAUTION:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, may result in minor or moderate injury, or damage to proper-
ty.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfed, originals might be
damaged, or data might be lost. Be sure to read this.
Preparation
This symbol indicates prior knowledge or preparation is required before opera-
tion.
Note
This symbol indicates precautions for operation, or actions to take after mal-op-
eration.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
[]
Keys that appear on the machine's display.
[]
Keys and buttons that appear on the computer's display.
{}
Keys built into the machine's control panel.
{}
Keys on the computer's keyboard.

2

3
1. Functions Available over a
Network
This machine provides printer and scanner functions over a network.
Using the Printer
The network interface board is compatible with Windows NT4.0 / 2000
(TCP/IP, IPP *1 ), Windows XP (TCP/IP, IPP *1 ), Windows Server 2003 (TCP/IP,
IPP *1 ), and Windows 98SE / Me operating systems and protocols. This flexibil-
ity allows you to operate the machine in networks that use different protocols
and operating systems.
*1 IPP (Internet Printing Protocol) is a protocol for printing via the Internet.
Reference
For details about network settings you need to make, see p.7 “Setting Up the
Machine on a Network”.
For details about network printing, see p.15 “Using the Printer Function”.
ARL001S

Functions Available over a Network
4
1
Network TWAIN Scanner
You can use the scanning function of this machine from a computer connected
via a network. You can scan documents the same way you would if you were
using a scanner connected directly to your computer.
Reference
For details about network settings you need to make, see p.7 “Setting Up the
Machine on a Network”.
For details about TWAIN scanning over a network, see "Using the TWAIN
Scanner Function", Printer / Scanner Reference.
ARL002S

5
2. Connecting the Network
Cable to the Network
Confirming Connection
1. 10BASE-T/100BASE-TX port
Port for connecting the network interface
cable.
ARL003S

Connecting the Network Cable to the Network
6
2
Connecting to the Ethernet
Interface
The network interface board supports
10BASE-T or 100BASE-TX connec-
tions.
ATurn off the main power switch.
Important
❒Make sure the main power is
off. See “Turning On the Pow-
er”, Copy Reference.
BLoop the network interface cable
and attach the ferrite core.
Note
❒The network interface cable
loop should be about 10 cm
(4”)(A) from the end of the ca-
ble (closest end to the printer).
The ferrite core at the end of the
cable should be a ring type.
CConnect the network interface ca-
ble to the 10BASE-T/100BASE-TX
port.
DTurn on the main power switch.
1. Indicator (green)
Remains green when the machine is
properly connected to the network.
2. Indicator (yellow)
Turns yellow when 100 BASE-TX is
operating. Turns off when 10 BASE-T
is operating.
AAW026S1
ARL008S
AAW022S1
1.
2.

7
3. Setting Up the Machine on
a Network
User Tools Menu (Interface Settings)
This section describes the network settings you can change with User Tools (In-
terface Settings). Make settings according to the functions you want to use and
the interface to be connected.
Important
❒These settings should be made by the systems administrator, or after consult-
ing with the systems administrator.
Reference
For details about settings, see p.9 “Settings You Can Change with User Tools”
❖Viewing the Information Displayed in the List
$These items must be set to use the function. Be sure to set them before at-
tempting to use the corresponding function.
❍These items must be set if required.
Printer
Network TWAIN Scanner
Settings
Interface Settings/Network
See p.9 “Interface Settings”.
IP Address $
Gateway Address ❍
Ethernet Speed ❍
Settings
Interface Settings/Network
See p.9 “Interface Settings”.
IP Address $
Gateway Address ❍
Ethernet Speed ❍

Setting Up the Machine on a Network
8
3
Network Configuration
Changes made with User Tools re-
main in effect after the main power
switch or operation switch is turned
off, or the {Clear Modes}key is
pressed.
Configuring the network using the
control panel
Note
❒Operations for Interface Settings
are different from normal opera-
tions. To exit User Tools, press the
{User Tools/Counter}key.
❒If a key operator code has been set,
the key operator code entry screen
appears. Enter the code, and then
press the {OK}key. For details
about the key operator code, see
General Settings Guide.
APress the {User Tools/Counter}key.
BSelect [Interface Settings]using the
{U} or {T} key, and then press
the {OK}key.
CSelect the setting you want to
change, and then press the {OK}
key.
D Change the setting, and then press
the {OK}key.
Note
❒Press the {Escape}key to cancel
the setting.
EPress the {User Tools/Counter}key.
Configuring the network using other utilities
Network settings can be made not only from the control panel, but by Web
browser also. The following table shows the settings you can make using a Web
browser:
Note
❒❍Indicates machine settings that can be changed.
❒- Indicates the setting cannot be changed from that device.
Name on the control panel Web browser
Interface Set-
tings
Network IP Address Auto-Obtain (DHCP) ❍
Specify IP Add. ❍
Subnet M ❍
Mac Add. -
Gateway Address ❍
Ethernet Speed -

User Tools Menu (Interface Settings)
9
3
Settings You Can Change with
User Tools
Interface Settings
❖IP Address
To use this machine in a network
environment, you must first con-
figure its IP address and subnet
mask.
•Auto-Obtain(DHCP)
•Specify
When you select [Specify], enter
[IP Address:]and [Sub-net Mask:]
as “xxx.xxx.xxx.xxx”(“x” indi-
cates a number).
• IP Address: 011.022.033.044
•
Sub-net Mask: 000.000.000.000
Note
❒Default: Auto-Obtain (DHCP)
❒When you select [Specify], be
sure not to set the same [IP Ad-
dress:]as that of another ma-
chine on the network.
❒The physical address (MAC ad-
dress) also appears.
❖Gateway Address
A gateway is a connection or inter-
change point between two net-
works. Configure the gateway
address for the router or host com-
puter used as a gateway.
•
Gateway Address: 000.000.000.000
Note
❒Default: 000.000.000.000
❖Ethernet Speed
Set the network access speed.
Select a speed that is suitable for
your network environment. [Auto
Select]should usually be selected.
•AutoSelect
• 100Mbps Fixed
•10MbpsFixed
Note
❒Default: Auto Select

Setting Up the Machine on a Network
10
3

11
4. Windows Configuration
Configuring TCP/IP
This section explains configuring
Windows for TCP/IP and IPP.
Configuring a Windows 98SE /
Me Computer
Follow the procedure below to con-
figure a Windows 98SE / Me compu-
ter to use TCP/IP.
AOpen [Control Panel], and then
double-click the Network icon.
Make sure [TCP/IP]is selected in
the [The following network compo-
nents are installed]box on the [Con-
figuration]tab.
Note
❒Select TCP/IP if it is not already
selected.
❒If TCP/IP is not installed, click
[Add]on the [Configuration]tab to
install it. For details about in-
stalling TCP/IP, see Windows
98SE / Me Help.
BClick [Properties].
CConfigure TCP/IP using the ap-
propriate IP address, subnet
mask, and other settings.
Check with the network adminis-
trator that the settings are correct.
Configuring a Windows 2000
Computer
Follow the procedure below to con-
figure a Windows 2000 computer to
use TCP/IP.
AOn the [Start]menu, point to [Set-
tings], and then click [Network and
Dial-up Connections].
BDouble-click [Local Area Connec-
tion]. On the [General]tab, click
[Properties].
C Make sure [ Internet Protocol (TCP/IP) ]
is selected in the [Components
checked are used by this connection]
box on the [General]tab.
Note
❒Select TCP/IP if it is not already
selected.
❒If TCP/IP is not installed, click
[Install]on the [General]tab to in-
stall it. For details about install-
ing TCP/IP, see Windows 2000
Help.
DClick [Properties].
EConfigure TCP/IP using the ap-
propriate IP address, subnet
mask, and other settings.
Check with the network adminis-
trator that the settings are correct.

Windows Configuration
12
4
Configuring a Windows XP
Computer
Follow the procedure below to con-
figure a Windows XP computer to use
TCP/IP.
AOn the [Start]menu, click [Control
Panel], and then click [Network Con-
nections].
BClick [Network Connections], and
then double-click [Local Area Con-
nection].
COn the [General]tab, click [Proper-
ties].
D Make sure [ Internet Protocol (TCP/IP) ]
is selected in the [This connection
uses the following items]box on the
[General]tab.
Note
❒Select TCP/IP if it is not already
selected.
❒If TCP/IP is not installed, click
[Install]on the [General]tab to in-
stall it. For details about install-
ing TCP/IP, see Windows XP
Help.
EClick [Properties].
FConfigure TCP/IP using the ap-
propriate IP address, subnet
mask, and other settings.
Check with the network adminis-
trator that the settings are correct.
Configuring a Windows Server
2003 computer
Follow the procedure below to con-
figure a Windows Server 2003 com-
puter to use TCP/IP.
AOn the [Start]menu, point to [Con-
trol Panel], point to [Network Connec-
tions], and then click [Local Area
Connection].
BOn the [General]tab, click [Proper-
ties].
C Make sure [ Internet Protocol (TCP/IP) ]
is selected in the [This connection
uses the following items]box on the
[General]tab.
Note
❒Select TCP/IP if it is not already
selected.
❒If TCP/IP is not installed, click
[Install]on the [General]tab to in-
stall it. For details about install-
ing TCP/IP, see Windows
Server 2003 Help.
DClick [Properties].
EConfigure TCP/IP using the ap-
propriate IP address, subnet
mask, and other settings.
Check with the network adminis-
trator that the settings are correct.

Configuring TCP/IP
13
4
Configuring a Windows NT 4.0
Computer
Follow the procedure below to con-
figure a Windows NT 4.0 computer to
use TCP/IP.
AOpen [Control Panel], and then
double-click the Network icon.
Make sure [TCP/IP Protocol]is se-
lected in the [Network protocols]
box on the [Protocols]tab.
Note
❒Select TCP/IP if it is not already
selected.
❒If TCP/IP is not installed, click
[Add]on the [Protocols]tab to in-
stall it. For more information
about installing TCP/IP, see
Windows NT 4.0 Help.
BClick [Properties].
CConfigure TCP/IP using the ap-
propriate IP address, subnet
mask, and other settings.
Check with the network adminis-
trator that the settings are correct.

Windows Configuration
14
4
